slide-1
SLIDE 1

Australian Gas Infrastructure Group Shipper Forum

March 2018

slide-2
SLIDE 2

2018 Shipper Forum

3:00 PM 4:00 PM Open

  • 1. Welcome
  • 2. Safety Moment
  • 3. Introduction by Chief Executive Officer - Ben Wilson
  • 4. Update by General Manager Commercial - Jon Cleary
  • 5. 2021 Shipper Engagement
  • 6. DBP Updates
  • 7. 2018 Operational Overview
  • 8. Tubridgi
  • 9. Questions?

An electronic version of the presentations delivered at today’s Shipper Forum will be made available to Shippers upon request

slide-3
SLIDE 3

Safety Moment

slide-4
SLIDE 4

B-Double Trailer Fire- December 2017

  • 4:51 am : Prowest Logistics Driver departed CS4 bound for CS3 and then

CS2

  • 9:05 am : departed for CS 2
  • 10:30am: As driver approached North West Coastal Highway from an

unsealed road he pulled over and “knocked” all the wheels to remove dust (usual practice) as well as check all wheels and tyres

  • 11:01am: Driver heard tyre blow out, and pulled over safely. Drivers found

tyre was on fire and attempted to extinguish but fire grew too strong and too quick. They attempted to separate trailer and prime mover (could only separate prime mover)

  • 11:31am: fire has engulfed both trailers, all drivers are safe and

acceptable distance from fire, await for DFS Onslow

  • 12:26pm: fire has burned almost out, drivers able to put out small spot

fires

  • 1:15 pm: DFES Onslow Arrived
  • 3:35 pm: DFES extinguished the fire and declared area safe
slide-5
SLIDE 5
slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9

Outcomes

  • That even with the best systems and processes in place that accidents

happen

  • Training and proper equipment minimised the impact of what could have

resulted from the accident (bush fires from spot fires)

  • Training also ensured that there was minimal risk to personnel and

environment

  • DFES commended drivers on controlling traffic and using the extinguisher to

put out spot fires

slide-10
SLIDE 10

Introducing Ben Wilson Chief Executive Officer AGIG

slide-11
SLIDE 11

About AGI G | A Leading Gas Player

  • Australian Gas Infrastructure Group (AGIG) was formed in May 2017.
  • Combines the operations of the DBP

, DDG, AGN and Multinet.

  • One of the largest gas infrastructure businesses in Australia

Combined Portfolio

Customers (million)

N/A N/A 0.66 1.25

1.91 Distribution (km)

  • 9,866

23,898

33,764 Transmission (km)

1,839 440 164 1,132

3,575 Storage Facilities (PJ)

  • 42
  • Storage

capacity Area

Western Australia Pilbara Melbourne Eastern and Central Australia

A national business Credit Rating

BBB N/A BBB+ BBB+ (pos)

Upgrades received Asset Value ($bn)

3.5 0.2 1.2 3.4

8.2

  • Largest gas

distributor in Australia

  • Major

transmission business

  • Strong balance

sheet

  • Enhanced

growth platform

  • Opportunities to

improve customer service and cost efficiency

slide-12
SLIDE 12
slide-13
SLIDE 13

About AGI G | Western Australia

Tubridgi Gas Storage

slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16

About AGI G | Executive Management Team

GM Network Operations Mark Beech Melbourne GM Transmission Operations James Smith Perth GM Transmission Asset Management Tawake Rakai Perth Chief Financial Officer Paul May Perth/Adelaide

4

GM People and Strategy Craig de Laine Adelaide GM Customer & I nformation Services Andrew Staniford Adelaide GM Commercial Jon Cleary Perth CEO Ben Wilson Perth/Adelaide

slide-17
SLIDE 17
  • 111 km, 6” diameter pipeline gas, completed June 2016.
  • Connects Onslow township to the DBNGP
  • Provides firm capacity of 9.6TJ/d with expandable capacity
  • f up to 12TJ/d
  • 270km, 16” diameter gas pipeline, completed March 2015.
  • Connects the central Pilbara area to the DBNGP
  • Provides firm capacity of 65TJ/d with expandable capacity
  • f up to 300TJ/d

FORTESCUE RIVER GAS PIPELINE

  • 110km, 16” diameter gas pipeline with a second 87km 10”

looped section, completed Dec 2014.

  • Connects the Wheatstone LNG Project to the DBNGP and

provides firm capacity of 337TJ/d with expandable capacity

  • f up to 600TJ/d

WHEATSTONE GAS PIPELINE ASHBURTON GAS PIPELINE

  • Construction to increase DBNGP capacity by over 50% since

2005 over three expansion programs has seen about $1.8 bln invested.

  • Stage 4 pipeline expansion completed in 2006. The

expansion included the construction of 217km of looping on the existing pipeline.

  • Stage 5A pipeline expansion completed in 2008. The

expansion included the construction of 570km of looping on the existing pipeline.

  • Stage 5B pipeline expansion completed in 2010. The

expansion included the construction of 440km of looping on the existing pipeline. DBP EXPANSION PROGRAM

  • Construction of a 50TJ/d gas processing plant at Tubridgi to

support the underground gas storage facility. TUBRIDGI GAS PROCESSING

Construction Capabilities

slide-18
SLIDE 18
  • Over 30 years of experience operating the DBNGP and third party

transmission pipelines and infrastructure assets

  • In-depth knowledge of legislations apply to domestic gas pipeline
  • Expert in the development and management of Safety Case and

Environmental Plan

  • Strong relationship with Western Australian regulatory agencies
  • Strong relationship with landowners and Native Title groups
  • 24/7 control room operation in Perth co-located with other DBP engineering

and corporate functions

  • Comprehensive and structured emergency response and preparedness

PIPELINE OPERATIONS

  • Pipeline construction experience acquired from DBNGP expansion Stage 4, 5

and recent construction of the Wheatstone, Fortescue and Ashburton Gas Pipelines

  • Successful delivery of projects valued at ~ $2.0b in time, on budget with zero

lost time injury (LTIs)

  • In-house project management capability
  • Established relationship with specialised contractors and equipment

manufacturers and maximising local content

  • Flexible commercial terms focusing on long-term strategic relationship over

short term gains PIPELINE DEVELOPMENT

Pipeline Operations Capability

slide-19
SLIDE 19

Update from General Manager Commercial Jon Cleary

slide-20
SLIDE 20

General Manager COMMERCIAL JON CLEARY Commercial Manager DDG Pipelines DAVID GANT Analyst Commercial CHRIS FAY Manager Control Room ROD LAMBERT Senior Commercial Manager DBNGP RACHAEL SMITH Manager C&P MARK WILLIAMS Commercial Officer FIONA DENNIS Commercial Manager Storage AARON BITMEAD Commercial Officer KYLIE MAWHINNEY Billing Services Specialist BRIAN MCGINLEY Senior Billing Service Analyst CRAIG MITCHELL Financial Analyst EMMA CONNOR Senior Commercial Manager Business Development COLIN SADLIER Commercial Administration MEL BUCHANAN

Commercial Organisation Chart

Commercial Officer MICHELLE AL- AJARMAH Commercial Analyst MARK WHITTINGTON Commercial Advisor GARETH OWENS Commercial Advisor TRENT LEACH Control Room Superintendent ANDREW PERRY CONTROL ROOM C & P TEAM

slide-21
SLIDE 21

Growth across AGI G| Tubridgi Gas Storage

  • Tubridgi Gas Storage facility commissioned
  • 42 PJ, 50TJ injection and 50 TJ withdrawal gas storage

facility connected to the 16” and 10” Wheatstone Ashburton West gas pipelines, 6” Tubridgi Lateral and the DBNGP

  • Preparing to expand the facility to 90TJ injection and

60TJ withdrawal with further expansion possible

slide-22
SLIDE 22

Growth across AGI G| Ashburton Onslow Gas Pipeline

  • Ashburton to Onslow Gas Pipeline being commissioned
  • 4”, 24km gas pipeline in Western Australia
  • An important piece of gas infrastructure to support the

development in the Onslow area and the development of a new gas fired power station in Onslow

slide-23
SLIDE 23

Growth across AGI G| Pluto Compressor Station

  • Pluto inlet compressor station under construction
  • 25TJ/d capacity providing a new inlet point on the DBNGP
  • An important piece of gas infrastructure to support the

development in the Onslow area and the development of a new gas fired power station in Onslow

slide-24
SLIDE 24

Growth across AGI G| Tanami Gas Pipeline

  • Tanami gas pipeline now under construction
  • 8”, 440km gas pipeline in Northern Territory
  • Tanami gas pipeline will provide gas to Newmont’s gold
  • perations in the Tanami desert and will be

interconnected to the Amadeus Gas Pipeline

slide-25
SLIDE 25

Growth across AGI G | Hydrogen Park South Australia

  • Hydrogen Park South Australia is being developed. Located in

Adelaide, the HyP SA project comprises a 1.25MW electrolyser

  • wned and operated by AGIG
  • Hydrogen will be produced from renewable electricity and

recycled water

  • Hydrogen injected into:
  • AGIG’s SA gas network decarbonising the direct use gas

sector

  • Tonsley Innovation District’s residential development,

delivering the greenest gas in Australia

  • Connected to the National Electricity Market, the project will

also investigate the ability of electrolysers to assist with network stability

  • First hydrogen production expected mid-2020

HyP SA, an achievable, short-term hydrogen production project, but modular and scalable with potential for future growth

slide-26
SLIDE 26

2021 Shipper Engagement

slide-27
SLIDE 27

Australian Gas I nfrastructure Group

  • We are committed to delivering for our Shippers
  • Over the next 6 months we will be engaging with the market to

understand future needs and requirements for gas transportation and other services.

  • The next Access Arrangement period is from 1 January 2021. Our

approach to the updated Access (ERA) proposal and potential recontracting will be focused on Shipper needs and expectations.

  • To ensure we keep improving our service offering, we will be

asking for your feedback via a regular satisfaction survey. We want to hear what we do well, and what we can do better.

  • We will also be engaging with you throughout the Access proposal

and recontracting processes.

slide-28
SLIDE 28

2018 DBP Updates

slide-29
SLIDE 29

Highlights

  • 100% availability of

the pipeline

  • 100% reliability of the

pipeline

  • No curtailments
slide-30
SLIDE 30

Three Years of WA Throughput

CY2015 CY2016 CY2017 Summary

  • Minor increase in demand across the Pilbara and additional production added
slide-31
SLIDE 31

Throughput and End Use

Throughput Analysis

slide-32
SLIDE 32

Throughput and End Use

2017

slide-33
SLIDE 33

Production Split and Equity Marketers

WA Annual Production Share

slide-34
SLIDE 34

Wheatstone Operations

DBP Producer Marketer 1 Marketer 1 Shipper 1 Shipper 2 Marketer 2 Marketer 2 Shipper 1 Shipper 3 Marketer 3

Physical Gas Meter at I nlet Gas Day + 1: 0800 Gas Day ends 0925 Producer / DBP agree Production for Gas Day; 0930 Marketers I nitial I nlet Allocation; 1025 Marketer to marketer transactions close 1030 DBP to Marketers Final Allocations; 1100 Marketers to Shippers & DBP Allocations for Gas Day 1300 DBP to Shippers with Final Allocation

slide-35
SLIDE 35

Gas I ndustry Golf Day

  • TBC
  • Proposed date: October 2018
  • Each team to self fund player fees (approx. ~ $1000 for 4

players)

  • Sponsorships available – enquire within (starts at $500)
slide-36
SLIDE 36

2018 Operational Overview

slide-37
SLIDE 37

General Maintenance: Unit and station offline. Projects: Turbine exchange, Vessel inspections, Pigging.

Outage Plan 2018

slide-38
SLIDE 38

Outage Plan 2018

Proposed maintenance program for 2018

  • All compressor units will be taken offline for maintenance on

a 6 monthly basis.

  • Outage time for the units will alternate between 42 and 66 hours.
  • All stations will be taken offline annually for checks to station

valves and ESD functions.

  • Station Outage times will vary between 12 and 72 hours.
slide-39
SLIDE 39

Project Plan 2018

Loopline Pigging 1 x Turbine exchange 4 x Vessel inspections.

slide-40
SLIDE 40

Outage Plan 2018

Unit

  • ffline

Station

  • ffline

Handov er Online Maint

APRIL 2018 PIPELINE OPERATION PLAN

1-Apr 2-Apr 3-Apr 4-Apr 5-Apr 6-Apr 7-Apr 8-Apr 9-Apr 10-Apr 11-Apr 12-Apr 13-Apr 14-Apr 15-Apr 16-Apr 17-Apr 18-Apr 19-Apr 20-Apr 21-Apr 22-Apr 23-Apr 24-Apr 25-Apr 26-Apr 27-Apr 28-Apr 29-Apr 30-Apr SM Sun Mon Tue Wed Thu Fri Sat Sun Mon Tue Wed Thu Fri Sat Sun Mon Tue Wed Thu Fri Sat Sun Mon Tue Wed Thu Fri Sat Sun Mon CS1 ST CS1 U1 CS1 U2 CS2 ST CS2 U1 CS2 U2 CS2 U3 CS3 ST CS3 U1 CS3 U2 CS3 U3 CS4 ST CS4 U1 CS4 U2 CS4 U3 CS5 ST CS5 U1 CS5 U2 CS6 ST CS6 U1 CS6 U2 CS6 U3 CS7 ST CS7 U1 CS7 U2 CS7 U3 CS8 ST CS8 U1 CS8 U2 CS9 ST CS9 U1 CS9 U2 CS10 ST CS10 U1 CS10 U2 CS10 U3 CS10 U4

Rev 3

16 Feb 18

slide-41
SLIDE 41

Unit offline Station

  • ffline

Handover Preferred Unit

MARCH 2018 PIPELINE OPERATION PLAN

1-Mar 2-Mar 3-Mar 4-Mar 5-Mar 6-Mar 7-Mar 8-Mar 9-Mar 10-Mar 11-Mar 12-Mar 13-Mar 14-Mar 15-Mar 16-Mar 17-Mar 18-Mar 19-Mar 20-Mar 21-Mar 22-Mar 23-Mar 24-Mar 25-Mar 26-Mar 27-Mar 28-Mar 29-Mar 30-Mar 31-Mar SM Thu Fri Sat Sun Mon Tue Wed Thu Fri Sat Sun Mon Tue Wed Thu Fri Sat Sun Mon Tue Wed Thu Fri Sat Sun Mon Tue Wed Thu Fri Sat CS1 ST CS1 U1 CS1 U2 CS2 ST CS2 U1 CS2 U2 CS2 U3 CS3 ST CS3 U1 CS3 U2 CS3 U3 CS4 ST CS4 U1 CS4 U2 CS4 U3 CS5 ST CS5 U1 CS5 U2 CS6 ST CS6 U1 CS6 U2 CS6 U3 CS7 ST CS7 U1 CS7 U2 CS7 U3 CS8 ST CS8 U1 CS8 U2 CS9 ST CS9 U1 CS9 U2 CS10 ST CS10 U1 CS10 U2 CS10 U3 CS10 U4

Rev 5

02 Mar 18

slide-42
SLIDE 42

Tubridgi Update

slide-43
SLIDE 43

Tubridgi Gas Storage

  • Commissioned 2 September 2017
  • 42PJ storage capacity
  • 50TJ/d injection and withdrawal capacity
  • Foundation customer Citic Pacific Mining
  • Traditional uses
  • Balancing seasonal load variations
  • Security of supply
  • Non-traditional uses
  • Gas trading opportunities
  • Electricity price arbitrage
  • Gas contract management
  • Several storage contracting options are available
slide-44
SLIDE 44

Tubridgi Gas Storage- Before

slide-45
SLIDE 45

Tubridgi Gas Storage- After

slide-46
SLIDE 46

Tubridgi Gas Storage

slide-47
SLIDE 47

Tubridgi Gas Storage

slide-48
SLIDE 48

Tubridgi Gas Storage

slide-49
SLIDE 49

Questions?

slide-50
SLIDE 50
