Blue Kenue enhancements from 2014 to 2019 Alan J. Barton 9:30am 9:45am, 17 October 2019 Conference Room CIC, Mto-France campus, TELEMAC User Conference Organized by: European Center for Advanced Research and Training for Computational

slide-1
SLIDE 1

Blue Kenue enhancements from 2014 to 2019

Alan J. Barton 9:30am – 9:45am, 17 October 2019 Conference Room CIC, Météo-France campus, TELEMAC User Conference Organized by: European Center for Advanced Research and Training for Computational Science (CERFACS), Toulouse, France

slide-2
SLIDE 2

NRC at a glance

NRC R&D facilities IRAP locations

NRC’s Mission: Develop and deploy solutions to meet Canada’s current and future industrial and societal needs Delivery through a set of focused large- scale, collaborative, multi-disciplinary R&D programs.

100-year history

  • f science and innovation

for Canada $1B Total expenditures in 2016/17 3,700 employees

Ottawa, Ontario, Canada

slide-3
SLIDE 3

3

NRC-OCRE in Ottawa, Ontario Canada

  • 1. 50m x 30m Large Area Basin
  • 2. 36m x 30m Multidirectional Wave Basin
  • 3. 64m x 14m Coastal Wave Basin
  • 4. 93m x 2m Large Wave Flume
  • 5. 63m x 1.4m Steel Wave Flume
  • 6. 21m x 7m Ice Tank
slide-4
SLIDE 4

Tools for hydraulic and hydrologic modellers

Green Kenue for hydrology Blue Kenue for hydraulics/hydrodynamics pyEnSim etc…

slide-5
SLIDE 5

Blue Kenue

5

Free for use with models such as open TELEMAC Developed at the National Research Council Canada

  • Formerly NRC-CHC… now NRC-OCRE

Blue Kenue’s predecessor is HYDA (1991) Father of Blue Kenue… Martin Serrer (retired in 2015) And now mini-Martin (started in 2014), who uses CHyMS a lot…

NATIONAL RESEARCH COUNCIL CANADA

slide-6
SLIDE 6

CHyMS

6

https://chyms.nrc.gc.ca

User: Public.User Password: anonymous

  • A collaborative space for Blue Kenue…

– for more details see the FAQ

  • Use your phones to get the CHyMS URL from the above QR code

– will show it again at the end…

NATIONAL RESEARCH COUNCIL CANADA

Hosts Blue Kenue alpha and other things too!

slide-7
SLIDE 7

CHyMS hosts a free Blue Kenue Community (not a forum… not email… another “way”…)

7

NATIONAL RESEARCH COUNCIL CANADA

slide-8
SLIDE 8

Example of ONE piece of work described in ONE ticket on CHyMS: (forum is good for question+answer but harder to use to track work)

slide-9
SLIDE 9

CHyMS helps to track and organize lots of pieces of work:

slide-10
SLIDE 10

Work can change STATE and therefore tickets move around:

slide-11
SLIDE 11

11

KNOWN work as recorded in CHyMS Work direction Ticket COUNTS Open Closed Strategic (large) 85 23 See paper for more details… New Feature (small) 22 12 Proactive Maintenance 113 38 Reactive Maintenance 48 46 Total (394) 270 124

slide-12
SLIDE 12

12

NATIONAL RESEARCH COUNCIL CANADA

slide-13
SLIDE 13

SOME NEW DEVELOPMENTS OR CAREFULLY TOUCHING 300,000 LINES OF CODE...

13

NATIONAL RESEARCH COUNCIL CANADA

slide-14
SLIDE 14

Example 1 – Colour scales now show “oneof” details

14

Both the textual category and the associated numeric value are now shown when the colour scale for a “oneof” attribute is selected

NATIONAL RESEARCH COUNCIL CANADA

slide-15
SLIDE 15

Example 2 – A new simple polygon creator…

15

NATIONAL RESEARCH COUNCIL CANADA

slide-16
SLIDE 16

Example 3 – XYZ Point Set: Swap X and Y (lat/lon vs lon/lat in an undocumented XYZ file)

16

NATIONAL RESEARCH COUNCIL CANADA

slide-17
SLIDE 17

Map Object… and the new Map File(s)…

17

1– Select one data object in the workspace 2– Select: Tools -> Map Object… or the new Map File(s)… 3– Then a – All available reductions will be shown b – Select the one reduction to use c – Select the files to use (i.e. the reduction “options”)

NATIONAL RESEARCH COUNCIL CANADA

slide-18
SLIDE 18

Load XYZ File, Select XYZ Point Set in Workspace, Tools -> Map File(s)… (Example 4)

18

NATIONAL RESEARCH COUNCIL CANADA

slide-19
SLIDE 19

Example 2 –

19

NATIONAL RESEARCH COUNCIL CANADA

slide-20
SLIDE 20

20

NATIONAL RESEARCH COUNCIL CANADA

Create grid, Select Rect 2D Scalar in Workspace, Tools -> Map File(s)… (Example 5)

slide-21
SLIDE 21

1 selected object + 1 selected reduction 2 operational reducers used (grid changed resolution)

21

NATIONAL RESEARCH COUNCIL CANADA

10 km (CaPA) vs 15 km (CaPA)

slide-22
SLIDE 22

1 selected object + 1 selected reduction 2 operational reductions due to change in grid resolution

22

NATIONAL RESEARCH COUNCIL CANADA

SIDE NOTE: missing data due to…

slide-23
SLIDE 23

23

NATIONAL RESEARCH COUNCIL CANADA

New grid goes out

  • f DATA domain

Grid in new co-ord system is NOT regular Regular grid

slide-24
SLIDE 24

THANK YOU TO ALL let’s chat…?

Alan (mini-Martin)

forum (questions) vs. email (threads) vs. CHyMS (tracking)

https://chyms.nrc.gc.ca Public.User anonymous
