CEF Approach in CESNET Backbone Network ACSAT Kuala Lumpur 2012 Outline CESNET CEF Approach CZECHLIGHT Future plans ACSAT

slide-1
SLIDE 1

CEF Approach in CESNET Backbone Network

ACSAT Kuala Lumpur 2012

slide-2
SLIDE 2

Outline

 CESNET  CEF Approach  CZECHLIGHT  Future plans

ACSAT Kuala Lumpur 2012

slide-3
SLIDE 3

CESNET

ACSAT Kuala Lumpur 2012

slide-4
SLIDE 4

CESNET

ACSAT Kuala Lumpur 2012

slide-5
SLIDE 5

CESNET

 The CESNET (Czech Educational and Scientific

Network) association was formed by the Czech universities (27) and Academy of Sciences of the Czech Republic in 1996

 Non-profit organization, funded by Ministry of

Education of the Czech Republic, association members and external sources (EU)

 First ISP in Czech republic  Now pure academic network  More details on www.ces.net

ACSAT Kuala Lumpur 2012

slide-6
SLIDE 6

Network Topology

ACSAT Kuala Lumpur 2012

slide-7
SLIDE 7

CEF Approach

Customer Empowered Fiber (CEF) concept

  • Leased dark fibers equipped by own transmission

technology

  • The first lines enlighted in 2000 (PoS STM-16 and

1 GE lines)

  • Standard SMF G.652 and NZDSF G.655 fiber

types

  • About 5,000 km of leased dark fiber lines

ACSAT Kuala Lumpur 2012

slide-8
SLIDE 8

CEF Approach

 Mostly the whole backbone on CEF  Both single-channel and DWDM  Cost effective solution on speed 10Gb and above  CBF – Cross Border Fiber  Commercial equipment and Cesnet developed

devices

ACSAT Kuala Lumpur 2012

slide-9
SLIDE 9

CzechLight

 CESNET fiber optics experimental facility  Development of fiber optics equipment  International cooperation and participation on

joint research activities

ACSAT Kuala Lumpur 2012

slide-10
SLIDE 10

CzechLight equipment

 Based on similar components like commercially

available devices

 Linux based management  Widely deployed in CESNET production network  Commercially available now  The family of equipment still growing

ACSAT Kuala Lumpur 2012

slide-11
SLIDE 11

CzechLight equipment

ACSAT Kuala Lumpur 2012

slide-12
SLIDE 12

CzechLight equipment

 Discrete EDFA optical amplifiers  Raman amplifiers  Variable Multiplexers  Reconfigurable Optical Add/Drop Multiplexer  Tunable CD Compensators  Photonic Switches  Photonic Switches with Multicast Option  Optical Channel Monitor

ACSAT Kuala Lumpur 2012

slide-13
SLIDE 13

Conclusion

 CEF seems to be viable methodology  Started be utilized outside CESNET

ACSAT Kuala Lumpur 2012

slide-14
SLIDE 14

The end

Thank for your attention! Q & A ?

ACSAT Kuala Lumpur 2012
