SLIDE 1
Spring 2018 CIS 693, EEC 693, EEC 793:
Autonomous Intelligent Robotics
Instructor: Shiqi Zhang
http://eecs.csuohio.edu/~szhang/teaching/18spring/
Reinforcement Learning
Adapted form Peter Bodík
Autonomous Intelligent Robotics Instructor: Shiqi Zhang - - PowerPoint PPT Presentation
Autonomous Intelligent Robotics Instructor: Shiqi Zhang - - PowerPoint PPT Presentation
Spring 2018 CIS 693, EEC 693, EEC 793: Autonomous Intelligent Robotics Instructor: Shiqi Zhang http://eecs.csuohio.edu/~szhang/teaching/18spring/ Reinforcement Learning Adapted form Peter Bodk Previous Lectures l Supervised learning l
SLIDE 2
SLIDE 3
Previous Lectures
l Supervised learning
l classifjcation, regression
l Unsupervised learning
l clustering, dimensionality reduction
l Reinforcement learning
l generalization of supervised learning l learn from interaction w/ environment to achieve a goal
environment agent action reward new state
SLIDE 4
Today
l examples l defjning a Markov Decision Process
l solving an MDP using Dynamic Programming
l Reinforcement Learning
l Monte Carlo methods l Temporal-Difgerence learning
l automatic resource allocation for in-memory database l miscellaneous
l state representation l function approximation, rewards
SLIDE 5
Robot in a room
+1
- 1
START
actions: UP , DOWN, LEFT , RIGHT UP 80% move UP 10% move LEFT 10% move RIGHT
l reward +1 at [4,3], -1 at [4,2] l reward -0.04 for each step l what’s the strategy to achieve max reward? l what if the actions were deterministic?
SLIDE 6
Other examples
l pole-balancing l walking robot (applet) l TD-Gammon [Gerry Tesauro] l helicopter [Andrew Ng] l no teacher who would say “good” or “bad”
l is reward “10” good or bad? l rewards could be delayed
l explore the environment and learn from the experience
l not just blind search, try to be smart about it
SLIDE 7
Outline
l examples l defjning a Markov Decision Process
l solving an MDP using Dynamic Programming
l Reinforcement Learning
l Monte Carlo methods l Temporal-Difgerence learning
l miscellaneous
l state representation l function approximation, rewards
SLIDE 8
Robot in a room
+1
- 1
START
actions: UP , DOWN, LEFT , RIGHT UP 80% move UP 10% move LEFT 10% move RIGHT
reward +1 at [4,3], -1 at [4,2] reward -0.04 for each step
l states l actions l rewards l what is the solution?
SLIDE 9
Is this a solution?
+1
- 1
l only if actions deterministic
l not in this case (actions are stochastic)
l solution/policy
l mapping from each state to an action
SLIDE 10
Optimal policy
+1
- 1
SLIDE 11
Reward for each step -2
+1
- 1
SLIDE 12
Reward for each step: -0.1
+1
- 1
SLIDE 13
Reward for each step: -0.04
+1
- 1
SLIDE 14
Reward for each step: -0.01
+1
- 1
SLIDE 15
Reward for each step: +0.01
+1
- 1
SLIDE 16
Markov Decision Process (MDP)
l set of states S, set of actions A, initial state S0 l transition model P(s’|s,a)
l P( [1,2] | [1,1], up ) = 0.8 l Markov assumption
l reward function r(s)
l r( [4,3] ) = +1
l goal: maximize cumulative reward in the long run l policy: mapping from S to A
l π(s) or π(s,a)
l reinforcement learning
l transitions and rewards usually not available l how to change the policy based on experience l how to explore the environment
environment agent action reward new state
SLIDE 17
Computing return from rewards
l episodic (vs. continuing) tasks
l “game over” after N steps l optimal policy depends on N; harder to analyze
l additive rewards
l V(s0, s1, …) = r(s0) + r(s1) + r(s2) + … l infjnite value for continuing tasks
l discounted rewards
l V(s0, s1, …) = r(s0) + γ*r(s1) + γ2*r(s2) + … l value bounded if rewards bounded
SLIDE 18
Value functions
l state value function: Vπ(s)
l expected return when starting in s and following π
l state-action value function: Qπ(s,a)
l expected return when starting in s, performing a, and following π
l useful for fjnding the optimal policy
l can estimate from experience l pick the best action using Qπ(s,a)
l Bellman equation
s a s’ r
SLIDE 19
Optimal value functions
l there’s a set of optimal policies
l Vπ defjnes partial ordering on policies l they share the same optimal value function
l Bellman optimality equation
l system of n non-linear equations l solve for V*(s) l easy to extract the optimal policy
l having Q*(s,a) makes it even simpler
s a s’ r
SLIDE 20
Outline
l examples l defjning a Markov Decision Process
l solving an MDP using Dynamic Programming
l Reinforcement Learning
l Monte Carlo methods l Temporal-Difgerence learning
l miscellaneous
l state representation l function approximation, rewards
SLIDE 21
Dynamic programming
l main idea
l use value functions to structure the search for good policies l need a perfect model of the environment
l two main components
l policy evaluation: compute Vπ from π l policy improvement: improve π based on Vπ l start with an arbitrary policy l repeat evaluation/improvement until convergence
SLIDE 22
Policy evaluation/improvement
l policy evaluation: π -> Vπ
l Bellman eqn’s defjne a system of n eqn’s l could solve, but will use iterative version l start with an arbitrary value function V0, iterate until Vk converges
l policy improvement: Vπ -> π’
l π’ either strictly better than π, or π’ is optimal (if π = π’)
SLIDE 23
Policy/Value iteration
l Policy iteration
l two nested iterations; too slow l don’t need to converge to Vπk l just move towards it
l Value iteration
l use Bellman optimality equation as an update l converges to V*
SLIDE 24
Using DP
l need complete model of the environment and rewards
l robot in a room l state space, action space, transition model
l can we use DP to solve
l robot in a room? l back gammon? l helicopter?
l DP bootstraps
l updates estimates on the basis of other estimates
SLIDE 25
Outline
l defjning a Markov Decision Process
l solving an MDP using Dynamic Programming
l Reinforcement Learning
l Monte Carlo methods l Temporal-Difgerence learning
l miscellaneous
l state representation l function approximation, rewards
SLIDE 26
Monte Carlo methods
l don’t need full knowledge of environment
l just experience, or l simulated experience
l averaging sample returns
l defjned only for episodic tasks
l but similar to DP
l policy evaluation, policy improvement
SLIDE 27
Monte Carlo policy evaluation
l want to estimate Vπ(s)
= expected return starting from s and following π l estimate as average of observed returns in state s
l fjrst-visit MC
l average returns following the fjrst visit to state s
s0 s s +1
- 2
+1
- 3
+5 R1(s) = +2 s0 s0 s0 s0 s0 R2(s) = +1 R3(s) = -5 R4(s) = +4
Vπ(s) ≈ (2 + 1 – 5 + 4)/4 = 0.5
SLIDE 28
Monte Carlo control
l Vπ not enough for policy improvement
l need exact model of environment
l estimate Qπ(s,a) l MC control
l update after each episode
l non-stationary environment l a problem
l greedy policy won’t explore all actions
SLIDE 29
Maintaining exploration
l key ingredient of RL l deterministic/greedy policy won’t explore all actions
l don’t know anything about the environment at the beginning l need to try all actions to fjnd the optimal one
l maintain exploration
l use soft policies instead: π(s,a)>0 (for all s,a)
l ε-greedy policy
l with probability 1-ε perform the optimal/greedy action l with probability ε perform a random action l will keep exploring the environment l slowly move it towards greedy policy: ε -> 0
SLIDE 30
Simulated experience
l 5-card draw poker
l s0: A♣, A♦, 6♠, A♥, 2♠ l a0: discard 6♠, 2♠ l s1: A♣, A♦, A♥, A♠, 9♠ + dealer takes 4 cards l return: +1 (probably)
l DP
l list all states, actions, compute P(s,a,s’) l P( [A♣,A♦,6♠,A♥,2♠], [6♠,2♠], [A♠,9♠,4] ) = 0.00192
l MC
l all you need are sample episodes l let MC play against a random policy, or itself, or another algorithm
SLIDE 31
Summary of Monte Carlo
l don’t need model of environment
l averaging of sample returns l only for episodic tasks
l learn from:
l sample episodes l simulated experience
l can concentrate on “important” states
l don’t need a full sweep
l no bootstrapping
l less harmed by violation of Markov property
l need to maintain exploration
l use soft policies
SLIDE 32
Outline
l defjning a Markov Decision Process
l solving an MDP using Dynamic Programming
l Reinforcement Learning
l Monte Carlo methods l Temporal-Difgerence learning
l miscellaneous
l state representation l function approximation, rewards
SLIDE 33
Temporal Difgerence Learning
l combines ideas from MC and DP
l like MC: learn directly from experience (don’t need a model) l like DP: bootstrap l works for continuous tasks, usually faster then MC
l constant-alpha MC:
l have to wait until the end of episode to update
l simplest TD
l update after every step, based on the successor target
SLIDE 34
MC vs. TD
l observed the following 8 episodes:
A – 0, B – 0 B – 1 B – 1 B - 1 B – 1 B – 1 B – 1 B – 0
l MC and TD agree on V(B) = 3/4 l MC: V(A) = 0
l converges to values that minimize the error on training data
l TD: V(A) = 3/4
l converges to estimate l of the Markov process A B
r = 0 100% r = 1 75% r = 0 25%
SLIDE 35
Sarsa
l again, need Q(s,a), not just V(s) l control
l start with a random policy l update Q and π after each step l again, need ε-soft policies
st st+1
at
st+2
at+1 at+2
rt rt+1
SLIDE 36
Q-learning
l previous algorithms: on-policy algorithms
l start with a random policy, iteratively improve l converge to optimal
l Q-learning: ofg-policy
l use any policy to estimate Q l Q directly approximates Q* (Bellman optimality eqn) l independent of the policy being followed l only requirement: keep updating each (s,a) pair
l Sarsa
SLIDE 37
Outline
l defjning a Markov Decision Process
l solving an MDP using Dynamic Programming
l Reinforcement Learning
l Monte Carlo methods l Temporal-Difgerence learning
l miscellaneous
l state representation l function approximation, rewards
SLIDE 38
Model-based approach
l Classical RL is model-free
l need to explore to estimate efgects of actions l would take too long in this case
l Model of the system:
l input: workload, system confjguration l output: performance under this workload l also model transients: how long it takes to move data
l Policy can estimate the efgects of difgerent actions:
l can efgiciently search for best actions l move smallest amount of data to handle workload
SLIDE 39
Outline
l examples l defjning a Markov Decision Process
l solving an MDP using Dynamic Programming
l Reinforcement Learning
l Monte Carlo methods l Temporal-Difgerence learning
l miscellaneous
l state representation l function approximation, rewards
SLIDE 40
State representation
l pole-balancing
l move car left/right to keep the pole balanced
l state representation
l position and velocity of car l angle and angular velocity of pole
l what about Markov property?
l would need more info l noise in sensors, temperature, bending of pole
l solution
l coarse discretization of 4 state variables l left, center, right l totally non-Markov, but still works
SLIDE 41
Function approximation
l until now, state space small and discrete l represent Vt as a parameterized function
l linear regression, decision tree, neural net, … l linear regression:
l update parameters instead of entries in a table
l better generalization l fewer parameters and updates afgect “similar” states as well
l TD update
l treat as one data point for regression l want method that can learn on-line (update after each step) x y
SLIDE 42
Splitting and aggregation
l want to discretize the state space
l learn the best discretization during training
l splitting of state space
l start with a single state l split a state when difgerent parts of that state have difgerent values
l state aggregation
l start with many states l merge states with similar values
SLIDE 43
Designing rewards
l robot in a maze
l episodic task, not discounted, +1 when out, 0 for each step
l chess
l GOOD: +1 for winning, -1 losing l BAD: +0.25 for taking opponent’s pieces l high reward even when lose
l rewards
l rewards indicate what we want to accomplish l NOT how we want to accomplish it
l shaping
l positive reward often very “far away” l rewards for achieving subgoals (domain knowledge) l also: adjust initial policy or initial value function
SLIDE 44
Summary
l Reinforcement learning
l use when need to make decisions in uncertain environment l actions have delayed efgect
l solution methods
l dynamic programming l need complete model l Monte Carlo l time difgerence learning (Sarsa, Q-learning)
l simple algorithms l most work
l designing features, state representation, rewards
