C ONSISTENT M ANAGEMENT OF C ONTEXT I NFORMATION IN U BIQUITOUS S YSTEMS Gabriel Guerrero-Contreras gjguerrero@ugr.es Jos Luis Garrido jgarrido@ugr.es Carlos Rodrguez-Domnguez carlosrodriguez@ugr.es Sara Balderas-Daz

slide-1
SLIDE 1

CONSISTENT MANAGEMENT OF CONTEXT INFORMATION IN UBIQUITOUS SYSTEMS

Gabriel Guerrero-Contreras José Luis Garrido Carlos Rodríguez-Domínguez Sara Balderas-Díaz 7th International Conference on Internet and Distributed Computing Systems 22nd September 2014 gjguerrero@ugr.es jgarrido@ugr.es carlosrodriguez@ugr.es sarabd@correo.ugr.es

University of Granada Software Engineering Department

slide-2
SLIDE 2

OUTLINE

  • 1. Introduction
  • 2. Consistent Management of Context Information

> The Service Entity and Replica Manager > The Synchronization and Monitoring Services > The Context Manager

  • 3. Case Study
  • 4. Conclusions and Future Work
  • G. Guerrero-Contreras et al.

2

slide-3
SLIDE 3
  • 1. INTRODUCTION (1)
  • Context-aware systems use the context information to

make decisions about their future behavior

  • Ubiquitous environments make use of context-aware

techniques to provide a natural and unconscious interaction with the computational system to the user

  • Features of ubiquitous environment can affect to the

consistency of distributed context information

> Uneven conditioning, limited resources, dynamic network topology, etc.

  • G. Guerrero-Contreras et al.

3

slide-4
SLIDE 4
  • 1. INTRODUCTION (& 2)
  • G. Guerrero-Contreras et al.

4

Support the synchronization and consistent management of distributed context information

Objective

  • SOA, EDA and middleware technologies are not enough to

support dynamic environments

  • Existing approaches to manage context information follow

a centralized scheme

  • In context-aware systems it is decisive to maintain the

correctness and the quality of context information

Motivation

slide-5
SLIDE 5
  • 2. CONSISTENT MANAGEMENT OF

CONTEXT INFORMATION

  • A model is proposed as a common basis for the

management of shared resources

> It is based on the SOA model > It provides two main services: Monitoring and Synchronization

  • A Context Manager Service has been created from

the specialization of the Synchronization service

  • G. Guerrero-Contreras et al.

5

slide-6
SLIDE 6

2.1 THE SERVICE ENTITY AND REPLICA MANAGER (1)

  • G. Guerrero-Contreras et al.

6

slide-7
SLIDE 7

2.1 THE SERVICE ENTITY AND REPLICA MANAGER (1)

  • G. Guerrero-Contreras et al.

7

  • The applications and services are considered Software Entities

deployed in a device

  • A service may be being accessed by one or more applications,

and by one or more services (i.e., service composition)

slide-8
SLIDE 8

2.1 THE SERVICE ENTITY AND REPLICA MANAGER (1)

  • G. Guerrero-Contreras et al.

8

  • A service can manage a kind of shared resources
  • Documents, images, database, etc.
slide-9
SLIDE 9

2.1 THE SERVICE ENTITY AND REPLICA MANAGER (1)

  • G. Guerrero-Contreras et al.

9

  • Each service is made up of a Replica Manager
  • This avoid central controls and strengthen the system against

node disconnections and network partitions

slide-10
SLIDE 10

2.1 THE SERVICE ENTITY AND REPLICA MANAGER (& 2)

  • The Replica Manager is responsible of encapsulating

the adaptation logic regarding the deployment of the services

> Providing a distributed solution to the dynamic deployment > Improving the availability

  • f

shared resources (documents, images, etc.)

  • The Replica Manager will need the information

provided by the Context Manager Service

  • G. Guerrero-Contreras et al.

10

slide-11
SLIDE 11

2.2 THE SYNCHRONIZATION AND MONITORING SERVICES

(1)

  • G. Guerrero-Contreras et al.

11

slide-12
SLIDE 12

2.2 THE SYNCHRONIZATION AND MONITORING SERVICES

(1)

  • G. Guerrero-Contreras et al.

12

  • The Synchronization Service is an abstract service which must

be specialized according to each particular resource to be synchronized

  • It is based on the Monitoring Service
slide-13
SLIDE 13

2.2 THE SYNCHRONIZATION AND MONITORING SERVICES

(1)

  • G. Guerrero-Contreras et al.

13

  • The Monitoring Service is a basic service which stores all kind
  • f information about changes on the different replicas of the

shared resources

slide-14
SLIDE 14

2.2 THE SYNCHRONIZATION AND MONITORING SERVICES

(& 2)

  • Thus

a common basis for the consistent management of the shared resources is provided

  • G. Guerrero-Contreras et al.

14

Synchronization service

The common part related to manage the resource is identified and assigned to the Synchronization service

Specialization of the service

The particular requirements

  • f a resource are implemented

in the specialization of the service

slide-15
SLIDE 15

2.3 THE CONTEXT MANAGER (1)

  • G. Guerrero-Contreras et al.

15

slide-16
SLIDE 16

2.3 THE CONTEXT MANAGER (1)

  • G. Guerrero-Contreras et al.

16

  • The context information can be distributed

and replicated

slide-17
SLIDE 17

2.3 THE CONTEXT MANAGER (1)

  • G. Guerrero-Contreras et al.

17

  • Through the specialization of the Synchronization service, a

Context Manager which can address these context inconsistencies at the service level is provided

slide-18
SLIDE 18

2.3 THE CONTEXT MANAGER (& 2)

  • The Context Manager will implement the ‘synchronize’ abstract method,

where it will should add the specific synchronization algorithms for managing the context data resource.

  • G. Guerrero-Contreras et al.

18

slide-19
SLIDE 19
  • 3. CASE STUDY
  • In a hospital there is an Emergency service which

form part of an ubiquitous environment

  • The Emergency service will look for the most

appropriate doctor to attend the emergency

  • Different information need to be managed

> Location of the medical staff, availability of the medical resources, profile of the patients, etc.

  • G. Guerrero-Contreras et al.

19

slide-20
SLIDE 20
  • 3. CASE STUDY
  • G. Guerrero-Contreras et al.

20

The doctor is in the hospital Context Manager Replica 1 Context Information Emergency Service Monitoring Service

slide-21
SLIDE 21
  • 3. CASE STUDY
  • G. Guerrero-Contreras et al.

21

Context Manager Replica 1 Context Information Emergency Service The doctor is in the hospital Context Manager Replica 2 Context Information The doctor is in the ambulance Monitoring Service

slide-22
SLIDE 22
  • 3. CASE STUDY
  • G. Guerrero-Contreras et al.

22

Context Manager Replica 1 Context Information Emergency Service The doctor is in the hospital Context Manager Replica 2 Context Information The doctor is in the ambulance Monitoring Service

slide-23
SLIDE 23
  • 3. CASE STUDY
  • G. Guerrero-Contreras et al.

23

Context Manager Replica 1 Context Information Emergency Service The doctor is in the hospital Context Manager Replica 2 Context Information The doctor is in the ambulance

‘synchronize’

Monitoring Service

slide-24
SLIDE 24
  • 3. CASE STUDY

/** * @param list: a list of events obtained from the `disjointSet' method */ void synchronize(List<Events> list){ foreach(Event evt in list){ evtName = evt.getMemberValue("object").GetString(); evtValue = evt.getMemberValue("value").GetString(); evtTime = evt.getMemberValue("timestamp").GetInt64(); [...] if(this.getContextObject(evtName).getTimestamp() < evtTime){ this.setContextValue(evtName, evtValue); } [...] } }

  • G. Guerrero-Contreras et al.

24

slide-25
SLIDE 25
  • 4. CONCLUSIONS
  • The devised model provides to the software engineers

the basis for a correct and consistent management of replicated/distributed resources

  • From this basis a Context Manager has been provided
  • The model is based on distributed scheme
  • It also contemplates the adaptation logic of the

replication of services at run-time

  • G. Guerrero-Contreras et al.

25

slide-26
SLIDE 26
  • 4. FUTURE WORK
  • Currently, a simulation on ns3 network simulator is

under development. In order to perform a study the behavior of the Replica Manager component

  • We plan to study the composition between the

herein presented services and other high level self- adaptive services, such as a location service

  • G. Guerrero-Contreras et al.

26

slide-27
SLIDE 27

THANKS FOR YOUR ATTENTION! QUESTIONS?

7th International Conference on Internet and Distributed Computing Systems 22nd September 2014

University of Granada Software Engineering Department
