BEAM Alliance

Enjoy the messy moments…

Dealer Welcome Presentation

No more selling just a power unit! Instead, we are selling a Central Vacuum System. Includes:

• Power Unit
• Hose Set
• Cleaning Accessories

BEAM Alliance : Innovation in Central Vacuum Systems

BEAM Alliance : Power Unit Overview

Press & Release Bucket Simply press down on any two points around the ring and pull down to empty the

• bucket. The bucket is easily

snapped back into place with one hand. HEPA Filtration Now there is not need to vent to the outdoors. The BEAM Alliance HEPA Filter removes any impurities left in the air before it is re-circulated. Breathe easy! Quick Clean Valve Opens easily with the touch of a

• finger. The Quick Clean valve is

powered and lets you turn on the system from the hose handle. Use for quick clean-ups around the area of the power unit. Smart Screen The Advanced Smart Screen is interactive and keeps you informed about your system’s performance with a motion detecting LCD screen that illuminates to provide status information such as motor speed, suction level and when to empty the dirt receptacle. HE Motor A flow-through HE motor is at the heart of every BEAM Alliance vacuum system. HE motors perform better, make less noise, and last longer — Up to four times

• longer. You’ll get the same optimal

performance you have come to trust with BEAM while using 30% less energy. Self Cleaning GORE-TEX Filter The exclusive BEAM Self Cleaning Filter with GORE-TEX filters out 98% of particles at .3 microns such as dust, pollen, bacteria, and pet dander. The Self Cleaning Filter protects the HE motor for prolonged life with no loss of performance as the dirt bucket fills up. No bags required!

BEAM Alliance: Alliance Cleaning Set Overview

BEAM Alliance Interface The Alliance monitoring system communicates with the LED interface of the hose handle to keep you informed about the system level performance while

• vacuuming. The advanced

fingertip controls adjust suction and turn the entire system on/off with the push of a button. DD Shape Nozzle Improves airflow and cleaning performance and decreases the airflow noise from hose handle. Crush Proof Hose Available in 9m, 10m, and 12m hose lengths. The universal hose cuff will fit all inlet valves. 3-in-1 Cleaning Tool The on-board 3-in-1 cleaning tool means you always have the right tool at hand. Easily converts from a dusting brush to crevice and fabric tool. Beam Q Powerhead The quietest electric powerhead

• n the market, the BEAM Q
• ffers 3 height-adjustment levels

and the E-Z Change™ release that quickly disconnects the wand from the powerhead for touch-up cleaning.

BEAM Alliance : Smart Controls at your Fingertips

On/Off Variable Speed Indicator Powerhead Control Variable Speed Control

BEAM Alliance : Intelligently Designed for Smarter Cleaning

High Efficiency motors offer higher performance and uses 30% lower energy consumption than traditional central vacuum system motors.

Maximum cleaning performance – with the combination of a more powerful motor and fully sealed AeroPro™ hose & wand, BEAM Alliance is able to provide SUPERIOR clean ability test results. Advanced Sound Suppression – BEAM Alliance

• ffers the quietest central vacuum at both the

power unit & during actual cleaning, delivering 700 air watts!!!

BEAM Alliance : HE Motor Technology

Domel HE Motor

• Flow Thru Motor
• Single Stage
• 5.3” Fan
• High RPM
• 50,000 RPM
• High Air Watt
• 700 AW
• High Efficiency
• 44%
• Low Vibration
• Quiet Operation
• Longer Life
• 800+ Hours

HE Motor Enclosure

• Exclusive to Beam Alliance
• Alliance Dealers Exclusive
• Fully Engineered System
• Patent Pending
• Optimized Air Flow
• 100% Sealed Air Path
• Sound control
• HEPA exhaust
• Sound Suppression
• Ease of Service
• Entire POD
• Motor
• Circuit Board

Meet the Family

BEAM Alliance Central Vacuum Systems

The Plus X Award for innovative technologies and lifestyle products honors manufacturers for their quality advantage. It distinguishes products that are innovative and viable for the future and possess at least one "Plus X" factor – the additional value of a product.

Recipient of the prestigious

BEAM Alliance : Model 700TC

The top-of-the-line power unit intelligently designed for large families living in large homes. It combines ultimate cleaning performance with visually attractive Smart Screen technology, providing complete system monitoring with direct link to the handle.

Part #: 700TCN01A

Air watts 700 Size 15 x 43 in Press & Release bucket 4 gal Quick Clean Valve Powered Filtration Self Clean Gore Sound suppression 68 dB Smart screen Advanced System On Indicator Yes LED Backlit & Ring Yes Motion Sensor Yes Empty Bucket Yes Performance Bars Yes Motor speed Yes Hose Link Icon Yes Navigation Buttons Yes Motor Fault Icon Yes Clock/Error Code Yes HEPA filter Yes Paper bag & adaptor Optional MSRP $1169.99

BEAM Alliance : Model 700TB

Designed to clean medium to large size homes with frequent cleaning needs powered through the new space-saving small- size model. It combines strong cleaning performance with attractive Smart Screen technology, providing complete system monitoring with a direct link to handle.

Part #: 700TBN01A

Air watts 700 Size 15 x 43 in Press & Release bucket 4 gal Quick Clean Valve Powered Filtration Self Clean Gore Sound suppression 68 dB Smart screen Intelligent System On Indicator Yes LED Backlit & Ring Yes Motion Sensor Yes Empty Bucket Yes Performance Bars

• Motor speed
• Hose Link Icon

Yes Navigation Buttons

• Motor Fault Icon

Yes Clock/Error Code

• HEPA filter

Optional Paper bag & adaptor Optional MSRP $1099.99

BEAM Alliance : Model 650SB

Intelligently designed for small to medium size homes, combining high performance with an attractive design. The integrated system performance screen with the attractive 360° light-ring links with the hose handle, providing continuous system monitoring for optimal cleaning.

Part #: 650SBN01A

Air watts 700 Size 15 x 36 in Press & Release bucket 4 gal Quick Clean Valve Powered Filtration Self Clean Gore Sound suppression 68 dB Smart screen Intelligent System On Indicator Yes LED Backlit & Ring Yes Motion Sensor Yes Empty Bucket Yes Performance Bars

• Motor speed
• Hose Link Icon

Yes Navigation Buttons

• Motor Fault Icon

Yes Clock/Error Code

• HEPA filter

Optional Paper bag & adaptor Optional MSRP $1049.99

BEAM Alliance : Model 600SA

The new space-saving compact design features good cleaning performance and innovative features for small to medium

• homes. The integrated system performance screen with the

attractive 360° light-ring links with the hose handle, providing continuous system monitoring for optimal cleaning.

Model: 600SA

Air watts 600 Size 15 x 36 in Press & Release bucket 4 gal Quick Clean Valve Powered Filtration Self Clean Gore Sound suppression 68 dB Smart screen Simple System On Indicator Yes LED Backlit & Ring

• Motion Sensor
• Empty Bucket
• Performance Bars
• Motor speed
• Hose Link Icon
• Navigation Buttons
• Motor Fault Icon

Yes Clock/Error Code

• HEPA filter

Optional Paper bag & adaptor Optional MSRP $849.99

BEAM Alliance : Power Unit Line

600SA 650SB 700TB 700TC Air Watts

600 650 700 700

Cylinder Height

36” 36” 43” 43”

Cylinder Diameter

15” 15” 15” 15”

User Interface

Smart Screen A Smart Screen B

Smart Screen B Smart Screen C

2-way Communication w/Handle Motor Fault Icon Bucket Level Icon System Performance / Warning Light ring w/ Motion Sensor Quick Clean LV Valve Exhaust Muffler HEPA Filter

BEAM Alliance : Individual Hose Sets

Cleaning Sets Length Part #

Beam Alliance Q 30ft, 35ft 012337, 012329 Beam Alliance Solaire 30ft, 35ft 012336, 012330 Beam Alliance Air Kit 30ft, 35ft 060871, 060890

BEAM Alliance : Alliance Cleaning Sets

Standard Accessories: Air Kit Solaire Beam Q

Hose Length 30ft/35ft 30ft/35ft 30ft/35ft Alliance Handle w/2 Way Communication Variable Speed Controls Electric Powerbrush Height Adjustment

BEAM Alliance : Marketing Support

Spec Sheets Image Library

The Alliance of Dealer Support

Enjoy the Messy Moments : Party Scenario

A new marketing campaign to evoke emotion and connect with consumers.

Enjoy the Messy Moments : Kitchen Scenario

Creating real life scenarios of a fun and memorable messy moment.

Enjoy the Messy Moments : Foyer Scenario

Messy moments created in a tidy and organized living environment.

BEAM Website : Main Page

Lifestyle image carousel

• Rotates through images of various messy moments

What will a BEAM Central Vacuum do for me?

• Links to Benefits of a Beam Page

Which BEAM is right for me?

• Links to Product Wizard

How does it work?

• How a central vacuum works
• Warranty information
• Owner’s manuals
• Trouble shooting / FAQ

How is it installed?

• New home build installation
• Existing home installation
• Do it yourself
• Installation materials

Did you know?

• Clinical proof
• Indoor air quality facts
• Filtration facts
• Cleaning tips
• Glossary of terms

What do they say?

• Links to Social Media

BEAM Alliance Consumer Brochure

Enjoy the messy moments…

Connecting with consumers through emotional marketing.

BEAM Alliance Spec Sheets

Front highlights features & benefits of the model. Back highlights product specs of power unit.

BEAM Alliance Brand Guidelines

BEAM Alliance : Price List

BEAM Alliance Animated Videos

5 New Animated Videos

Press & Release Bucket Self Cleaning Filtration 3-in-1 Cleaning Tool Quick Clean Utility Valve Alliance System Monitoring www.beamvac.com www.youtube.com/beamcentralvac/

Product Display Stand

Display Features:

• Branded cleaning attachments
• Organized product placement
• Interactive multimedia monitor
• Consumer literature

Modular Wall Features:

• Able to hold complete Beam Alliance

product line

• Live product (piped and plugged)
• Includes wall inlets
• Accessible power bars
• Vac pan (double modular)
• Powerhead shelves
• Interchangeable display boards

Modular Display Size:

• 4 Unit: (11’ w x 8’h x 2.5’d)
• 3 Unit: (9’ w x 8’h x 2.5’d)
• 2 Unit: (7’ w x 8’h x 2.5’d)

Remember to enjoy the messy moments…
