www.purebroadband.org Broadband Town Hall Lyndon Township Green Lake Lyndon Township, MI Photo Credit: UnagiUnagi Michigan Broadband Cooperative Mission: To build community-controlled broadband infrastructure for unserved and underserved

slide-1
SLIDE 1

www.purebroadband.org

Broadband Town Hall Lyndon Township

slide-2
SLIDE 2

Green Lake Lyndon Township, MI

Photo Credit: UnagiUnagi

slide-3
SLIDE 3

Mission:

To build community-controlled broadband infrastructure for unserved and underserved areas of Michigan

Michigan Broadband Cooperative

slide-4
SLIDE 4

Michigan Broadband Cooperative

Board of Directors

President - Ben Fineman, Lyndon Twp Vice President - Rose LaForest, Waterloo Twp Secretary - Melanie Bell, Ypsilanti Treasurer - David Brooks, Sylvan Twp Director - Chris Leonello , Webster Twp Director - Gary Munce, Lyndon Twp Director -Todd Anuskiewicz, Scio Twp Director - Barb Fuller, Sharon Twp

slide-5
SLIDE 5
  • Marc Keezer, Lyndon

Township Supervisor

  • Harley Rider, Dexter

Township Supervisor

  • John Kingsley, Webster

Township Supervisor

slide-6
SLIDE 6
slide-7
SLIDE 7

What is Broadband?

slide-8
SLIDE 8

Truly high-speed wired Internet access is as basic to innovation, economic growth, social communication, and the country’s competitiveness as electricity was a century ago

  • Susan P. Crawford
slide-9
SLIDE 9

The Homework Gap

slide-10
SLIDE 10

20%

slide-11
SLIDE 11

Quality of Life

slide-12
SLIDE 12

Where are we now?

slide-13
SLIDE 13
slide-14
SLIDE 14

Cable + DSL + Cellular & Satellite Coverage

slide-15
SLIDE 15

Data Caps

slide-16
SLIDE 16

Streaming Video: $1,605 Home Computer Backups: $2,320 Security Camera: $1,220 Software Updates: $135 Software Purchases: $600 Video Chat: $575 Total: $6,455

slide-17
SLIDE 17

Cable + DSL Coverage

slide-18
SLIDE 18
  • 10

10 30 50 70 90 110 130 150 DSL Cable

Bandwidth (Mbps)

FCC Broadband Threshold

slide-19
SLIDE 19

“Distance learning and telecommuting requires speeds of at least 25 Mbps for a single user to have an ‘OK’ experience, and 50Mbps for a ‘Good’ experience.”

– U.S. Small Business Administration, 2010 Report

slide-20
SLIDE 20

Nielsen’s Law of Bandwidth

slide-21
SLIDE 21

Cable Coverage

slide-22
SLIDE 22

Rural Reach Great Lakes High Speed Air Advantage

slide-23
SLIDE 23
  • 10

10 30 50 70 90 110 130 150 Fixed Wireless DSL Cable

Bandwidth (Mbps)

FCC Broadband Threshold

slide-24
SLIDE 24

Lyndon Township Unserved Areas

slide-25
SLIDE 25

21% 91% 77% 79% 9% 23% Does your broadband service meet your needs? Are you interested in alternate broadband providers? Would you support a millage for broadband?

Yes Yes No

No

Yes No

slide-26
SLIDE 26

How do we get broadband?

slide-27
SLIDE 27
slide-28
SLIDE 28

www.purebroadband.org

Grass Roots

slide-29
SLIDE 29

www.purebroadband.org

slide-30
SLIDE 30

100 200 300 400 500 600 700 800 900 1000 Fixed Wireless DSL Cable Fiber

Bandwidth (Mbps)

e.g.

FCC Broadband Threshold

slide-31
SLIDE 31

www.purebroadband.org

slide-32
SLIDE 32

www.purebroadband.org

Sebewaing, MI

  • Built fiber to

the home for 1700 residents

  • Offering up to

1Gb service

  • Leveraging

municipal power co.

  • Funded out of

general fund

slide-33
SLIDE 33

www.purebroadband.org

http://muninetworks.org/communitymap

slide-34
SLIDE 34

www.purebroadband.org

Feasibility Study

slide-35
SLIDE 35

Bottom Line Cost: $6,767,086 3.7 Mils

slide-36
SLIDE 36

Decision Point #1: Aerial Vs. Underground

slide-37
SLIDE 37

Aerial

slide-38
SLIDE 38

Underground

slide-39
SLIDE 39

Aerial: $5,931,816 Underground: $6,295,086 Difference: $363,270 (0.2 mils)

slide-40
SLIDE 40

Decision Point #2: Driveways

slide-41
SLIDE 41

Road Miles: 62.8 Miles Driveways: 65.8 Miles Driveways @ 600’: $1,550,562 Driveways @ 300’: $815,562 Difference: $735,000 (0.4 mils)

slide-42
SLIDE 42

If Driveway Length is Limited: Cost Over 300’: $4.25/foot Examples: 300’ Driveway: $0 600’ Driveway: $1,275 1200’ Driveway: $3,825

slide-43
SLIDE 43

If Home Connection is Excluded: Cost: $420 plus $4.25/foot Examples: 300’ Driveway: $1,695 600’ Driveway: $2,970 1200’ Driveway: $5,520

slide-44
SLIDE 44

If Home Connection is Included: Cost: $0 Examples: 300’ Driveway: $0 600’ Driveway: $0 1200’ Driveway: $0

slide-45
SLIDE 45

Decision Point #3: Central vs. Distributed Split

slide-46
SLIDE 46

Central vs. DistributedSplit

slide-47
SLIDE 47

Distributed

Instead of

Central Split Difference: $456,737 (0.25 mils)

slide-48
SLIDE 48

Decision Point #4: Service Provider Equipment

slide-49
SLIDE 49
slide-50
SLIDE 50

Included

Instead of

Not Included Difference: $472,000 (0.25 mils)

slide-51
SLIDE 51

Decision Point #5: Head End Location

slide-52
SLIDE 52

Lyndon Township Hall

slide-53
SLIDE 53

Dexter Fire Station #2

slide-54
SLIDE 54

City of Chelsea

slide-55
SLIDE 55

Areas of Further Research

1. Bonding Costs 2. Construction Cost Estimates 3. Boring vs Trenching Estimates 4. Edge Parcels 5. Head End Locations

slide-56
SLIDE 56

Decision Point Summary

1. Aerial vs Underground (0.2 mils) 2. Driveways @ 300ft / 600 ft (0.4 mils) 3. Distributed vs Central Split (0.25 mils) 4. Service Provider Equipment Included (0.25 mils)

slide-57
SLIDE 57

Decision Point Summary

1. Aerial vs Underground (+0.2 mils) 2. Driveways @ 300ft / 600 ft (+0.4 mils) 3. Distributed vs Central Split (-0.25 mils) 4. Service Provider Equipment Included (+0.25 mils)

Current Model: $6,767,086 (3.7 mils)

slide-58
SLIDE 58

Personal Finance

slide-59
SLIDE 59

Personal Finance

  • Average Lyndon Home Value:

$206,916

  • 3.7 mils = $383/year ($32/month)
  • Estimated monthly service fee:

$50/month

  • Total monthly cost: $82/month
slide-60
SLIDE 60

Current Lyndon ISPs: Cheapest

Cellular Satellite Fixed Wireless Fiber

12Mb 12Mb 1Mb 25Mb 2GB 10GB UNLIMITED UNLIMITED

$40 $50 $60 $82

slide-61
SLIDE 61

Current Lyndon ISPs: Best Available

Cellular Satellite Fixed Wireless Fiber

12Mb 12Mb 25Mb 30GB 30GB UNLIMITED UNLIMITED

$120 $130 $200 $82

8Mb

slide-62
SLIDE 62

Current Lyndon ISPs: Best Available

Cellular Satellite Fixed Wireless Fiber

12Mb 12Mb 1000Mb 30GB 30GB UNLIMITED UNLIMITED

$120 $130 $200 $132

8Mb

slide-63
SLIDE 63

Personal Finance: Total Cost of Ownership

slide-64
SLIDE 64

150000 170000 190000 210000 230000 250000 Oct-95 Jul-98 Apr-01 Jan-04 Oct-06 Jul-09 Apr-12 Dec-14 Sep-17

Broadband Gap in Home Values

No Broadband Broadband

20.9%

$206,916 $250,216 $163,481

slide-65
SLIDE 65

Personal Finance: TCO

  • Average Lyndon Home Value
  • 1998: $163,481
  • Today: $206,916
  • Comparable Home With Broadband
  • 1998: $163,481
  • Today: $250,216
slide-66
SLIDE 66

Personal Finance: TCO

  • 3.7 mils for 20 years for average

Lyndon home: $7,660

  • Projected property value increase:

$43,300

  • Net Equity Change: $35,640
  • $7,660

Millage $43,300 Property Value $35,640 Equity Gain

slide-67
SLIDE 67

Community Discussion

1. Aerial vs Underground 2. Driveways @ none/300ft/600 ft 3. Distributed vs Central Split 4. Service Provider Equipment Included 5. Head End Location

slide-68
SLIDE 68

www.purebroadband.org

www.mbcoop.org ben@mbcoop.org
