AUTOMATIC FIRE EXTINGUISHING SYSTEM Fire extinguishing system - - PowerPoint PPT Presentation

AUTOMATIC FIRE EXTINGUISHING SYSTEM Fire extinguishing system Sapfir is an unique system of extinguishing fire in open spaces , like warehouses, factory halls, hay-barns, gas stations, office spaces and tunnels.

High reliability and efficiency Relatively low price Blocking a fire in the initial stage In a self- activating way The module is designed to fire outbreaks in closed boxes with electrical and electronic security of small volume, cable channels, technical security.

12 years of use without the need for a technical service Simplicity of assembly and use Versatility – fire extinguishing of all classes, including power supply under voltage The module is designed to protect against fire in automatic, self-activating or manual mode in rooms

• f all types and purposes, technical security of the

property up to 15 m2 with volume up to 28 m3

The module is designed to protect against fire in automatic, self-activating or manual mode in rooms

• f all types and purposes, technical property

security up to 32 m2 and with volume up to 65 m3 Simply remove the extinguishing powder after use, no damage caused by water, foam or salts Minimal damage in case of fire in buildings in comparison to water extinguishing

The module is designed to protect against fire in automatic, self-activating or manual mode in rooms of all types and purposes, technical security of the property up to 40 m2 with volume up to 100 m3 Extinguishing powder is safe for humans, animals,technology and environment Versatility – can extinguish fires of all classes, including electrical units under voltage

Coverage of all fire classes, including installations below electrical voltage. Module is designed to protect against fire in automatic, self-activating or manual mode in rooms of all types and purposes, technical property security up to 78 m2 with volume up to 100 m3 Cheap maintenance

A hand-started module that drops into a fire outbreak. Our “fire-grenade” shouldnt be missed in any household, plant, fire truck, supermarket, etc. The unit is simply thrown into the fire and automatically extinguishes it in seconds. An extinguishing grenade is therefore easy to

• perate and up to 12 years maintenance free.

Use of cartridges as part of fire fighting vehicles significantly extends the fire brigade possibilities and reduces the danger of burns and fire extinguishing at high level buildings to quickly block the source of the fire and protect people in the room in which the fire already exists. Cassette TPS - 24.2 structurally consists

• f two modules of extinguishing fires

SAPFIR MPH-24 and is a device of multiple uses. It requires no power source and no technical service for 12 years of service.

Integrate our modules into your existing system The module is designed to protect against fire in automatic, self-activating or manual mode in rooms of all types and purposes, technical property security up to 50 m2 with volume up to 150 m3

The module is designed to protect against fire in automatic, self-activating or manual mode in rooms of all types and purposes, technical property security on an area up to 72 m2 with a volume up to 216 m3 Early control of the fire in self-starting mode or in automatic mode

The module is designed to protect against fire in automatic, self-activating

• r manual mode in rooms of all types and

purposes, technical property security up to 36 m2 with a volume up to 216 m3 Easy installation and simple operation of the systems

The system is designed to extinguish fires in places where no fire departments are available and deployed:small municipalities,airports and aircraft parking spaces,stretches of forest plants,large metallurgical factories and oil processing locations.The system consists of 12 cassettes TPS-2-24 placed on rotating base and is installed on the bearing surface.The system can be installed on any mobile carrier- four wheeler,trailer,tractor,and

• ther.

TPS is a unigue autonomous thermal activation and detection device that allows detecting a fire and activating a powder,aerosol or gaseous fire suppression system.Also the device has features such as provision of a signal to a fire panel and incorporation of an additional output designed to shut down the electrical equipment or activate an alarm.TPS can also be used as a thermal detector with a fixed temperature reading an can be connected to an existing fire detection circuit or a fire- indicating panel

TPS-920.24

Sapfir system does not require additional electricity or source, product generates own electricity at the time of the danger.

Device of the autonomous activation TPS – 01 Thermal fire-fighting sensor

The TPS sensor is a unique and autonomous sensor for combating fire sources in conjunction with the SAPFIR fire extinguishers. The sensor also provides the possibility of sending signals for detection in a fire detection

• system. It is fully networkable, but does not

require any current - neither from the power supply nor from a battery! The sensor TPS operates as an independent, thermo-activating detection device. It reacts to the heat of a fire and activates the extinguishing modules. The TPS-01 sensor can also be used as a thermometer.

• Sensor TPS-01-72 - 72 ± 5 ° C
• Sensor TPS-01-93 - 93 ± 5 ° C
• Sensor TPS-01-110 - 110 ± 5 ° C
• Sensor TPS-01-М - activated manually

info@proteng.hu +40741 211 696 +36 70 213 7246 +36 70 453 8721 www.proteng.hu 417165,Romania Jud,Bihor.Com Cetariu. Str Morii 230/A

Distributor in Romania, Hungary : Sc AGCHEM Srl
