Overview

INTRODUCTION Trends in electric power distribution and it‘s challenges. PLUGGABLE SYSTEM & INTERFACE Principle and properties

• f a pluggable system –

the pluggable interface as a flexible solution PROTECTION A surge arrester as a pluggable enabler for encapsulated systems. CASE STUDIES Examples of different solutions with the pluggable system

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Trends in electric power distribution and it‘s challenges.

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Introduction

Challenges in power grids and distribution networks

Urbanization and integration of renewable energy sources lead to bidirectional energy flows New concepts and higher transmission capacity is required. ■ Higher transmission capabilities required due to ■ Restrictions of power supply lines ■ Growing energy need of industry & habitant areas ■ Energy flow due to additional renewable energy sources ■ Fluctuating energy (e.g. wind, solar) ■ Distance between generation and consumption (windmills / urban areas, dam / industry) ■ Direction of energy flow mostly not considered (rooftop solar, cogeneration unit) ■ Flexible and fast available solution ■ Service work on equipment like power lines, transformers, ■ Breakdowns, due to weather disasters, malfunction, etc.

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Challenges in power grids and distribution networks

Growing renewable energy sources ■ Non-hydro renewable and waste ■ Includes geothermal, solar, wind, tide/wave/ocean, biofuels, waste, heat ■ 1973: 0,6% ■ 2015: 7,1% ■ As the overall electric generation raised significant, the absolute values increased from 37 TWh to 1722 TWh.

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

1) excludes electricity generation from pumped storage. 2) includes geothermal, solar, wind, tide/wave/ocean, biofuels, waste, heat and other. source: www.iea.org – Key world energy statistics, 2017.

Challenges in power grids and distribution networks

Growing renewable energy sources ■ Non-hydro renewable and waste ■ Includes geothermal, solar, wind, tide/wave/ocean, biofuels, waste, heat ■ 1973: 0,6% ■ 2015: 7,1% ■ As the overall electric generation raised significant, the absolute values increased from 37 TWh to 1722 TWh. ■ Highly fluctuating ■ Often decentralized

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

1) NON-OECD Asia excludes China source: www.iea.org – Key world energy statistics, 2017.

World solar PV electricity production (TWh) World wind electricity production (TWh)

Principle and properties of a pluggable system – the pluggable interface as a flexible solution

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

PLUGGABLE SYSTEM & INTERFACE

How can a pluggable system help to face this challenges

Principle and properties of a pluggable system Main tasks of the socket and connector of a pluggable system are: ■ Handle the high electrical stress ■ Integrated elements ensure a proper electrical stress relief ■ Independent of cable diameter and cable insulation material (VPE, EPR) ■ Independent from insulation fluids /gasses of the equipment

• > dielectric stress of every component may never exceed material limits

■ Guarantee the electrical contact / current transfer ■ Electrical contact between socket and connector via contact lamella ■ Fits all common available cable diameter ■ Solutions for special cables, such as enameled conductors or high flexible wires ■ Manage mechanical forces

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

How can a pluggable system help to face this challenges

Advantages of a pluggable system – Socket side The PFISTERER socket as an interface for flexible solution ■ The socket acts as an interface for different electrical equipment ■ Usage as interface for gas insulated equipment, e.g. switchgear ■ Usage as interface for transformer or reactor Mineral oil as insulation fluid Natural or synthetic insulation fluids (Esther, Midel) ■ Fulfills all relevant standards and is 100% pretested ■ The socket closes the equipment ■ Ensures the equipment’s tightness (insulation gas, insulation liquid) ■ Enables fully internal treatment of the equipment in the factory ■ Equipment could be shipped “ready for use”: no oil- or gas-work onside ■ Offers a touch proof encapsulation, also offshore certificates are available

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Cable connector

IEC 60840, IEC 62067

Transformer

IEC 60137

GIS

IEC 62271-203

How can a pluggable system help to face this challenges

Advantages of a pluggable system – Plug side The pluggable part as the completion of a flexible solution offers different possibilities to connect: ■ An underground cable ■ Most used solution, completely touch-proof ■ Available for all common cable diameters of all manufacturer ■ Fast installation possible. Cable could be prepared anytime, all parts are pretested ■ An overhead line ■ Pluggable termination fits to the same interface ■ Equipment and termination can be shipped separate – simpler transportation ■ Testing equipment ■ High current testing or earthing plugs ■ Supports further expandability via dummy plug

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

A surge arrester as a pluggable enabler for encapsulated systems.

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Protection

Protection – how to protect a fully enclosed system

A pluggable system is an enclosed system The advantage of an enclosed system – all live parts are covered – becomes an challenge for standard surge protection: ■ No direct connection to HV-side nor MV-side possible ■ Available space is limited ■ FAT testing of equipment should be still possible ■ Protection equipment must be temporarily removable to allow voltage testing levels ■ Flexibility should not be impeded

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Protection – how to protect a fully enclosed system

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Duration Magnitude

Types of overvoltages Overvoltages could be classified in mainly three types: ■ Lightning overvoltages Cause: Atmospheric discharge Duration: microseconds (1,2/50 µs) Magnitude: > 5 Um ■ Switching overvoltages Cause: switching in power systems Duration: milliseconds Magnitude: 2 to 3,6 Um ■ Temporary overvoltages (TOV) Cause: Load flow in power Systems Duration: seconds Magnitude: <1,3 Um

Surge Arrester can be limited can be limited must (!) not be limited surge arrester and equipment must be rated to withstand TOV!

Switching

• vervoltage

(Milliseconds) Temporary

• vervoltage

(Seconds) Highest voltage for Equipment = 1 Um (Continuously) Lightning

• vervoltage

(Microseconds)

Function areas of a surge arrester

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Duration Magnitude of Voltage in p.u. of Um 5 4 3 2 1

Protection – how to protect a fully enclosed system

• Withstand voltage of equipment
• restricted area
• Voltage on equipment

without surge arrester

• Voltage on equipment

limited by surge arrester

Gas (SF6) insulated Air insulated Pluggable Surge arrester Space requirements - distance to other equipment + Low

• High

+ Low Distance to equipment (protective zone) + Near to equipment

• Far from equipment

+ Near to equipment Climatic influence + No influence

• Crucial influence

+ No influence FAT testing

• Complex

+ Easy possible + Easy possible (Dummy plug) Assembly time

• Complex assembly

+ Quick assembly + Quick assembly Monitoring, Maintenance

• Gas monitoring needed

+ - Cleaning if heavy polluted + No maintenance necessary Replacement in case of overload

• Complex (re)assembly

+ Easy replacement + Easy replacement

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Comparison of different construction designs

Protection – how to protect a fully enclosed system

The pluggable System as a flexible solution – some examples of different solutions with the pluggable system

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Case Studies

Examples of a pluggable system for flexible solutions

Flexible solutions with pluggable equipment ■ Emergency transformer, “plug and operate”: ■ Pluggable socket

• > allows a compact design

■ Pluggable HV and MV side

• > Bushings can be removed

■ Easy to transport via truck or train ■ quick to install ■ can be used for many applications

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Examples of a pluggable system for flexible solutions

Flexible solutions with pluggable equipment ■ Emergency transformer, “plug and operate”: ■ Pluggable socket

• > allows a compact design

■ Pluggable HV and MV side

• > Bushings can be removed

■ Easy to transport via truck or train ■ quick to install ■ can be used for many applications

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Examples of a pluggable system for flexible solutions

Flexible solutions with pluggable equipment ■ Mobile partly replacement of overhead lines ■ Fast and flexible solution ■ Customizable cable length ■ Replacement during construction works near/under OHL ■ For service works of OHL /poles ■ Easy to transport

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Examples of a pluggable system for flexible solutions

Flexible solutions with pluggable equipment ■ Mobile partly replacement of overhead lines ■ Fast and flexible solution ■ Customizable cable length ■ Replacement during construction works near/under OHL ■ For service works of OHL /poles ■ Easy to transport ■ Setup in Austria, 220/280 kV upgrade, 150-250m cable length

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Examples of a pluggable system for flexible solutions

Flexible solutions with pluggable equipment ■ Pluggable connection of offshore platforms ■ Connecting platform with sea cables and/or inter array cabling ■ No oil or gas involved ■ Connection between different cable diameter ■ System is fully offshore proved

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017

Examples of a pluggable system for flexible solutions

Flexible solutions with pluggable equipment ■ Pluggable connection of offshore platforms ■ Connecting platform with sea cables and/or inter array cabling ■ No oil or gas involved ■ Connection between different cable diameter ■ System is fully offshore proved ■ Complete cabling of the platform can be done onshore ■ Testing can be done onshore ■ Only one plug-process offshore

Cable Accessories as Enablers for the Future Grid | Dr. Michael Zerrer | INMR 2017 Barcelona | Nov 5-8, 2017
