CAMDA 2004 Dissecting the Malaria Transcriptome Malaria - the disease More than 400 million affected every year 1 - 2.7 million annual deaths Most deaths are children under 5 A child dies every 20-40 seconds Transmitted by

slide-1
SLIDE 1

CAMDA 2004 Dissecting the Malaria Transcriptome

slide-2
SLIDE 2

Malaria - the disease

  • More than 400 million affected every year
  • 1 - 2.7 million annual deaths
  • Most deaths are children under 5
  • A child dies every 20-40 seconds
  • Transmitted by Anopheles mosquito
  • Large economic burden

in afflicted countries

slide-3
SLIDE 3

Why is malaria a problem?

  • Third world disease
  • Widespread drug resistance
  • Very few drugs available
  • No effective vaccine
  • Very few established drug targets
slide-4
SLIDE 4
  • ! " "#
slide-5
SLIDE 5

Centers for Disease Control (1997)

Distribution of Malaria and Chloroquine-Resistant P. falciparum

slide-6
SLIDE 6

Strategies against P. falciparum

Quinine Chloroquine Mefloquine Pyrimethamine Artemisinin

1. 2. 3.

Drugs Vaccines Mosquito Control

slide-7
SLIDE 7

Why is malaria research difficult?

  • Poor genetics, haploid
  • Low transfection efficiency
  • Very high A/T content (> 80%)
  • Difficult to express proteins
  • Difficult to scale up culturing
slide-8
SLIDE 8

Plasmodium

  • Malaria caused by parasites of the genus Plasmodium
  • Plasmodium are protists of the class Apicomplexa
  • Over 5,000 described Apicomplexa species
  • All Apicomplexa are parasites

4 infect humans:

  • P. ovale
  • P. malariae
  • P. vivax
  • P. falciparum
slide-9
SLIDE 9
  • P. falciparum Lifecycle Stages
  • D. Wirth
  • 1. Mosquito
  • 2. Liver
  • 3. Blood
slide-10
SLIDE 10

Intraerythrocytic Development

Merozoite Ring Trophozoite Schizont ~ 48 Hours

L.H. Bannister

slide-11
SLIDE 11

Aims of Project

1) To determine the transcriptional profile

  • f every gene throughout asexual red

blood cell development 2) Characterize which genes are being utilized during the asexual red blood cell stage 3) Use the dataset to identify putative candidates for further study as drug and/or vaccine candidates

slide-12
SLIDE 12

What are the Big Issues?

  • P. falciparum pathogenesis?
  • parasite/host interaction
  • Host immune evasion?
  • antigenic variation by P. falciparum
  • Regulation of developmental cycles?
  • factors for transcriptional control
  • Active metabolic pathways?
  • Role of the plastid?
  • Ability to respond to environment?
slide-13
SLIDE 13

Initial Goal

A comprehensive examination of the transcriptome of the intraerythrocytic lifecycle of P. falciparum

slide-14
SLIDE 14

Design Issues

  • Array production
  • Obtaining sufficient material (RNA)
  • Culture uniformity
  • Entire intraerythrocytic lifecycle

?

slide-15
SLIDE 15

The P. falciparum genome

!$%&

  • 14 linear chromosomes
  • 22.8Mbp, ~5,400 genes
  • 6kb linear mitochondrial genome
  • 3 proteins + rRNAs
  • 35kb circular plastid genome
  • ribosomal proteins + tRNAs, rRNAs
  • Overall A/T content: 80% - 90% non-coding

60% of ORFs UNKNOWN!

slide-16
SLIDE 16

Oligo Selection Flowchart

ArrayOligoSelector

http://arrrayoligosel.sourceforge.net

slide-17
SLIDE 17
  • P. falciparum Array

70-mer oligonucleotide elements predicted for 3D7 reference strain 70-mer oligonucleotide elements predicted for 3D7 reference strain

  • 4,488 ORFs
  • 990 ORFs with multiple oligos
  • 1,315 elements outside of ORFs
  • Now updated plus 1000 ORFs
  • 4,488 ORFs
  • 990 ORFs with multiple oligos
  • 1,315 elements outside of ORFs
  • Now updated plus 1000 ORFs
slide-18
SLIDE 18

DNA Microarray Hybridization

Reference Sample Experimental Sample

Cy3 Cy5 Ratio: Cy5/Cy3

slide-19
SLIDE 19

Culture Uniformity and RNA?

Traditional approach:

  • Grow up many flasks
  • Synchronize the parasites
  • Split back out into flasks

TOO SMALL-SCALE AND TOO MUCH VARIABILITY!

slide-20
SLIDE 20

5L Parasite Culture System

slide-21
SLIDE 21

Experimental Setup

48 hourly time points

Cy3-RNA reference pool Cy5-single time point

Large scale culture of highly synchronized parasites (HB3 strain)

total RNA labeling

slide-22
SLIDE 22

Uniformity and Synchronization

slide-23
SLIDE 23

Overview of the Data

  • Most ORFs characterized by a

single max and min

  • Large variation in the amplitude
  • f overall signal
  • Timing of expression significantly

varies throughout the IDC

slide-24
SLIDE 24

Reproducibility of the Data

slide-25
SLIDE 25

How can we determine which genes are highly regulated during the intraerythrocytic development of P. falciparum?

slide-26
SLIDE 26

The Fast Fourier Transform

“The Fourier transform, in essence, decomposes

  • r separates a waveform or function into

sinusoids of different frequency which sum to the

  • riginal waveform. “
  • Forrest Hoffman

Frequency domain Time domain hours

slide-27
SLIDE 27

Power spectrum example

This shows that a sine wave of frequency two can fit the above line.

“power spectrum” sine p=2

slide-28
SLIDE 28

Real data example

Power in Two Main Frequency Components

% POWER =

(Signal to Noise) Total Power in All Frequency Components

slide-29
SLIDE 29

Data Power Spectra

74.4% 95.6% 53.1% % Power

slide-30
SLIDE 30

Distribution of % Power for

  • P. falciparum
slide-31
SLIDE 31

Distribution of % Power in Randomized Dataset

slide-32
SLIDE 32

Distribution of % Power for

  • S. cerevisiae cell cycle

(%) Power at Peak Frequencies

10 20 30 40 50 60 70 80 90 100

IDC Regulated

more less

300 200 100

Spellman, P.T. et. al., Mol. Biol. Cell 1998

slide-33
SLIDE 33

Fourier phase and timing

FFT phase

  • Related to when the maximal and minimal expression occurs.
  • Allowed us to order the profiles by the timing of expression.
slide-34
SLIDE 34

Overview Set of Most Regulated Genes

819 ORFs (24%) 2,714 ORFs (76%)

PLOT BY PHASE

slide-35
SLIDE 35

The Asexual Intraerythrocytic Developmental Cycle of Plasmodium falciparum

PHASEOGRAM

  • Continuum of expression
  • Similar function/phase
  • Just-in-time expression

“viral-like”

  • Once and only once
slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38

Glycolysis - redundant genes

May be utilized in a different stage of development?

slide-39
SLIDE 39

Pyrimidine Synthesis dNTPs NTPs

“Just in time”

These two processes are transcriptionally uncoupled.

slide-40
SLIDE 40
slide-41
SLIDE 41
slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44

Transcriptome Overview

  • Most genes are activated once and only once
  • The timing of expression is tightly correlated

with function (and trafficking)

  • Most genes in the genome are NOT

stage-specific

  • If the cascade is rigid, can it be perturbed?

Transcriptional Regulation?

slide-45
SLIDE 45
  • P. falciparum Chromosome II

Minimal coregulation within chromosomes

slide-46
SLIDE 46

Pearson Along Chromosomes

SERA Gene Family

14 total groups > 3 genes All functionally unrelated Transcription during the IDC is monocistronic.

slide-47
SLIDE 47

Apicoplast genome

Maréchal et al. Vol 6,5, 1 May 2001

  • 60 ORF RNA pol subunits,

rRNAs, tRNAs and 9 putative ORFs (one is ClpC homologue)

  • 41 represented on the array
slide-48
SLIDE 48

Comparative Genomic Hybridization

HB3 Strain used in this study vs. 3D7 Strain which was sequenced Variation in antigenic determinant genes: var, rifin, and stevor

100% loss in HB3 signal

slide-49
SLIDE 49

CGH between all chromosomes

Most differences in the highly antigenic telomere regions with some internal differences detected.

2 1 3 4 6 5 7 8 10 9 11 12 13 14

slide-50
SLIDE 50

Can we use the transcriptome to further gene predictions? Can we use the transcriptome to find anti-malarial targets?

slide-51
SLIDE 51

Apicoplast targeted ORFs

slide-52
SLIDE 52

Protease Drug Targets

slide-53
SLIDE 53

Putative Vaccine Targets

190 ORFs Unknown Function

slide-54
SLIDE 54

Erythrocyte Binding Antigen Transcriptionally-related genes

slide-55
SLIDE 55

Public availability of Data

malaria.ucsf.edu PlasmoDB.org

slide-56
SLIDE 56
  • How rigid is the IDC transcriptome?
  • Does it vary between strains of

falciparum?

  • Can P. falciparum sense and react to

external stimuli or is it hard coded? …. if so how?

New Directions

slide-57
SLIDE 57

Comparison of Three Strains

pyrimethamine sensitive pyrimethamine sensitive pyrimethamine resistant sulfadoxine resistant sulfadoxine resistant sulfadoxine sensitive chloroquine sensitive chloroquine resistant chloroquine sensitive Netherlands Indochina Honduras 3D7 Dd2 HB3

slide-58
SLIDE 58

Three Time courses

HB3: 48 timepoints Dd2: 50 timepoints 3D7: 53 timepoints

slide-59
SLIDE 59

What might change?

Genes may not be expressed in the other strains. Genes may change their timing of expression (phase). Genes may change their mode of regulation (constitutive). AMPLITUDE PHASE

slide-60
SLIDE 60

Overall program is preserved

slide-61
SLIDE 61

Sample Profiles

General Conclusions:

  • Most of the expression

profiles are similar.

  • Confirmation of initial

HB3 results.

slide-62
SLIDE 62

FFT % Power for 3 Strains

slide-63
SLIDE 63

Variable Expression Infrequent

Less than 1% of the expression profiles measured for these three strains differ significantly in their phase of expression.

slide-64
SLIDE 64

Interesting Case

  • For the Dd2 strain there is

NO DETECTABLE SIGNAL from

  • PFC0772.

3D7 HB3

Alternative Splicing?

slide-65
SLIDE 65

Data will be available at PlasmoDB.org soon!

slide-66
SLIDE 66

Perturbation Study No specific transcriptional response to an external stimulus has ever been detected in P. falciparum.

slide-67
SLIDE 67

> 350 genes

With so many similar profiles, how do we further dissect genes which are functionally related?

slide-68
SLIDE 68

6,000 genes

Expression Map of the Yeast Genome

Meiosis specific genes

100s of experiments

slide-69
SLIDE 69

Perturbation study

Chloroquine Glucose Depletion Serum Depletion Hypoxanthine 42 ° C Heat Shock MMS Run timecourse experiments so we can anchor the results in the transcriptome.

slide-70
SLIDE 70

Conclusions

  • Definitive first pass analysis of the transcriptome
  • See a cascade of gene expression which once

initiated continues until cycle terminates

  • Genes of similar function cluster together
  • aid in assignment of function to 60% unknown
  • Differences between strains will be important to

understanding drug resistance and provide leads for drug targets

slide-71
SLIDE 71

Bioinformatics + “wet lab”

  • Use all available data: PlasmoDB

Long-oligo microarray data Affymetrix data (Le Roch et al.)

  • other developmental stages

Other Plasmodium genomes EST data Proteomics data

  • More data on related strains and

environmental perturbations

slide-72
SLIDE 72

Acknowledgements

Joseph L. DeRisi malaria.ucsf.edu

The Rest of the Malaria Team...

  • Sandler Foundation
  • NIAID
