Cast Resin LV Busway (IP68) Taiwan Busway Company

TBC Company Overview

— Taiwan Busway Company, Ltd. — Est. 2002; located in Taipei — Brand: TBC — Busway market leader in Taiwan, presence in China, Germany/

Europe, USA. Now positioned to grow in APAC region through cooperation with EMAY International Marketing Ltd.

— Capabilities:

— Experienced engineers and technical staff who participated in technical

development in Germany and the study of cast resin busway manufacturing.

— Production technicians have over 25 years experience in the manufacture

• f HV electrical equipment (69-345kV GIS) and LV cast resin transformers

& busway.

— Participated in the research and development of insulation materials,

<36kV cast resin transformers, and cast resin busway systems.

How is Cast Resin Busway different?

Conductor Busbar Insulation & Housing = Cast Resin

Cast-resin busway

Conductor Busbar Insulation Housing

Sandwich busway

Advantages of Cast Resin Busway

— IEC 60529 Ingress protection rating to IP68

— Dust resistance: IP6x; Water resistance: IPx8

— IEC 60331 fire resistant rating, 750°C for 3 hours — IEC 60332 self-extinguishing insulation rating — CNS 12514 / JIS A1034 fire resistant certified – 840°C for 30 minutes — Ex.m.II.T5 explosion-proof classified to CNS 3376/IEC 60079 — High mechanical strength (IK10 impact test) to IEC 61439-1, clause 10.2.6 — Seismic certified to 0.8g — Chemical resistant In addition to widely-known benefits of busway: — Low impedance & Low voltage drop — High short-circuit withstand strength — Compact dimensions offer substantial space savings — Easy to install & Maintenance-free — Customizable fittings available to meet special requirements

Product Overview

— Voltage: up to 1000V* — Current ratings:

— 600−6400A (Cu); — 600−4000A (Al)

— Conductor material:

— Copper or Aluminum — Tin or Silver plated

— Insulation material:

— Epoxy cast resin – Class F (155°C)

— IEC 60439-2 certified

* For Low Voltage (LV) range. Medium Voltage (MV) range up to 17.5kV is also available.

Product Overview

Standard bridge joint (with IP68 covers) Silicone casted joint

• casting done on site after installation
• x2 layers of IP68 (joint cover + casting)
• explosion-proof rated

— Two joint designs are available:

• r

A full line of Fittings...

...and Accessories

Wall/floor flange Vertical hangers Horizontal hangers

Product Features: IP68 Ingress Rating

— Meets IP68 dust-proof and water-proof requirements

under IEC60529 standards.

— IP6x: Products are placed in a sealed testing

chamber brought to a vacuity of 20mbar. Lime powder is then circulated in the chamber for eight hours, after which the busway and its internal connection parts show no sign of dust penetration/accumulation.

— IPx8: Products are subject to fixed power voltage

and submerged with connection parts under 1M of

• water. Voltage pressure is steadily increased for
• ne hour without short-circuit.

Product Features: Explosion & Impact Resistance

— Explosion-proof tested to CNS 3376.18 / IEC 60079-18

for Ex-m-II-T5 classification

— Suitable for use in hazardous application environments –

— Class 1, Div 2 — IEC Zone 1 or Zone 2 — or equivalent

— Certified to IEC61439-1, clause 10.2.6 for Mechanical

Impact strength IK10

Product Features: Fire Resistance

— IEC60331

— Operation for up to 3 hours at 750° C without short circuit.

— IEC60332

— self-extinguishing insulation rating

— CNS12514 & JIS A1034

— Resistance to 30 minutes of burning at 840° C without short

circuit;

— Dielectric withstand voltage test at 1.5kV/1 min, with

insulation resistance test over 0.4 M-Ohm.

Classification (Peak Ground Acceleration, PGA) 5 strong 0.08g~0.25g 6 very strong 0.25g~0.4g 7 great Above 0.4g

Product Features: Seismic Certified to 0.8g

Wide Product Certifications for International Markets and Special Applications

— Busway standards: — IEC 60439-2, IEC 60439-1, CNS 14286, JIS C8364 — China Compulsory Certification (CCC) — Fire resistance testing: — CNS 14286, CNS 12514, JIS C8364, JIS A1304 — Ex.m.II.T5 explosion-proof, IK10 impact test & Seismic

Vigorous Routine and In-Process Testing

• Temperature rise-testing equipment
• Burning endurance testing facility
• Waterproof testing equipment
• Dielectric withstand voltage testing equipment
• Impact testing equipment
• Insulation resistance testing equipment
• Thermal scans & Infrared temperature monitoring
• Ultrasonic measuring equipment
• Low resistance measurement
• High resistance measurement
• Conductivity measurement

High resistance meas. Temperature rise Low resistance meas. Dielectric withstand Ultrasonic meas. Infrared monitoring Thermal scans Conductivity Infrared monitoring

Applications for Cast Resin Busway

Ideally suited for applications in harsh operating environments that require higher levels of protection.

Projects Reference – Completed Installations

Key Customers Served

Sample Projects Completed

Sample Projects Completed

Sample Projects Completed

Joint Casting Process

(1) Install joint cover (2) Prepare casting materials (3) Pouring/casting (4) Curing & casting completed
