Autonomous driving visual perception on the DRIVE PX2 Dr. Antonio - - PowerPoint PPT Presentation

1

http://adas.cvc.uab.es/elektra/

Autonomous driving visual perception

• n the DRIVE PX2
• Dr. Antonio M. López

www.cvc.uab.es/~antonio http://adas.cvc.uab.es/elektra/

• Dr. Antonio Espinosa

http://grupsderecerca.uab.cat/hpca4se/en/content/gpu

2

http://adas.cvc.uab.es/elektra/

Our background: camera-based ADAS

3

http://adas.cvc.uab.es/elektra/

Our current research:

4

http://adas.cvc.uab.es/elektra/

Stereo Vision for Depth Computation

Disparity: distance between same point in left & right images higher disparity = Objects are closer

10 meters

5

http://adas.cvc.uab.es/elektra/

Optimize Stereo Matching: Semi-Global Matching (SGM)

Image Resolution

• Max. Disparity: 256

640 x 480 0.63 B ops. 1280 x 480 1.26 B ops. 1280 x 960 2.51 B ops.

Total Computation Work  ( Height × Width × MaxDisp × Path Directions )

DEVICE (GPU) HOST (CPU) HOST (CPU)

… Input: Left and Right Images Output: Disparity Image

Matching Cost Smoothed Cost

6

http://adas.cvc.uab.es/elektra/

GPU Implementation: Proposal

…

x

… …

x

…

C

y d

L

First level parallelism (big granularity) Second level parallelism (medium granularity)

SGM stencil SGM stencil

Third level parallelism (fine-grained)

Dependency: Serialized Collaborative work

…

7

http://adas.cvc.uab.es/elektra/

GPU Implementation: Performance & Energy Efficiency

• Tegra X1 achieves real-time ( 20 FPS ) with > 2X efficiency than Titan X
• Newer GPUs, with higher memory bandwidth, will achieve faster solutions

Energy Efficiency

50 100 TEGRA X1: Performance (Frames/Second, fps)

640x480 1280x480 1280x960

D= 128

# path directions 2 4 8 real-time

8

http://adas.cvc.uab.es/elektra/

GPU Implementation: Results

9

http://adas.cvc.uab.es/elektra/

• Stereo of 1280 x 960 = 1,228,800 pixels => Too much data to process
• Medium-level representation with only relevant information
• Fixed width stixels, variable number of stixels per column
• Stixel = Stick + Pixel

Stereo + Horizon Line + Road Slope Stixels

slope Horizon

Stereo Images

Stixel World: Compact representation of the world

Obj. Sky Obj. Obj. Grnd

10 10

http://adas.cvc.uab.es/elektra/

Image Resolution Computation 640 x 480 147 M ops. 1280 x 480 294 M ops. 1280 x 960 1179 M ops. Total Computation Work  ( Width × Height 2 )

Find best configuration

Sky: Far pixels, near 0 disparity Object: constant disparity Ground: close to expectedmodel

Stixel World: a Mid-level Image Representation

Computed independently for each column Enforces constraints: no sky below horizon, no neighbors objects at the same distance… Combinatorial explosion (of possible segments): dynamic programming technique

11 11

http://adas.cvc.uab.es/elektra/

Stereo Disparity

First level parallelism (big granularity): Second level parallelism (fine-grained):

• Independent / Task level: Typical CPU parallelization
• Each image column is processed in parallel by a CTA
• CTA = Cooperating Threads Array

CTA

···

…

CTA

h h

GPU Implementation: Proposal

12 12

http://adas.cvc.uab.es/elektra/

GPU Implementation: Second Level Parallelism

CTA

step 1

C

i

C

i

C

i

C

i

step 2 step 3 …..

• Extra parallelism level needed for efficient GPU use
• Sequentially perform h (image height) steps
• CTA threads collaborate sharing info each step
• Decreasing Parallelism: Each step uses one thread less

Second level parallelism (fine-grained):

h

Computational Analysis

Thread Parallelism h×w Compute Work per thread h Total Global Data Reads h2×w Total Global Data Stores h×w step h …..

13 13

http://adas.cvc.uab.es/elektra/

13

GPU Performance (Frames/Second, fps) Energy Efficiency

• Real-time performance for energy efficient GPU: NVIDIA DRIVE PX
• NVIDIA Drive PX has better energetic efficiency than high-end GPUs

8.68 4.00 4.57 2.32 2.23 1.49

1 2 3 4 5 6 7 8 9 10 Tegra X1 Titan X

frames per second / Watt

1280 x 240 640 x 480 1280 x 480

86.8 1000 45.7 581.0 22.3 373.0

1.0 10.0 100.0 1000.0

Tegra X1 Titan X frames per second

1280 x 240 640 x 480 1280 x 480

GPU Implementation: Performance & Energy Efficiency

14 14

http://adas.cvc.uab.es/elektra/

GPU Implementation: Result (using SYNTHIA)

15 15

http://adas.cvc.uab.es/elektra/

Image generator to acquire thousands of precise data with several kinds of ground truth.

• RGB & Per pixel: depth, semantic class, instance ID, optical flow
• Covering popular Cityscapes classes (see www.synthia-dataset.net)

What is this for? teaching cars to perceive the environment using machine learning techniques (e.g. deep learning, reinforcement learning).
