National Aeronautics and Space Administration Automatically Encapsulating HPC Best Practices Into Data Transfers Paul Z. Kolano NASA Advanced Supercomputing Division paul.kolano@nasa.gov www.nasa.gov Outline of Presentation

slide-1
SLIDE 1

National Aeronautics and Space Administration www.nasa.gov

Automatically Encapsulating
 HPC Best Practices Into Data Transfers

Paul Z. Kolano NASA Advanced Supercomputing Division paul.kolano@nasa.gov

slide-2
SLIDE 2

NASA High End Computing Capability

Outline of Presentation

  • Introduction
  • Transport tuning and selection
  • Global resource management
  • File system optimization
  • Conclusions

2

slide-3
SLIDE 3

NASA High End Computing Capability

Introduction

  • Data transfers are part of life in HPC environments
  • Finite storage capacity
  • Transfer to cheaper tape storage
  • Back up existing data
  • Make room for new data
  • Transfer from tape storage to reprocess old data
  • Transfer between file systems to fix imbalances
  • Finite computational capacity
  • Transfer from off-site systems with cheaper pre-processing
  • Transfer to off-site systems for cheaper post-processing

3

slide-4
SLIDE 4

NASA High End Computing Capability

Introduction (cont.)

  • User transfer concerns
  • Ease to use, integrity, turnaround time
  • Administrator and owner transfer concerns
  • Environment stability, cost effectiveness
  • These items can conflict with each other
  • Easy to use tools or those ensuring integrity may not be fast
  • Easiest file structure may degrade tape performance
  • Fastest turnaround time may lead to resource exhaustion
  • Takes HPC expert to reconcile conflicts
  • Understands and applies accepted best practices to achieve

fast and efficient verified transfers without impact on stability

4

slide-5
SLIDE 5

NASA High End Computing Capability

Goal

  • Let scientists focus on science without wading

through documentation on transfer best practices

  • Specify transfers in simplest, naive fashion
  • Source and destination
  • Provide tool to perform transfer as if scientist were

HPC expert

  • Choose appropriate tools and optimize for best performance
  • Fully utilize available resources without starving other users
  • Manage files appropriately by file system type to ensure

efficient access by later and/or behind the scenes processes

5

slide-6
SLIDE 6

NASA High End Computing Capability

Shift: Self-Healing Independent File Transfer

  • Satisfies user requirements
  • Simple cp/scp syntax for local/remote transfers
  • End-to-end integrity via checksums and sanity checks
  • High speed via transport selection/tuning and automatic parallelization
  • Satisfies administrator and owner requirements
  • Helps prevent resource exhaustion that leads to environment instability
  • Global throttling to allocate resources fairly
  • Load balancing to avoid highly loaded hosts
  • Automatic striping to avoid imbalanced disk utilization
  • Helps prevent wasted resources that impact cost effectiveness
  • Allows easy utilization of idle resources
  • Reduces wasted CPU cycles during jobs due to inefficient disk I/O
  • Prevents issues leading to inefficient tape I/O

6

slide-7
SLIDE 7

NASA High End Computing Capability

Shift: Self-Healing Independent File Transfer (cont.)

  • Used in production at NASA's Advanced

Supercomputing Facility for over 3.5 years

  • User transfers across local/LAN/WAN
  • Disaster recovery backups to/from remote organizations
  • Rebalancing entire multi-PB Lustre file systems
  • etc.
  • Facilitated transfers of over 14 PB in past year
  • 8 PB local transfers
  • 4 PB LAN transfers
  • 2 PB WAN transfers
  • "I used to hate archiving data - now I almost look for

a reason to archive something" –Shift user

7

slide-8
SLIDE 8

NASA High End Computing Capability

Shift Interface

> shiftc --create-tar /nobackup/user1/dataset1 archive1:dataset1.tar Shift id is 36 Detaching process (use --status option to monitor progress) > shiftc --status

id | state | dirs | files | file size | date | run | rate | | sums | attrs | sum size | time | left |

  • --+-------+-------------+-------------+---------------+-------+------------+---------

34 | error | 0/0 | 23121/23121 | 39.5TB/39.5TB | 10/02 | 2d14h32m5s | 175MB/s | | 46222/46242 | 23111/23121 | 79TB/79TB | 10:26 | | 35 | done | 1/1 | 5131/5131 | 303GB/303GB | 10/05 | 1m35s | 3.19GB/s | | 10262/10262 | 5132/5132 | 605GB/605GB | 12:28 | | 36 | run | 24/24 | 26656/26656 | 1.78TB/1.78TB | 10/06 | 2h48m37s | 176MB/s | | 15463/53312 | 10/26684 | 1.02TB/3.56TB | 12:11 | 1h47m55s |

8

slide-9
SLIDE 9

NASA High End Computing Capability

Shift Components

9

  • Command-line client
  • Performs file operations and reports results to manager
  • Command-line manager
  • Invoked by clients to track operations and parcel out work

Client Host Shift Client Remote Host App C1 Interconnect App C2 App Cj OS Client File System App R1 App R2 App Rk Shift Manager(s) OS Remote File System

slide-10
SLIDE 10

NASA High End Computing Capability

Outline of Presentation

  • Introduction
  • Transport tuning and selection
  • Global resource management
  • File system optimization
  • Conclusions

10

slide-11
SLIDE 11

NASA High End Computing Capability

Transport Tuning and Selection

  • Shift includes built-in local/remote transports and

checksum capabilities

  • Fully functional out of the box
  • Perl-based equivalents of cp, sftp, fish, m(d5)sum
  • Shift calls higher performance tools when available
  • bbcp, bbftp, gridftp, mcp, rsync, msum
  • Knows how to construct command-lines and parse output
  • Tune transports for optimal performance
  • Select transports based on transfer characteristics

11

slide-12
SLIDE 12

NASA High End Computing Capability

Transport Tuning

  • TCP-based transports
  • bbcp, bbftp, gridftp
  • Choose TCP window size
  • Transports with internal parallelism
  • TCP streams (bbcp, bbftp, gridftp) or threads (mcp, msum)
  • Choose appropriate level of parallelism
  • SSH-based transports
  • fish, rsync, sftp-perl
  • Choose fastest SSH cipher and MAC algorithm

12

slide-13
SLIDE 13

NASA High End Computing Capability

TCP Window Size Tuning

  • TCP window is amount of data sender or receiver

willing to buffer while waiting for acknowledgment

  • Optimal value is bandwidth delay product (BDP)
  • bandwidth * round-trip time
  • Constrained by configured operating system limits
  • e.g. Linux net.core.[wr]mem_max
  • Single stream only achieves bandwidth if limit at least BDP

13

slide-14
SLIDE 14

NASA High End Computing Capability

TCP Window Size Tuning (cont.)

100 200 300 400 500 600 700 Default 1 4 16 64 100 LAN Transfer Performance (MB/s) TCP Window Size (MB) bbcp bbftp gridftp 100 200 300 400 500 600 700 800 Default 1 4 16 64 100 WAN Transfer Performance (MB/s) TCP Window Size (MB) bbcp (get) bbftp (get) gridftp (put) 14

  • Shift determines latency using icmp/echo/syn ping
  • Shift guesses bandwidth based on network type

and client hardware if not given via --bandwidth

  • Bandwidth difficult to compute a priori
  • Chooses window size up to operating system limit
slide-15
SLIDE 15

NASA High End Computing Capability

Transport Parallelism Tuning

  • Number of streams in TCP-based transports
  • Overcome improperly configured TCP window maximums
  • Overcome improperly specified TCP window
  • Overcome interference by cross traffic
  • Number of threads in mcp and msum
  • Take advantage of excess resource capacity on one host

15

slide-16
SLIDE 16

NASA High End Computing Capability

Transport Parallelism Tuning (cont.)

100 200 300 400 500 600 1 2 4 8 LAN Transfer Performance (MB/s) TCP Streams bbcp bbftp gridftp 100 200 300 400 500 600 700 1 2 4 8 WAN Transfer Performance (MB/s) TCP Streams bbcp (get) bbftp (get) gridftp (put) 16

  • Shift chooses streams based on bandwidth

available beyond operating system window limit

  • A minimum value can be configured for LAN/WAN

to help overcome cross traffic

slide-17
SLIDE 17

NASA High End Computing Capability

Transport Parallelism Tuning (cont.)

17 500 1000 1500 2000 2500 3000 3500 1 2 4 8 16 32 64 Local Copy Performance (MB/s) Mcp Threads Haswell (12-core, 4x FDR) Ivy Bridge (10-core, 4x FDR) Sandy Bridge (8-core, 4x FDR) Westmere (6-core, 4x QDR)

  • Threads can be centrally

configured on the manager

  • High thread counts can

induce high load on shared resources

  • Intentionally set lower than
  • ptimal at NAS due to high

load on archive front-ends

slide-18
SLIDE 18

NASA High End Computing Capability

SSH Cipher and MAC Algorithm Tuning

  • SSH-based transports use SSH pipe to communicate
  • Performance directly correlated to SSH performance
  • SSH does not expose TCP window settings
  • HPN SSH patches can be used for better window handling
  • Main SSH tuning parameters available
  • Encryption algorithm
  • Message authentication code (MAC) algorithm

18

slide-19
SLIDE 19

NASA High End Computing Capability

SSH Cipher and MAC Algorithm Tuning (cont.)

50 100 150 200 250 a e s 1 2 8

  • c

b c a e s 1 9 2

  • c

b c a e s 2 5 6

  • c

b c a e s 1 2 8

  • c

t r a e s 1 9 2

  • c

t r a e s 2 5 6

  • c

t r a r c f

  • u

r a r c f

  • u

r 1 2 8 a r c f

  • u

r 2 5 6 b l

  • w

f i s h

  • c

b c c a s e 1 2 8

  • c

b c c h a c h a 2 3 d e s

  • c

b c LAN Transfer Performance (MB/s) (fish with umac-64 MAC) SSH Cipher 50 100 150 200 250 h m a c

  • m

d 5 h m a c

  • m

d 5

  • 9

6 h m a c

  • r

i p e m d 1 6 h m a c

  • s

h a 1 h m a c

  • s

h a 1

  • 9

6 h m a c

  • s

h a 2

  • 2

5 6 h m a c

  • s

h a 2

  • 5

1 2 u m a c

  • 6

4 u m a c

  • 1

2 8 LAN Transfer Performance (MB/s) (fish with arcfour256 cipher) SSH MAC Algorithm 19

  • Shift allows preferred cipher/mac order to be

centrally configured

  • Availability checked on client host before transfer
slide-20
SLIDE 20

NASA High End Computing Capability

Transport Selection

  • Different transports have different strengths and

weaknesses

  • Supporting multiple transports provides opportunity

to vary transport across each batch of files within transfer

20

slide-21
SLIDE 21

NASA High End Computing Capability

Transport Selection (cont.)

0.1 1 10 100 1000 1 4 16 64 256 1024 4096 16384 65536 SSH/Non-SSH Break-Even Point LAN Transfer Performance (MB/s) File Size (MB) bbcp bbftp fish gridftp rsync sftp-perl 0.1 1 10 100 1000 1 4 16 64 256 1024 4096 16384 65536 SSH/Non-SSH Break-Even Point WAN Transfer Performance (MB/s) File Size (MB) bbcp bbftp fish gridftp rsync sftp-perl 21

  • Using a single transport does not achieve

maximum performance

  • Shift's support of multiple transports allows it to

use the optimum transport for each batch of files

slide-22
SLIDE 22

NASA High End Computing Capability

Transport Selection (cont.)

22 0.1 1 10 100 1000 1 4 16 64 256 1024 4096 16384 65536 Local Transfer Performance (MB/s) File Size (MB) bbcp bbftp cp-perl fish gridftp mcp rsync

  • Traditionally remote

transports also perform well for local transfers

slide-23
SLIDE 23

NASA High End Computing Capability

Transport Selection (cont.)

500 1000 1500 2000 2500 3000 bbcp bbftp cp/sftp-perl fish gridftp mcp rsync 64 x 1GB Performance (MB/s) Transport Local LAN WAN 50 100 150 200 250 300 350 400 450 500 bbcp bbftp cp/sftp-perl fish gridftp mcp rsync 1000 x 4MB Performance (MB/s) Transport Local LAN WAN 23

  • Shift has configurable small file thresholds
  • Preferred local/LAN/WAN transports above/below
  • Transport chosen using avg. size of each batch
slide-24
SLIDE 24

NASA High End Computing Capability

Outline of Presentation

  • Introduction
  • Transport tuning and selection
  • Global resource management
  • File system optimization
  • Conclusions

24

slide-25
SLIDE 25

NASA High End Computing Capability

Global Resource Management

  • Transfer parallelization
  • The only way to maximize performance in HPC

environments is to use multiple resources at once

  • Global throttling
  • If everyone tries to run at the maximum rate possible,

everyone loses

  • Load balancing
  • Avoid resource exhaustion on individual hosts

25

slide-26
SLIDE 26

NASA High End Computing Capability

Transfer Parallelization

  • Single host may have excess capacity
  • Transport does not have its own parallelism
  • Single client cannot fully utilize host's resources
  • Full HPC environment may have excess capacity
  • Single system bottlenecks
  • Aggregate resources of many hosts
  • Two complementary forms of parallelization
  • Multiple clients running on a single host
  • One or more clients running on multiple hosts

26

slide-27
SLIDE 27

NASA High End Computing Capability

Transfer Parallelization (cont.)

500 1000 1500 2000 2500 3000 1 2 4 8 16 Local Transfer Performance (MB/s) Parallel Clients bbcp bbftp cp-perl fish gridftp mcp rsync 2000 4000 6000 8000 10000 12000 1 2 4 8 16 32 Local Transfer Performance (MB/s) Parallel Hosts bbcp bbftp cp-perl fish gridftp mcp rsync 27

  • Shift derives file system equivalency from mount

information to determine parallelization candidates

  • Shift can automatically parallelize all transfers using

centrally configured clients/hosts values

  • Can trivially run across allocated compute nodes
  • e.g. --host-file=$PBS_NODEFILE
slide-28
SLIDE 28

NASA High End Computing Capability

Global Throttling

  • Support transfers at

full speed when excess capacity exists

  • Prevent resource

exhaustion when systems are busy

1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 Configured Limit Local Write Performance (MB/s) Time Unthrottled (5.34 GB/s) Throttled (3.62 GB/s) 28

  • Shift supports throttling limits on CPU %, disk

usage, I/O rate, and network rate

  • Limits can be global, per user, per host, per file system
  • Transfers directed to sleep until average reaches

(transfer's fair share of) user's fair share of limit

slide-29
SLIDE 29

NASA High End Computing Capability

Load Balancing

29

  • Single host resource

limitations impact maximum transfer speed of all processes on that host

  • Less loaded hosts have

more resources available for new transfers

1000 2000 3000 4000 5000 6000 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 32-way dd write iperf IPoIB I/O Bandwidth Utilization (MB/s) Time 32 Hosts 16 Hosts 8 Hosts 4 Hosts 2 Hosts 1 Host

slide-30
SLIDE 30

NASA High End Computing Capability

Load Balancing (cont.)

30

  • Shift load balances during host parallelization
  • Picks least loaded hosts when spawning clients
  • Shift load balances during remote transfers
  • Remote host switched to least loaded
  • Overlap prevented between parallel clients

1000 2000 3000 4000 5000 6000 7000 1 2 4 8 16 32 LAN Transfer Performance (MB/s) Client Hosts Disjoint remote hosts Same remote host

slide-31
SLIDE 31

NASA High End Computing Capability

Outline of Presentation

  • Introduction
  • Transport tuning and selection
  • Global resource management
  • File system optimization
  • Conclusions

31

slide-32
SLIDE 32

NASA High End Computing Capability

File System Optimization

  • Different file systems have different idiosyncrasies
  • Can impact performance, stability, and operating cost
  • Not always directly visible to users
  • Tape optimization
  • File extents impact tape write speed
  • Sequential retrieval results in inefficient tape movement
  • Tar creation/extraction
  • Tape I/O is inefficient with small files
  • Lustre striping
  • Too few stripes creates later I/O inefficiencies

32

slide-33
SLIDE 33

NASA High End Computing Capability

Tape Optimization

  • Tape-backed file systems have limited parallelism

due to large slow-moving physical components

  • Inefficient access by one user can have major impact
  • n all others
  • Large number of file extents degrades write speed
  • Sequential file retrieval inhibits minimization of internal tape

movement

33

slide-34
SLIDE 34

NASA High End Computing Capability

Tape Optimization (cont.)

50 100 150 200 250 300 350 1 4 16 64 256 1024 4096 16384 65536 Performance (MB/s) Source File Extents Tape Write Buffered dd Read Direct dd Read 500 1000 1500 2000 2500 1 4 16 64 Tape Writes Degrade Extents Produced File Size (GB) bbcp bbftp cp-perl fish gridftp mcp rsync 34

  • Shift can be configured to preallocate files below

a given sparsity

  • Minimize extents for most common regular files
  • Minimize disk usage for large sparse files
slide-35
SLIDE 35

NASA High End Computing Capability

Tape Optimization (cont.)

200 400 600 800 1000 1200 1400 1600 1 2 4 8 16 32 64 Tape Retrieval Time (s) 1GB Files Sequential Batched

  • Files automatically

retrieved from tape if

  • ffline when accessed
  • May be accessed in

different order than stored on tape

35

  • Shift automatically initiates a retrieval of all source

files on SGI DMF file systems

  • Retrieval initiated again for files in each batch in

case files pushed offline before being transferred

slide-36
SLIDE 36

NASA High End Computing Capability

Tar Creation/Extraction

36 50 100 150 200 250 300 1 4 16 64 256 1024 4096 16384 65536 Tape Performance (MB/s) Source File Size (MB) Write Read

  • Users prefer archiving data

in original hierarchy

  • Each file accessed as needed
  • Small files impact stability
  • Not migrated below certain

size so consume limited disk

  • Tape I/O is inefficient
  • Normally use tar files
  • Tar is very slow (100 MB/s)
  • Must retrieve to view contents
  • No assurance of integrity
  • Retrieve entire tar for one file
  • May not have quota to create
slide-37
SLIDE 37

NASA High End Computing Capability

Tar Creation/Extraction (cont.)

500 1000 1500 2000 2500 1 2 4 8 16 Tar Creation Performance (MB/s) Parallel Hosts Local (mcp) LAN (fish) WAN (fish) GNU tar 1000 2000 3000 4000 5000 6000 1 2 4 8 16 Tar Extraction Performance (MB/s) Parallel Hosts Local (mcp) LAN (fish) WAN (fish) GNU tar 37

  • Shift has built-in tar creation/extraction
  • Uses high performance transports and parallelism
  • Automatic creation of index files to see contents
  • Integrity verification of every file added/extracted
  • Automatic split of tar files at configurable size
  • Direct creation/extraction over network without use of quota
slide-38
SLIDE 38

NASA High End Computing Capability

Lustre Striping

  • Striping must be set before a file is first written
  • Higher stripe count
  • More I/O bandwidth available for large files
  • More balanced distribution of large files over OSTs
  • Lower stripe count
  • Less contention during metadata operations
  • Less wasted space for small files
  • Striping can only be changed by copying file

38

slide-39
SLIDE 39

NASA High End Computing Capability

Lustre Striping (cont.)

2000 4000 6000 8000 10000 12000 1 2 4 8 16 32 64 Noncontiguous Write Performance (MB/s) Lustre Stripes 64 Nodes 32 Nodes 16 Nodes 8 Nodes 4 Nodes 2 Nodes 500 1000 1500 2000 2500 3000 3500 1 2 4 8 16 32 64 Noncontiguous Read Performance (MB/s) Lustre Stripes 64 Nodes 32 Nodes 16 Nodes 8 Nodes 4 Nodes 2 Nodes 39

  • Shift automatically stripes files according to size
  • Increases write performance during parallel transfers
  • Increases read performance during later job access
  • Reduces wasted CPU cycles due to I/O
  • Preserves non-default striping when applicable
slide-40
SLIDE 40

NASA High End Computing Capability

Conclusion

  • Shift is an automated transfer tool that encapsulates

HPC best practices to achieve better performance while preserving stability of HPC environments

  • Centralized configuration in manager component allows

policies to be changed globally across all clients

  • New best practices can be incorporated transparently

without user in the loop

  • Shift is open source and available for download
  • http://shiftc.sourceforge.net
  • Contact info
  • paul.kolano@nasa.gov
  • Questions?

40
