Automobile Intrusion Detection Jun Li Twitter @bravo_fighter - - PowerPoint PPT Presentation

Jun Li

Twitter：@bravo_fighter

UnicornTeam

Qihoo360

Automobile Intrusion Detection

2

What this talk is about? Automotive intrusion detection Automotive cyber-security architecture

3

From the highest viewpointJ

Outline

• Quick recap of the status quo of

car security research

• Little automobile working principle
• CAN bus anomaly detection

Performance Tuning by modifying firmware Immobilizer Cracking （Hitag， Keeloq） DARPA&UW OBD interface attack，etc. Karl et al. Remote attack via wireless OBD interface Telsa Qihoo360

BMW

ConnectedDrive

vuln

Mbrace

Jeep Uconnect Charlie&Chris

GM Onstar Vuln,Sammy More to come ？ Sure！

Car hacking development

Car explained

Sensor security

In automotive electronics, Electronic Control Unit (ECU) is a generic term for any secret system that controls one or more of the electrical system or subsystems in a transport vehicle Types of ECU include Electronic/engine Control Module (ECM), Powertrain Control Module (PCM), Transmission Control Module (TCM), Brake Control Module (BCM or EBCM), Central Control Module (CCM), Central Timing Module (CTM), General Electronic Module (GEM), Body Control Module (BCM), Suspension Control Module (SCM), control unit, or control module

ECU (Electronic Control Unit)

Electronic Control Module Example

9

Automotive Mechatronics

10

Non-hackable hackable

11

Throttle position sensor

Drive-by-wire system

12

Steering-by-wire system

Universal joint Steer-by –wire （with mechanical fallback clutch）

Automotive Control System Architecture

Vehicle CAN BUS System

Vehicle Communication System

OBDII

MOST LIN CAN FlexRay Bluetooth Wifi SubGHz Infotainment System

ESP TCU ACC

ESP（electronic stability program） TCU（transmission control unit） ACC（adaptive cruise control）

… CAN-C 网关 Speedometer CAN-B Infotainment System

Music Player

INS（Inertial navigation system）

INS EMU

EMU（engine management

system）

Seat Controller

Vehicle Communication System example

CAN BUS Signaling

CAN Frame Structure

0 dominant 1 recessive 1 1 1 1 1 1 1 1 0 1 1 1 0 0 0 0 0 0

CAN Bus Access Arbitration

Packets injection Parameter spoofing

CAN BUS Attack

Jeep Uconnect Vulnerability

WiFi femotocell Sprint Internet CAN

Remote Attack Example

Automotive intrusion detection researches

Automotive intrusion detection researches

Not considering Temporal feature

Distributed architecture

CAN总线安全防御模型 IDS IDS（Intrusion Detection System）

① Real time requirements ② Hard to trace back to sender ③ High cost of false positive ④ …

Difficulties of CAN bus defence

CAN Anomaly Detection

McAfee&Intel

CAN bus defence

IDS

CAN security architecture

Bluetooth WiFi Cellular V2X IDS

Experiment Car

• Cellular Connection
• Cloud Service
• Bluetooth Key
• Hybrid
• Electronic Brake
• Electric Power

Steering

• Electronic Throttle

Experiment car’s CAN network

The CAN database

Why don’t we build a model Take the relation ship of rpm and speed ， gear for example，we can create a model of the System‘s behavior

汽车工作原理

Anomaly detection system

Realtime data stream Cross Prediction Parameter extraction

System model requirements

Gear

Build the system model

Data Collection Data preprocess Data analysis Feature Selection

Model Training &Testing

Data Acquisition

Parameter presence on different BUS

Parameter Speed Engine RPM Acceleration Pedal Intake Pressure Brake Pedal Steering Wheel Gear

BUS

Instrument

• x

x

• Comfort
• x

x

• x

x

Power

• x

x

ECM

• x
• ESC
• x

Data Acquisition Setup

Data Analysis

Can database is kept highly confidential

Data Preprocess

Data Preprocess

Interpolation Sampling Normalization

Normalization Must make sure the maximum and minimum value，don’t calculate from the training data

数据插值

Observation Interpolation

Sub-Sampling

Sub-Sampling

Time_ ms RPM Speed MAP MAF AccPeda l Throttle 13897 3 0.287983 8 0.134259 2 0.059055 1 0.167567 5 0.697107 0.137795 2 13897 4 0.287312 5 0.134259 2 0.055118 1 0.167567 5 0.697107 0.137795 2 13897 5 0.287312 5 0.134259 2 0.051181 1 0.167567 5 0.697107 0.137795 2 13897 6 0.285970 0.134259 2 0.047244 0.167567 5 0.697107 0.137795 2 13897 7 0.285970 0.134259 0.051181 1 0.167567 5 0.697107 0.137795 2

Sub-Sampling

Model training

Model training

Results

Result

Model testing

Model testing

Acknowledgement Professor Shuicheng Yan Doctor Ming Lin Doctor Zhanyi Wang Doctor Lin Huang

Thank You！ Q&A
