2017 WCPA Concrete Pavement Workshop Barry Paye P.E. Bureau of Technical Services WCPA 2017 Workshop Wisconsin Concrete Pavement Association February 16, 2017 2017 WCPA Concrete Pavement Workshop Concrete Tech Team Items Optimized

slide-1
SLIDE 1

Barry Paye P.E. Bureau of Technical Services WCPA 2017 Workshop

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-2
SLIDE 2

 Concrete Tech Team Items

  • Optimized Gradations & Mixtures PEM
  • Flexural Strength
  • MIT 2 Scanner
  • Dowel Bar & Tie Bar Updates
  • Joint Sealing

 Aggregate Specifications  Materials Coordinator Training

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-3
SLIDE 3

 Goal of Optimized Aggregate Gradation and

Concrete Mixtures:

  • Increase the volume of aggregate while decreasing the

volume of paste.

 Paste = Binder + Water

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-4
SLIDE 4

 Tarantula

Curve

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-5
SLIDE 5

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-6
SLIDE 6

 Individual gradations  2- 5 aggregates  Determine optimized

combined gradation

 Submit gradation  Apply the requirements

  • f the job mix formula

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-7
SLIDE 7

 Allows belt sampling  Sublot of 1500 CY of

concrete

 Lot is two sublots  4 point running average  Contractor eligible for a 3%

incentive

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-8
SLIDE 8

 Reduced cementitious

contents could be the new normal

 Volume of Paste to Volume

  • f Voids Ratio

 New national mix design

standard !!!

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-9
SLIDE 9

 WisDOT participating in national pooled fund

research project

 WHRP Research starting in 2017 to evaluate

current designs with the procedures

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-10
SLIDE 10

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-11
SLIDE 11

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-12
SLIDE 12

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-13
SLIDE 13

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-14
SLIDE 14

 It is a modified typical

ASTM C 231 pressure meter so that it can hold larger pressures

 We have replaced the

typical gage with a digital

  • ne

 The test takes 8 - 10

minutes

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-15
SLIDE 15

10 20 30 40 50

Pressure (psi) Time

Top Chamber, Pc Bottom Chamber, Pa Equilibrium Pressure

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-16
SLIDE 16

 WisDOT moving toward replacing compressive

strength cylinders with flexural strength beams

 SPV in use on the IH 39 corridor Madison-

Rockford

 Department is evaluating the impacts on staff and

laboratories for QV testing

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-17
SLIDE 17

 Strength parameter used in design  Key performance parameter

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-18
SLIDE 18

 Beam Molds  Beam Breakers  Curing and Storage of Beams  QC vs. QV and equivalent curing  Custody of beams for QV  Risk Management

  • Weight of beam and mold
  • transport

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-19
SLIDE 19

 Same PWL approach as compressive strength  Rejectable quality limit = 500 psi  Lower specification limit = 650 psi  Lot standard deviation less than 60 psi

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-20
SLIDE 20

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-21
SLIDE 21

Based on 2010 -2015 Flexural Strength Data

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-22
SLIDE 22

 2016 - first full year for pavement thickness

acceptance

 Section 415.3.16 of standard specs  References Procedure 8-70.4.7.2 of the CMM  WisDOT reviewed discrepancies between

contractor probing data and MIT-Scan results

 Cored projects correlated with the MIT-Scan

results

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-23
SLIDE 23

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-24
SLIDE 24

 250 foot basic units  2 plate locations  Measure one location 3

times and average

 2nd location is measured

if nonconforming

 Coring is the dispute

resolution and tool for finding limits of thin

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-25
SLIDE 25

 Dowel bars used on concrete pavement repair and

replacement projects.

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-26
SLIDE 26

 Tie bars installed in new concrete are usually #4

deformed bar, 24-inches long spaced between 21 to 48-inches center to center depending on the pavement thickness.

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-27
SLIDE 27

 Spacing based on thickness.

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-28
SLIDE 28

 Beginning in 2018 WisDOT will participate sealing

all joints on low speed urban projects

 Goal is to keep out incompressible and alleviate

joint distress

 “Great Unsealing” still valid reviewed high speed

rural pavements

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-29
SLIDE 29

Changes to Section 715 QMP Pavement and Structures

 715.3.1.2 Lot and Sublot Definition

  • Mix design change

 For paving mixes, a source change under item 1 of 710.4(5) for fly ash of the same class that does not require a modification under items 2 through 4 of 710.4(5) does not constitute a mix design change.  A new lot should be started when a new source is introduced however.

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-30
SLIDE 30

FLY ASH

 Class F Ash

  • Allowed on projects with a December 2016 or later LET.

 Not in the 2017 Standard Specifications  Allowed by ASP-6.

  • Must be listed of the departments APL, Approved

Products List.

  • Currently allows Prairie State Energy located in Marissa,

IL.

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-31
SLIDE 31

 Unique Source Identification Number  Aggregate Quality Testing Frequency  Tolerance and Dispute Resolution  Move QMP Base Aggregate STSP to Standard Spec  Lightweight Particles and Chert Revision  Base Coarse Compaction Use

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-32
SLIDE 32

Changes to Section 501

 501.2.5.4.4 Alkali Silica Reactivity Testing and

Mitigation Requirements

  • For course aggregates only:

 ASTM C1260  ASTM C1567

 501.2.5.4.5(4) to also allow #1 stone-only mixes in

foundations for soldier pile walls and noise walls.

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-33
SLIDE 33

 Only recent significant change is 501.2.5.4.4 on

Alkali Silica Reactivity

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-34
SLIDE 34

Changes to Section 106

 106.1.2 Project Materials Coordinator

  • (1) Ensure that this person is certified as having completed

the HTCP online materials coordinator training available at: https://www.uwplatt.edu/htcp/mct

  • (3) Also ensure that the contractor-designated materials

person participates in scheduled weekly construction meetings or meets with their department counterpart as requested.

 106.3.4.3.2 Process Control

  • (1) The department doesn’t require or use non-random

contractor tests for dispute resolution.

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-35
SLIDE 35

 Revised location/registration with HTCP website  MCT-D and MCT-C registration is open !

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-36
SLIDE 36

Materials Coordinator Training Registration

2017 WCPA Concrete Pavement Workshop Wisconsin Concrete Pavement Association February 16, 2017

slide-37
SLIDE 37

Barry Paye Materials Management Section Phone: 608-246-7945 Email: Barry.paye@dot.wi.gov
