At which IPv6 stage are you? Scared The address is too long! All my IP addresses are traceable! Angry It's a conspiriacy there is no IPv4 shortage! As long as I get an IPv4 address I don't care! Nobody is using it anyway! Confused

slide-1
SLIDE 1

At which IPv6 stage are you?

slide-2
SLIDE 2

The address is too long! All my IP addresses are traceable!

Scared

slide-3
SLIDE 3

It's a conspiriacy there is no IPv4 shortage! As long as I get an IPv4 address I don't care! Nobody is using it anyway!

Angry

slide-4
SLIDE 4

There are so many new acronyms. SLAAC, DAD, RA, ND ... Why can't I reach IPv6 websites over IPv4? Why are multiple IPv6 address assigned to interfaces?

Confused Confused

slide-5
SLIDE 5

My home network is running on IPv6. I know what SLAAC, RD and ND are. I can classify IPv6 addresses. I can configure an IPv6 firewall.

::BFF

slide-6
SLIDE 6

The address is too long!

Really?

T h i s i s a P e r f e c t l y v a l i d I P v 6 a d d r e s s

fd00::1

slide-7
SLIDE 7

All my IP addresses are traceable!

slide-8
SLIDE 8

It's a conspiriacy there's no IPv4 shortage!

Source: http://ipv6.he.net

Hurricane Electric's IPv4 exhaustion counter shows a big yellow zero. And RIRs are running towards 0 as well.

slide-9
SLIDE 9

Nobody is using it anyway!

Source: http://www.google.com/intl/en/ipv6/statistics.html

slide-10
SLIDE 10

Nobody is using it anyway!

Source: http://www.google.com/intl/en/ipv6/statistics.html

World Wide Users

slide-11
SLIDE 11

As long as I get my IPv4 address I don't care!

Source: https://www.metanet.ch/support/online-hilfe-faq/question?questionid=371

IPv6 Status

Umstellungsphase Alle Kunden erhalten die gleiche Anzahl IPv6-Adressen gemäss Zuteilung im IPv4-Adressraum, um die Dual-Stack-Implementation (Parallelbetrieb) sicherstellen zu können. Die Zuweisung erfolgt ohne zusätzlichen Kosten. Bestehende Kunden können die Zuteilung via Support System jederzeit anfragen. Diese Phase dauert an bis die METANET IPv4-Allokation ausgeschöpft ist. Post-Transitionsphase Neue Systeme erhalten ab diesem Zeitpunkt nur noch IPv6-

  • Adressen. Dies wird voraussichtlich nicht vor 2016 der Fall sein.
slide-12
SLIDE 12

There are so many new acronyms.

SLAAC

StateLess Address AutoConfiguration.

Unlike DHCP in IPv4 the host portion of the IPv6 address is independently determined by the host itself.

DAD

Duplicate Address Detection

Ensures there is no other Host on the same broadcast domain.

ND

Neighbor Discovery Protocol

Used for getting information about the network neighborhood, somwhat similar to ARP.

RA

Router Advertisement

Part of the NDP. Sent by a router to annouce a gateway to into the subnet.

slide-13
SLIDE 13

Why can't I reach IPv6 websites over IPv4?

P r

  • t
  • c
  • l
slide-14
SLIDE 14

Why are multiple IPv6 addresses on interfaces?

urs@teefix:~$ ip -6 addr show dev eth0

2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qlen 1000 inet6 2001:8e0:2003:b200:c0d7:1c4e:f566:cfbb/64 scope global \ temporary dynamic valid_lft 86395sec preferred_lft 14395sec inet6 2001:8e0:2003:b200:b9a9:fd99:2034:3634/64 scope global \ temporary deprecated dynamic valid_lft 86395sec preferred_lft 0sec inet6 2001:8e0:2003:b200:216:17ff:fe32:ed96/64 scope global \ dynamic valid_lft 86395sec preferred_lft 14395sec inet6 fe80::216:17ff:fe32:ed96/64 scope link valid_lft forever preferred_lft forever

L i n k L O c a l E U I

  • 6

4

`

D e p r e c a t e d P EA c t i v e P E

`

slide-15
SLIDE 15

Dualstack champions IPv4 only lamers!

Tech Company IPv6 Probe

kernel.org kernel.org

slide-16
SLIDE 16

Wanna use IPv6 at home?

slide-17
SLIDE 17

IPv6 ready IPv4 only lamers!

Swiss ISP ofgering IPv6*

slide-18
SLIDE 18

Dig a tunnel!

slide-19
SLIDE 19

IPv6 consumer routers*

slide-20
SLIDE 20

Get a free certifjcate

slide-21
SLIDE 21
slide-22
SLIDE 22

Fun with IPv6 addresses!

slide-23
SLIDE 23

Fun with IPv6 addresses! IPv4 is 32bit 4 294 967 296

11111111 11111111 11111111 11111111

255 . 255 . 255 . 255

slide-24
SLIDE 24

Fun with IPv6 addresses! IPv6 is 128bit 340 282 366 920 938 \ 463 463 374 607 431 \ 768 211 456

slide-25
SLIDE 25

Fun with IPv6 addresses!

032: 1111 1111 1111 1111 1111 1111 1111 1111 064: 1111 1111 1111 1111 1111 1111 1111 1111 096: 1111 1111 1111 1111 1111 1111 1111 1111 128: 1111 1111 1111 1111 1111 1111 1111 1111

255.255.255.255.255.255.255.255.\ 255.255.255.255.255.255.255.255

fgfg:fgfg:fgfg:fgfg:fgfg:fgfg:fgfg:fgff

slide-26
SLIDE 26

Fun with IPv6 addresses!

2001:0db8:0000:0000:0000:0001:0002:0003

2001:db8:0:0:0:1:2:3

2001:db8::1:2:3

slide-27
SLIDE 27

Fun with IPv6 addresses!

Elite = 1337 Newbie = n00b

slide-28
SLIDE 28

Fun with IPv6 addresses! Translation table

g i k l o s t y z 9 : 1 c 1 0 5 7 : 1 2

slide-29
SLIDE 29

2001:db8::face:b00c

slide-30
SLIDE 30

2001:db8::D00:d1e

slide-31
SLIDE 31

2001:db8::da7e

slide-32
SLIDE 32

2001:db8::900:91e

slide-33
SLIDE 33

2001:db8::C057:a:de1:501

slide-34
SLIDE 34

2001:db8::ad:da5

slide-35
SLIDE 35

2001:db8::ba:1a:ba:1a

slide-36
SLIDE 36

2001:db8::1ad:9a9a

slide-37
SLIDE 37

Eidgenössische Zollverwaltung EZV

2001:db8::2011:57:7011

slide-38
SLIDE 38

2001:db8::ea7:1e55

slide-39
SLIDE 39

2001:db8::9e:55

slide-40
SLIDE 40

2001:db8::90a7

slide-41
SLIDE 41

2001:db8::9:9010

slide-42
SLIDE 42

2001:db8::Be1f:e

slide-43
SLIDE 43

2001:db8::bab:face

slide-44
SLIDE 44

2001:db8::B055

slide-45
SLIDE 45

2001:db8::4:be57:1dea

slide-46
SLIDE 46

2001:db8::50:50:1a:1a

slide-47
SLIDE 47

2001:db8::ba1a:ba1a

slide-48
SLIDE 48

No IP Address or Network Equipment was harmed in the making of this presentation
