Assessing Fault Sensitivity in MPI Applications

Charng-Da Lu Center for Computational Research SUNY at Buffalo Daniel A. Reed Microsoft Research

Outline

• Introduction

– background and motivations – reliability challenges of large PC clusters

• Failure modes

– memory and communication errors

• Fault injection experiments

– methodology and experiments – analysis and implications

• Conclusions

– large-scale cluster design – software strategies for reliability

Large Computing Systems

Machine Processor Cores PetaFLOPS Year K Computer 705,000 10.5 2011 Jaguar 224,000 1.8 2009 Tianhe-1A 186,000 2.6 2010 Hopper 153,000 1.1 2011 Cielo 142,000 1.1 2011 Tera100 138,000 1.0 2010 RoadRunner 122,000 1.0 2008

• Dominant constraints on size

– power consumption, reliability and usability

Node Failure Challenges

• Domain decomposition

– spreads vital data across all nodes – each spatial cell exists in one memory

» except possible ghost or halo cells

• Single node failure

– causes blockage of the overall simulation – data is lost and must be recovered

• “Bathtub” failure model operating regimes

– infant mortality – normal mode – late failure mode

• Simple checkpointing helps; the optimum interval is roughly

where δ is time to complete a checkpoint M is the time before failure R is the restart time due to lost work

Elapsed Time Failure Rate Burn in Normal Aging Late Failure

Machine Core Count Reliability ASCI Q

8,192 MTBI 6.5 hr. 114 unplanned outages/month. HW outage sources: storage, CPU, memory *

ASCI White

8,192 MTBF 5 hr (’01) and 40 hr (’03) HW outage sources: storage, CPU, 3rd party hardware **

NERSC Seaborg

6,656 MTBI 14 days. MTTR 3.3 hr Availability 98.74%. SW is main outage source. ***

PSC Lemieux

3,016 MTBI 9.7 hr Availability 98.33% ****

Google

~15,000 20 reboots/day. 2-3% machines replaced/year. HW outage sources: storage, memory *****

Large Systems Reliability

*J. Morrison (LANL): “The ASCI Q System at Los Alamos,” SOS7, 2003 ** M. Seager (LLNL): “Operational machines: ASCI White,” SOS7, 2003 *** http://hpcf.nersc.gov/computers/stats/AvailStats **** M. Levine (PSC): “NSF’s terascale computing system,” SOS7, 2003 ***** J. Hennessy et al, “Computer Architecture: A Quantitative Approach”, 3rd edition, 2002

Large System Reliability

• Facing the issues

– component MTBF – system size – usable capability

• A few assumptions

– assume independent component failures

» an optimistic and not realistic assumption

– N is the number of processors – r is probability a component operates for 1 hour – R is probability the system operates for 1 hour

• Then or for large N

1 hour reliability System Size MTTF (hours)

Component Reliability

• Two basic types

– hard (permanent) errors – soft (recoverable) errors

• Hard errors

– permanent physical defects – memory: 160-1000 years MTBF for 32-64 Mb DRAM chips – disk: 50-100 years MTBF (?) – node: 3-5 years (warranty period)

• Soft errors

– transient faults in semiconductor devices

» alpha particles, cosmic rays, overheat, poor power supplies, ..

– ECC memory isn’t 100% secure

» 80-95% protection rate

– much more likely than hard errors

» 10 days MTBF for 1GB RAM

– continues to worsen as chip geometries shrink

Memory Soft Error Rates

Memory Type MTBF in days (1 GB) Commercial CMOS memory 0.8 4M SRAM > 1.2 1Gb memory (NightHawk) 2.3 SRAM and DRAM 2.6-5.2 8.2 Gb SRAM (Cray YMP-8) 4 SRAM 5.2 256 MB 7.4 160 Gb DRAM (FermiLab) 7.4 32 Gb DRAM (Cray YMP-8) 8.7 MoSys 1T-SRAM (no ECC) 10.4 Micron estimates, 256 MB 43-86

Source: Tazzaron Semiconductor, “Soft Errors in Electronic Memory – A White Paper”

Communication Errors

• Soft errors occur on networks as well

– routers, switches, NICs, links ...

• Link-level checksum = Reliable transmission?

– Stone and Patridge’s study* shows

» probability of Ethernet’s 32-bit CRC not catching errors

 1/1,100 to 1/32,000

– theoretically, it should be 1/(4 billion)

• To make things worse

– performance-oriented computing favors OS-bypass protocols

» relative to TCP

– message integrity solely relies on link-level checksum

* J. Stone and C. Partridge “When the CRC and TCP checksum disagree” in ACM SIGCOMM 2000

Terminology

• Error/failure

– system behavior deviates from specification – omission

» occasionally no response…

– response

» incorrect

– performance

» response is correct but not timely

– crash/hang

• Fault

– single event upset

» bit flips

– single event burnout

» power surge

– Bohrbug

» determinism

– Heisenbug

» race condition » rare input

– ageing

» resource exhaustion is the source

• f

is the manifestation

• f

Experiments

• Goal: study the impact of bit-flip faults on MPI codes
• Rationale

– it is easier to detect hard errors and assess their damage – what about transient faults? – crash? hang? incorrect output? …

• Approach: fault injection

 Software-based – inexpensive and portable – targets a wide range of components – OS, libraries, applications ... – address bus, ALU, memory ...

• Hardware-based

– expensive – heavy ion bombarding or lasers – pin-level probes and sockets – Alpha particles, bit-flips, power surge, 0/1 stuck-at ...

Register Fault Injection

• Processor (x86)

– User-space injection – Regular registers and x87 FPU registers – No injection to special purpose registers (need root privilege)

» System control registers, debug and performance registers » Virtual memory management registers, MMX/SSE..

– No injection to L2/L3 caches, TLB

Memory Fault Injection

• Memory

– Focus on application memory – Injection addresses have uniform distribution. – Skip library memory

» MPI and shared libraries

– Text, Data, BSS – Heap and stack

Linux Process Memory Model

Message Fault Injection

• Simulate faults that link-

level checksums miss

– Use MPICH for communication – Inject at the level closest to

• perating system

» but avoid perturbing the

• perating system (for

testability)

– Can affect all kinds of messages

» Control, point-to-point, collective operations…

Memory Fault Injector

• ptrace UNIX system call

– Attach to and halt a host process – Peek/poke register and memory contents (like gdb)

• Static objects (Text, Data, BSS)

– Used nm and objdump utilities to find the range of injection – Skipped all MPI objects

• Dynamic objects (Heap and stack)

– Created customized malloc/free

» separates application objects from MPI objects

– Examined return addresses in stack frames

» determine the range of stack injection

Message Fault Injector

• MPICH

– Developed by Argonne National Laboratory – Highly portable MPI implementation – Adopted by many hardware vendors

• Fault injector

– Modified MPICH library – Uses “ch_p4” channel (TCP/IP) – Faults injected in the payload

» immediately after receipt from a socket

– Both MPICH and user applications are vulnerable to message faults

Experimental Environment

• A meta-cluster formed from two clusters

– Rhapsody

» 32 dual 930 MHz Pentium III nodes » 1 GB RAM/node » 10/100 Gigabit Ethernet

– Symphony

» 16 dual 500 MHz Pentium II nodes » 512 MB RAM/node » Ethernet and Myrinet

Fault Assessment Code Suite

• Cactus Wavetoy

– PDE solver for wave functions in physics – Test problem

» 150x150x150 for 100 steps » 196 processes

• CAM

– Community Atmospheric Model – Test problem

» default test dataset for 24 hours of simulated time » 64 processes

• NAMD

– Molecular dynamics code – Test problem

» 92,000 atoms and 20 steps » 96 processes

Injection Location Cactus NAMD CAM Memory 1.1 MB 25-30 MB 80 MB Text Size 330 KB 2 MB 2 MB Data Size 130 KB 110 KB 32 MB BSS Size 5 KB 598 KB 38 MB Heap Size 450-500 KB 22-27 MB 8 MB Message 2.4-4.8 MB 13-33 MB 125-150 MB

Test Code Suite Characteristics

Experimental Fault Assessment

• Failure modes

– Application crash

» MPI error detected via MPI error handler » Application detected via assertion checks » Other(e.g., Segmentation fault)

– Application hang (no termination) – Application execution completion

» correct (fault not manifest) or incorrect output

Cactus Wavetoy Results

500-2000 injections for each category

NAMD Results

~500 injections for each category

CAM Results

~500 injections for each category

Register Injection Analysis

• Registers are the most vulnerable to transient faults

– 39-63% error rate overall – Results could depend on register management

» Live register allocation and size of register file » Optimization increases register use

• Error rates for floating point registers are much lower

– 4-8% error rate – Most injections into control registers do not generate errors

» Except the Tag Word register, which turns a number into NaN

– Injections into data registers do not yield high error rates

» At most 4 out of 8 data registers are in use » A data register is actually 80-bit long, but only 64 bits can be read out.

Memory Injection Analysis

• Error rates for memory injections are very low

– 3-15% error rate – Spatial locality: Memory is not accessed – Temporal locality: Memory is overwritten before reuse

• Working set analysis

– To understand memory access behavior – Collected memory load data

» Using Valgrind, an open-source x86 memory debugging tool

Working Set Analysis

• Definition of working set at time t

– Size of accessed memory since t – Non-increasing

• Larger working size → Higher chance of

fault-induced errors

Memory Access Behavior

Memory Access Behavior

Message Injection Analysis

• NAMD and CAM are sensitive to message faults

– 38% and 24% error rates, respectively

• NAMD

– Built-in message integrity checks are lightweight and effective – 46% of errors are detected, only 28% of errors are incorrect output

• CAM

– only 3% of errors are caught, 71% of errors are incorrect output

• Cactus Wavetoy’s error rate is very low

– The output we used to verify correctness is in plain text format – Low order decimal digits are not reported – Only perturbation in significant bits will manifest in a short run – After more steps of execution, the error will manifest

What is an Exascale System?

• Embrace failure, complexity, and scale

– a mind set change

Failures and Autonomic Recovery

• 106 hours for component MTTF

– Sounds like a lot until you divide by 105!

• It’s time to take RAS seriously

– Systems do provide warnings

» Soft bit errors – ECC memory recovery » Disk read/write retries, packet loss and retransmission

– Status and health provide guidance

» Node temperature/fan duty cycles

• Software and algorithmic responses

– Diagnostic-mediated checkpointing – Algorithm-based fault tolerance – Domain-specific fault tolerance – Loosely synchronous algorithms – Optimal system size for minimum execution time

Fault Tolerance Support in MPI

• MPI is a standard, not an implementation

– MPI standard: “After an error is detected, the state of MPI is undefined” – Most implementations: Abort whenever there is any error.

• What about MPI_Errhandler_set API in MPI 1 ?

– Not what you think ! – Only handles semantic errors such as sending messages to a non- existing MPI process.

• What about MPI 2 standard?

– Can spawn MPI processes dynamically. – Has listen/accept/connect BSD socket-like APIs.

• MPI 3 work-in-progress

– Redefines MPI semantics: e.g. Failed MPI processes treated as non-existing MPI processes – MPI 3 FT Working Group: http://www.mpi-forum.org

Conclusions

• The most damaging soft bit errors

– Register and message contents

• Memory errors, albeit less likely

– Are still a critical failure mode for large systems

• Application internal checks can catch errors

– Defensive programming is important at scale

• MPI Standard

– Supports very minimal error detection and recovery – Fault-tolerant MPI support and extensions are needed

• It’s time to take reliability seriously

– RAS is critical to continued system scaling
