SLIDE 1

caagt

Toroidal azulenoids

Nico Van Cleemput

Nicolas.VanCleemput@UGent.be

Research group CAAGT, Department of Applied Mathematics and Computer Science, Ghent University (Joint work with Gunnar Brinkmann, Olaf Delgado-Friedrichs and Edward Kirby)

Toroidal azulenoids – p.1/29

SLIDE 2

caagt

Outline

1. Motivation
2. Translation to tiles
3. Tools
4. Methods
5. Results

Toroidal azulenoids – p.2/29

SLIDE 3

caagt

Azulenoids

Azulene

Toroidal azulenoids – p.3/29

SLIDE 4

caagt

Azulenoids

An azulenoid is a carbon network (cubic) for which there exists a partition of the vertices into azulenes.

Toroidal azulenoids – p.3/29

SLIDE 5

caagt

Question

How many variations of such networks are theoretically possible if there can only be one orbit of azulenes under the symmetry group? Edward Kirby

Toroidal azulenoids – p.4/29

SLIDE 6

caagt

Question

How many variations of such networks are theoretically possible if there can only be one orbit of azulenes under the symmetry group? Edward Kirby Toroidal, but also planar and cylindrical

Toroidal azulenoids – p.4/29

SLIDE 7

caagt

Torus

Toroidal azulenoids – p.5/29

SLIDE 8

caagt

Torus

Toroidal azulenoids – p.5/29

SLIDE 9

caagt

Tiling

Tiling T = set of tiles t1, t2, . . . with ti ⊂ E2, ti homeomorph to B(0, 1) that satisfy the following conditions: 1.

t∈T

t = E2

2. ∀ti, tj(i = j) ∈ T : t◦

i ∩ t◦ j = ∅ ∧ ti ∩ tj ∈

{∅, {points}, {lines}}.

3. ∀x ∈ E2 : x has a neighbourhood that only intersects a

finite number of tiles.

Toroidal azulenoids – p.6/29

SLIDE 10

caagt

Tiling

Tiling T = set of tiles t1, t2, . . . with ti ⊂ E2, ti homeomorph to B(0, 1) that satisfy the following conditions: 1.

t∈T

t = E2

2. ∀ti, tj(i = j) ∈ T : t◦

i ∩ t◦ j = ∅ ∧ ti ∩ tj ∈

{∅, {points}, {lines}}.

3. ∀x ∈ E2 : x has a neighbourhood that only intersects a

finite number of tiles. Periodic tiling ⇐ ⇒ symmetry group contains two independent translations

Toroidal azulenoids – p.6/29

SLIDE 11

caagt

Example tiling

Toroidal azulenoids – p.7/29

SLIDE 12

caagt

Example tiling

Toroidal azulenoids – p.7/29

SLIDE 13

caagt

Barycentric subdivision

For each face: one point For each edge: one point For each vertex: one point ⇒ subdivision consists of triangles

Toroidal azulenoids – p.8/29

SLIDE 14

caagt

Chamber system

Define Σ = σ0, σ1, σ2|σ2

i = 1

σ0 : change the green point (vertex). σ1 : change the red point (edge). σ2 : change the black point (face).

Toroidal azulenoids – p.9/29

SLIDE 15

caagt

Chamber system

Define Σ = σ0, σ1, σ2|σ2

i = 1

σ0 : change the green point (vertex). σ1 : change the red point (edge). σ2 : change the black point (face). Chamber system C of T = barycentric subdivision together with Σ

Toroidal azulenoids – p.9/29

SLIDE 16

caagt

Delaney/Dress graph

The Delaney/Dress graph D of a periodic tiling is the set of

rbits of the chambers of the chamber system of the tiling

under the symmetry group.

Toroidal azulenoids – p.10/29

SLIDE 17

caagt

Example Delaney/Dress graph

Toroidal azulenoids – p.11/29

SLIDE 18

caagt

Example Delaney/Dress graph

Toroidal azulenoids – p.11/29

SLIDE 19

caagt

Example Delaney/Dress graph

Toroidal azulenoids – p.11/29

SLIDE 20

caagt

Example Delaney/Dress graph

Toroidal azulenoids – p.12/29

SLIDE 21

caagt

Example Delaney/Dress graph

Toroidal azulenoids – p.12/29

SLIDE 22

caagt

Example Delaney/Dress graph

⇒ Delaney/Dress graph is not sufficient to distinguish be- tween tilings!

Toroidal azulenoids – p.12/29

SLIDE 23

caagt

Delaney/Dress symbol

Define functions rij : C → N; c → rij(c) with rij(c) the smallest number for which c(σiσj)rij(c) = c.

Toroidal azulenoids – p.13/29

SLIDE 24

caagt

Delaney/Dress symbol

Define functions rij : C → N; c → rij(c) with rij(c) the smallest number for which c(σiσj)rij(c) = c. r02 is a constant function with value 2. r01(c) is the size of the face of T that belongs to c. r12(c) is the number of faces that meet in the vertex that belongs to c.

Toroidal azulenoids – p.13/29

SLIDE 25

caagt

Delaney/Dress symbol

Define functions mij : D → N; d → mij(c) in such a manner that the following diagram is commutative: C rij

✲ N

D mij

✲ ✲

Toroidal azulenoids – p.14/29

SLIDE 26

caagt

Delaney/Dress symbol

Define functions mij : D → N; d → mij(c) in such a manner that the following diagram is commutative: C rij

✲ N

D mij

✲ ✲

Delaney/Dress symbol of the tiling is (D; m01, m12)

Toroidal azulenoids – p.14/29

SLIDE 27

caagt

Example Delaney/Dress symbol

Toroidal azulenoids – p.15/29

SLIDE 28

caagt

Example Delaney/Dress symbol

m01 = 4 m12 = 4

Toroidal azulenoids – p.15/29

SLIDE 29

caagt

Example Delaney/Dress symbol

Toroidal azulenoids – p.16/29

SLIDE 30

caagt

Example Delaney/Dress symbol

m01 = 6 m12 = 3

Toroidal azulenoids – p.16/29

SLIDE 31

caagt

Example Delaney/Dress symbol

Toroidal azulenoids – p.17/29

SLIDE 32

caagt

Example Delaney/Dress symbol

Toroidal azulenoids – p.17/29

SLIDE 33

caagt

Example Delaney/Dress symbol

Toroidal azulenoids – p.17/29

SLIDE 34

caagt

Example Delaney/Dress symbol

Toroidal azulenoids – p.17/29

SLIDE 35

caagt

Example Delaney/Dress symbol

m01 m12 A 4 B C

Toroidal azulenoids – p.17/29

SLIDE 36

caagt

Example Delaney/Dress symbol

m01 m12 A 4 B C

Toroidal azulenoids – p.17/29

SLIDE 37

caagt

Example Delaney/Dress symbol

m01 m12 A 4 B 8 C 8

Toroidal azulenoids – p.17/29

SLIDE 38

caagt

Example Delaney/Dress symbol

m01 m12 A 4 B 8 C 8

Toroidal azulenoids – p.17/29

SLIDE 39

caagt

Example Delaney/Dress symbol

m01 m12 A 4 3 B 8 3 C 8 3

Toroidal azulenoids – p.17/29

SLIDE 40

caagt

Delaney/Dress symbol

(D; m01, m12) is the Delaney/Dress symbol of a periodic tiling iff

1. D is finite
2. Σ works transitively on D
3. m01 is constant on σ0, σ1 orbits and

∀d ∈ D : d(σ0σ1)m01(d) = d

4. m12 is constant on σ1, σ2 orbits and

∀d ∈ D : d(σ1σ2)m12(d) = d

5. ∀d ∈ D : d(σ0σ2)2 = d

Toroidal azulenoids – p.18/29

SLIDE 41

caagt

Delaney/Dress symbol

K(D) =

d∈D

( 1 m01(d) + 1 m12(d) − 1 2)

1. K(D) < 0
2. K(D) = 0
3. K(D) > 0

Toroidal azulenoids – p.19/29

SLIDE 42

caagt

Delaney/Dress symbol

K(D) =

d∈D

( 1 m01(d) + 1 m12(d) − 1 2)

1. K(D) < 0 → hyperbolic plane
2. K(D) = 0
3. K(D) > 0

Toroidal azulenoids – p.19/29

SLIDE 43

caagt

Delaney/Dress symbol

K(D) =

d∈D

( 1 m01(d) + 1 m12(d) − 1 2)

1. K(D) < 0 → hyperbolic plane
2. K(D) = 0 → euclidean plane
3. K(D) > 0

Toroidal azulenoids – p.19/29

SLIDE 44

caagt

Delaney/Dress symbol

K(D) =

d∈D

( 1 m01(d) + 1 m12(d) − 1 2)

1. K(D) < 0 → hyperbolic plane
2. K(D) = 0 → euclidean plane
3. K(D) > 0 → sphere iff

4 K(D) ∈ N

Toroidal azulenoids – p.19/29

SLIDE 45

caagt

Representation

σ0 σ1 σ2 m01 m12

1 σ0(1) σ1(1) σ2(1) m01(1) m12(1)

2 σ0(2) σ1(2) σ2(2) m01(2) m12(2)

3 σ0(3) σ1(3) σ2(3) m01(3) m12(3)

. . . . . . . . . . . . . . . . . .

N σ0(N) σ1(N) σ2(N) m01(N) m12(N)

Toroidal azulenoids – p.20/29

SLIDE 46

caagt

Minimal symbol

Toroidal azulenoids – p.21/29

SLIDE 47

caagt

Minimal symbol

Toroidal azulenoids – p.21/29

SLIDE 48

caagt

Minimal symbol

add symmetry

Toroidal azulenoids – p.21/29

SLIDE 49

caagt

Minimal symbol

add symmetry ⇒ map orbits onto each other

Toroidal azulenoids – p.21/29

SLIDE 50

caagt

Minimal symbol

add symmetry ⇒ map orbits onto each other Choose two orbits c and d

Toroidal azulenoids – p.21/29

SLIDE 51

caagt

Minimal symbol

add symmetry ⇒ map orbits onto each other Choose two orbits c and d Is mij(c) = mij(d)?

Toroidal azulenoids – p.21/29

SLIDE 52

caagt

Minimal symbol

add symmetry ⇒ map orbits onto each other Choose two orbits c and d Is mij(c) = mij(d)? index priority depth-first traversal from c and d

σi(c) maps onto σi(d)

Toroidal azulenoids – p.21/29

SLIDE 53

caagt

Minimal symbol

add symmetry ⇒ map orbits onto each other Choose two orbits c and d Is mij(c) = mij(d)? index priority depth-first traversal from c and d

σi(c) maps onto σi(d) mij(·) = mij(·)?

Toroidal azulenoids – p.21/29

SLIDE 54

caagt

Example minimal symbol

Toroidal azulenoids – p.22/29

SLIDE 55

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 A B B A C 8 3 B C C D B 4 3 C D D C E 4 3 D E E F D 8 3 E F F E A 8 3 F

Toroidal azulenoids – p.22/29

SLIDE 56

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 A B B A C 8 3 B C C D B 4 3 a D D C E 4 3 a E E F D 8 3 E F F E A 8 3 F

Toroidal azulenoids – p.22/29

SLIDE 57

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 A B B A C 8 3 B C C D B 4 3 a D D C E 4 3 a E E F D 8 3 E F F E A 8 3 F

Toroidal azulenoids – p.22/29

SLIDE 58

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 A B B A C 8 3 b C C D B 4 3 a D D C E 4 3 a E E F D 8 3 b F F E A 8 3 F

Toroidal azulenoids – p.22/29

SLIDE 59

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 A B B A C 8 3 b C C D B 4 3 a D D C E 4 3 a E E F D 8 3 b F F E A 8 3 F

Toroidal azulenoids – p.22/29

SLIDE 60

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 c B B A C 8 3 b C C D B 4 3 a D D C E 4 3 a E E F D 8 3 b F F E A 8 3 c

Toroidal azulenoids – p.22/29

SLIDE 61

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 c B B A C 8 3 b C C D B 4 3 a D D C E 4 3 a E E F D 8 3 b F F E A 8 3 c

Toroidal azulenoids – p.22/29

SLIDE 62

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 A A B F 8 3 c B B A C 8 3 b C C D B 4 3 a D D C E 4 3 a E E F D 8 3 b F F E A 8 3 c

Toroidal azulenoids – p.22/29

SLIDE 63

caagt

Example minimal symbol

σ0 σ1 σ2 m01 m12 a a a b 4 3 b b c a 8 3 c c a b 8 3

Toroidal azulenoids – p.22/29

SLIDE 64

caagt

Translation

Restrictions azulenoid: 1 orbit of azulenes every atom part of exactly one azulene in that orbit

Toroidal azulenoids – p.23/29

SLIDE 65

caagt

Translation

Restrictions azulenoid: 1 orbit of azulenes every atom part of exactly one azulene in that orbit Restrictions Delaney/Dress symbol: ∃σ0σ1 orbit O :        r01(O) = 8 ∀σ1σ2 orbit V : O ∩ V = ∅ ∀d ∈ O : σ2(d) / ∈ O

Toroidal azulenoids – p.23/29

SLIDE 66

caagt

Translation

Restrictions azulenoid: 1 orbit of azulenes every atom part of exactly one azulene in that orbit Restrictions Delaney/Dress symbol: ∃σ0σ1 orbit O :        r01(O) = 8 ∀σ1σ2 orbit V : O ∩ V = ∅ ∀d ∈ O : σ2(d) / ∈ O ∀σ1σ2 orbit V : r12(V ) = 3

Toroidal azulenoids – p.23/29

SLIDE 67

caagt

Translation

Restrictions azulenoid: 1 orbit of azulenes every atom part of exactly one azulene in that orbit Restrictions Delaney/Dress symbol: ∃σ0σ1 orbit O :        r01(O) = 8 ∀σ1σ2 orbit V : O ∩ V = ∅ ∀d ∈ O : σ2(d) / ∈ O ∀σ1σ2 orbit V : r12(V ) = 3

d∈D

( 1 m01(d) + 1 m12(d) − 1 2) = 0

Toroidal azulenoids – p.23/29

SLIDE 68

caagt

Method

Octagon and the different vertex orbits

Toroidal azulenoids – p.24/29

SLIDE 69

caagt

Method

Octagon and the different vertex orbits

Toroidal azulenoids – p.24/29

SLIDE 70

caagt

Method

Octagon and the different vertex orbits Calculate and assign remaining m01 values

Toroidal azulenoids – p.24/29

SLIDE 71

caagt

Method

Octagon and the different vertex orbits Calculate and assign remaining m01 values

Toroidal azulenoids – p.24/29

SLIDE 72

caagt

Method

Octagon and the different vertex orbits Calculate and assign remaining m01 values Assign remaining σ0’s

Toroidal azulenoids – p.24/29

SLIDE 73

caagt

Method

Octagon and the different vertex orbits Calculate and assign remaining m01 values Assign remaining σ0’s Replace octagon with azulene

Toroidal azulenoids – p.24/29

SLIDE 74

caagt

Method

Octagon and the different vertex orbits Calculate and assign remaining m01 values Assign remaining σ0’s Replace octagon with azulene

Toroidal azulenoids – p.24/29

SLIDE 75

caagt

Method

Octagon and the different vertex orbits Calculate and assign remaining m01 values Assign remaining σ0’s Replace octagon with azulene

Toroidal azulenoids – p.24/29

SLIDE 76

caagt

Method

Octagon and the different vertex orbits Calculate and assign remaining m01 values Assign remaining σ0’s Replace octagon with azulene

Toroidal azulenoids – p.24/29

SLIDE 77

caagt

Visualisation

Toroidal azulenoids – p.25/29

SLIDE 78

caagt

Visualisation

Toroidal azulenoids – p.25/29

SLIDE 79

caagt

Visualisation

Toroidal azulenoids – p.25/29

SLIDE 80

caagt

Visualisation

Toroidal azulenoids – p.25/29

SLIDE 81

caagt

Results

m01 values # strings # symbols 1 4 4 4 4 4 6 24 24 21 6 2 4 4 4 4 4 8 12 24 42 42 3 4 4 4 4 4 8 16 16 21 48 4 4 4 4 4 4 10 10 20 21 5 4 4 4 4 4 12 12 12 7 44 6 4 4 4 4 6 6 8 24 105 7 4 4 4 4 6 6 12 12 54 2 8 4 4 4 4 6 8 8 12 105 12 9 4 4 4 4 8 8 8 8 10 160 10 4 4 4 6 6 6 6 12 35 6 11 4 4 4 6 6 6 8 8 70 38 12 4 4 6 6 6 6 6 6 4 25

Toroidal azulenoids – p.26/29

SLIDE 82

caagt

Results

383 symbols of tilings containing octagons

Toroidal azulenoids – p.26/29

SLIDE 83

caagt

Results

383 symbols of tilings containing octagons ⇓ 1274 minimal unmarked azulenoids 1324 minimal marked azulenoids

Toroidal azulenoids – p.26/29

SLIDE 84

caagt

Marked vs. Unmarked

structures that have an azulenoid set vs. structures with their azulenoid set

Toroidal azulenoids – p.27/29

SLIDE 85

caagt

Marked vs. Unmarked

Toroidal azulenoids – p.27/29

SLIDE 86

caagt

Marked vs. Unmarked

Toroidal azulenoids – p.27/29

SLIDE 87

caagt

Translation only

ne orbit of azulenes under the subgroup of translations
r

all the azulenes have the same orientation

Toroidal azulenoids – p.28/29

SLIDE 88

caagt

Translation only

Toroidal azulenoids – p.28/29
