Chapter Two

Problem Solving Using Search

Defining the Problem

• How do you represent a problem so that

the computer can solve it?

• Even before that, how do you define the

problem with enough precision so that you can figure out how to represent it?

State Space

• First have to develop a mapping from game space world of pieces

and the geometric pattern on board, to a data structure that captures the essence of the current game state.

• Start with an initial State. A combination of the initial state and the

set of operators make up a state space. The sequence of states produced Is called the path. We have to detect the goal state.

• Often we want to reach the goal with lowest possible cost. The cost

function is usually denoted by g.

• Effective search algorithms must cause motion in a controlled

systematic manner. A systematic search that doesn’t use info about the problem is called brute-force or blind search, others are called heuristic or informed search. Here we can make better choices where to expand next.

• An algorithm is optimal if it finds the best solution, complete if it

guarantees a solution if one exists, efficient in terms of time and space complexity.

Search Strategies

• Breadth-First Search
• Depth-First Search
• The SearchNode

Breadth-First Search

• Searches a state space by constructing a hierarchical

tree.

• The algorithm defines a way to move through the

structure, examining the values at nodes in a controlled and systematic way to find a node that

• ffers a solution to the problem.
• Algorithm:

– create a queue and add the first SearchNode to it. – Loop

– if the queue is empty, quit. – remove the first SearchNode from the queue – if the SearchNode contains the goal state, then exit with the SearchNode as the solution – for each child of the current SearchNode, add the new SearchNode to the back of the queue.

Depth-First Search

• Instead of completely searching each level of the

tree before going deeper, follow a single branch

• f the tree down as many levels as possible until

it either reaches a solution of a dead end.

• Algorithm:

– create a queue and add the first SearchNode to it. – Loop:

– If the queue is empty, quit – Remove the first SearchNode from the queue – If the SearchNode contains the goal state, then exit with the SearchNode as the solution – For each child of the current SearchNode: add the new SearchNode to the front of the queue.

Search Application

Grand Forks

International Falls Bemidji Duluth Minneapolis St.Cloud Fargo Sioux Falls Rochester Dubuque Rockford Chicago Wausau Green Bay Milwaukee LaCrosse Madison

Breadth First Search

• Chicago to Rochester

– Milwaukee

• Madison

– LaCrosse

• Green Bay

– LaCrosse – Wausau

– Rockford

• Dubuque

– LaCrosse – Rochester (Goal State)

• Madison
• Path: Chicago, Rockford, Dubuque, Rochester

Depth First Search

• Chicago to Rochester

– Milwaukee

• Green Bay

– LaCrosse » Minneapolis »

• St. Claude

»

• Fargo

»

• Grand Forks

»

• International Falls

»

• Sioux Falls

»

• Bemidji

»

• Duluth

» Rochester (Goal State)

• Path: Chicago, Milwaukee, Green Bay, LaCrosse,

Rochester

Iterative Deepening Search-1

• Depth 0: Chicago
• Depth 1: Chicago

» Rockford » Milwaukee

• Depth 2: Chicago

» Rockford

• Dubuque
• Madison

» Milwaukee

• Madison
• Green Bay

Iterative Deepening Search-2

• Depth 3: Chicago

– Milwaukee

• Madison

– LaCrosse

• Green Bay

– LaCrosse – Wausau

– Rockford

• Dubuque

– LaCrosse – Rochester (Goal State)

• Path: Chicago, Rockford, Dubuque, Rochester

Heuristic Search

• Generate and Test
• Best First Search
• Greedy Search
• A* Search

Generate and Test

• 1. Generate a possible solution
• 2. Test to see if this is actually a solution
• 3. If a solution has been found ,quit.

Otherwise, return to step 1

Best First Search

• Is just a General Search
• minimum-cost nodes are expanded first
• we basically choose the node that appears to be

best according to the evaluation function Two basic approaches:

• Expand the node closest to the goal
• Expand the node on the least-cost solution path

Greedy Search

• “ … minimize estimated cost to reach a goal”
• a heuristic function calculates such cost estimates

h(n) = estimated cost of the cheapest path from the state at node n to a goal state

Straight-line distance

• The straight-line distance heuristic function is a for

finding route-finding problem

hSLD(n) = straight-line distance between n and the goal location

75 118 111 140 80 97 99 101 211 A B C D E F G H I

A E B C h=253 h=329 h=374

State h(n) A 366 B 374 C 329 D 244 E 253 F 178 G 193 H 9 8 I

A E C B A F G

h=253 h = 366 h = 178 h = 193

State h(n) A 366 B 374 C 329 D 244 E 253 F 178 G 193 H 98 I

A A F B C E G I E

h = 253 h =366 h=178 h=193 h = 0 h = 253

State h(n) A 366 B 374 C 329 D 244 E 253 F 178 G 193 H 98 I

Optimality

A- E- F- I = 450 A- E- G- H- I = 418 vs.

75 118 111 140 80 97 99 101 211 A B C D E F G H I

State h(n) A 366 B 374 C 329 D 244 E 253 F 178 G 193 H 98 I

Completeness

• Greedy Search is incomplete
• Worst-case time complexity

O(bm)

Straight-line distance

A B C D

h(n)

5 7 6 A D B C

Target node

Starting node

A* search

f(n) = g(n) + h(n)

• h = heuristic function
• g = uniform-cost search

75 118 111 140 80 97 99 101 211 A B C D E F G H I

State h(n) A 366 B 374 C 329 D 244 E 253 F 178 G 193 H 98 I

“ Since g(n) gives the path from the start node to node n, and h(n) is the estimated cost of the cheapest path from n to the goal, we have… ” f(n) = estimated cost of the cheapest solution through n

A E C B

f = 75 +374 =449 f = 118+329 =447 f=140 + 253 =393

f(n) = g(n) + h(n) A E C B A F G

f = 140+253 = 393 f =0 + 366 = 366 f = 280+366 = 646 f =239+178 =417 f = 220+193 = 413

A A F B C E G H E

f = 140 + 253 = 393 f =220+193 =413 f = 317+98 = 415 f = 300+253 = 553

f =0 + 366= 366

A A F B C E G H E f = 140 + 253 = 393 f =220+193 =413 f = 300+253 = 553 f =0 + 366= 366 f = 317+98 = 415 I

f = 418+0 = 418

f(n) = g(n) + h(n)

State h(n) A 366 B 374 C 329 D 244 E 253 F 178 G 193 H 98 I

A- E- G- H- I = 418

Remember earlier

G H I E A

f = 418+0 = 418

Genetic Algorithm-1

• Use Biological process metaphor
• The problem state must be encoded into a string

called a chromosome ( usually binary)

• An Evaluation function that takes that encoded

string as input and produces “Goodness” or biological fitness score.

• This score is then used to rank a set of strings

(individuals)

• The individuals that are most fit are randomly

selected to survive and even procreate into the next generation

Genetic Algorithm-2

• Genetically inspired operators are used:

mutation and cross over.

• The mutation operator performs random

mutation or changes in the chromosome. In the usual binary string case, few bits are randomly flapped

• The crossover operator takes two

particular fit individuals and combine their genetic material forming two new children

Genetic Algorithm-3

• Example

– Parent A: 0010010011 – Parent B: 1100001010 – Mutate (A): 0011010001 – Crossover (A,B) Child1: 0010001010 Child2: 1100010011
