Central Coast Blue Draft EIR Public Meeting #1 August 6, 2020 PAGE - - PowerPoint PPT Presentation

PAGE 1

Central Coast Blue Draft EIR Public Meeting #1

August 6, 2020

PAGE 2

AGENDA

• Regulatory background
• Project overview
• Summary of environmental impacts and

mitigation measures

• Overview of alternatives

PAGE 3

GROUND RULES

• Participant audio will be muted during

meeting

• Attendees can submit questions/comments

during presentation using chat function

• There will be time after the presentation

to submit verbal comments

• Meeting is being recorded and will be

posted online

• Chat is also being recorded

PAGE 4

4

REGULATORY BACKGROUND

PAGE 5 PAGE 5

• Provide an overview of the project and the Draft EIR
• Receive your input on the Draft EIR
• Inform the community about next steps in the CEQA process

PURPOSE OF THE PUBLIC MEETING

PAGE 6 PAGE 6

• Disclose the significant environmental effects of proposed projects
• Identify ways to avoid or reduce environmental impacts
• Consider feasible alternatives to proposed projects
• Enhance public participation in the planning process

PURPOSE OF CEQA

PAGE 7 PAGE 7

YOU ARE HERE

CEQA PROCESS

PAGE 8 PAGE 8

CEQA PROCESS (CONT.)

PAGE 9

9

PROJECT OVERVIEW

PAGE 10 PAGE 10

PROJECT BACKGROUND

State Water |

Santa Maria Groundwater Basin

| Lake Lopez || Groundwater

PAGE 11 PAGE 11

PROJECT BACKGROUND (CONT.)

Source: European Geosciences Union - https://blogs.egu.eu/network/gfgd/2018/02/12/saltwater-intrusion-causes-impacts-and-mitigation/

Increased Groundwater Demand Typical Well

Saltwater Intrusion

Freshwater Freshwater Saltwater Saltwater

PAGE 12 PAGE 12

• Regional advanced purified water project including an advanced treatment

facility complex (ATF; including an advanced purified water storage tank, an equalization basin, a pump station), pipelines, injection wells, monitoring wells, and one new production well

• Multi-agency collaboration:
• City of Pismo Beach
• City of Grover Beach
• City of Arroyo Grande
• Oceano Community Services District
• South San Luis Obispo County Sanitation District (SSLOCSD)

PROJECT OVERVIEW

NCMA Agencies

PAGE 13 PAGE 13

REGIONAL PROJECT LOCATION

PAGE 14 PAGE 14

PROJECT COMPONENTS

Proposed Project

Disposal to Ocean

PAGE 15 PAGE 15

PROJECT COMPONENTS (CONT.)

PAGE 16 PAGE 16

• Proposed site: 980 Huber Street, Grover Beach(APN 060-543-016)
• Approximately 1.5 acres of land
• Existing use: several unpaved storage yards for vehicles, equipment, and containers
• Will treat water from Pismo Beach and SSLOCSD Wastewater Treatment Plants
• Initial treatment capacity of 1.3 million gallons per day (Phase I) with final

treatment capacity of 5.4 million gallons per day (Phase II)

• Includes staff support facilities (offices, restrooms, break room, etc.)
• Appurtenant structures:
• Equalization basin
• Advanced purified water storage tank
• Pump station

ADVANCED TREATMENT FACILITY COMPLEX

PAGE 17 PAGE 17

ATF COMPLEX LOCATION

Agricultural Industrial Industrial Residential Current Land Use

PAGE 18 PAGE 18

MICROFILTRATION

PAGE 19 PAGE 19

REVERSE OSMOSIS

PAGE 20 PAGE 20

ULTRAVIOLET/ADVANCED OXIDATION

PAGE 21 PAGE 21

• Reverse osmosis process produces a waste water stream (concentrate) in

addition to the purified water

• Concentrate will be discharged via existing Pismo Beach/SSLOCSD WWTPs
• cean outfall pipeline
• Must be compliant with City of Pismo Beach and SSLOCSD National Pollutant

Discharge Elimination System (NPDES) permit requirements

DISCHARGE OF REVERSE OSMOSIS CONCENTRATE

PAGE 22 PAGE 22

Pismo and SSLOCSD WWTPs are connected via the existing outfall line

Pismo Beach WWTP SSLOCSD WWTP

Concentrate discharge to

• cean outfall

PAGE 23 PAGE 23

PAGE 24 PAGE 24

• Seven injection wells
• 12 inches in diameter
• 200 to 600 feet in depth
• Ten monitoring wells
• Footprints:
• Up to 3,000 square feet per injection well (conservative assumption of footprint)
• 25 square feet per monitoring well
• Heights:
• 6 feet for injection wells
• Flush-mounted for monitoring wells

INJECTION AND MONITORING WELLS

PAGE 25 PAGE 25

• Four sets:
• 1. Convey secondary treated effluent from the existing Pismo Beach WWTP discharge

pipeline to the ATF complex

• 2. Convey secondary treated effluent from the SSLOCSD WWTP to the ATF complex
• 3. Convey advanced purified water from the ATF complex to the injection wells
• 4. Convey concentrate from the ATF complex to the existing WWTP discharge pipeline
• Approximately 6 to 24 inches in diameter
• Primarily in existing rights-of-way
• Will require drilling under the Union Pacific Railroad track
• Will require work within the Oceano County Airport

PIPELINES

PAGE 26 PAGE 26

WELL AND PIPELINE LOCATIONS

Five injection wells in Coastal Dunes RV Park and Campground Two injection wells at SSLOCSD Wastewater Treatment Plant property

PAGE 27 PAGE 27

• Location is yet to be determined – likely to be in Grover Beach
• Intended to optimize groundwater pumping
• Will be owned by City of Pismo Beach
• 14 inches diameter
• 300 to 600 feet in depth
• Up to 3,000 square feet at surface (conservative assumption of footprint)

NEW PRODUCTION WELL

PAGE 28 PAGE 28

INCREASED GROUNDWATER PUMPING

Acre-Feet per Year

2018 Levels 764 Total Adjudicated Amount for Urban Uses* 4,330 Net Increase

3,566

*Note: There will be no increase in the groundwater allocations for any of the NCMA agencies.

PAGE 29 PAGE 29

• Potentially a supplemental (not primary) use of advanced purified water
• Will require pipelines between the ATF complex and agricultural lands to the

south of Oceano

• Exact locations are yet to be determined

AGRICULTURAL IRRIGATION

PAGE 30 PAGE 30

• Phase I:
• Five injection wells (IW-1, IW-2A, IW-3, IW-4, and IW-5A)
• Ten monitoring wells
• Water distribution pipelines
• ATF complex with initial capacity to treat flows from Pismo Beach Wastewater

Treatment Plant

• Phase II
• Two injection wells (IW-2B and IW-5B)
• Expansion upgrades to the ATF complex with full capacity to treat additional flows

from SSLOCSD Wastewater Treatment Plant

• Potentially agricultural irrigation pipelines

CONSTRUCTION PHASING

PAGE 31 PAGE 31

• California Code of Regulations Title 22, Division 4, Chapters 1-3
• Regulations on use of recycled water for a range of purposes, including groundwater

replenishment/indirect potable reuse and agricultural irrigation

• Requires at least two months of travel time between injection wells and drinking water

wells to allow for monitoring and response if needed

REGULATIONS FOR RECYCLED WATER

PAGE 32

32

SUMMARY OF THE ENVIRONMENTAL IMPACT REPORT

PAGE 33 PAGE 33

• Hybrid Project/Program EIR
• CEQA-Plus for SWRCB Clean Water State Revolving Fund Loan Program application
• Project-level for Components with Known Locations:
• Injection and monitoring wells
• Water distribution pipelines
• Advanced treatment facility complex
• Discharge via ocean outfall
• Program-level for Components with Unknown Locations:
• New production well
• Agricultural irrigation pipelines

EIR APPROACH

PAGE 34 PAGE 34

ENVIRONMENTAL IMPACTS

Significant and Unavoidable Less than Significant with Mitigation Incorporated

• Nighttime construction noise
• Land use (associated with nighttime

construction noise impacts)

• Construction-related air pollutant emissions
• Special status species
• Riparian habitat
• Wetlands
• Native trees
• Archaeological resources
• Consistency with City of Pismo Beach Climate Action Plan and City of

Grover Beach General Plan (related to energy and GHG emissions)

• Environmental justice
• Hazardous materials
• Emergency response/evacuation plans and emergency access
• Water quality
• Operational noise
• Construction traffic

PAGE 35 PAGE 35

MITIGATION MEASURES

Topic Mitigation Measure

Air Quality – Construction and Cumulative

• Standard control measures and best available control technology for

construction equipment Biological Resources – Special Status Species

• California Red-legged Frog Habitat Avoidance
• California Red-legged Frog Avoidance and Minimization Measures
• Southwestern Pond Turtle Avoidance and Minimization Measures
• Monarch Butterfly Avoidance Measures
• Nesting Bird Avoidance and Minimization Measures
• Biological Resources Assessment*
• Special Status Plant Species Surveys*
• Special Status Plant Species Avoidance, Minimization, and Mitigation

Measures*

• Restoration Plan for Special Status Plant Species*
• Endangered/Threatened Species Avoidance and Minimization Measures*
• Non-listed Special Status Animal Species Avoidance and Minimization

Measures*

* Programmatic mitigation measure only

PAGE 36 PAGE 36

MITIGATION MEASURES

Topic Mitigation Measure

Biological Resources – Riparian Habitat

• Sensitive Plant Community and Environmentally Sensitive Habitat Area

Avoidance and Minimization Measures Biological Resources – Wetlands

• Jurisdictional Delineation
• Drainages and Wetlands Impact Mitigation
• Drainages and Wetlands Best Management Practices During Construction

Biological Resources – Native Trees

• Native Tree Inventory, Protection, and Replacement

Cultural Resources – Archaeological Resources

• Worker’s Environmental Awareness Program
• Archaeological and Native American Monitoring
• Unanticipated Discovery of Cultural Resources Provisions
• Archaeological Resource Studies*

Energy – Consistency with City of Pismo Beach’s Climate Action Plan and City of Grover Beach’s General Plan and Cumulative Impact

• Energy Efficiency and Renewable Energy Measures (incorporation of LEED

Silver design standards, orientation and design of building to conserve energy and maximize passive solar heating and daylighting)

* Programmatic mitigation measure only

PAGE 37 PAGE 37

MITIGATION MEASURES

Topic Mitigation Measure

Environmental Justice – Construction, Operation, and Cumulative

• Mitigation measures for impacts related to hazardous materials, noise, and

transportation Greenhouse Gas Emissions – Consistency with City of Pismo Beach’s Climate Action Plan and Cumulative Impact

• GHG Emission Reduction Measures (Solar Photovoltaic System and Recycling

Receptacles) Hazards and Hazardous Materials – Use and Accidental Release of Hazardous Materials

• Hazardous Materials Management and Spill Prevention and Control Plan
• Preparation of Hazardous Materials Business Plan

Hydrology and Water Quality – Violation

• f Water Quality Standards
• Initial Quarterly Radioactive Testing

Land Use – Conflicts with Land Use Plans, Policies, and Regulations Adopted for the Purpose of Avoiding or Mitigating an Environmental Effect

• Mitigation measures for impacts related to biological resources, cultural

resources, hazardous materials and noise

PAGE 38 PAGE 38

MITIGATION MEASURES

Topic Mitigation Measure

Noise – Construction and Cumulative Impact • Construction Noise Reduction Measures (mufflers, portable sound enclosures, sound walls, scheduling, campsite closures, temporary relocations) Noise – Operational

• Acoustical Analysis of ATF Complex Operations*

Transportation/Hazards and Hazardous Materials – Construction Traffic, Interference with Emergency Response/Evacuation Plans and Emergency Access (Construction), and Cumulative Impact

• Construction Transportation Management Plan

* Programmatic mitigation measure only

PAGE 39 PAGE 39

• Alternative 1: No Project Alternative (required by CEQA)
• Alternative 2: No Agricultural Irrigation Pipelines
• Alternative 3: Locating Advanced Treatment Facility Complex at SSLOCSD

Wastewater Treatment Plant

• Alternative 4: Modified Locations of Injection and Monitoring Wells
• Alternative 5: Increased State Water Project Allocation
• Alternative 6: Increased Storage of Lopez Reservoir

ALTERNATIVES

PAGE 40 PAGE 40

• Environmentally Superior Alternative
• Avoids adverse project impacts
• Does not provide project benefits of:
• Augmenting groundwater supply
• Creating a sustainable, drought-resistant, local water supply
• Providing a new source of recharge to the SMGB
• Reducing wastewater discharges to the ocean
• Facilitating continued water resources collaboration in the NCMA

ALTERNATIVE 1: No Project Alternative

PAGE 41 PAGE 41

• Environmentally Superior Alternative of those alternatives that accomplish

project objectives

• Avoids adverse project impacts associated with construction of agricultural

irrigation pipelines

• Does not avoid significant and unavoidable construction noise and land use

impacts associated with 24-hour well drilling activities

ALTERNATIVE 2: No Agricultural Irrigation Pipelines

PAGE 42 PAGE 42

ALTERNATIVE 3: PIPELINE AND ATF COMPLEX LOCATIONS

PAGE 43 PAGE 43

ALTERNATIVE 3: CONCEPTUAL ATF COMPLEX LAYOUT AT SSLOCSD WWTP

PAGE 44 PAGE 44

• Similar environmental impacts as the proposed project with greater impacts

related to:

• Energy - inconsistency SLO County EnergyWise Plan
• Hydrology and Water Quality – location of ATF complex in the 100-year floodplain
• Does not avoid significant and unavoidable construction noise and land use

impacts associated with 24-hour well drilling activities

ALTERNATIVE 3: ATF Complex at SSLOCSD WWTP

PAGE 45 PAGE 45

ALTERNATIVE 4 MODIFIED WELL LOCATIONS

PAGE 46 PAGE 46

• Similar environmental impacts as the proposed project with greater impacts

related to:

• Biological Resources – potential additional impacts to resources near Meadow Creek
• Cultural Resources – potential additional impacts to several known archaeological

resources in vicinity of Pismo State Beach Corp Yard

• Does not avoid significant and unavoidable construction noise and land use

impacts associated with 24-hour well drilling activities

ALTERNATIVE 4: Modified Locations of Injection and Monitoring Wells

PAGE 47 PAGE 47

• Environmentally Superior Alternative of the alternatives that are not No Project
• Avoids most project impacts because no construction activities would be required
• Greater environmental impacts as compared to proposed project related to:
• Energy – energy-intensive water source
• Greenhouse Gas Emissions – inconsistency with 2017 Scoping Plan,

which prioritizes use of local water supplies and water recycling

• Avoids significant and unavoidable construction noise and

land use impacts associated with 24-hour well drilling activities

• Does not meet project objectives

ALTERNATIVE 5: Increased SWP Allocation

PAGE 48 PAGE 48

• Greater environmental impacts as compared to proposed project related to:
• Air Quality and Greenhouse Gas Emissions – greater emissions from intensive construction activities and

inconsistency with 2017 Scoping Plan, which prioritizes use of local water supplies and water recycling

• Cultural Resources – submersion and/or demolition of potential historical and archaeological resources
• Lesser environmental impacts as compared to proposed project related to:
• Environmental justice
• Hydrology and water quality
• Noise
• Avoids significant and unavoidable construction noise and

land use impacts associated with 24-hour well drilling activities

• Does not meet project objectives

ALTERNATIVE 6: Increased Storage of Lopez Reservoir

PAGE 49 PAGE 49

COMPARISON OF ALTERNATIVES

Alternative Degree of Environmental Impacts Compared to Project Achieves Project Objectives? Avoids Project’s Significant and Unavoidable Impacts?

1: No Project Less No Yes 2: No Agricultural Irrigation Pipelines Less Yes No 3: ATF Complex at SSLOCSD WWTP Greater Yes No 4: Modified Locations of Injection and Monitoring Wells Greater Yes No 5: Increased SWP Allocation Less No Yes 6: Increased Storage of Lopez Reservoir Similar No Yes

PAGE 50 PAGE 50

• Providing recycled water at Disinfected Secondary-23 standards for

restricted reuse

• Providing recycled water at Disinfected Tertiary standards for unrestricted

landscape irrigation

• Pursuing desalination
• Implementing aggressive water conservation measures

ALTERNATIVES CONSIDERED BUT REJECTED

PAGE 51 PAGE 51

• August 18, 2020 – Draft EIR Public Meeting #2 at Pismo Beach City Council

Meeting

• September 3, 2020 – Last day to submit comments on Draft EIR
• Fall/Winter 2020 – Preparation and certification of Final EIR

PROJECTED EIR SCHEDULE

PAGE 52 PAGE 52

WE WELCOME YOUR COMMENTS!

Please provide comments on the adequacy of the Draft EIR including:

• Environmental impacts of the project
• Mitigation measures
• Alternatives

For more information, visit http://centralcoastblue.com/ Thank you for participating!

PAGE 53 PAGE 53

ADDITIONAL DISCUSSION GUIDELINES

• Reminder: meeting and chat are being recorded
• Questions/comments can be submitted via chat or verbally
• Questions/comments from chat will be read aloud in the order they were received
• If you wish to provide verbal comments, please “raise your hand” (3 minutes per person)
• Call-in attendees will then be unmuted to see if they have verbal comments to share (3 minutes per person)

You can also submit a written comment via letter or email. Matthew Downing 760 Mattie Road Pismo Beach, CA 93449 mdowning@pismobeach.org

PAGE 54
