Ceramics session

• Processes for additive manufacturing
• f large parts, State of the art, locks

and design constraints.

OLIVIER LARRE, ESTIA Thursday, June 4, 2020

Ceramics session RESIM 2020- 4th and 5th of june 2020 2

The issue of the keynote

Keywords

• the different additive manufacturing technologies for large metal parts and

mainly the deposition of molten wire and the different suppliers (Sciaky, Gefertec, Prodways, Addilan...),

• stresses related to the process material couple
• and consequently the parts in question
• as well as the target markets,
• product design constraints related to the process,
• material and use and the expected mechanical properties.
• The economic impact of these processes.
• Coldspray, FSW for additive manufacturing.

3

The Context

Metal additive manufacturing "Powder bed" manufacture large metal parts direct energy/material deposition technologies: DED (Direct Energy Deposition) or HDR (High Deposition Rate). processes for depositing material in the form of powder or wire on a substrate

Ceramics session RESIM 2020- 4th and 5th of june 2020

4

The Context

Processes arising from welding :

• Processes based on

powder deposition PLAM process gives about 0.25 to 0.6 kg/h maximum

Ceramics session RESIM 2020- 4th and 5th of june 2020

5

The Context

powder deposition

Ceramics session RESIM 2020- 4th and 5th of june 2020

6

The Context

Hybrid = powder deposition + machining

Ceramics session RESIM 2020- 4th and 5th of june 2020

7

The Context

• Processes based on wire

deposition :

• Here is an explanation of

the process (courtesy of Mazak) :

Ceramics session RESIM 2020- 4th and 5th of june 2020

8

The Context

WAAM process (1.2 mm wire) gives approx. 8 to 10 kg/h maximum

Ceramics session RESIM 2020- 4th and 5th of june 2020

9

The Context

Ceramics session RESIM 2020- 4th and 5th of june 2020

10

The Context

WLAM process (1.2 mm wire) gives about 2 to 3 kg/h maximum

Ceramics session RESIM 2020- 4th and 5th of june 2020

11

The Context

And finally, weldingless processes have the particular advantage of making it possible to manufacture parts of good metallurgical quality with low porosity without welding and therefore without excessive residual stresses:

• Processes similar to Cold Spray:
• Speed3D

Ceramics session RESIM 2020- 4th and 5th of june 2020

12

The Context

• Processes close to FSW :
• MELD

https://www.youtube.com/watch?v=a mRccXbJFEs

Ceramics session RESIM 2020- 4th and 5th of june 2020

13

The Context

A very strong trend at the moment is therefore to use 6-axis robots. Many research centers in France and around the world are working on this. Among the most dynamic are Cranfield University on the large WAAM and, in France, entities such as the Welding Institute on the CMT, the LIRM, the Maupertuis Institute, Centrale Nantes... or Estia and its Addimadour platform. For this purpose, many suppliers offer heads / effectors.

Ceramics session RESIM 2020- 4th and 5th of june 2020

14

The Context

As seen previously, multi-axis direct deposit techniques are currently undergoing strong development because they offer :

• larger working dimensions,
• Possibility of rework on parts (repair,

addition of functions...)

• Process Hybridization
• and can be combined with machining

processes. The multi-material approach is also easily possible with these processes.

Ceramics session RESIM 2020- 4th and 5th of june 2020

15

The Stakes

• Design – CAD

Re-designing parts and designing for AM (Design for AM) is a key factor in making the process interesting. Limitations of existing software: how to design a part for the DED process, how to take into account aspects such as multi-materials Autodesk

• CAM

The generation of trajectories is an issue common to all direct deposit processes. Taking into account thermal issues when generating trajectories is also an area of research. The influence of the overall trajectory, the filling strategy, the manufacturing strategy in the broadest sense is enormous on the metallurgical quality of the part as well as in terms of residual stresses.

Ceramics session RESIM 2020- 4th and 5th of june 2020

16

The Stakes

• Simulation

Process simulation, especially for wire deposition and the manufacture of very large parts, becomes essential to predict and counteract deformations due to residual stresses and to manufacture a good part the first time. ESI, Virfac

• Digital continuity of software

The preceding points show the need for a strong numerical integration from CAD to CAD/CAM through simulation, some software publishers are beginning to offer complete suites: Siemens with Siemens NX, Dassault Systèmes with 3DExperience.

Ceramics session RESIM 2020- 4th and 5th of june 2020

17

The Stakes

• Manufacturing

The manufacturing process must take into account not only the additive manufacturing part itself but also the post-processes necessary or not (thermal treatment, HIP, dimensional control, material health (which methods?...)). The material flows and the industrial and logistic organization must be rethought with the arrival of this new means of production in the workshop.

• Industrialization and Make or Buy

DED processes are still generally in the laboratory domain (except for a few concrete cases), so it will be necessary to go through an industrialization phase (industrialists and not labs taking over the means) and therefore decide for the principals whether to do in-house or to subcontract (depending on the need to integrate the skills to evaluate the techno, the strategic importance of certain parts, etc.).

Ceramics session RESIM 2020- 4th and 5th of june 2020

18

The Stakes

• Costs, Deadlines, Quality

Additive manufacturing by metal wire deposition is a process that many manufacturers are banking on to reduce the cost of manufacturing parts in the future. Indeed, this very flexible technology has many advantages

• ver other additive manufacturing processes:
• low investment (of the order of 100 to 500 k€, compared to 600 k€ to

1.5 M€ for powder bed processes and 800 k€ to 2 M€ for powder spraying),

• large working space (several meters), of course subjects such as

inerting for materials like Titanium still remain partly to be solved (local inerting, overflow tank, inerting of the whole manufacturing space ...)

Ceramics session RESIM 2020- 4th and 5th of june 2020

19

The Stakes

• “high productivity" (several kg/h as opposed to a few

g/h), this should make the process economically viable, even if it remains slow. The advantage of being able to do without long lead times compared to forged or castings is important.

• good metallurgical quality (defects similar to welding,

no porosities...),

• little downtime and material loss,
• low cost and quick material changeover,

Ceramics session RESIM 2020- 4th and 5th of june 2020

20

The Stakes

• the materials currently addressed are the weldable

materials but the emergence for the additive manufacture of

• ld techno like ColdSpray or FSW (Friction Stir Welding)

makes it possible to address the manufacture of certain aero-non-weldable materials for example, but also to free

• neself from certain constraints due to the process, (residual

thermal constraints in particular).

Ceramics session RESIM 2020- 4th and 5th of june 2020

21

The Stakes

• Health, Safety and Environment (HSE)

The HSE constraints linked to powder additive manufacturing are heavy, even if for LMD processes, they are a little less so given the size of the powders (45-75 μm, variable according to material). We can mention the need to have an isolated room managed in hygrometry and temperature, preferably with a vacuum. The intervention of the operators is preferably done in combination and with a recirculating air mask. On the other hand, there is a reduction in HSE risks for wire technologies compared to metal powders.

Ceramics session RESIM 2020- 4th and 5th of june 2020

22

The Stakes

• Certification

New processes require new modes of certification. In the aeronautical sector in particular, few parts are currently flying in relation to the overall volume of parts.

• Training

Specific training courses are beginning to be developed in engineering schools in the form of modules or complete training courses for initial training. Training modules are also available for industrialists in post (particularly in engineering and design).

Ceramics session RESIM 2020- 4th and 5th of june 2020

23

Conclusion

There are many processes (from welding and research centres) and suppliers on the market, however TRL levels are often intermediate (3-5). The target markets are the manufacture of large parts (stiffeners...) in the form of parts close to the final shape or blanks which in all cases will require post-treatment by machining, or even thermal treatment. These technologies make it possible to address the addition of function, repair, multi-material manufacturing, and the production of blanks by an alternative process to casting or forging. The most dynamic sectors are aeronautics and space, even if markets such as energy, oil & gas and naval are investigating the use of these technologies.

Ceramics session RESIM 2020- 4th and 5th of june 2020

24

Conclusion

The materials used are therefore titanium, Inconel bases... even if we are beginning to investigate special steels for naval, nuclear or tooling

• applications. In any case, the materials used are necessarily weldable

and this limits the wider use of the technology, but processes such as coldspray or FSW make it possible to remedy this (manufacture of aero grade aluminium parts). The mechanical properties achieved are often similar to those of additive production in general between casting and forging. The locks are still numerous and concern all the stages of the part and in particular the constraints of design, manufacture and control.
