Best-Path vs. Multi-Path Overlay Routing

David G. Andersen (MIT) Alex C. Snoeren (UCSD) Hari Balakrishnan (MIT)

October 2003 http://nms.lcs.mit.edu/ron/

Overview

Best-path vs. redundant overlay routing

• What tactics work best to

– Reduce loss? – Reduce latency? – Avoid outages?

• In what circumstances do they perform best?
• Implications for new strategies

Context: Reliability via Path Diversity

• Backup links provide alternatives

➔ Mechanisms for obtaining diversity (existing diversity) ➔ Mechanisms for using diversity (overlay techniques)

Obtaining Diversity

Engineered diversity:

• Exploiting existing diversity:

Existing AS-level Redundancy

• Traceroute between 12 hosts,

showing Autonomous Systems (AS’s)

AS5650 AS6521 AS1239 AS226 AS3967 AS210 AS701 UTREP AS3 AS7015 AS1742 AS145 AS1 AS7922 AS7018 AS3561 AMNAP AS209 AS1103 AS3756 AS6453 AS1785 AS3356 AS8297 AS5050 AS9 AS13790 AS702 AS26 AS1200 AS9057 AS8709 AS7280 AS13649 AS6114 AS1790

CCI Utah Aros Sightpath NYU CA−T1 CMU MA−Cable MIT VU−NL Cornell

vBNS NYSERNet Abilene Known private peering

Exploiting Diversity via overlays

• Send packets through cooperating peers
• End-hosts only, no network support

Exploiting Diversity via Overlays

Reactive Routing

• Probe paths
• Route via best
• RON (SOSP’01)

Detour

Probes and Routing Updates

Exploiting Diversity via Overlays

Reactive Routing

• Probe paths
• Route via best

Probes and Routing Updates

• Redundant Routing
• Parallel paths
• No probing
• Mesh routing

(SOSP’01)

Reactive vs. Redundant Routing

0% 100% 100%

Capacity limit

Desired Loss Rate Improvement % Capacity used by data Data Traffic Probe/Redundant Traffic

• Capacity limits probing and redundancy

Reactive vs. Redundant Routing

0% 100%

Independence Best Expected

100%

Capacity limit Path Limit Limit

Desired Loss Rate Improvement % Capacity used by data

• Reactive limit: best path performance
• Redundant limit: Path independence

Reactive vs. Redundant Routing

0% 100%

Reactive

Independence Best Expected

100%

Capacity limit Path Limit Limit

Desired Loss Rate Improvement % Capacity used by data

Redundant

• Reactive limit: best path performance
• Redundant limit: Path independence

Reactive vs. Redundant Routing

0% 100%

Reactive Redundant

Independence Best Expected

100%

Capacity limit Path Limit Limit

Desired Loss Rate Improvement % Capacity used by data

• Reactive limit: best path performance
• Redundant limit: Path independence
• Overhead scaling: throughput vs. nodes

8 Routing Methods

Direct Single packet, direct path Direct Direct 2 packets, direct, no spacing DD 10ms 2 packets, direct, 10ms spacing DD 20ms 2 packets, direct, 20ms spacing

8 Routing Methods

Direct Single packet, direct path Direct Direct 2 packets, direct, no spacing DD 10ms 2 packets, direct, 10ms spacing DD 20ms 2 packets, direct, 20ms spacing Lat Reactive routing, min latency Loss Reactive routing, min loss

8 Routing Methods

Direct Single packet, direct path Direct Direct 2 packets, direct, no spacing DD 10ms 2 packets, direct, 10ms spacing DD 20ms 2 packets, direct, 20ms spacing Lat Reactive routing, min latency Loss Reactive routing, min loss Direct Rand 2pkts, Redundant routing, simplest

8 Routing Methods

Direct Single packet, direct path Direct Direct 2 packets, direct, no spacing DD 10ms 2 packets, direct, 10ms spacing DD 20ms 2 packets, direct, 20ms spacing Lat Reactive routing, min latency Loss Reactive routing, min loss Direct Rand 2pkts, Redundant routing, simplest Lat Loss 2pkts, Reactive + Redundant (Falls back to random)

Probing on Internet Testbed

Each node repeats:

• 1. Pick random node j
• 2. Pick one of the 8 routing types

(direct, loss, lat, etc.) in round-robin order. Send to j.

• 3. Delay for random interval [0.6s - 1.2s]

Probes are one-way, recorded at sender & receiver.

Datasets From Internet Deployment

Dataset Nodes Time Measurements RONwide 17 5 days 4.7M RONnarrow 17 3 days 2.8M RON2003 30 14 days 32.6M ✔ Variety of network types and bandwidths 5 int’l, 3 Cable/DSL, 7 universities... ✔ N 2 path scaling ∼ 900 paths

One-way Loss Rates Are Low

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1 2 3 4 5 6 7

fraction of paths average path−wide loss rate (%) 2003 dataset 2002 dataset 90% of paths under 1% loss rate

• Overall loss

0.42% in 2003

• Includes quiescent periods
• Outages still (painfully) apparent

Duplication Reduces Overall Loss

Type Loss % direct 0.42 direct direct 0.30 dd 10ms 0.27 dd 20ms 0.27

Duplication Reduces Overall Loss

Type Loss % direct 0.42 direct direct 0.30 dd 10ms 0.27 dd 20ms 0.27 Lat 0.43 Loss 0.33 Direct Rand 0.26 Lat Loss 0.23

Loss Probabilities Sanity Check

• 0.42% loss << [Paxson 94,95] (2.8%, 5%).
• Unloaded paths vs. loaded by TCP transfer
• Conditional loss probabilities are similar

Study P(lose P2|lost P1) Paxson TCP ∼ 50% Bolot 8ms spacing 60% RON2003 no spacing 72% RON2003 20ms 65% RON2003 direct rand 62%

Latency Improvements

0.7 0.75 0.8 0.85 0.9 0.95 1 50 100 150 200 250 300 Fraction of paths Latency (ms)

lat loss lat direct rand direct Mean Latency 48.0 51.7 54.1

5% of connections exhibit large latency improvement

46.8 ms

Unlike loss, most latency from specific bad paths

# High Loss Periods (1 hr, normalized)

Type > 0% direct 1 (8817) direct direct 0.59 dd 20ms 0.43 Lat 1.2 Loss 0.80 ← Worse than naive duplication Direct Rand 0.44 for low loss situations Lat Loss 0.38

# High Loss Periods (1 hr, normalized)

Type > 0% > 30% direct 1 (8817) 1 (630) direct direct 0.59 0.93 dd 20ms 0.43 0.91 Lat 1.2 0.96 Loss 0.80 0.91 ← on par Direct Rand 0.44 0.92 Lat Loss 0.38 0.89

# High Loss Periods (1 hr, normalized)

Type > 0% > 30% > 60% direct 1 (8817) 1 (630) 1 (255) direct direct 0.59 0.93 0.98 dd 20ms 0.43 0.91 0.98 Lat 1.2 0.96 0.91 Loss 0.80 0.91 0.86 ★ Direct Rand 0.44 0.92 0.92 ★ Lat Loss 0.38 0.89 0.84 ★

Measurement Summary

✔ Redundant beats reactive for low loss – “Meshing” beats controls during outages ✔ Reactive finds specific good paths – Latency improvements – Low loss paths ✘ No overlay technique near independent paths – Hypothesis: Access link failures – More severe outages harder to correct

Why Not FEC?

Redundant assumption: Fast recovery, low rate 0.42% loss rate → need little redundancy

...100 packets... Recovery 1st packet lost

X

Failure losses bursty (≥ 0.5 conditional loss) ✘ Spread FEC over even more packets ➔ Latency-critical traffic: 2-redundant mesh

Conclusions

• Loss rate for low-rate traffic low (0.42%)
• Conditional loss probability high (0.72)

even for random mesh (0.62)

• 40-60% of loss avoidable

✔ Reundant: Avoiding low loss rates ✔ Reactive: Avoiding high loss, latency ➔ Low loss suggests selective approach ...

Future Work

Strategies for avoiding losses and outages:

• Selective redundancy: Protecting SYNs, etc.

(shameless plug: Currently implementing)

• Selective probing: Activate on first loss

Measurements:

• Engineered network redundancy impact?

(testing now, looking for multihomed sites) http://nms.lcs.mit.edu/ron/

Scaling

• Reactive: Scales with # nodes
• Redundant: Scales with traffic volume

Best Path Scaling

Routing and probing add packets: Responsiveness vs. overhead vs. size

10 nodes 13.3Kbps 30 nodes 2.2Kbps 33Kbps 50 nodes 35000 5 10 15 20 25 30 35 40 45 50 Overhead (bits/second) Number of Nodes Overhead 25000 20000 15000 10000 5000 30000

• 50 nodes near limit, enough for many apps.

Best Path Routing

Probes and Routing

• Frequently measure all inter-node paths
• Exchange routing information
• Route along app-specific best path

consistent with routing policy

Probing and Outage Detection

Record "success" with RTT 6

Node A Node B

I n i t i a l P i n g R e s p

• n

s e 1 R e s p

• n

s e 2 ID 5: time 10 ID 5: time 15 ID 5: time 33 ID 5: time 39 Record "success" with RTT 5

• Probe every random(14) seconds
• 3 packets, both sides get RTT and reachability
• If “lost probe,” send next immediately

Timeout based on RTT and RTT variance

• If N lost probes, notify outage

Architecture: Probing

• ➔ Probe between nodes, determine path qualities

– O

• N 2

probe traffic with active probes – Passive measurements
