SLIDE 1
Berry Bypass Urban Design Strategy
Berry Bridge and Northern Interchange
7 March 2012
Contents
- Precincts
- Setting
- North Approach
- Community Feedback
- Design Principles
- Design Response
Berry Bypass Urban Design Strategy Berry Bridge and Northern - - PowerPoint PPT Presentation
Berry Bypass Urban Design Strategy Berry Bridge and Northern - - PowerPoint PPT Presentation
Berry Bypass Urban Design Strategy Berry Bridge and Northern Interchange 7 March 2012 Contents - Precincts - Setting - North Approach - Community Feedback - Design Principles - Design Response Precinct Location Plan Berry Bridge &
SLIDE 2
SLIDE 3
North Street Precinct Kangaroo Valley Road Interchange & Victoria St Precinct Berry Bridge & Northern Interchange Precinct
Precinct Location Plan
SLIDE 4
SLIDE 5
SLIDE 6
SLIDE 7
SLIDE 8
SLIDE 9
SLIDE 10
SLIDE 11
SLIDE 12
SLIDE 13
SLIDE 14
SLIDE 15
SLIDE 16
SLIDE 17
SLIDE 18
SLIDE 19
SLIDE 20
SLIDE 21
Exhibited Design
Prestressed concrete bridge option – view from Woodhill Mountain Rd
SLIDE 22
Exhibited Design
Prestressed concrete bridge option – typical cross section
SLIDE 23
Super T concrete bridge option – view from Woodhill Mountain Rd
Exhibited Design
SLIDE 24
Exhibited Design
Super T concrete bridge option – typical cross section
SLIDE 25
Exhibited Design
Woodhill Mountain Road crossing bridge height comparison
SLIDE 26
SLIDE 27
Community Feedback
Berry Bridge
Summary of Berry Bypass Alignment Issues Report, Jan 2012
Develop design options to clarify preferred community design direction. Heritage Response Involve NSW Government Architect in design review process. Design Process Minimise expansion joints and adopt low noise pavement. Noise Mitigation Develop urban and landscape reference design, and bridge architecture. Visual Impact
Design Response Issues
SLIDE 28
Overall Objective
Integrate the Berry Bridge and Northern Interchange structures and earthworks within the landscape of northeast Berry. Berry Bridge - Urban Design Principles
- Develop bridge architecture that complements the pastoral setting.
- Maximise retention of existing screen landscape.
- Minimise bridge piers and profile.
- Keep undercroft areas open, ventilated and with access to light.
- Maintain a consistent bridge profile without awkward junctions,
steps or faceting.
- Explore opportunities to reflect the unique character of Berry
and the Shoalhaven.
- Utilise locally sourced stone for abutment linings and scour protection.
SLIDE 29
Berry Bridge Sketch Alternative 1
- Prestressed concrete planks (15m span)
- Integrated headstocks
- Cost effective rectilinear frame support.
Typical Cross Section Elevation at Pier
SLIDE 30
Advantages:
- Smoother vertical curve/less faceted
- Thin profile
- Attractive integrated support piers
- Cost competitive overall
Disadvantages:
- More columns, closer together
SLIDE 31
Berry Bridge Sketch Alternative 2
- Super ‘T’ concrete beams (35m span)
- Integrated headstocks
- Headstock recessed in depth of beams
- Cost effective rectilinear frame support
Typical Cross Section Elevation at Pier
SLIDE 32
Advantages:
- Attractive integrated/recessed support piers
- Less columns than with Planks
Disadvantages:
- Less columns than with Planks
- Faceting of vertical curve may cause difficult junctions
SLIDE 33
SLIDE 34
SLIDE 35
Community Feedback
Northern Interchange
Summary of Berry Bypass Alignment Issues Report, Jan 2012
Road design optimised to reduce heavy vehicle braking. Truck Noise Impact Investigate traffic demand for second north bound
- ff ramp.
Second North Bound Off Ramp
Design Response Issues
SLIDE 36
Northern Interchange - Urban Design Principles
- Minimise the visual presence of interchange structures.
- Minimise impacts on existing properties and access.
- Minimise the interchange footprint.
- Retain mature trees along the highway.
- Consider the sequential views on the northern approach.
- Contribute to the township arrival/departure experience and to legibility.
- Develop Berry township entry signage strategy.
- Frame rural and township views from elevated vantage points.
- Relocate Berry Memorial sculptures.
SLIDE 37
SLIDE 38
A A B B C C
SLIDE 39
Section A
SLIDE 40
Section B
SLIDE 41
Section C
