As Fit Solutions The Steel Way The FT Story Started in 1982 over 30 years trading with a steady, constant expansion of customers, supply chains and product lines. Circa 50M turnover in AMP 4 and AMP 5 combined.

slide-1
SLIDE 1

“As Fit” Solutions – The Steel Way

slide-2
SLIDE 2

The FT Story

  • Started in 1982 – over 30 years trading with a steady, constant expansion of

customers, supply chains and product lines.

  • Circa £50M turnover in AMP 4 and AMP 5 combined.
  • Now have two divisions of the Frazer and Tabberer Group:
  • FT Pipeline Systems & FT Ductile are based in Lichfield, Staffordshire.
  • FT Pipeline Systems cover:
  • Locking Replacement Lids
  • Coated and Lined Steel Pipes
  • Fittings
  • As Fit Solutions
  • Field Joint Protection
slide-3
SLIDE 3

Steel Specifications

  • Specifications: CESWI ed 7
  • Mill: EN10224
  • Stockist: EN10208, EN10225, EN10215,

EN10217, API

  • Steel

Grades:

L235, L275, L355

  • r

equivalent according to specification

  • Dimensions: 100mm to 4000mm
  • Standard pipe lengths:

8m – 13.5mL +/-500mm

  • Test certification: EN 10204/3, 1.
slide-4
SLIDE 4

Coatings and Linings

Surface Preparation SA 2.5 ISO 8501 Coatings:

Standard

– Three Layer Polyethylene EN DIN 30 670 – Three Layer Polypropylene EN DIN 30 678 – Versathane EN 10339 – Scotchkote 165 HB 3M instructions – Interzone 954 International Paints instructions – Polyken Tape Coatings AWWA Standard C-209 – Scotchkote 206N 3M instructions

Linings:

– Cement Mortar EN 10298 – Seal coated cement ISO EN 6132 – Scotchkote 162 PW 3M instructions – Scotchkote 206 N 3M instructions – Thixo 468 BS Coatings instructions – Waste Water various options available Other standards: SSPC-PA2,

slide-5
SLIDE 5

Gloucester SoS and Mitcheldean

Grade L275 Wt 6.3mm PN25 rated No Thrust Blocks Three Layer PE coating Cathodic Protection

slide-6
SLIDE 6

Directional Drills

Wessex Water’s Grid Mains South Staffs @ Stourport Butt Weld

slide-7
SLIDE 7

River Crossings

250mm twin main and 800mm single main installation – welded above ground and lifted into position at the River Irwell Socket Weld

slide-8
SLIDE 8

Waste Water

Southern Water @ Budds Farm Welsh Water – Chester Sewer Replacement

slide-9
SLIDE 9

Outfall pipework

  • Specialist coatings for specific

applications:

T-Rib for crossings and weight coatings

1. Steel 2. FBE 3. Adhesive 4. Polyethylene 5. T-Rippe 6. Cement 1 2 3 5 4 6

Isle of Man, Jurby and Saint Michael’s Outfalls

slide-10
SLIDE 10

Pipe Bridges

Holywell Dene – NWL Indeck Bridge Crossings for Scottish Water Self supporting pipe spans Flanged Pipework

slide-11
SLIDE 11

Auger bore pipework

STW – Trimpley WTW (450mm) SEW – Barcombe (800mm) Bespoke spacers as single or double carriers

slide-12
SLIDE 12

Pipe Bursting

slide-13
SLIDE 13

Abberton Reservoir - NWL

Ejoint Pipework

slide-14
SLIDE 14

Canusa Sleeve Application

EN DIN 30 672

slide-15
SLIDE 15

Cathodic Protection BS 7361

1) Sacrificial Anode 2) Impressed Current

Peter Smith – ProTech CP 07717 487632 pmsmith@protechcp.com Corrosion cell / Bimetallic corrosion

Standards:

BS 7361 & AWWA M27

Causes of corrosion:

Difference in natural potential between materials Metallurgical differences at different points of the surface Environmental differences – O2 levels

Influences on corrosion:

Water table Electrified railway Power cables Other pipelines Metallic bridges Low Resistivity Brownfield sites Aggressive soils Acidic Conditions

slide-16
SLIDE 16

Quality Control and Traceability

Welding specification EN 4515 Magnetic Particle Inspection EN ISO 9934 Inspection Documents EN 10204
