Characterizing Beam-correlated Neutron Backgrounds in the ANNIE detector

Amanda Weinstein

• n behalf on the ANNIE collaboration

Iowa State University

TAUP 2019 9/9/2019 1

1

ANNIE Collaboration meeting – Spring 2019 at Fermilab

ANNIE Collaboration

9/9/2019 TAUP 2019 2

tank

Accelerator Neutrino Neutron Interaction Experiment (ANNIE)

9/9/2019 TAUP 2019 3

• Booster Neutrino Beam (Fermilab)
• 700 MeV peak energy
• 93% νμ purity
• 3-5x1012 POT per spill at 5Hz
• ANNIE: One νμ charged-current

interaction in the water every 150 spills

Primary physics goal: Study abundance of final-state neutrons from and measure cross-section of neutrino-nucleus interactions (in water) as a function of muon kinematics

Physics Motivation

9/9/2019 TAUP 2019 4

ANNIE Concept

9/9/2019 5

Reconstruct muon interaction vertex and momentum Muon momentum information (legacy from SciBooNE) Consider CC νμ interactions in fiducial volume

ANNIE Concept

9/9/2019 TAUP 2019 6

PMTs detect neutron capture on Gd after thermalization

Neutron Capture Cross-Section

9/9/2019 TAUP 2019 7

ANNIE and New Technologies

9/9/2019 TAUP 2019

See talk in Weds. New Technology Session for further details

8

• Large Area Picosecond

PhotoDetectors (LAPPDs):

• 20x20 cm micro-channel

plates with ∼60-ps time resolution and <1 cm spatial resolution

Muon Range Detector (MRD)

• Gd-loaded water
• Enhances neutron

capture x-section

• Shifts de-excitation

gammas to higher energy

• Shortens neutron

capture time

ANNIE Neutron Backgrounds

9/9/2019 TAUP 2019 9

Secondary neutrons from beam dump that leak into atmosphere From beam neutrinos interacting in dirt, rock

• Constant-in-time (CIT) backgrounds controlled for using data taken in the absence of beam.
• Beam-correlated backgrounds must be measured.

Beam-correlated Background Measurement

9/9/2019 TAUP 2019 10

Neutron Capture Volume

Calibration: Scintillation paddles kinematically select cosmic muons

Sealed, optically isolated acrylic vessel EJ-335 liquid scintillator (0.25% Gd w/w)

9/9/2019 TAUP 2019 11

The Neutron Capture Volume (NCV)

Data Acquisition

9/9/2019 TAUP 2019 12

Two modes of data acquisition

CIT background estimation

Custom VME ADCs (500 MS/s, ~80 µs buffer)

Data Samples I

9/9/2019 TAUP 2019

Also six calibration runs with 252Cf neutron source

13

Neutron candidate selection

9/9/2019 TAUP 2019 14

• All pulses
• Both NCV PMTs fire

within 40 µs

• No prior candidate

within 10 µs (afterpulsing)

• Energy deposition <

34 MeV (true neutrons < 9 MeV)

• 8 or fewer water

PMTs fire (vetos energy dep. from muons)

• Pre-beam, late-time data used to

subtract CIT background

9/9/2019 TAUP 2019 15

• Method II: from simulations, derive

fraction of events above measured energy threshold (4.76 MeV) ln L = d j

j

∑

ln f j − f j f j ε NCVα n, j +δ j,γ flashP

γ + Δt jR

( )

⇒ ε NCV = 9.60 ± 0.57stat% ⇒ ε NCV = 12.8 ± 0.9stat%

• Method I: use 252Cf neutron

source calibration

NCV efficiency measurements

Neutron rates vs. shielding

9/9/2019 TAUP 2019 16

• Dominant sources
• f syst. uncertainty:
• NCV efficiency
• CIT Background
• Skyshine dominates
• ver dirt neutrons
• Qualitative

agreement with previous SciBooNE results

Active volume

Skyshine Dirt neutrons

Notes: Neutron Capture Cross-Section

9/9/2019 TAUP 2019

vs Phase II:

Rates in NCV slightly higher Shielding effects somewhat lower

17

Integrated per-spill neutron rate

9/9/2019 TAUP 2019 18

• vs. 0.42 primary

neutrons per CC νμ interaction Conclusion: background in

• ptically isolated

active volume acceptably low.

Active volume

Rn

tank = 0.053−0.025stat+syst +0.053stat+syst

Measurements in active volume to right of blue line
