Galteh Ltd. Is one of European distributor of CTI products especially antennas. CTi is an established innovative brand powered by AAMP Global. We provide all our customers a high-quality range of antenna solutions and accessories.

www.galteh.eu

Galteh is one of EU distributor of

CTI antenna . CTi is a world class designer and manufacturer of communication and tracking antennas . www.galteh.eu

• Available as Body Mount,

Glass Mount, and Magnetic Mount or as an internal Embedded Solutions, this range of antennas cover the 1575.42 MHz frequency. Typical applications include, Sat Nav solutions, Telematics, Machine to Machine (M2M), Security and Asset Management.

• GPS antennas

Our product range includes 4G/LTE, GPRS/GSM, GPS, Zigbee and WiFi antenna’s and cable products.

www.galteh.eu

AEB680

GPS ACTIVE ANTENNA WITH A FILTERED CERAMIC PATCH Part Number: AEB680 Gain: 26dB Power Consumption: 125mW (max) Supply Voltage: 3-5v Supply Current: 15mA - 25mA VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Gross Dimensions: 41mm x 41mm x 26mm Cable Type:RG174 Rohs Compliant: YES

GPS_AMP UNIVERSAL ( GLASS & MAG MOUNT) GPS ANTENNA

UNIVERSAL MOUNT GPS ANTENNA Part Number: GPS_AMP Gain: 5dBi VSWR: Less than 1.5: 1 in all bands Impedance: 50 Ohms

www.galteh.eu

GPS060

GPS ACTIVE ANTENNA WITH A FILTERED CERAMIC PATCH Part Number: GPS060 Gain: 26dB Power Consumption: 125mW (max) Supply Voltage: 3.0 - 5.0v Supply Current: 15mA - 25mA VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Gross Dimensions: 41mm x 41mm x 14mm Cable Type: RG174 Rohs Compliant: YES

GPLS_TRK

GPS/GLONASS ANTENNA Part Number: GPLS_TRK Gain: 27dB Power Consumption: 125mW (max) Supply Voltage: 3-5v Supply Current: 15mA - 25mA VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Cable Type: RG174 Rohs Compliant: YES

www.galteh.eu

GSM/GPRS Antennas

This range of antennas is available as Body Mount, Glass Mount, and Magnetic Mount or as an internal Embedded Solution. Typical applications include, Mobile solutions, Telematics,

Machine to Machine (M2M),

Security and Electronic Point

• f Sale (EPOS). Frequency

ranges: 850, 900, 1800, 1900 MHz and 2.1 MHz, 3G standard.

www.galteh.eu

GSM/GPRS antennas

AEB285 GSM ANTENNA

GSM ANTENNA Part Number: AEB285 Gain: 2.0dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms IP Rating: IP67 Cable Type: RG174 Rohs Compliant: YES

GSMS/SMA

QUAD BAND DIPOLE ANTENNA SWIVEL Part Number: GSMS/SMA Gain: 2.0dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Gross Dimensions: 9.5mm diameter x 100mm long Rohs Compliant: YES

www.galteh.eu

www.galteh.eu

GSM/GPRS antennas

AG360

WATERPROOF STRIP ANTENNA Part Number: AG360 Gain: 2dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms IP Rating: IP67 Gross Dimensions: 131mm x 12mm x 4mm Cable Type: RG174 Rohs Compliant: YES

AM102/2

1/4 WAVE MULTI-BAND MICROMAG ANTENNA Part Number: AM102/2 Gain: 2dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Gross Dimensions: 30mm diameter x 100mm Cable Type: RG174 Rohs Compliant: YES

www.galteh.eu

GSM/GPS combination antennas The ideal solution for applications where space is at a premium, these antennas house both GSM and GPS elements and also reduce installation time that would be required to fit two separate antennas.

www.galteh.eu

AEB720

GPS/GSM COMBINATION ANTENNA Part Number: AEB720 Gain: 2.5dBi Power Consumption: 125mW (max) Supply Voltage: 3.3 - 5.0v Supply Current: 15mA - 25mA VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Cable Type: RG174 Rohs Compliant: YES

GPLS088

PENTA BAND GPS/GLONASS/GSM COMBINATION ANTENNA Part Number: GPLS088 Gain: 26dB Power Consumption: 125mW (max) Supply Voltage: 3-5v Supply Current: 15mA - 25mA VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Cable Type: RG174 Rohs Compliant: YES

www.galteh.eu

GPS_TM/1

GPS/GSM COMBINATION ANTENNA Part Number: GPS_TM/1 Gain: 26dB Power Consumption: 125mW (max) Supply Voltage: 3-5v Supply Current: 125mW (max) VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Cable Type: RG174 Rohs Compliant: YES

AEB650

GSM/GPS BODY MOUNT ANTENNA Part Number: AEB650 Gain: 26dB Power Consumption: 125mW (max) Supply Voltage: 3-5v Supply Current:8mA-20mA VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Cable Type: RG174 Rohs Compliant: YES

www.galteh.eu

STUBBY antennas

This range of antennas is available straight, 90º, or swivel mount. Typical applications include, Mobile solutions, Telematics, Man to Machine (M2M), Security and Electronic Point of Sale. Frequency ranges: 433, 868, 915 ISM BANDS, GSM 850 900 1800 1900MHz and 2.1MHz; the new 3G standard.

www.galteh.eu

CTI-SB-02

2.4GHz SMA(M) RIGHT ANGLED STUBBY ANTENNA Part Number: CTI-SB-02 Gain: 0dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

CTI-RA-C01

2.4GHZ SMA(M) RP 3DBI ANTENNA Part Number: CTI-RA-C01 Gain: 0dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

www.galteh.eu

STUBBY antennas CTI-RA-H01

2.4GHz SMA(M) RP 5DBI ANTENNA Part Number: CTI-RA-H01 Gain: 0dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

ISM868/915

ISM868-915MHZ SWIVEL ANTENNA Part Number: ISM868/915 Gain: 2.0dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Gross Dimensions: 9.5mm x 100mm Rohs Compliant: YES

www.galteh.eu

GSMS/SMA/SLIM

SLIMLINE GSM PENTA-BAND GSM ANTENNA Part Number: GSMS/SMA/SLIM Gain: 3.0dBi VSWR: Less than 2.5:1 in all bands Impedance: 50 Ohms Gross Dimensions: 10mm diameter X 70mm long Rohs Compliant: YES

GSMEV/SMA

MULTI-BAND DIPOLE ANTENNA Part Number: GSMEV/SMA Gain: 3.0 dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

STUBBY antennas

www.galteh.eu

Office and base station antenna

CTI-CA-01000-01-9 SOHO WIFI CEILING ANTENNA Part Number: CTI-CA-01000-01-9 Gain: 5dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

AO156

OUTDOOR GSM ANTENNA Part Number: AO156 Gain: 3dBi VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Cable Type: RG58 Rohs Compliant: YES

www.galteh.eu

Office and base station antenna

AO100

OUTDOOR COLINEAR ANTENNA Part Number: AO100 Gain: 2-3dBi VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Cable Type: RG58 Rohs Compliant: YES

AG360WB

WATERPROOF STRIP ANTENNA Part Number: AG360WB Gain: 2dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms IP Rating: IP67 Gross Dimensions: 135mmx 90mm x70mm Cable Type: RG174 Rohs Compliant: YES

www.galteh.eu

Embedded antennas

CTi’s partners in the Far East are proud to offer a range of embedded component antennas that are manufactured to a high standard using proven and reliable mass production

• techniques. Material control is

maintained by using precise process

• technology. Ongoing development of

dielectric materials and antenna design is used to achieve the best possible performance from our antennas.

• GPS • Bluetooth, WLAN, 2.4GHz ISM •

FM Antenna • GSM/GPRS ISM 433• • ISM 868 (EU) • ISM 915 (US) Any size of ceramic patches available.

www.galteh.eu

Embedded antennas

CTI-AMMAP003

GSM MULTI-BAND EMBEDDED ANTENNA Part Number: CTI-AMMAP003 Gain: -1-1dBi VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

CTI-AMMAP009

EMBEDDED MULTI-BAND ANTENNA Part Number: CTI-AMMAP009 Gain: 2dBi VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

www.galteh.eu

Embedded antennas CTI- AMMAP010

EMBEDDED MULTI-BAND ANTENNA Part Number: CTI-AMMAP010 Gain: 2dBi VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

250PCB

MULTI-BAND GSM PCB ANTENNA Part Number: 250PCB Gain: 2.3dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

www.galteh.eu

Embedded antennas

PA25MM/CH/2450

WIFI/ZIGBEE/ BLUETOOTH CERAMIC PATCH ANTENNA Part Number: PA25MM/CH/2450 Gain: 3dBi VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Gross Dimensions: 25mm x 25 mm x 8.5mm Rohs Compliant: YES

PA17MM/CH

GPS CERAMIC PATCH ANTENNA 17X17X4MM Part Number: PA17MM/CH Gain: 3dBi VSWR: Less than 2:1 in all bands Impedance: 50 Ohms Rohs Compliant: YES

GPLS_MOD/25X4/UFL0-1

GPS GLONASS MODULE 25X25X4MM WITH 100MM OF UFL Part Number: GPLS_MOD/25X4/UFL0-1 Gain: 26dB VSWR: Less than 1.5:1 in all bands Impedance: 50 Ohms Cable Type: 1.13MM (UFL) Rohs Compliant: YES

www.galteh.eu

Bespoke antennas

In addition to our partner CTI off-the-shelf range, we can also provide a bespoke design and manufacturing service for connectors, wiring and cable assemblies. These solutions can cover anything from a simple connector change to a complete antenna design. CTI have a UK based production facility with co-axial cable processing machines, a wide range of stocked RF connectors and skilled operators. This enables us to customise any of our standard antennas with the connector and cable length you need. It also allows us to provide these services with very modest MOQ’s and a quickturn-around.

www.galteh.eu

Cable assemblies

Bespoke Cable Assembly & Loom Manufacturing – On-site cable assembly manufacturing facility in the UK – Fully automated KOMAX cable assembly machine – Quality assured production – Geared to providing shorter lead times – Ability to manufacture in small quantities We supply a variety of cable assemblies, connectors, adaptors and wiring harnesses, either as a standard off the shelf product or custom made options, designed to meet individual customer requirements. As a result we supply products to various sectors such as Automotive, Medical, Vending, Telecommunications and Telematics.

www.galteh.eu

Cable assemblies

www.galteh.eu

Connectors

We stock a whole range of RF connector solutions, from BNC to UFL including the automotive FAKRA and USCAR range.

SMA male and SMA male Riverse polarity FME female BNC male

SMA female bulkhead MMCX male SMA male right angel

www.galteh.eu

Connectors

MINI UHF (M) TO FME (M) ADAPTOR SMA (M) TO FME (F) ADAPTOR FME (F) TO FME (F) ADAPTOR BNC (M) TO FME (M) ADAPTOR TNC (M) TO FME (M) ADAPTOR

www.galteh.eu

FAKRA connectors

Fakra F) Blue C code Fakra (M) Blue C code Fakra (F) D code bourdeaus Fakra (M) D code bourdeaux Fakra (M) Z code waterblue Fakra (F) Z code waterblue

www.galteh.eu

FAKRA connectors

FAKRA (M) RIGHT ANGLED PCB MOUNT CONNECTOR CODE C (BLUE) FAKRA (M) RIGHT ANGLED PCB MOUNT CONNECTOR CODE D (BORDEAUX) FAKRA(M) PANEL MOUNT CONNECTOR CODE D (BORDEAUX) FAKRA(M) PANEL MOUNT CONNECTOR CODE Z (WATERBLUE)

www.galteh.eu

Distributed By GALTEH Ltd.
