SLIDE 1

Center for Secure and Resilient Maritime Commerce

slide-2
SLIDE 2

Developing a Resiliency Framework for Regional Freight Platforms

  • T. Wakeman, H. Gajjar, J. Ramirez-Marquez,

and H. Salloum Stevens Institute of Technology Center for Secure and Resilient Maritime Commerce

slide-3
SLIDE 3

Trade & Transport Trends

  • Continuing global population/trade growth
  • MTS consolidation (liner services merging)
  • Global supply chain integration
  • Changing trade patterns and markets
  • Expanding economies of scale/scope
  • Business driver of service reliability
  • Emerging regional freight platforms (RFP)
  • Are RFPs a resiliency strategy?
slide-4
SLIDE 4

31 Oct 2011 - 7 Billion ~2026

World Population Growth 1950 to 2050 (projected)

slide-5
SLIDE 5

Shipping Grows with Trade

(Source: Kaluza, Kolzsch, Gastner, and Blasiusu (2010) “The complex network of global ship cargo movements” J. Royal Society: Interface)

slide-6
SLIDE 6

Global Seaborne Shipping 1968-2008

(Source: http://www.marisec.org/shippingfacts/worldtrade/volume-world-trade-sea.php)

TRIPLED in 40 years!

slide-7
SLIDE 7

Trade & Transport Trends

Continuing global population/trade growth

  • MTS consolidation (liner services merging)
  • Global supply chain integration
  • Changing trade patterns and markets
  • Expanding economies of scale/scope
  • Business driver of service reliability
  • Emerging regional freight platforms (RFP)
  • Are RFPs a resiliency strategy?
slide-8
SLIDE 8

Marine Transportation System

The Marine Transportation System (MTS) consists of vessels, waterways, ports, and intermodal landside connections, which allow the various modes of transportation to move people and goods to, from, and on the water... and its character is changing.

Source: After MTSNAC: http://www.mtsnac.org

slide-9
SLIDE 9

Global Terminal Acquisitions

Date Terminal Acquirer Price ($million) Volume (TEUs) Price TEU Multiple Sept 04 CSX World Terminals DP World 1,142 3,300,000 $346 14 Jan 06 P&O Ports DP World 6,800 22,500,000 $302 16 Nov 06 OOIL Terminals Ontario Teacher’s Pension Plan 2,400 2,570,000 $935 27 Dec 06 Halterm Macquarie 157.5 210,000 $750 23 Feb 07 Montreal Gateway Morgan Stanly 409.5 995,000 $515 23 Mar 07 Maher Terminals Deutsche Bank 2,300 (?) 1,900,000 $1,053 ~40 (?)

Source: After B. Cashon, Oct. 2010, AAPA Terminal Conf.

slide-10
SLIDE 10

Carrier Consolidation from 1970 to 2010

NYK Line Showa Nippon Liner

NYK Line

CP Ships Canmar Lykees Lines Contship Avaran Lines ANZDL

CP Ships Hapag Lloyd

CMA CGM Australia National Lines

CMA CGM

NOL APL

APL

Evergreen Lloyd Triestino Uniglory Hatsu Marine

Evergreen

P&O Containers Nedlloyd Lines Blue Star Lines Farrell Line

P&O Nedlloyd Maersk

Maersk Line Sea-Land Safmarine SCL Line/CMBT

Maersk/ Sealand

slide-11
SLIDE 11

Trade & Transport Trends

Continuing global population/trade growth MTS consolidation (liner services merging)

  • Global supply chain integration
  • Changing trade patterns and markets
  • Expanding economies of scale/scope
  • Business driver of service reliability
  • Emerging regional freight platforms (RFP)
  • Are RFPs a resiliency strategy?
slide-12
SLIDE 12

Integration of Supply Chain Relationships

Traditional Supply Chain Model Logistics Network Model

slide-13
SLIDE 13

From “Point-to-Point” Movement to Continuous Flow Pipelines

  • Freight transportation

is a “systems” issue and must be seen from a regional/national mobility perspective.

  • The “logistics system”

include waterways and terminals as well as landside access and distribution centers.

slide-14
SLIDE 14

Four Mega-Trading Blocks

Russia China India Europe

slide-15
SLIDE 15

Two Mega-Trading Blocks

North America South America

slide-16
SLIDE 16

Trade & Transport Trends

Continuing global population/trade growth MTS consolidation (liner services merging) Global supply chain integration Changing trade patterns and markets

  • Expanding economies of scale/scope
  • Business driver of service reliability
  • Emerging regional freight platforms (RFP)
  • Are RFPs a resiliency strategy?
slide-17
SLIDE 17

1996 Generation “Regina” & 2006 Generation “Emma”

slide-18
SLIDE 18

Economies of Scale

As quantity of production increases from Q to Q2, the average cost of each unit decreases from C to C1.

http://en.wikipedia.org/wiki/File:Economies_of_scale.PNG

slide-19
SLIDE 19

Cost of Construction

Cost/DWT per DWT Bulkers

100 200 300 400 500 600 700 800 900 50,000 100,000 150,000 200,000 DWT Cost/DWT ($/ton)

Source: Tradewinds Sales and Purchase Data, November 2009

slide-20
SLIDE 20

20

14k Ship with Eight Gantry Cranes

Source: DPW_Daniela_14k.jpeg

slide-21
SLIDE 21

21

Bigger Ships Mean Bigger Infrastructure - New $5B Panama Canal Expansion Opens in 2014

Total excavation = 133 MCM Original 1914 construction = 205 MCM

slide-22
SLIDE 22

Cost Advantage Comparison with 4000/8000 TEU Ships

(Source: Worley Parsons, Richard West)

slide-23
SLIDE 23

East Coast ports reportedly investing more than $6 billion for expansions…

  • Demand for increased capacity
  • Driven by ships/expansion of the Panama Canal
  • Port & intermodal infrastructure issues

–Availability of deep water and air draft –On-dock intermodal container transfer facilities –Seamless road and rail connectivity to nation –Access to warehouse & logistics centers

  • Increasing business focus on system reliability
slide-24
SLIDE 24

Trade & Transport Trends

Continuing global population/trade growth MTS consolidation (liner services merging) Global supply chain integration Changing trade patterns and markets Expanding economies of scale/scope

  • Business driver of service reliability
  • Emerging regional freight platforms (RFP)
  • Are RFPs a resiliency strategy?
slide-25
SLIDE 25

National Export Initiative

  • In 2010, President Obama launched the

National Export Initiative (NEI), which aims to double exports over the next five years.

  • This initiative is envisioned to significantly

increase the volume of American products entering the global marketplace.

  • Beyond the export of service sector products,

these exports include agricultural goods, manufactured products, and natural resources.

  • The President declared that exports are

important to boost the U.S. GDP, reduce the trade deficit, and help stimulate job creation.

slide-26
SLIDE 26

U.S. Exports Transport Cost from Midwest to Northern Europe

2000 1000 900 800 700 600 500 400 300 200 100 50 40 30 20 10

32% 20 %

1.4 % 10 % 6 % 10 % 2 % 12 % .5 % .75 % 2 % 100 %

$

U.S. INLAND U.S. PORT U.S. EMPTY POSITIONING EQUIP P/D OCEAN TRAN EU PORT EU EMPTY POSITIONING EU INLAND CLAIMS FF FEE AGENT TOTAL

US 63.4% Cost EU 24% Cost

slide-27
SLIDE 27

Cargo Owners’ Demands from their Logistics Networks

  • Competitive costs
  • Velocity to the point of sale
  • Reliability in cargo delivery

...and Reliability is KING!

If cargo moves from its current route because of poor performance to a new route, it almost never returns.

slide-28
SLIDE 28

Trade & Transport Trends

Continuing global population/trade growth MTS consolidation (liner services merging) Global supply chain integration Changing trade patterns and markets Expanding economies of scale/scope Business driver of service reliability

  • Emerging regional freight platforms (RFP)
  • Are RFPs a resiliency strategy?
slide-29
SLIDE 29

29

Planning for International (Import and Export) & Domestic Freight Movement

slide-30
SLIDE 30
slide-31
SLIDE 31

Economies of Scope

  • r “Bigger is Better”
  • Regional Freight Platforms serve expanded

geographic scopes beyond historic tributary cargo flows to gain logistic efficiencies.

  • These transport and distribution networks have

redundant infrastructure and distribution capabilities available to enable the existing supply chain to absorb a shock or disruption without crippling the chain’s ability to meet regional customer’s needs.

  • There will be competition among components.
slide-32
SLIDE 32

Formation of a “Port Pole”

  • A “Port Pole” is a Regional Freight

Platform of collaborating ports that attract cargo because of their combined capacity, enhanced resiliency to shocks, and ability to contribute value through economies of scope and scale.

  • Examples of existing port poles include the

LA(16)-LB(17) port complex, ports of Rotterdam(9)-Antwerp(13), and ports of Hamburg(11)-Bermerhaven(19).

slide-33
SLIDE 33

Creating a New Port Pole ...or RFP

  • Collaborations among

the Port of New York and New Jersey with the Delaware River Ports of Wilmington- Philadelphia-Camden could form a new port pole that serves the Northeast, Midwest and the nation.

slide-34
SLIDE 34

Two Gateways – One Port

  • North Port (PANYNJ) is the import

gateway... moving containerized goods quickly into the region and the hinterlands... and connects to:

  • South Port (W-P-C) is the bulk cargo and

container export gateway... making use of available local land and labor resources in Wilmington, Philadelphia and South Jersey region to increase efficiency.

slide-35
SLIDE 35

New Jersey Freight Flows

  • 199 Million Tons entering

the State

  • 126 Million Tons moving

through the State

  • 131 Million tons moving

within the State

  • 165 Million Tons leaving

the State

More than 600 million tons!

slide-36
SLIDE 36

New Jersey’s Proposed Marine Highway & Regional Freight Platform

  • Upper New York Bay (Jersey

City Hub)

  • Newark Bay (Elizabeth Hub)
  • Edison/Linden

(Raritan/Linden Hub)

  • Camden/Gloucester/

Paulsboro (C/P Hub)

  • Salem (Salem Hub)
slide-37
SLIDE 37

Trade & Transport Trends

Continuing global population/trade growth MTS consolidation (liner services merging) Global supply chain integration Changing trade patterns and markets Expanding economies of scale/scope Business driver of service reliability Emerging regional freight platforms (RFP)

  • Are RFPs a resiliency strategy?
slide-38
SLIDE 38

DISRUPTIONS!

MSC Chitra, Mumbai, India (2010) USS Cole – Oct. 12, 2000 Earthquakes: Port Au Prince Car Float, 2009

slide-39
SLIDE 39

Maritime Transportation System Terminals Ships Waterway Intermod al Users Port Security Protection (Detect, Deter, Defend) Resilience (Consider, Mitigate) Technological

  • Sensors
  • Networks

Physical

  • Guns
  • Gates
  • Guards

Reactive Approach

  • After

disruption Proactive Approach

  • Before

disruption requires

MTS

Vessels Waterways Terminals Intermodals Users

slide-40
SLIDE 40

Balancing Security from Disruptions and Free Movement of Cargo at Ports

Most Protection No Danger Stops all Movement How to achieve the

  • ptimum?

No Protection No Cost Extremely Vulnerable

If you cannot afford to protect it, what can you do to make it resilient?

slide-41
SLIDE 41

What is Resilience?

Resilience is the ability of a system to provide and maintain an acceptable level of service in the face of various major disruptions and challenges to normal operations.

slide-42
SLIDE 42

42

Resiliency Curve

Operational Capacity Time

Preparation Disruption Recovery Time Lost Performance Zone

Baseline Resilience Option

slide-43
SLIDE 43

Proactive and Reactive Resiliency Strategies

Proactive Resiliency Strategies Reactive Resiliency Strategies

Disruption / Catastrophic Event

slide-44
SLIDE 44

Developing a Modeling Framework

  • Define the system

– Delineate network boundary – Identify Unit of Benefit and FOM

  • Scenario Analysis

– Define baseline conditions of current state – Determine business model – Identify possible disruptive scenarios

  • Determine action measures and effects
slide-45
SLIDE 45

Selecting Model Parameters

  • Unit of Benefit

– Cargo Throughput

  • Figure of Merits

– Cargo Security – Redundant Capacity (and hence Resiliency) – Capacity Alternatives – Job creation/retention – Reduction in congestion – Reduction in emissions – Asset utilization – Highway safety – Public-private partnership – Profits

slide-46
SLIDE 46

Assessing Impact of RFP on Business and Security

Economic Importance Resilient System Low Medium High Low Medium High 1 Cargo security Redundant capacity Job creation Public profits Political obstacles Congestion & Emission reduction Highway safety Environmental requirements Community resistance Asset Utilization Adequate infrastructure Adequate equipment Highway & Railway maintenance Public-Private Partnership Available Finance 2 3 4 5 1 2 3 4 5

slide-47
SLIDE 47

Trade & Transport Trends

Continuing global population/trade growth MTS consolidation (liner services merging) Global supply chain integration Changing trade patterns and markets Expanding economies of scale/scope Business driver of service reliability Emerging regional freight platforms (RFP) ? Are RFPs a resiliency strategy in NJ?

slide-48
SLIDE 48

Answer: YES

Any Questions?
