BA Systems 6th biannual Danish District Heating Days in Serbia, 19-21 April, 2017 April 20th 2017 Building Automation Systems DH Days Page 1 AGENDA 1. Company presentation 2. Welcome to our world 3. System headlines 4. Communications

slide-1
SLIDE 1

April 20th 2017 Building Automation Systems – DH Days Page 1

BA Systems

6th biannual Danish District Heating Days in Serbia, 19-21 April, 2017

slide-2
SLIDE 2

April 20th 2017 Building Automation Systems - Agenda Page 2

AGENDA

  • 1. Company presentation
  • 2. Welcome to ”our world”
  • 3. System headlines
  • 4. Communications
  • 5. Protocols
  • 6. Typical installations
  • 7. BAS Web Server
  • 8. BAS 918S/BAS 929S
  • 9. BAS 920
  • 10. Visualisation
  • 11. Built-in Web Server
  • 12. SCADA Client
  • 13. Installer benefits
  • 14. End-User benefits
slide-3
SLIDE 3

April 20th 2017 Building Automation Systems - Company Page 3

  • BA Systems is a Danish owned company with more than 20 years

experience in the building automation industry.

  • Established in 1986 as a software development company
  • Based in Northern Zealand, approx. 40 km North of Copenhagen,

close to Hillerød

  • From 1991 and onwards focused on BMS solutions with both

hardware and software developed in-house

  • Partners with NS Koncept DOO and Termonet DOO since 2008

Company presentation

slide-4
SLIDE 4

April 20th 2017 Building Automation Systems – Our World Page 4

Welcome to ”our world”

BAS920 BAS Web Server BAS 918S/ 929S BAS SCADA

slide-5
SLIDE 5

April 20th 2017 Building Automation Systems - Platform Page 5

What the system enables The BAS Series of controllers enables:

  • Full control of almost any conceivable system
  • Possibility for PLC like control
  • Many built-in protocols
  • Interface to a variety of other controllers and system
  • Data collection from many meter types and foreign controllers
  • All products have a built-in html5 compatible webserver

System headlines

slide-6
SLIDE 6

April 20th 2017 Building Automation Systems – Communications Page 6

Communications

RS232 RS485 M-Bus RS232

Wi-Fi/4G BAS SCADA Server SQL Server PC/BAS Tool Ethernet/IP Browser/html5 Remote Management Internet/Intranet Android BAS Web Server iOS

M-Bus meters Modbus units Modbus units Kamstrup meter M-Bus meters

BAS 920

Modbus unit

BAS OPC Server BAS 918S BAS 929S BAS 920

Modbus units Modbus units

slide-7
SLIDE 7

April 20th 2017 Building Automation Systems – Installations Page 7

Protocols

BAS920 Protocols RS232 RS485 M-Bus LON IP KNX BACnet Slave Modbus Master Master Master/Slave M-Bus Master Master Geni Master DNIP Master Kamstrup Master KMP Master Master BAS Native Master/Slave LON Master/Slave KNX Master/Slave Physical Interface

BAS WS Protocols RS232 RS485 M-BUS IP (ethernet) BACnet Slave Modbus Master Master Master/Slave M-Bus Master Master BAS Native Master/Slave Kamstrup Master KMP Master Master Physical Interface BAS9XXS Protocols RS232 RS485 M-Bus LON IP KNX WM-Bus BACnet Slave Modbus Master Master Master/Slave M-Bus Master Master Kamstrup Master KMP Master Master BAS Native Master/Slave LON Master/Slave KNX Master/Slave WM-Bus Master Physical Interface

Contains 3xRS232, RS485 and M-Bus Only one interface can be mounted i.e. M-Bus, LON, KNX, RS485 or WM-Bus Contains 1xRS232 RS485 and M-Bus as optional modules KNX or LON as optional internal modules Modular with up to 140 I/O channels

slide-8
SLIDE 8

April 20th 2017 Building Automation Systems – Installations Page 8

A BAS installation can range from a: Single controller that controls a simple plant like a kindergarten where the systems controls:

  • floor heating
  • mechanical ventilation
  • hot-water heater
  • radiator system
  • meter data collection

The BAS Series controllers can also be scaled:

  • To a virtually limitless plant
  • Individual controllers shares data
  • Creates a large virtual controller
  • Uses built-in Ethernet connectivity

Typical installations

slide-9
SLIDE 9

April 20th 2017 Building Automation Systems – Web Server Page 9

Data collection and possibly control

Data collection:

  • Modbus data collection
  • M-Bus data collection
  • Counter inputs and digital inputs

Control:

  • Modbus control of discrete HVAC unit(s)
  • ECL Series
  • Samson

System features:

  • Energy Efficient management
  • Cost optimized solution
  • All data (consumptions, temperature, ...), may be presented in graphics and

accessed remotely via the html5 based web server and/or OPC, SCADA aso.

  • Extensive datalogging and web services

Example, BAS Web Server

slide-10
SLIDE 10

April 20th 2017 Building Automation Systems – BAS 918S/BAS 929S Page 10

Control and possibly data collection BAS 918S or BAS 929S depending on the needed I/O count

Control of:

  • HVAC
  • Hotwater heater
  • Central heating

Data collection:

  • Modbus or M-Bus data collection
  • Counter inputs, digital inputs and analog inputs

System features:

  • Energy Efficient management
  • Cost optimized solution
  • Easy local control via color display and button
  • Ability to share data across the network with other BAS Series controllers
  • All data (consumptions, temperature, ...), may be presented in graphics and

accessed remotely via the web server and/or OPC, SCADA aso.

Example, BAS 918S/929S

slide-11
SLIDE 11

April 20th 2017 Building Automation Systems – BAS 920 Page 11

Control and data collection BAS920 + extension modules totalling up to 140 channels

Control of:

  • PLC like control, freely programmable
  • ”Anything that can be measured, can also be controlled”
  • Compatible with foreign SCADA systems via OPC, BACnet/IP or Modbus/IP

All BAS Series controllers can communicate directly with each other and exchange any available data Data collection:

  • Modbus or M-Bus data collection
  • Counters, Analog inputs and calculated values

System features:

  • Very flexible and efficient industrial strength control with powerful programming.
  • Compatible with foreign systems via our open platform with many protocols.
  • Large scale SCADA system available

Example, BAS 920

slide-12
SLIDE 12

April 20th 2017 Building Automation Systems - Visualisation Page 12

  • Using html5 we fully support:
  • Windows, Mac and Linux
  • Operator panel
  • Android phone/tablet
  • iPhone/iPad

Browser based, so there’s no need to install any client software

Visualisation

slide-13
SLIDE 13

April 20th 2017 Building Automation Systems – Built-in Web Server Page 13

Built-in Web Server

slide-14
SLIDE 14

SCADA Client

April 20th 2017 Building Automation Systems – SCADA Client Page 14

slide-15
SLIDE 15

April 20th 2017 Building Automation Systems – Installer benefits Page 15

Installer benefits

BAS Series substations:

  • Support for many different protocols
  • Trend logging data can save data locally for months so it can be

retrieved even after a long-term communications breakdown

  • Substation emulator
  • Most scenarios can be tested before the actual roll-out
  • Includes a graphical html5 based user interface
  • Easily configurable and adaptable both locally and remotely

SCADA:

  • Web based html5 user interface
  • 3-tier system
  • All data stored in SQL database
  • Data-mining
  • Scheduled backups
slide-16
SLIDE 16

April 20th 2017 Building Automation Systems – End-User benefits Page 16

End-User benefits

A Sample installation

  • BAS Web Server Device
  • ECL 200/300 connected via RS232
  • Samson Valve connected via RS232
  • Various M-Bus meters and HCA’s connected via the M-Bus

interface

  • Various Modbus units connected via RS485

RS232 RS485 M-Bus RS232

BAS Web Server

M-Bus meters Modbus units Modbus units Samson Valve M-Bus meters ECL 200/300

Benefits

  • A Single box acts as a data concentrator
  • Saving of trend data for later retrieval
  • Built-in presentation using the web/html5
  • Native, OPC, Modbus/IP and/or BACnet

connection to central data collection either using BAS SCADA or other SCADA systems

slide-17
SLIDE 17

THE END

THANK YOU FOR YOUR ATTENTION

April 20th 2017 Building Automation Systems - End Page 17
