E le c trifying Our Building s California Commercial Building Energy Use by Fuel Type ALISO CANYON GAS LEAK Learning Objectives 1. The benefits of electrification: why policymakers and designers are moving towards electrifying new and

slide-1
SLIDE 1

California Commercial Building Energy Use by Fuel Type

ALISO CANYON GAS LEAK

E le c trifying Our Building s

slide-2
SLIDE 2

Learning Objectives

  • 1. The benefits of electrification: why policymakers and designers are

moving towards electrifying new and existing commercial buildings

  • 2. What technologies will be used to electrify commercial buildings?
  • 3. How right timing and integrated solutions can enable capital and energy

cost-effective electrification.

  • 4. How to choose the right electrification technology based on existing

building systems

slide-3
SLIDE 3

Session Description: Learn the process of electrification for new and existing commercial

  • buildings. Information about recent technologies, including HVAC, hot

water, and the whole systems approach, will be presented. Learn more about the various incentives and clean energy programs available.

slide-4
SLIDE 4

Agenda:

  • Why? Climate, Efficiency Safety, Health
  • When? - It’s Time to Flip the Switch
  • What? – End Use Breakdown
  • How? – How to Electrify Commercial Buildings
slide-5
SLIDE 5

Wha t?

slide-6
SLIDE 6

6

Clothes Dryer Cooktop Water Heater Space Heater Additional Gas Uses:

  • Labs
  • Healthcare
  • Manufacturing
  • Pool/Spa Heating
slide-7
SLIDE 7

End Use Breakdown, US Southwest

Commercial

Heating 28% Water Heating 19% Cooking 5% Clothes Drying 4% Refrigerators 16% Other 28%

Residential

Heating 14% Water Heating 10% Cooking 10% Refrigeratio n 11% Cooling 10% Ventilation 9% Lighting 11% Office Eqpt 3% Computing 8% Other 14% Source: EIA – REC & CBECS

slide-8
SLIDE 8

Why? - Environment

slide-9
SLIDE 9

Carbon Dioxide

Co a l

(C 240H

90O 4NS)

SOx NOx Particulates

Na tura l Ga s

(CH4)

So la r, Wind, Hydro , Nuc le a r

Methane Carbon Dioxide

slide-10
SLIDE 10

Carbon Dioxide

Co a l

(C 240H

90O 4NS)

SOx NOx Particulates

Na tura l Ga s

(CH4)

E le c tric ity Po we re d b y So la r, Wind, Hydro

Methane Carbon Dioxide

slide-11
SLIDE 11

Carbon Dioxide

Co a l

(C 240H

90O 4NS)

SOx NOx Particulates

Na tura l Ga s

(CH

4)

E le c tric ity Po we re d b y So la r, Wind, Hydro

(O 2)

Methane Carbon Dioxide Fresh air

slide-12
SLIDE 12

Methane Leakage

slide-13
SLIDE 13

Burning vs Leaking Methane

10x Worse for Global Warming to Leak a Therm than to Burn a Therm

Combustion Leakage

slide-14
SLIDE 14

Gas May Be Worse Than Coal

1.9 2.5 4.8 7.6 13.4 0.0 2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 Excluding Leakage 1% leakage rate 5% leakage rate 10% leakage rate 20% leakage rate MT CO2e per Year

Impact of Including Methane Leakage on GHG Calculations - Single Family Homes

Due to Combustion Due to Leakage

slide-15
SLIDE 15

Gas May Be Worse Than Coal

1.9 2.5 4.8 7.6 13.4 0.0 2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 Excluding Leakage 1% leakage rate 5% leakage rate 10% leakage rate 20% leakage rate MT CO2e per Year

Impact of Including Methane Leakage on GHG Calculations - Single Family Homes

Due to Combustion Due to Leakage

slide-16
SLIDE 16

Nevada Policy Direction

slide-17
SLIDE 17

Nevada Policy Direction

Source: State of Nevada, Governor’s Energy Office, 2017 Status of Energy

slide-18
SLIDE 18

Nevada Policy Direction

Source: State of Nevada, Governor’s Energy Office, 2017 Status of Energy

16 Nations US Cities

  • Burlington, VT
  • Aspen, CO
  • Greensburg, KS
  • Kodiak Island, AK
  • Rock Port, MO
  • Georgetown, TX
  • Palo Alto, CA
  • West Hollywood
  • More every year

100% Renewable Becoming Commonplace

slide-19
SLIDE 19

Why?

Building Gas Emissions Electricity Emissions Other

Transportation Emissions 46% Building Gas Emissions 43%

Transportation and Gas Emissions Are a Focus Point in a Renewable Grid

slide-20
SLIDE 20

Why? - Safety

slide-21
SLIDE 21

Dangers of Flammable Gas

San Bruno, CA Merrimack Valley, Mass

slide-22
SLIDE 22

Why? - Efficiency

slide-23
SLIDE 23

Electricity IS Efficiency

0.8 1 3.5 Natural Gas Electric Resistance Electric Heat Pump

Coefficient of Performance of Various Heating Technologies

slide-24
SLIDE 24

100 BTU of Natural Gas in 100 BTU of Natural Gas in

3.5 COP Heat Pump 82% Efficiency Furnace 50% Efficient Power Plant

Heat Pumps are 2 times more efficient than gas, even if the grid is dirty.

slide-25
SLIDE 25

100 BTU of Natural Gas in 100 BTU of Natural Gas in 166 BTU of Space Heating

  • ut

80 BTU of Space Heating

  • ut

3.5 COP Heat Pump 82% Efficiency Furnace 50% Efficient Power Plant

Heat Pumps are 2 times more efficient than gas, even if the grid is dirty.

slide-26
SLIDE 26

Why? – No Better Option

slide-27
SLIDE 27

Does Gas Provide Resiliency?

Water Heating Space Heating Cooking Clothes Drying Gas furnaces require electric fans, but fireplaces still work. Gas water heaters require electronic ignition Electric motor runs tumbler Will work without electricity

slide-28
SLIDE 28

Biogas Can’t Get Us There

slide-29
SLIDE 29

Whe n?

slide-30
SLIDE 30

When? – To the Whiteboard!

slide-31
SLIDE 31

Wha t?

slide-32
SLIDE 32

32

Clothes Dryer

Capital: equivalent

Cooktop

Capital: $380 ↑

Gas Meter & Service Not Needed

Capital: $6,000 ↓

Water Heater

Capital: $510 ↓

Space Heater

Capital: $2000 ↓, assuming air- conditioning also installed

Indoor Gas Piping Not Needed

Capital: $2,450 ↓

All-Electric Home

Capital: $10,580 ↓

Summary

slide-33
SLIDE 33

Ho w?

slide-34
SLIDE 34

One in Four US Homes are All-Electric Norway has no Gas, and uses Carbon Free Electricity

slide-35
SLIDE 35

1752 1825 1850 1875 1900 1925 1950 1975 2000 2025 1897: Boston’s Electric Subway Opens 1899: Ferdinand Porsche’s Electric Car 1839: Discovery of Photovoltaic Effect 2008: Tesla Roadster 1996: GM EV1 Released 1892: First Electric Range 2003: Patent for Heat Pump Dryer 1954: First PV Panel 1970s: Westinghouse Induction Range 1933: Frigidaire Demonstrates Induction Stove 1930s: Natural Gas Piped to Homes 1940: First Ground Source HP 1938: Moore Releases Both Electric and Gas Dryers 1752: Ben Franklin’s Kite Experiment Solar Space Heating Water Heating Cooking Clothes Drying Electric Vehicles 2012: Hyperheat released 2009: Geospring released 1980s: First US Heat Pump Water Heaters 1929: Stiebel Eltron Invents Tankless Electric 1857: First Heat Pump Built 1824: Carnot Heat Engine Theorized 1889: Ruud Invents Electric Water Heater 1852: Kelvin Conceptualizes Heat Pump

slide-36
SLIDE 36

1752 1825 1850 1875 1900 1925 1950 1975 2000 2025 1897: Boston’s Electric Subway Opens 1899: Ferdinand Porsche’s Electric Car 1839: Discovery of Photovoltaic Effect 2008: Tesla Roadster 1996: GM EV1 Released 1892: First Electric Range 2003: Patent for Heat Pump Dryer 1954: First PV Panel 1970s: Westinghouse Induction Range 1933: Frigidaire Demonstrates Induction Stove 1930s: Natural Gas Piped to Homes 1940: First Ground Source HP 1938: Moore Releases Both Electric and Gas Dryers 1752: Ben Franklin’s Kite Experiment

ELECTRIC HEATING

2012: Hyperheat released 2009: Geospring released 1980s: First US Heat Pump Water Heaters 1929: Stiebel Eltron Invents Tankless Electric 1857: First Heat Pump Built 1824: Carnot Heat Engine Theorized 1889: Ruud Invents Electric Water Heater 1852: Kelvin Conceptualizes Heat Pump

slide-37
SLIDE 37

1752 1825 1850 1875 1900 1925 1950 1975 2000 2025 1897: Boston’s Electric Subway Opens 1899: Ferdinand Porsche’s Electric Car 1839: Discovery of Photovoltaic Effect 2008: Tesla Roadster 1996: GM EV1 Released 1892: First Electric Range 1929: Stiebel Eltron Invents Tankless Electric 2003: Patent for Heat Pump Dryer 1954: First PV Panel 1970s: Westinghouse Induction Range 1933: Frigidaire Demonstrates Induction Stove 1930s: Natural Gas Piped to Homes 1940: First Ground Source HP 1938: Moore Releases Both Electric and Gas Dryers 1752: Ben Franklin’s Kite Experiment

ELECTRIC HOT WATER

2012: Hyperheat released 2009: Geospring released 1980s: First US Heat Pump Water Heaters 1857: First Heat Pump Built 1824: Carnot Heat Engine Theorized 1889: Ruud Invents Electric Water Heater 1852: Kelvin Conceptualizes Heat Pump

slide-38
SLIDE 38

1752 1825 1850 1875 1900 1925 1950 1975 2000 2025 1897: Boston’s Electric Subway Opens 1899: Ferdinand Porsche’s Electric Car 1839: Discovery of Photovoltaic Effect 2008: Tesla Roadster 1996: GM EV1 Released 1892: First Electric Range 2003: Patent for Heat Pump Dryer 1954: First PV Panel 1970s: Westinghouse Induction Range 1933: Frigidaire Demonstrates Induction Stove 1930s: Natural Gas Piped to Homes 1940: First Ground Source HP 1938: Moore Releases Both Electric and Gas Dryers 1752: Ben Franklin’s Kite Experiment

ELECTRIC COOKING

2012: Hyperheat released 2009: Geospring released 1980s: First US Heat Pump Water Heaters 1929: Stiebel Eltron Invents Tankless Electric 1857: First Heat Pump Built 1824: Carnot Heat Engine Theorized 1889: Ruud Invents Electric Water Heater 1852: Kelvin Conceptualizes Heat Pump

slide-39
SLIDE 39

1752 1825 1850 1875 1900 1925 1950 1975 2000 2025 1897: Boston’s Electric Subway Opens 1899: Ferdinand Porsche’s Electric Car 1839: Discovery of Photovoltaic Effect 2008: Tesla Roadster 1996: GM EV1 Released 1892: First Electric Range 2003: Patent for Heat Pump Dryer 1954: First PV Panel 1970s: Westinghouse Induction Range 1933: Frigidaire Demonstrates Induction Stove 1930s: Natural Gas Piped to Homes 1940: First Ground Source HP 1938: Moore Releases Both Electric and Gas Dryers 1752: Ben Franklin’s Kite Experiment

ELECTRIC DRYERS

2012: Hyperheat released 2009: Geospring released 1980s: First US Heat Pump Water Heaters 1929: Stiebel Eltron Invents Tankless Electric 1857: First Heat Pump Built 1824: Carnot Heat Engine Theorized 1889: Ruud Invents Electric Water Heater 1852: Kelvin Conceptualizes Heat Pump

slide-40
SLIDE 40

1752 1825 1850 1875 1900 1925 1950 1975 2000 2025 1897: Boston’s Electric Subway Opens 1899: Ferdinand Porsche’s Electric Car 1839: Discovery of Photovoltaic Effect 2008: Tesla Roadster 1996: GM EV1 Released 1892: First Electric Range 2003: Patent for Heat Pump Dryer 1954: First PV Panel 1970s: Westinghouse Induction Range 1933: Frigidaire Demonstrates Induction Stove 1930s: Natural Gas Piped to Homes 1940: First Ground Source HP 1938: Moore Releases Both Electric and Gas Dryers 1752: Ben Franklin’s Kite Experiment

ELECTRIC VEHICLES

2012: Hyperheat released 2009: Geospring released 1980s: First US Heat Pump Water Heaters 1929: Stiebel Eltron Invents Tankless Electric 1857: First Heat Pump Built 1824: Carnot Heat Engine Theorized 1889: Ruud Invents Electric Water Heater 1852: Kelvin Conceptualizes Heat Pump

slide-41
SLIDE 41
slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44

Total Electric Award

Click for Video

slide-45
SLIDE 45

Gas Usage

People Food Clothes Drying Water

slide-46
SLIDE 46

Gas Usage

People Food Clothes Drying Water Induction

slide-47
SLIDE 47

Gas Usage

People Food Clothes Drying Water Induction Electric, or Clothesline

slide-48
SLIDE 48

Gas Usage

People Food Clothes Drying Water Induction Electric, or Clothesline Heat Pump or Radiant

slide-49
SLIDE 49

Co o king

slide-50
SLIDE 50
slide-51
SLIDE 51
slide-52
SLIDE 52
slide-53
SLIDE 53

HVAC

slide-54
SLIDE 54

The Reversing Valve

slide-55
SLIDE 55

The Reversing Valve

slide-56
SLIDE 56

Air Source Heat Pumps Ground Source Heat Pumps Packaged / Unitary Split System

slide-57
SLIDE 57
slide-58
SLIDE 58

Residential Heat Pumps

slide-59
SLIDE 59

Commercial Heat Pumps

slide-60
SLIDE 60

Commercial Heat Pumps

slide-61
SLIDE 61

Cold Climate Heat Pumps

slide-62
SLIDE 62

Cold Climate Heat Pumps

slide-63
SLIDE 63

Right System Depends on Existing Condition

slide-64
SLIDE 64
slide-65
SLIDE 65

Ho t Wa te r

slide-66
SLIDE 66
slide-67
SLIDE 67
slide-68
SLIDE 68

Heat Pump Hot Water Heaters

700 ft3 Volume (10’ x 10’ x 7’) Louvered Door

slide-69
SLIDE 69

Commercial Heat Pump Water

slide-70
SLIDE 70

Commercial Heat Pump Water

slide-71
SLIDE 71

Pool Heating

slide-72
SLIDE 72

T he Who le Syste ms Appro a c h

slide-73
SLIDE 73

Waste Heat Recovery at Stanford

slide-74
SLIDE 74

Waste Heat Recovery at Stanford

slide-75
SLIDE 75

Waste Heat Recovery at Stanford

slide-76
SLIDE 76

Waste Heat Recovery

slide-77
SLIDE 77

Do You Need That Heat? Envelope/Water Efficiency Waste Heat Recovery Solar Ground/Water/Air Source Heat Pump 1 2 3 4 5 Electric Resistance 6

slide-78
SLIDE 78

shuttle bike dr

  • p- off

pe de str ians

_____

All- E le c tric T he rma l Syste ms

Re duc e He a ting De ma nd E nve lo pe / Wa te r E ffic ie nc y Wa ste He a t Re c o ve ry So la r T he rma l Air So urc e He a t Pump 1 2 3 4 5 E le c tric Re sista nc e a s L a st Re so rt 6

slide-79
SLIDE 79

Thank you

Blake Herrschaft 619-955-0754 Blake.Herrschaft@dnvgl.com
