Auto-scaling deadline- constrained workloads in containers in the cloud Jay Jay DesLauriers DesLauriers Research Associate, University of Westminster Project COLA Horizon 2020 33 months Completion September 2019 14

SLIDE 1

Auto-scaling deadline- constrained workloads

in containers in the cloud

Jay Jay DesLauriers DesLauriers Research Associate, University of Westminster

SLIDE 2

Project COLA

June 5th 2019 www.project-cola.eu 2

Horizon 2020
33 months
Completion September 2019
14 Partners in 6 Countries
10 SME/Public Sector
4 HE/Research Institutions

This project has received funding from the European Union’s Horizon 2020 research and innovation programme under grant agreement No 731574

SLIDE 3

Head in the clouds

June 5th 2019 www.project-cola.eu 3

On-Premise

Capital Expense High Upfront Cost High Maintenance Cost

Off-Premise

Pay-as-you-go No Upfront Cost No Maintenance Cost

SLIDE 4

A match made in ...

June 5th 2019 www.project-cola.eu 4

Containers

Operating-system virtualisation and application packaging for reusable, portable software

SLIDE 5

The Problem

June 5th 2019 www.project-cola.eu 5

Application 1 Application 2 Application N Service 1 Service 2 Service 3 Service 4 Service 5 Baseline resource consumption Variable resource consumption Cloud services Dynamic demand Manually adjusted supply Resource requirements To be replaced by automatically adjusted supply

Some requirements:

Dynamic Supply

(auto-scaling)

Vendor–free
Modular
Flexible
Secure

SLIDE 6

Finding a solution...

June 5th 2019 www.project-cola.eu 6

SLIDE 7

The Solution

June 5th 2019 www.project-cola.eu 7

cAdvisor Orchestrate VMs Monitor VMs & containers Translates ADT Enforces scaling Orchestrate containers

Occopus

Prometheus Submitter Policy Keeper Kubernetes TOSCA Application Description Template (ADT) Describes application, infrastructure, scaling policies, security policies Export VM/ container metrics Container Runtime

MiCADO MASTER NODE MiCADO WORKER NODE

ML based

ptimisation

Optimiser Node Exporter Docker

SLIDE 8

Scaling Use-Case No.1

June 5th 2019 www.project-cola.eu 8

Resource intensive services
Typically CPU/memory –bound apps/services
Containers & underlying VMs scale to meet demand

SLIDE 9

Scaling Use-Case No.2 ... ?

June 5th 2019 www.project-cola.eu 9

Multi-job experiments
Typically batch/parameter sweep jobs
Containers/VMs scale to complete jobs by deadline
Where do we put the jobs?
How do we execute them

(in containers!)

MICADO MASTER ADT: infrastructure and scaling rules MiCADO Submitter Policy Keeper (Scaling logic)

cqueue worker

MICADO WORKER

cqueue worker Jobs

Scale up/ down

R R jQueuer Agent

Jobs

Container and Cloud Orchestrator MICADO

<insert queue here>

SLIDE 10

JQueuer

June 5th 2019 www.project-cola.eu 10

Asynchronous Distributed Task Queue
Master Component
Runs externally
Queue & monitoring
Agent Component
Runs on worker VMs
Fetch & execute jobs

MICADO MASTER ADT: infrastructure and scaling rules

End user

MiCADO Submitter Policy Keeper (Scaling logic)

cqueue worker

MICADO WORKER

cqueue worker Jobs

Scale up/ down

jQUEUER MASTER jQueuer Agent

Jobs

experiment .json Container and Cloud Orchestrator MICADO

SLIDE 11

JQueuer Metrics

June 5th 2019 www.project-cola.eu 11

Metrics exported to MiCADO for scaling:

Queue length Jobs completed Jobs failed Jobs running Jobs remaining Time elapsed Average job length Time to deadline

SLIDE 12

The experiment

June 5th 2019 www.project-cola.eu 12

Determining the impact of changes in behavior on the spread of a disease across a population

SLIDE 13

Experiment design

June 5th 2019 www.project-cola.eu 13

Agent-based simulation
Repast Simphony
Three agents
Infected
Susceptible
Recovered
Simulate movement & interaction
f agents in an environment

SLIDE 14

Manual job allocation (baseline)

June 5th 2019 www.project-cola.eu 14

200 jobs

VM 3

Repast 3

1-hour

to complete all jobs VM 4

Repast 4

VM 1

Repast 1

VM 2

Repast 2

VM 5

Repast 5

equal distribution 40x jobs per VM

SLIDE 15

Automatic job allocation (MiCADO)

June 5th 2019 www.project-cola.eu 15

experiment.json

JQueuer Manager

MiCADO Worker 1

JQueuer Agent

Repast 1

MiCADO Master

200 jobs

MiCADO Worker 2

JQueuer Agent

Repast 2

MiCADO Worker n

JQueuer Agent

Repast n 1-hour

deadline

SLIDE 16

Results

June 5th 2019 www.project-cola.eu 16

Dynamic allocation of variable length jobs

results in a better use of cloud resources

Manually Allocated Allocated by MiCADO Manually Allocated Allocated by MiCADO

Manual allocation (baseline) Dynamic allocation (MiCADO)

5 VMs 3.86 VMs

SLIDE 17

Thanks!

June 5th 2019 www.project-cola.eu 17

github.com/micado-scale/ansible-micado
project-cola.eu/
T. Kiss, J. DesLauriers, G. Gesmier et al.,

A cloud-agnostic queuing system to support the implementation of deadline-based application execution policies, Future Generation Computer Systems (2019), https://doi.org/10.1016/j.future.2019.05.062

This project has received funding from the European Union’s Horizon 2020 research and innovation programme under grant agreement No 731574 Project Director: Dr. Tamas Kiss, University of Westminster, UK
