NATCORE TECHNOLOGY CHANGING HOW SOLAR CELLS ARE MADE February, 2017 NATCORE TECHNOLOGY Forward Looking Statements This presentation contains certain forward looking statements relating to the companys financial results, business prospects

slide-1
SLIDE 1

NATCORE TECHNOLOGY

February, 2017

CHANGING HOW

SOLAR CELLS ARE MADE

slide-2
SLIDE 2

NATCORE TECHNOLOGY

Forward Looking Statements

2

This presentation contains certain forward looking statements relating to the company’s financial results, business prospects and the development and commercialization of the company’s solar

  • technology. These statements are based on management’s current expectations and beliefs and

are subject to a number of factors which involve known and unknown risks, delays, uncertainties and other factors not under the company’s control which may cause actual results, performance

  • r achievements of the company to be materially different from the results, performance or
  • ther expectations implied by these forward looking statements.

In any forward looking statement in which Natcore Technology Inc. expresses an expectation or belief as to future results, such expectations or beliefs are expressed in good faith and are believed to have a reasonable basis, but there can be no assurance that the statement or expectation or belief will be achieved. These factors include risks associated with intellectual property protection, financial projections, market projections and other factors detailed in the company’s filings with SEDAR. Natcore does not undertake an obligation to update the forward looking statements, except as required by applicable laws.

slide-3
SLIDE 3

NATCORE TECHNOLOGY

The Solar Energy Industry is Growing

3

slide-4
SLIDE 4

NATCORE TECHNOLOGY NATCORE TECHNOLOGY

INCREASE efficiency REDUCE costs

4 NATCORE TECHNOLOGY

Foil Cell

(All Back Contact Solar Cell)

Natcore’s Technologies

Natcore’s Foil Cell uses high-speed, low temperature laser process

Black Silicon

Natcore’s black silicon technology streamlines the path to low solar cell reflectance

slide-5
SLIDE 5

NATCORE TECHNOLOGY

Natcore Laboratory – Rochester, N.Y.

5

Full solar cell process from bare silicon wafer to working cells

19,000

sq ft facility

8,000

sq ft of ‘class 10,000’ clean room

slide-6
SLIDE 6

NATCORE TECHNOLOGY 6

Natcore R&D Center – Rochester, N.Y.

Technician working at one of several clean room wet benches.

slide-7
SLIDE 7

NATCORE TECHNOLOGY

Natcore R&D Center – Rochester, N.Y.

7

(Left) Solar wafers entering the diffusion furnace. (Right) Work performed using customized R&D equipment.

slide-8
SLIDE 8

NATCORE TECHNOLOGY

A Versatile, Customizable System Traditional silicon hetero-junction cells hold the record for efficiency, but high costs make them impractical

25.6%

Output

The current world leader in efficiency

8

slide-9
SLIDE 9

NATCORE TECHNOLOGY NATCORE TECHNOLOGY 9

FOIL CELL TECHNOLOGY

slide-10
SLIDE 10

NATCORE TECHNOLOGY

Industry Standard: Front/Back Contact

front back

  • The mature current technology
  • Reaching its limit in efficiency
  • Requires a fair amount of silver
slide-11
SLIDE 11

NATCORE TECHNOLOGY

  • Back contact cells have the highest

potential:

  • Currently hold the world record for silicon

(>25%)

  • Will always be advantaged due to lack of

front grid shadowing

  • Currently difficult to make
  • Natcore process

Back Contact Solar cells

Simplified fabrication Aluminum

slide-12
SLIDE 12

NATCORE TECHNOLOGY

Current Cells: Cost Dominated by Silver

  • Metallization steps comprises >60% of cost
  • Ag and Ag/Al pastes are >80% of metallization cost

7% 7% 5% 10%

68%

3% Damage/Texture Etch Diffusion Oxide Etch/Edge Iso ARC/Passivation

Metallization

Cell Processing Cost Breakdown Metallization Cost Breakdown

*For 19% std multi cell; raw Ag $15.00/oz.

6.1% 6.0% 3.4% 2.0% 1.1% 0.6%

80.8%

CapEx Facilities Screens Labor Maintenance (labor/parts) Broken Wafer Paste

Pastes

slide-13
SLIDE 13

NATCORE TECHNOLOGY

Natcore Foil Cell Structure

  • Multilayer foil metallization
  • Low cost metal: Aluminum
  • Atmospheric & low cost process
  • Laser based processing

13

Key Features / Properties

  • Low cost contact metals
  • Simplified manufacture
  • Low capital equipment cost
  • Small factory footprint
  • Low temperature processing
slide-14
SLIDE 14

NATCORE TECHNOLOGY

Cost: Foils & Laminates

Minimized Material Cost

  • Current cells use about

190mg of Ag per cell:

  • Raw metal cost: ~10¢/cell
  • Replaced with ~1.5g Al:
  • Raw metal cost ~ 0.2¢/cell
  • Planning to work with NREL

for accurate cost model

Leveraging an existing industry

  • Worldwide Aluminum foil

production: ~100,000M m2 per year

  • The entire solar industry:

Requires ~400M m2

  • Low cost driven by existing

high volume

14

slide-15
SLIDE 15

NATCORE TECHNOLOGY

Foil Cell Process Flow

15

Front End Process (Solar Cell Fab) Texture Passivation Emitter Laminate Manufacture (Central Facility) Patterned Laminate Ready for attachment Laminate Attachment (Solar Cell Fab) Bonding Laser Contact

module

slide-16
SLIDE 16

NATCORE TECHNOLOGY

Vectors of Improvement

  • Technology and cost benefits sum to yield an improved system

16

Natcore Bilayer Foil Cell

Practical approach to back contact cells Low resistivity metallization in cell & module Leveraging an inexpensive metal (Al) Simplified Module assembly COST COST PERFORMANCE PERFORMANCE

slide-17
SLIDE 17

NATCORE TECHNOLOGY

2 4 6 8 10 12 14 16 18 20 22 24 26

Apr Jul Oct Jan Apr Jul Oct Jan Apr Jul

Efficiency (%)

Prototype Development at Natcore

  • Multilayer structure:

First versions achieved April 2015

  • Steady progress in

efficiency

17

2015 2016

Current world record

2017

slide-18
SLIDE 18

NATCORE TECHNOLOGY

Efficiency: Today & Projection

Laboratory

(current status, small test cells using a perforated emitter laminate foil & deposited base metal)

  • Efficiency: 20.3%
  • Voc = 0.66V
  • Isc = 41.3 mA/cm2
  • FF = 74.3%
  • Short term target: >20%

Production Estimates

  • Early phase: 22%
  • Existing Isc
  • Voc = 0.72V (typical implied Voc)
  • FF = 76% (conservative)
  • Long Term: 24 - 26%
  • Within the range of the highest

performing back contact cells

18

slide-19
SLIDE 19

NATCORE TECHNOLOGY

IP Position and Strategy

  • Natcore has strong

patent expertise

  • US and International

filings in various technologies

  • 31 granted patents
  • 34 applications
  • Laser / Back contact cell

& module IP: Comprehensive filings

  • Coverage areas:
  • Novel cell structure
  • Module integration
  • Processing methods

19

slide-20
SLIDE 20

NATCORE TECHNOLOGY

CTM Energy Loss

20 Data from IER 2015 Report

Less electrical resistance Less wasted space The best structure for eliminating CTM loss Sometimes a CTM gain if surface area isn’t wasted

14% 16% 18% 20% 22%

Module efficiency (%) Gen I Module Gen II Module

  • Std. Multi

Multi+SE Mono PERC N-PERT N-PERL HIT Multi MWT Multi MWT+SE Mono MWT MWT-PERC EWT-PERC N-MWT-PERT EWT-PERC N-EWT-PERL HJ-IBC

Cell efficiency (%)

15.0% 17.0% 19.0% 21.0% 23.0%

Natcore Back Contact: Better efficiency and Better CTM

slide-21
SLIDE 21

NATCORE TECHNOLOGY NATCORE TECHNOLOGY

BLACK SILICON TECHNOLOGY

21

slide-22
SLIDE 22

NATCORE TECHNOLOGY

Solar Cell Manufacturing Process

22

STANDARD PROCESS

Damage etch + Texture Emitter Diffusion PSG Remove Anti-Reflection Contact & Fire

slide-23
SLIDE 23

NATCORE TECHNOLOGY

Our Process

23

Low temperature reduces toxicity and produces the best condition for uniform, single-sided black silicon application

BLACK SILICON PROCESS

Wafers in a processing bath: Cleaning, Etching, Conditioning

Wafer carrier Wafers

Emitter Diffusion Contact & Fire

Processing Solution

Emitter Diffusion PSG Remove Anti-Reflection Contact & Fire Damage etch + Black Silicon Black Silicon

Reduction

  • f toxicity

Low temperature furnace

slide-24
SLIDE 24

NATCORE TECHNOLOGY NATCORE TECHNOLOGY

BUSINESS MODEL & COMMERCIALIZATION

24

slide-25
SLIDE 25

NATCORE TECHNOLOGY

Business Path

  • Natcore has demonstrated proof of concept of a revolutionary

new solar cell structure and process.

  • Now focused on improving the performance of prototype

devices

  • Seeking a partner that can assist in the commercialization

process

25

slide-26
SLIDE 26

NATCORE TECHNOLOGY

3 Revenue Streams

26

Licensing

  • Laser Processing
  • Black Silicon
  • Equipment

manufacturing

Royalties

  • Laser Processing
  • Black Silicon
  • Equipment

Material sales

  • Built/shipped by
  • thers, but unit

sales to Natcore

  • Chemicals, foils, etc.
slide-27
SLIDE 27

NATCORE TECHNOLOGY 27

Best-of-Breed

slide-28
SLIDE 28

NATCORE TECHNOLOGY 28

Best-of-Breed

slide-29
SLIDE 29

NATCORE TECHNOLOGY

Best-of-Breed

29

slide-30
SLIDE 30

NATCORE TECHNOLOGY

Natcore & Synergistic Partners

30

slide-31
SLIDE 31

NATCORE TECHNOLOGY

Consulting

31

We have been retained by United Energy Ltd. to develop a 75 MW facility in

  • Vietnam. This video shows some of the details (power station, point of delivery,

anti-intrusion system).

  • Provide project financing and technology;
  • Design, develop, implement and bring solar plants to the turnkey phase;
  • Serve as supplier and promoter of the project;
  • Select suppliers, PV plant locations and EPC company.
slide-32
SLIDE 32

NATCORE TECHNOLOGY

  • We serve on these projects as a Consultant or General Contractor.
  • Hire subcontractors and vet every component of the project.
  • Currently working on these Best of Breed projects:

32

Belize: 10 MW Vietnam: 200 MW Australia: 100 MW

Best-of-Breed Turnkey Projects

Middle East: 1,000 MW

slide-33
SLIDE 33

NATCORE TECHNOLOGY 33

slide-34
SLIDE 34

NATCORE TECHNOLOGY

Best of Breed Process

PROCESS

  • Identify In-Country Partner
  • Find and Control Suitable Land
  • Obtain Government Permits for Project
  • Confirm Engineering Feasibility Study
  • Negotiate Power Purchase Agreement
  • Source and Bid Equipment (Modules, Frames, Inverters, etc.)
  • Engage Engineering Procurement Company

34

slide-35
SLIDE 35

NATCORE TECHNOLOGY

Vietnam Project - 200 MW Drone aerial image of land.

35

Best-of-Breed - Vietnam

slide-36
SLIDE 36

NATCORE TECHNOLOGY

Pipeline Projects

36

Vietnam Australia Belize Middle East South Africa Ukraine/Moldova Philippines

slide-37
SLIDE 37

NATCORE TECHNOLOGY

  • Vietnamese Project - 56.18 MW PV Plant
  • Total Investment

$65.5 M

  • PPA:

$0.112 kWh

  • Average Yearly Revenue - $9.3 M (20 years)
  • Monthly Revenue -

$774,000

37

Vietnamese Project

slide-38
SLIDE 38

NATCORE TECHNOLOGY

Vietnamese Project – 56.18 MW

Revenue

  • Engagement fee -

$1.5 M

  • Cost Plus ($65 M x 5) -

$3.25 M

  • Annual Partnership Participation (10%) - $930,000
  • 20 Year Term -

$18.6 M

38

slide-39
SLIDE 39

NATCORE TECHNOLOGY

Vietnamese Project – 200 MW

Revenue

  • Engagement fee -

$6 M

  • Cost Plus -

$13 M

  • Annual Partnership Participation (10%) - $3.72 M
  • 20 Year term

$74.4 M

39

slide-40
SLIDE 40

NATCORE TECHNOLOGY 40
