CANYON CREST CABLE REPLACEMENT Canyon Creek Apartments Board of Public Utilities September 16, 2011 HMPE/CIC cable 8.6% 62.5% 37.5% 91.4% HMPE Cable All Other Cable Cable Replacement Program Examples of Failed Underground Cable


slide-1
SLIDE 1

CANYON CREST CABLE REPLACEMENT Canyon Creek Apartments Board of Public Utilities

September 16, 2011

slide-2
SLIDE 2

HMPE Cable All Other Cable 8.6% 91.4% 62.5% 37.5%

HMPE/CIC cable

slide-3
SLIDE 3

Cable Replacement Program Examples of Failed Underground Cable

slide-4
SLIDE 4

Canyon Crest Area Comprehensive Cable Replacement Program (est. Oct. 2010)

Area 1 Subarea A – Via Conception, Via Zapata East (COMPLETE) Subarea B – Canyon Creek Apts (Board Item 10, 9/16/2011) Subarea C – Apts. East of Towne Center (2012) Subarea D – Via Pintada, Via Zapata West (2012) Subarea E – North of Country Club Dr. (2012-13) Subarea F - South of Country Club (2013) Areas 2-5 – Future schedules to be determined

slide-5
SLIDE 5

June 14, 2010 Outage Report Cable Failure – Canyon Creek Apts

600 Central Canyon Creek Apts

slide-6
SLIDE 6

600 Central Canyon Creek Apts

October 6, 2010 Outage Report Cable Failure – Canyon Creek Apts

slide-7
SLIDE 7

Canyon Creek Cable Replacement Scope of Project

slide-8
SLIDE 8

Typical Cable Replacement Canyon Crest SFR Neighborhood

slide-9
SLIDE 9

Canyon Creek Cable Replacement Existing Facilities & Obstructions

slide-10
SLIDE 10

RECOMMENDATION:

That the Board of Public Utilities approve the estimated capital expenditure of $1,052,000 for the Canyon Crest Cable Replacement Project which will replace transformers and failing underground infrastructure in the Canyon Creek apartments area.
