Basic Concrete Tests Plastic Concrete Basic Tests Cylinder Compression Splitting Tension Beam Flexure Elastic Modulus Slump Unit Weight and Yield Air Content CIVL 3137 2 Slump The concrete slump test measures the workability of fresh

slide-1
SLIDE 1

Basic Concrete Tests

Plastic Concrete

slide-2
SLIDE 2

CIVL 3137 2

Basic Tests

Cylinder Compression Splitting Tension Beam Flexure Elastic Modulus Slump Unit Weight and Yield Air Content

slide-3
SLIDE 3

Slump

The concrete slump test measures the workability of fresh concrete by indirectly assessing the shearing resistance of the plastic concrete under its own weight. The test specification (ASTM C143) dates all the way back to 1922!

CIVL 3137 3

slide-4
SLIDE 4

CIVL 3137 4

slide-5
SLIDE 5

Slump

To perform the test, a conical metal mold called a slump cone is filled with fresh concrete. The slump cone is 12" tall and has a diameter of 4" at the top and 8" at the bottom. As with the dry-rodded unit weight test for aggregate, the mold is filled in three lifts of equal volume and each lift is rodded 25 times with a tamping rod to eliminate any voids in the specimen.

CIVL 3137 5

slide-6
SLIDE 6

Slump Cone

CIVL 3137 6

12" 4" 8"

slide-7
SLIDE 7

Slump

The concrete is then struck off level with the top of the mold and the mold is carefully lifted vertically upwards, allowing the now-unsupported concrete to subside (slump). The test measurement is the change in the height of the concrete from the supported to the unsupported

  • condition. This is called the slump, and is measured

to the nearest ¼ inch.

CIVL 3137 9

slide-8
SLIDE 8

Slump Test

CIVL 3137 10

http://cemsolutions.org/concrete-slump-test/

slide-9
SLIDE 9

Slump

The slump test is an index test. The higher the slump the more fluid is the concrete. Thus, it can tell you something about the consistency of the concrete. The shape of the slumped concrete can also tell you something about the cohesion of the concrete. A shear slump indicates a lack of cohesion and possible

  • segregation. A collapse slump suggests a mix that is

too wet or has too little cement and may be harsh.

CIVL 3137 12

slide-10
SLIDE 10

CIVL 3137 13

Slump Types

“True” slump Good cohesion Good consistency Collapse Slump Too lean or too wet May be harsh Shear Slump Lacks cohesion May segregate

slide-11
SLIDE 11

CIVL 3137 14

Basic Tests

Cylinder Compression Splitting Tension Beam Flexure Elastic Modulus Slump Unit Weight and Yield Air Content

slide-12
SLIDE 12

CIVL 3137 15

slide-13
SLIDE 13

Unit Weight

CIVL 3137 16

http://www.dot.state.oh.us

slide-14
SLIDE 14

Unit Weight

CIVL 3137 17

  • D = unit weight (density) of concrete (lb/ft3)

Mc = mass of unit weight measure filled with concrete (lb) Mm = mass of unit weight measure empty (lb) Vm = volume of unit weight measure (ft3)

Typical values are 140 lb/ft3 to 150 lb/ft3!

slide-15
SLIDE 15

Yield

CIVL 3137 18

Y = yield (volume of concrete produced per batch) (yd3) M = total mass of ingredients in each batch (lb) D = unit weight of concrete (lb/ft3)

Yield is used for quality control purposes

slide-16
SLIDE 16

Relative Yield

CIVL 3137 19

  • Ry = relative yield (dimensionless)

Y = yield (volume of concrete produced) (yd3) Yd = volume of concrete intended (yd3)

Sometimes expressed as ft3 per yd3 since mix designs are typically done for 1 yd3

slide-17
SLIDE 17

Cement Content

CIVL 3137 20

  • C = cement content (lb/yd3)

Cb = mass of cement in the batch (lb or kg) Y = yield (volume of concrete produced) (yd3 or m3)

Sometimes divided by 94 lb per sack of cement to get cement content in “bags” (e.g., a 7-bag mix)

slide-18
SLIDE 18

Gravimetric Air Content

CIVL 3137 21

A = air content (% by volume) D = actual density of the concrete (lb/ft3) T = theoretical air-free density of the concrete (lb/ft3)

slide-19
SLIDE 19

Gravimetric Air Content

CIVL 3137 22

A = air content (% by volume) D = actual density of the concrete (lb/ft3) T = theoretical air-free density of the concrete (lb/ft3)

This is the same calculation we did for |the void content of aggregate!

slide-20
SLIDE 20

Theoretical Air-Free Density

CIVL 3137 23

T = theoretical air-free density of the concrete (lb/ft3) M = total mass of batched ingredients (lb) V = total absolute volume of batched ingredients (ft3)

𝑊 𝑁 𝑆𝐸 𝛿

slide-21
SLIDE 21

Example

CIVL 3137 26

Assume a 10-yd3 batch of concrete requires 3200 lb of water (RD = 1.00) 5800 lb of cement (RD = 3.15) 19,400 lb of gravel (RD = 2.68) 11,100 lb of sand (RD = 2.65)

slide-22
SLIDE 22

CIVL 3137 27

Example (cont.)

𝑊 3200 1.00 62.4 51.3 ft 𝑊 5800 3.15 62.4 29.5 ft 𝑊 19,400 2.68 62.4 116.0 ft 𝑊 11,100 2.65 62.4 67.1 ft 𝑊 263.9 ft Wwater 3,200 lb Wcement 5,800 lb Wgravel 19,400 lb Wsand 11,100 lb M 39,500 lb

slide-23
SLIDE 23

Example (cont.)

CIVL 3137 28

  • T = theoretical air-free density of the concrete (lb/ft3)

M = total mass of batched ingredients (lb) V = total absolute volume of batched ingredients (ft3)

slide-24
SLIDE 24

CIVL 3137 29

Example (cont.)

Vm = 0.251 ft3 Mm = 8.3 lb Mc = 45.0 lb

Vm should be measured to 3 significant digits Masses should be measured to nearest 0.1 lb

slide-25
SLIDE 25

Example (cont.)

CIVL 3137 30

  • Mc = mass of unit weight measure filled with concrete (lb)

Mm = mass of unit weight measure empty (lb) Vm = volume of unit weight measure (ft3) D = unit weight (density) of concrete (lb/ft3)

Typical values are 140 lb/ft3 to 150 lb/ft3!

slide-26
SLIDE 26

Example (cont.)

CIVL 3137 31

  • M = total mass of ingredients in each concrete batch (lb)

D = unit weight of concrete (lb/ft3) Y = yield (volume of concrete produced per batch) (yd3)

slide-27
SLIDE 27

Relative Yield

CIVL 3137 32

  • Y = yield (volume of concrete actually produced per batch) (yd3)

Yd = volume of concrete batch was designed to produce (yd3) Ry = relative yield (dimensionless)

A value less than 1.00 indicates the batch produced is “short” of its design volume

slide-28
SLIDE 28

Cement Content

CIVL 3137 33

  • Cb = mass of cement in the batch (lb or kg)

Y = yield (volume of concrete actually produced per batch) (yd3 or m3) C = cement content (lb/yd3)

C =

⁄ ⁄

= 6.2 bags per cubic yard

slide-29
SLIDE 29

Gravimetric Air Content

CIVL 3137 34

  • 2.7%

A = air content (% by volume) D = actual density of the concrete (lb/ft3) T = theoretical air-free density of the concrete (lb/ft3)

This is the same calculation we did for |the void content of aggregate!

slide-30
SLIDE 30

CIVL 3137 35

Basic Tests

Cylinder Compression Split Tension Beam Flexure Elastic Modulus Slump Unit Weight and Yield Air Content

slide-31
SLIDE 31

CIVL 3137 37

slide-32
SLIDE 32

CIVL 3137 38

Volumetric Method

The measuring bowl is filled with concrete, the device is assembled, and water is added to reach the zero mark in the neck. As the device is agitated (“rolled”), the air in the concrete is replaced by water from the top section and the water level in the neck drops in proportion to the air content.

slide-33
SLIDE 33

Volumetric Method

CIVL 3137 39

“roller meter”

slide-34
SLIDE 34

CIVL 3137 40

slide-35
SLIDE 35

CIVL 3137 41

Pressure Method (Type A)

The bowl is filled with concrete, the device is assembled, and water is added to reach the zero mark in the neck. As the unit is pressurized, the air bubbles compress, the concrete surface falls and the water level drops in proportion to the change in air volume.

slide-36
SLIDE 36

Type A Pressuremeter

CIVL 3137 42

slide-37
SLIDE 37

CIVL 3137 43

Pressure Method (Type B)

The bowl is filled with concrete, the device is assembled, and the air chamber is pressurized. When the air pressure is released into the bowl, the air bubbles compress, the concrete surface falls and the chamber pressure drops in proportion to the change in air volume.

slide-38
SLIDE 38

Type B Pressuremeter

CIVL 3137 44
