Bridging the gap: FHL transfer-- cheaper, stronger, and fewer complications Michael J. Coughlin MD Conflicts None for this talk Consultant with Arthrex, Stryker, Integra Royalties from Arthrex, Stryker, Integra, Erchonia

slide-1
SLIDE 1

Bridging the gap: FHL transfer-- cheaper, stronger, and fewer complications Michael J. Coughlin MD

slide-2
SLIDE 2

Conflicts

  • None for this talk
  • Consultant with Arthrex, Stryker, Integra
  • Royalties from Arthrex, Stryker, Integra,

Erchonia

  • Textbook royalties- Elsevier
slide-3
SLIDE 3

History

  • 40 year old laborer presents

6 months after work related injury: MRI ahows a gap of 3 cm. with weak plantar flexion and gap

slide-4
SLIDE 4

Acute vs. old ruptures

slide-5
SLIDE 5

Bridging the gap

Delay of a week may make repair difficult

slide-6
SLIDE 6

Old ruptures

  • 20-25% of acute

ruptures are not diagnosed by primary care physician

  • Gap leads to

significant plantar flexion weakness

Inglis A, Sculco T, Clin Ortho 1981

slide-7
SLIDE 7

The problems

  • Poor tissue
  • Contracture of skin
  • Need for a large exposure
  • Tension free closure
slide-8
SLIDE 8

Complications

slide-9
SLIDE 9

Do you have a good plastic surgeon available?

slide-10
SLIDE 10

Eradicate infection

  • Antibiotics
  • Debridement
  • Skin graft
  • Wound vac

But you still have a tendon defect?? What now??

slide-11
SLIDE 11

Courtesy J. DeOrio MD

Major turn down flap!!

slide-12
SLIDE 12

“V-Y” plasty (can get 3-5 cm)

slide-13
SLIDE 13

Flexor Hallucis Longus

  • S. Hansen-1991
  • K. Wapner-1993,1995
slide-14
SLIDE 14

Open FHL transfer?

  • TWO WAYS TO DO IT!
slide-15
SLIDE 15

Pulled proximal

Free up at knot-of- Henry

slide-16
SLIDE 16

Insert guide pin

Make a small incision around the pin site

slide-17
SLIDE 17
slide-18
SLIDE 18

Separate incision for exit of drill and tendon

slide-19
SLIDE 19

Single incision technique

slide-20
SLIDE 20

Harvest the tendon, just above the tunnel

slide-21
SLIDE 21

Using the fiber loop to secure the tendon

slide-22
SLIDE 22

Size the tendon

slide-23
SLIDE 23

Drill pin out the plantar aspect

slide-24
SLIDE 24

Drilling hole with ACL reamer

slide-25
SLIDE 25

Passing the suture, and then the tendon

slide-26
SLIDE 26

Secure with appropriate tendon with biotenodesis screw

slide-27
SLIDE 27
slide-28
SLIDE 28

Post-op care

  • Immobilize in cast for 6 weeks
  • Partial weight bearing at 3 weeks
  • Cam-boot, FWB with ROM at 6

weeks

  • Jogging, speed walking -12 wks
slide-29
SLIDE 29

Results of FHL transfer

  • High satisfaction rate
  • Improvement in pain

and function

Rahm et al. Operative treatment of irreparable Achilles ruptures with large FHL tendon transfers. FAI 2013 Den Hartog B. FHL transfer for chronic Achilles tendinosis FAI 2003 Wilcox, d, Bohay D, Anderson J, Treatment

  • f chronic Achilles tendon disorders with

FHL transfer. FAI 2000

slide-30
SLIDE 30

Can you transfer FHL alone?

  • Wong M, Ng V. Modified FHL transfer for Achilles insertion

rupture in elderly patients CO 2005

Near normal gait pattern

slide-31
SLIDE 31

Arthroscopic tendon transfer

  • Goncalves et al. Salvage FHL transfer for a

failed Achilles repair: endoscopic technique

  • Lui T. Endoscopic assisted FHL transfer in

the management of chronic rupture of the AT

  • Hirose C- our personal experience

FootInnovate Lecture June 27, 2016

slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34

Exposing the FHL

slide-35
SLIDE 35

Grasping FHL

slide-36
SLIDE 36

Releasing FHL

slide-37
SLIDE 37

Bringing tendon out and placing Krakow suture

slide-38
SLIDE 38

Drill calcaneal hole

slide-39
SLIDE 39

Checking position of the fixation drill hole

slide-40
SLIDE 40

Pulling suture out the heel, tensioning the transfer

slide-41
SLIDE 41

Fixing tendon with interference screw

slide-42
SLIDE 42

Placing screw

slide-43
SLIDE 43

Post op 6 weeks

slide-44
SLIDE 44

Post-op protocol

  • Splint, plantar flexed
  • #2 POD- plantarflexion cast
  • #4 week post op- neutral

flexion BK cast

  • #8 week post op- Cam boot,

FWB, ROM

  • #12 week post op- boot

discontinued.

At 12 weeks, collagen fibers connected to bone in tunnel- best at 26 weeks

slide-45
SLIDE 45

Endoscopic indications

  • Old rupture
  • Prior infection
  • Thin skin, bad skin
  • Skin contracture
  • Collagen disease
  • ------------------
  • Avoid wound complication.
slide-46
SLIDE 46

FHL transfer

  • Good strength
  • Best of all tendons to transfer (Hansen)
  • Choices on technique:

– Two incision – One incision – endoscopic
