Billion Goods in Few Categories: how Histograms Save a Life?

November, 7, 2018

Sveta Smirnova

• The Case
• The Cardinality: Two Levels
• ANALYZE TABLE Limitations
• Solutions in Percona Server 5.7
• Histograms
• Conclusion

Table of Contents

2

• MySQL Support engineer
• Author of
• MySQL Troubleshooting
• JSON UDF functions
• FILTER clause for MySQL
• Speaker
• Percona Live, OOW, Fosdem,

DevConf, HighLoad... Sveta Smirnova

3

• Hardware
• Wise options
• Optimized queries
• Brain

Everything can be Resolved!

4

• This talk is about
• How I spent last two years
• Resolving the same issue
• For different customers

Not Everything

5

• This talk is about
• How I spent last two years
• Resolving the same issue
• For different customers
• Task was to speed up the query

Not Everything

5

• Specific data distribution
• Access on different fields
• ON clause
• WHERE clause
• GROUP BY
• ORDER BY
• Index cannot be used effectively

Not All the Queries can be Optimized

6

• Topic based on real Support cases
• Couple of them are still in progress

Disclaimer

7

• Topic based on real Support cases
• All examples are 100% fake
• They created such that
• No customer can be identified
• Everything generated

Table names Column names Data

• Use case itself is fictional

Disclaimer

7

• Topic based on real Support cases
• All examples are 100% fake
• All examples are simplified
• Only columns, required to show the issue
• Everything extra removed
• Real tables usually store much more data

Disclaimer

7

• Topic based on real Support cases
• All examples are 100% fake
• All examples are simplified
• All disasters happened with version 5.7

Disclaimer

7

The Case

• categories
• Less than 20 rows

Two tables

9

• categories
• Less than 20 rows
• goods
• More than 1M rows
• 20 unique cat id values
• Many other fields

Price Date: added, last updated, etc. Characteristics Store ...

Two tables

9

select * from goods join categories

• n

(categories.id=goods.cat_id) where date_added between ’2018-07-01’ and ’2018-08-01’ and cat_id in (16,11) and price >= 1000 and <=10000 [ and ... ] [ GROUP BY ... [ORDER BY ... [ LIMIT ...]]] ;

JOIN

10

• Select from the Small Table

Option 1: Select from the Small Table First

11

• Select from the Small Table
• For each cat id select from the large table

Option 1: Select from the Small Table First

11

• Select from the Small Table
• For each cat id select from the large table
• Filter result on date added[ and price[...]]

Option 1: Select from the Small Table First

11

• Select from the Small Table
• For each cat id select from the large table
• Filter result on date added[ and price[...]]
• Slow with many items in the category

Option 1: Select from the Small Table First

11

• Filter rows by date added[ and price[...]]

Option 2: Select from the Large Table First

12

• Filter rows by date added[ and price[...]]
• Get cat id values

Option 2: Select from the Large Table First

12

• Filter rows by date added[ and price[...]]
• Get cat id values
• Retrieve rows from the small table

Option 2: Select from the Large Table First

12

• Filter rows by date added[ and price[...]]
• Get cat id values
• Retrieve rows from the small table
• Slow if number of rows, filtered by

date added, is larger than number of goods

in the selected categories

Option 2: Select from the Large Table First

12

• CREATE INDEX index everything

(cat id, date added[, price[, ...]])

• It resolves the issue

What if use Combined Indexes?

13

• CREATE INDEX index everything

(cat id, date added[, price[, ...]])

• It resolves the issue
• But not in all cases

What if use Combined Indexes?

13

• Maintenance cost
• Slower INSERT/UPDATE/DELETE
• Disk space

The Problem

14

• Maintenance cost
• Slower INSERT/UPDATE/DELETE
• Disk space
• Tables may have wrong cardinality

The Problem

14

The Cardinality: Two Levels

• Optimizer
• Engine
• TokuDB
• InnoDB
• Any

MySQL is Layered Architecture

16

• Stores statistics on disk
• mysql.innodb table stats
• mysql.innodb index stats

InnoDB: Overview

17

• Stores statistics on disk
• Returns statistics to Optimizer

InnoDB: Overview

17

• Stores statistics on disk
• Returns statistics to Optimizer
• In ha innobase::info
• handler/ha innodb.cc

InnoDB: Overview

17

• Stores statistics on disk
• Returns statistics to Optimizer
• In ha innobase::info
• handler/ha innodb.cc
• When opens table
• flag = HA STATUS CONST
• Reads data from disk
• Stores it in memory

InnoDB: Overview

17

• Stores statistics on disk
• Returns statistics to Optimizer
• In ha innobase::info
• handler/ha innodb.cc
• When opens table
• Subsequent table accesses
• flag = HA STATUS VARIABLE
• Statistics from memory
• Up to date Primary Key data

InnoDB: Overview

17

• Table created with option STATS AUTO RECALC = 0
• Before ANALYZE TABLE

mysql> show index from test\G ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Seq_in_index: 1 Column_name: f1 Collation: A Cardinality: 64 ...

InnoDB: Flow

18

• Table created with option STATS AUTO RECALC = 0
• After ANALYZE TABLE

mysql> show index from test\G ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Seq_in_index: 1 Column_name: f1 Collation: A Cardinality: 2 ...

InnoDB: Flow

18

• Table created with option STATS AUTO RECALC = 0
• After inserting rows

mysql> show index from test\G ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Seq_in_index: 1 Column_name: f1 Collation: A Cardinality: 16 ...

InnoDB: Flow

18

• Table created with option STATS AUTO RECALC = 0
• After restart

mysql> show index from test\G ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Seq_in_index: 1 Column_name: f1 Collation: A Cardinality: 2 ...

InnoDB: Flow

18

• Takes data from the engine

Optimizer: Overview

19

• Takes data from the engine
• Class ha statistics
• sql/handler.h

Optimizer: Overview

19

• Takes data from the engine
• Class ha statistics
• sql/handler.h
• Does not have Cardinality field at all

Optimizer: Overview

19

• Takes data from the engine
• Class ha statistics
• sql/handler.h
• Does not have Cardinality field at all
• Uses formula to calculate Cardinality

Optimizer: Overview

19

• n rows: number of rows in the table
• Naturally up to date
• Constantly changing!

Optimizer: Formula

20

• n rows: number of rows in the table
• Naturally up to date
• Constantly changing!
• rec per key: number of duplicates per key
• Calculated by InnoDB in time of ANALYZE
• rec per key = n rows / unique values
• Do not change!

Optimizer: Formula

20

• n rows: number of rows in the table
• Naturally up to date
• Constantly changing!
• rec per key: number of duplicates per key
• Calculated by InnoDB in time of ANALYZE
• rec per key = n rows / unique values
• Do not change!
• Cardinality = n rows / rec per key

Optimizer: Formula

20

• Engine stores persistent statistics

TokuDB InnoDB Storage Files Tables Statistics As Calculated As Calculated Row Count Persistent Only in Memory

Persistent Statistics Are Not Persistent

21

• Engine stores persistent statistics

TokuDB InnoDB Storage Files Tables Statistics As Calculated As Calculated Row Count Persistent Only in Memory

• Optimizer calculates Cardinality every time

when accesses engine statistics

Persistent Statistics Are Not Persistent

21

• Engine stores persistent statistics

TokuDB InnoDB Storage Files Tables Statistics As Calculated As Calculated Row Count Persistent Only in Memory

• Optimizer calculates Cardinality every time

when accesses engine statistics

• Weak user control

Persistent Statistics Are Not Persistent

21

ANALYZE TABLE Limitations

• Counts number of pages in the table

How ANALYZE TABLE Works with InnoDB?

23

• Counts number of pages in the table
• Takes STATS SAMPLE PAGES

How ANALYZE TABLE Works with InnoDB?

23

• Counts number of pages in the table
• Takes STATS SAMPLE PAGES
• Counts number of unique values in

secondary index in these pages

How ANALYZE TABLE Works with InnoDB?

23

• Counts number of pages in the table
• Takes STATS SAMPLE PAGES
• Counts number of unique values in

secondary index in these pages

• Divides number of pages in the table on

number of sample pages and multiplies result on number of unique values

How ANALYZE TABLE Works with InnoDB?

23

• Number of pages in the table: 20,000
• STATS SAMPLE PAGES: 20 (default)
• Unique values in the secondary index:
• In sample pages: 10
• In the table: 11

Example

24

• Number of pages in the table: 20,000
• STATS SAMPLE PAGES: 20 (default)
• Unique values in the secondary index:
• In sample pages: 10
• In the table: 11
• Cardinality: 20,000 * 10 / 20 = 10,000

Example

24

• Number of pages in the table: 20,000
• STATS SAMPLE PAGES: 5,000
• Unique values in the secondary index:
• In sample pages: 10
• In the table: 11
• Cardinality: 20,000 * 10 / 5,000 = 40

Example 2

25

• Time consuming

mysql> select count(*) from goods; +----------+ | count(*) | +----------+ | 80303000 | +----------+ 1 row in set (35.95 sec)

Use Larger STATS SAMPLE PAGES?

26

• Time consuming
• With default STATS SAMPLE PAGES

mysql> analyze table goods; +------------+---------+----------+----------+ | Table | Op | Msg_type | Msg_text | +------------+---------+----------+----------+ | test.goods | analyze | status | OK | +------------+---------+----------+----------+ 1 row in set (0.32 sec)

Use Larger STATS SAMPLE PAGES?

26

• Time consuming
• With bigger number

mysql> alter table goods STATS_SAMPLE_PAGES=5000; Query OK, 0 rows affected (0.04 sec) Records: 0 Duplicates: 0 Warnings: 0 mysql> analyze table goods; +------------+---------+----------+----------+ | Table | Op | Msg_type | Msg_text | +------------+---------+----------+----------+ | test.goods | analyze | status | OK | +------------+---------+----------+----------+ 1 row in set (27.13 sec)

Use Larger STATS SAMPLE PAGES?

26

• Time consuming
• With bigger number
• 27.13/0.32 = 85 times slower!

Use Larger STATS SAMPLE PAGES?

26

User Manual claims it does not During the analysis, the table is locked with a read lock for InnoDB and MyISAM.

Does ANALYZE TABLE Block Reads?

27

User Manual claims it does not

• But!

Does ANALYZE TABLE Block Reads?

27

User Manual claims it does not Sometimes it blocks all subsequent queries

+------+-------------------------+---------------------------------+ | Time | State | Info | +------+-------------------------+---------------------------------+ | 32 | Writing to net | select * from t where c > ’%0%’ | | 12 | Waiting for table flush | select * from test.t where i=1 | | 12 | Waiting for table flush | select * from test.t where i=2 | | 12 | Waiting for table flush | select * from test.t where i=3 | | 11 | Waiting for table flush | select * from test.t where i=7 | | 10 | Waiting for table flush | select * from test.t where i=11 | ...

Does ANALYZE TABLE Block Reads?

27

Is not a solution

Simply Increasing STATS SAMPLE PAGES

28

Solutions in Percona Server 5.7

Considered as a bug

• jira.percona.com/browse/PS-2503
• lp:1704195
• bugs.mysql.com/87065

Blocking ANALYZE TABLE

30

Considered as a bug

• Fixed in Percona Server

5.6.38-83.0/5.7.20-18

Blocking ANALYZE TABLE

30

• Before the fix
• Opens table statistics

Concurrent DML allowed

• Updates table statistics

Concurrent DML allowed

• Update finished
• Invalidates entry in table definition cache

Concurrent DML forbidden

• Invalidates query cache

Concurrent DML forbidden

Non-Blocking ANALYZE TABLE

31

• After the fix
• Opens table statistics

Concurrent DML allowed

• Updates table statistics

Concurrent DML allowed

• Update finished
• Invalidates entry in table definition cache

Concurrent DML forbidden

• Invalidates query cache

Concurrent DML forbidden

Non-Blocking ANALYZE TABLE

31

• InnoDB stores its statistics

mysql.innodb index stats

Without the Fix: Manual Update

32

• InnoDB stores its statistics

mysql.innodb index stats

• This table is writable

Without the Fix: Manual Update

32

• InnoDB stores its statistics

mysql.innodb index stats

• This table is writable
• Updating it with following FLUSH TABLE

allows to fake any statistics

Without the Fix: Manual Update

32

• InnoDB stores its statistics

mysql.innodb index stats

• This table is writable
• Updating it with following FLUSH TABLE

allows to fake any statistics

• Hack
• Not documented
• Not recommended
• Can stop working any time

Without the Fix: Manual Update

32

• With Percona fix for blocking ANALYZE

TABLE we can use large value for STATS SAMPLE PAGES

• Does not help when
• Index cannot be used
• Data distribution in the index vary a lot

5.7: Resume

33

• With Percona fix for blocking ANALYZE

TABLE we can use large value for STATS SAMPLE PAGES

• Does not help when
• Index cannot be used
• Data distribution in the index vary a lot
• Manual update allows to fix statistics
• Not recommended
• Can stop working any time

5.7: Resume

33

Histograms

• Optimizer Column Statistics
• Engine-independent
• No fancy calculations
• Knows about data distribution

What are the Histograms?

35

1 2 3 4 5 6 7 8 9 10 200 400 600 800

Number of Values in Each Bucket

36

1 2 3 4 5 6 7 8 9 10 0.2 0.4 0.6 0.8 1

Data in the Histogram

37

• Accurate statistics
• Truly persistent
• No extra calculations on access
• Optimizer knows about data distribution
• Without touching the table!

How Histograms are Helpful?

38

• Example data

mysql> create table example(f1 int) engine=innodb; mysql> insert into example values(1),(1),(1),(2),(3); mysql> select f1, count(f1) from example group by f1; +------+-----------+ | f1 | count(f1) | +------+-----------+ | 1 | 3 | | 2 | 1 | | 3 | 1 | +------+-----------+ 3 rows in set (0.00 sec)

Filtered Rows

39

• Without a histogram

mysql> explain select * from example where f1 > 0\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 33.33 Extra: Using where

Filtered Rows

39

• Without a histogram

mysql> explain select * from example where f1 > 1\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 33.33 Extra: Using where

Filtered Rows

39

• Without a histogram

mysql> explain select * from example where f1 > 2\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 33.33 Extra: Using where

Filtered Rows

39

• Without a histogram

mysql> explain select * from example where f1 > 3\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 33.33 Extra: Using where

Filtered Rows

39

• With the histogram

mysql> analyze table example update histogram on f1 with 3 buckets; +-----------------+-----------+----------+------------------------------+ | Table | Op | Msg_type | Msg_text | +-----------------+-----------+----------+------------------------------+ | hist_ex.example | histogram | status | Histogram statistics created for column ’f1’. | +-----------------+-----------+----------+------------------------------+ 1 row in set (0.03 sec)

Filtered Rows

39

• With the histogram

mysql> select * from information_schema.column_statistics

• > where table_name=’example’\G

*************************** 1. row *************************** SCHEMA_NAME: hist_ex TABLE_NAME: example COLUMN_NAME: f1 HISTOGRAM: "buckets": [[1, 0.6], [2, 0.8], [3, 1.0]], "data-type": "int", "null-values": 0.0, "collation-id": 8, "last-updated": "2018-11-07 09:07:19.791470", "sampling-rate": 1.0, "histogram-type": "singleton", "number-of-buckets-specified": 3 1 row in set (0.00 sec)

Filtered Rows

39

• With the histogram

mysql> explain select * from example where f1 > 0\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 100.00 -- all rows Extra: Using where

Filtered Rows

39

• With the histogram

mysql> explain select * from example where f1 > 1\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 40.00 -- 2 rows Extra: Using where

Filtered Rows

39

• With the histogram

mysql> explain select * from example where f1 > 2\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 20.00 -- one row Extra: Using where

Filtered Rows

39

• With the histogram

mysql> explain select * from example where f1 > 3\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: example partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 5 filtered: 20.00 - one row Extra: Using where

Filtered Rows

39

• EXPLAIN without histograms

mysql> explain select goods.* from goods

• > join categories on (categories.id=goods.cat_id)
• > where cat_id in (20,2,18,4,16,6,14,1,12,11,10,9,8,17)
• > and
• > date_added between ’2000-01-01’ and ’2001-01-01’ -- Large range
• > order by goods.cat_id
• > limit 10\G -- We ask for 10 rows only!

Example

40

• EXPLAIN without histograms

*************************** 1. row *************************** id: 1 select_type: SIMPLE table: categories -- Small table first partitions: NULL type: index possible_keys: PRIMARY key: PRIMARY key_len: 4 ref: NULL rows: 20 filtered: 70.00 Extra: Using where; Using index; Using temporary; Using filesort

Example

40

• EXPLAIN without histograms

*************************** 2. row *************************** id: 1 select_type: SIMPLE table: goods -- Large table partitions: NULL type: ref possible_keys: cat_id_2 key: cat_id_2 key_len: 5 ref: orig.categories.id rows: 51827 filtered: 11.11 -- Default value Extra: Using where 2 rows in set, 1 warning (0.01 sec)

Example

40

• Execution time without histograms

mysql> flush status; Query OK, 0 rows affected (0.00 sec) mysql> select goods.* from goods

• > join categories on (categories.id=goods.cat_id)
• > where cat_id in (20,2,18,4,16,6,14,1,12,11,10,9,8,17)
• > and
• > date_added between ’2000-01-01’ and ’2001-01-01’
• > order by goods.cat_id
• > limit 10;

ab9f9bb7bc4f357712ec34f067eda364

• 10 rows in set (56.47 sec)

Example

40

• Engine statistics without histograms

mysql> show status like ’Handler%’; +----------------------------+--------+ | Variable_name | Value | +----------------------------+--------+ ... | Handler_read_next | 964718 | | Handler_read_prev | 0 | | Handler_read_rnd | 10 | | Handler_read_rnd_next | 951671 | ... | Handler_write | 951670 | +----------------------------+--------+ 18 rows in set (0.01 sec)

Example

40

• Now lets add the histogram

mysql> analyze table goods update histogram on date_added; +------------+-----------+----------+------------------------------+ | Table | Op | Msg_type | Msg_text | +------------+-----------+----------+------------------------------+ | orig.goods | histogram | status | Histogram statistics created for column ’date_added’. | +------------+-----------+----------+------------------------------+ 1 row in set (2.01 sec)

Example

40

• EXPLAIN with the histogram

mysql> explain select goods.* from goods

• > join categories
• > on (categories.id=goods.cat_id)
• > where cat_id in (20,2,18,4,16,6,14,1,12,11,10,9,8,17)
• > and
• > date_added between ’2000-01-01’ and ’2001-01-01’
• > order by goods.cat_id
• > limit 10\G

Example

40

• EXPLAIN with the histogram

*************************** 1. row *************************** id: 1 select_type: SIMPLE table: goods -- Large table first partitions: NULL type: index possible_keys: cat_id_2 key: cat_id_2 key_len: 5 ref: NULL rows: 10 -- Same as we asked filtered: 98.70 -- True numbers Extra: Using where

Example

40

• EXPLAIN with the histogram

*************************** 2. row *************************** id: 1 select_type: SIMPLE table: categories -- Small table partitions: NULL type: eq_ref possible_keys: PRIMARY key: PRIMARY key_len: 4 ref: orig.goods.cat_id rows: 1 filtered: 100.00 Extra: Using index 2 rows in set, 1 warning (0.01 sec)

Example

40

• Execution time with the histogram

mysql> flush status; Query OK, 0 rows affected (0.00 sec) mysql> select goods.* from goods

• > join categories on (categories.id=goods.cat_id)
• > where cat_id in (20,2,18,4,16,6,14,1,12,11,10,9,8,17)
• > and
• > date_added between ’2000-01-01’ and ’2001-01-01’
• > order by goods.cat_id
• > limit 10;

eeb005fae0dd3441c5c380e1d87fee84

• 10 rows in set (0.00 sec) -- 56 times faster!

Example

40

• Engine statistics with the histogram

mysql> show status like ’Handler%’; +----------------------------+-------++----------------------------+-------+ | Variable_name | Value || Variable_name | Value | +----------------------------+-------++----------------------------+-------+ | Handler_commit | 1 || Handler_read_prev | 0 | | Handler_delete | 0 || Handler_read_rnd | 0 | | Handler_discover | 0 || Handler_read_rnd_next | 0 | | Handler_external_lock | 4 || Handler_rollback | 0 | | Handler_mrr_init | 0 || Handler_savepoint | 0 | | Handler_prepare | 0 || Handler_savepoint_rollback | 0 | | Handler_read_first | 1 || Handler_update | 0 | | Handler_read_key | 3 || Handler_write | 0 | | Handler_read_last | 0 |+----------------------------+-------+ | Handler_read_next | 9 |18 rows in set (0.00 sec)

Example

40

• Data distribution is uniform
• Range optimization can be used
• Full table scan is fast

When Histogram are not Helpful?

41

Backward index scan

• Better Statistics Persistence in InnoDB
• MySQL bug #80178
• MySQL bug #84654
• Better PRIMARY key access

Other Improvements in 8.0

42

Conclusion

• Index statistics collected by the egine
• Optimizer calculates Cardinality each time

when accesses statistics

• Indexes not always improve performance
• Histograms can help

Still new feature

Conclusion

44

MySQL User Reference Manual Blog by Erik Froseth Blog by Frederic Descamps Talk by Oystein Grovlen @Fosdem Talk by Sergei Petrunia @PerconaLive Talk by Sergei Golubchik @HighLoad++

More information

45

Rate My Session!

46

http://www.slideshare.net/SvetaSmirnova https://twitter.com/svetsmirnova https://github.com/svetasmirnova

Thank you!

47

How TokuDB Updates Statistics

• Stores key statistics on disk and in memory
• tablename status id.tokudb

TokuDB: Overview

49

• Stores key statistics on disk and in memory
• Stores row count on disk and in memory
• tablename main id.tokudb
• tablename key keyname id.tokudb

TokuDB: Overview

49

• Stores key statistics on disk and in memory
• Stores row count on disk and in memory
• Returns statistics to Optimizer

TokuDB: Overview

49

• Stores key statistics on disk and in memory
• Stores row count on disk and in memory
• Returns statistics to Optimizer
• In ha tokudb::info (handler/ha tokudb.cc)

TokuDB: Overview

49

• Stored on disk

TokuDB: Key Statistics

50

• Stored on disk
• Updated during ANALYZE
• Background ANALYZE
• Explicitly called

TokuDB: Key Statistics

50

• Stored on disk
• Updated during ANALYZE
• Background ANALYZE
• Explicitly called
• Not updated when tokudb auto analyze=0

TokuDB: Key Statistics

50

• Updated in TOKUDB SHARE::update cardinality counts

TokuDB Key Statistics: Code

51

• Updated in TOKUDB SHARE::update cardinality counts
• Stored in tokudb::set card in status
• In standard ANALYZE
• standard t::on run

TokuDB Key Statistics: Code

51

• Updated in TOKUDB SHARE::update cardinality counts
• Stored in tokudb::set card in status
• Retrieved in tokudb::get card from status
• When table is open
• In ha tokudb::initialize share

TokuDB Key Statistics: Code

51

• Updated in TOKUDB SHARE::update cardinality counts
• Stored in tokudb::set card in status
• Retrieved in tokudb::get card from status
• Used in TOKUDB SHARE::set cardinality counts in table

for (uint32_t j = 0; j < key->actual_key_parts; j++) { ... assert_always(next_key_part < _rec_per_keys); ulong val = _rec_per_key[next_key_part++]; val = (val * tokudb::sysvars::cardinality_scale_percent) / 100;

TokuDB Key Statistics: Code

51

• Stored on disk
• Updated
• Each time table is updated
• When ha tokudb::info called

TokuDB Logical Rows Count

52

mysql> create table test(

• > id int not null auto_increment primary key,
• > f1 int,
• > ts timestamp,
• > key(f1)
• > ) engine=tokudb;

Query OK, 0 rows affected (0.10 sec) mysql> insert into test (f1, ts) values(1, NOW()), (2, NOW()); Query OK, 2 rows affected (0.03 sec) Records: 2 Duplicates: 0 Warnings: 0 ... mysql> insert into test (f1, ts) select f1, NOW() from test; Query OK, 32 rows affected (0.01 sec) Records: 32 Duplicates: 0 Warnings: 0

TokuDB Test Case

53

mysql> select count(distinct id), count(distinct f1) from test; +--------------------+--------------------+ | count(distinct id) | count(distinct f1) | +--------------------+--------------------+ | 64 | 2 | +--------------------+--------------------+ 1 row in set (0.01 sec)

TokuDB Test Case

53

• SHOW INDEX

mysql> show index from test\G *************************** 1. row *************************** Table: test Non_unique: 0 Key_name: PRIMARY Column_name: id Cardinality: 64 ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Column_name: f1 Cardinality: 64 ...

TokuDB: After First run

54

• Number of rows

$ ../bin/tokuftdump --header --nodata var/mysqld.1/data/test/test_key_f1_145_1_1d_B_1.tokudb ft: layout_version=29 layout_version_original=29 layout_version_read_from_disk=29 build_id=0 build_id_original=0 time_of_creation= 1537709029 Sun Sep 23 16:23:49 2018 time_of_last_modification=1537709100 Sun Sep 23 16:25:00 2018 ... estimated numrows=64 estimated numbytes=640 logical row count=64

TokuDB: After First run

54

• Index Statistics

Thread 44 "mysqld" hit Breakpoint 1, TOKUDB_SHARE::set_cardinality_counts_in_table (this=0x7fd86da54020, table=0x7fd86d90b020) at /home/sveta/src/percona-server/storage/tokudb/ha_tokudb.cc:400 400 if (val == 0 || _rows == 0 || (gdb) p key->name $21 = 0x7fd86d879999 "f1" (gdb) p val $22 = 0

TokuDB: After First run

54

• Cardinality = 64 / 0 = 64

TokuDB: After First run

54

mysql> analyze table test; +-----------+---------+----------+----------+ | Table | Op | Msg_type | Msg_text | +-----------+---------+----------+----------+ | test.test | analyze | status | OK | +-----------+---------+----------+----------+ 1 row in set (0.01 sec)

TokuDB: ANALYZE TABLE

55

• SHOW INDEX

mysql> show index from test\G *************************** 1. row *************************** Table: test Non_unique: 0 Key_name: PRIMARY Column_name: id Cardinality: 64 ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Column_name: f1 Cardinality: 2 ...

TokuDB: After ANALYZE TABLE

56

• Number of rows

$ ../bin/tokuftdump --header --nodata var/mysqld.1/data/test/test_key_f1_145_1_1d_B_1.tokudb ft: layout_version=29 layout_version_original=29 layout_version_read_from_disk=29 build_id=0 build_id_original=0 time_of_creation= 1537709029 Sun Sep 23 16:23:49 2018 time_of_last_modification=1537709100 Sun Sep 23 16:25:00 2018 ... estimated numrows=64 estimated numbytes=640 logical row count=64

TokuDB: After ANALYZE TABLE

56

• Index Statistics

Thread 44 "mysqld" hit Breakpoint 1, TOKUDB_SHARE::set_cardinality_counts_in_table (this=0x7fd86da54020, table=0x7fd86d90b020) at /home/sveta/src/percona-server/storage/tokudb/ha_tokudb.cc:400 400 if (val == 0 || _rows == 0 || (gdb) p key->name $26 = 0x7fd86d879999 "f1" (gdb) p val $27 = 32

TokuDB: After ANALYZE TABLE

56

• Cardinality = 64 / 32 = 2

TokuDB: After ANALYZE TABLE

56

mysql> insert into test (f1, ts) select f1, NOW() from test; Query OK, 64 rows affected (0.01 sec) Records: 64 Duplicates: 0 Warnings: 0 mysql> insert into test (f1, ts) select f1, NOW() from test; Query OK, 128 rows affected (0.01 sec) Records: 128 Duplicates: 0 Warnings: 0 mysql> insert into test (f1, ts) select f1, NOW() from test; Query OK, 256 rows affected (0.02 sec) Records: 256 Duplicates: 0 Warnings: 0 mysql> select count(distinct id), count(distinct f1) from test; +--------------------+--------------------+ | count(distinct id) | count(distinct f1) | +--------------------+--------------------+ | 512 | 2 | +--------------------+--------------------+ 1 row in set (0.01 sec)

TokuDB: Let’s Insert More Data

57

• SHOW INDEX

mysql> show index from test\G *************************** 1. row *************************** Table: test Non_unique: 0 Key_name: PRIMARY Column_name: id Cardinality: 512 ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Column_name: f1 Cardinality: 16 ...

TokuDB: After INSERT

58

• Number of rows

$ ../bin/tokuftdump --header --nodata var/mysqld.1/data/test/test_key_f1_145_1_1d_B_1.tokudb ft: layout_version=29 layout_version_original=29 layout_version_read_from_disk=29 build_id=0 build_id_original=0 time_of_creation= 1537709029 Sun Sep 23 16:23:49 2018 time_of_last_modification=1537709880 Sun Sep 23 16:38:00 2018 ... estimated numrows=512 estimated numbytes=5120 logical row count=512

TokuDB: After INSERT

58

• Index Statistics

Thread 44 "mysqld" hit Breakpoint 1, TOKUDB_SHARE::set_cardinality_counts_in_table (this=0x7fd86da54020, table=0x7fd86d90b020) at /home/sveta/src/percona-server/storage/tokudb/ha_tokudb.cc:400 400 if (val == 0 || _rows == 0 || (gdb) p key->name $30 = 0x7fd86d879999 "f1" (gdb) p val $31 = 32

TokuDB: After INSERT

58

• Cardinality = 512 / 32 = 16

TokuDB: After INSERT

58

• SHOW INDEX

mysql> show index from test\G *************************** 1. row *************************** Table: test Non_unique: 0 Key_name: PRIMARY Column_name: id Cardinality: 512 ... *************************** 2. row *************************** Table: test Non_unique: 1 Key_name: f1 Column_name: f1 Cardinality: 16 ...

TokuDB: After Restart

59

• Index Statistics

Thread 44 "mysqld" hit Breakpoint 1, TOKUDB_SHARE::set_cardinality_counts_in_table (this=0x7fd4e67ea020, table=0x7fd4e6765c20) at /home/sveta/src/percona-server/storage/tokudb/ha_tokudb.cc:400 400 if (val == 0 || _rows == 0 || (gdb) p key->name $3 = 0x7fd4e66d7599 "f1" (gdb) p val $4 = 32

TokuDB: After Restart

59

• Cardinality = 512 / 32 = 16

TokuDB: After Restart

59

• Cardinality = 512 / 32 = 16
• Same!

TokuDB: After Restart

59

• Index statistics updated only when ANALYZE

TABLE is running

TokuDB: Conclusion

60

• Index statistics updated only when ANALYZE

TABLE is running

• Logical row count updated each time when

number of rows change

TokuDB: Conclusion

60

• Index statistics updated only when ANALYZE

TABLE is running

• Logical row count updated each time when

number of rows change

• Cardinality based on both numbers

TokuDB: Conclusion

60

• Index statistics updated only when ANALYZE

TABLE is running

• Logical row count updated each time when

number of rows change

• Cardinality based on both numbers
• It is expected the cardinality is not the same
• After updates
• Even when ANALYZE TABLE never run

TokuDB: Conclusion

60
