ARTIFICIAL INTELLIGENCE

Lecturer: Silja Renooij

Pathfinding and search

Utrecht University The Netherlands

These slides are part of the INFOB2KI Course Notes available from www.cs.uu.nl/docs/vakken/b2ki/schema.html

INFOB2KI 2019-2020

Pathfinding

2

`Physical’ world: open space or structured?

Contents

• Dijkstra, BFS, DFS, DLS, IDS
• Differences with elective course

‘Algoritmiek’:

– Theory all by example: Dijkstra in detail,

• thers more superficial. Some more in-

depth in Project B – Emphasis on difference tree-search / graph-search – Emphasis on comparison of properties rather than proofs of properties.

3

4

Pathfinding in Romania

Requirements for search

• 1. States S: abstract represention of (set of) real state(s)

– E.g. all cities on a map, or all possible paths in a grid or (waypoint) graph – A problem typically assigns an initial state (e.g "in Arad“) and a goal state (e.g. "in Zerind“)

• 2. Actions (operators/production rules) S  S’: abstract

representation of combination of real actions

– E.g. change from one path to another by change of links – Each abstract action should be "easier" than the original problem; e.g., "Arad  Zerind" represents a complex set of possible routes, detours, rest stops, etc.

5

State space for search

The state space represents all states reachable from the initial state by any sequence of actions. A tree or graph with nodes S and (un)directed edges S  S’ is used as state space representation. A search algorithm is applied to the state space representation to find a solution (abstract representation of solution in the real world)

– for guaranteed realizability, a sequence of actions maps initial state to goal state – e.g. list of connections = real path

6

Searching the state space

• 3. Strategy

– Defines how to search through state space – E.g. Systematic (desirable, not always possible):

• All states are visited
• No state is visited more than once

Search algorithms:

• differ in employed strategy
• build a search tree to explore state space
• often “create” state space while searching (space often

too large to represent all solutions

• create (portions of) all paths while finding a good path

between two points

7

8

Different representations

• Real world is absurdly complex

 We often represent the world in a simplified way

In addition, the search space is abstracted for problem solving in the world An abstract representation of the world is not the same as a state space representation suitable for problem solving! The map of Romania is represented as a graph with cities as nodes, and edges representing existing connections between

• cities. We can also use grids or waypoint graphs to represent the

real world. As state space representation for path finding we can use, e.g.

• the same structure as the domain representation (nodes in the grid /

(waypoint) graph), or

• nodes to represent entire paths (lists of connections) on this grid/graph,…

Dijkstra’s algorithm

• Solves the single‐source shortest path

problem using GRAPH‐SEARCH

• Source state  start node of search
• Each connection is associated with a cost,
• ften called step‐cost
• The cost‐so‐far is the cost to reach a node n

along a given path from the start node (often called path‐cost, denoted g(n) )

• Result: to each n, a path with minimal g(n)

9

Edsger W. Dijkstra 1930‐2002

Dijkstra’s algorithm

Bookkeeping:

• open list (seen, but not processed)
• closed list (completely processed)
• cost‐so‐far & connections (path) followed to get here

Init: open list  (start node, cost‐so‐far=0) Iteration: Process node from open list with smallest cost‐so‐far Terminate:

• When open list is empty
• Follow back connections to retrieve path

10

11

Dijkstra’s algorithm: example

Open: (Arad,0) Closed:

12

Dijkstra’s algorithm: example

Open: (Z,75)Arad, (S,140)A, (T,118)A Closed: (Arad,0)

13

Dijkstra’s algorithm: example

Open: (S,140)A, (T,118) A, (O,146) Z Closed: (Arad,0), (Z,75)A

14

Dijkstra’s algorithm: example

Open: (S,140) A, (O,146) Z, (L,229)T Closed: (Arad,0), (Z,75) A, (T,118) A

15

Dijkstra’s algorithm: example

Open: (O,146)Z, (L,229) T, (R,220)S, (F,239) S Closed: (Arad,0), (Z,75) A, (T,118) A, (S,140) A

 140 + 151 > 146

16

Dijkstra’s algorithm: example

Open: (L,229) T, (R,220) S, (F,239) S Closed: (Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z

17

Dijkstra’s algorithm: example

Open: (L,229) T, (F,239) S, (C,366)R, (P,317) R Closed: (Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z, (R,220) S

18

Dijkstra’s algorithm: example

Open: (F,239) S, (C,366) R, (P,317) R, (M,299)L Closed: (Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z, (R,220) S, (L,229) T

19

Dijkstra’s algorithm: example

Open: (C,366) R, (P,317) R, (M,299) L, (B,450)F Closed: (Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z, (R,220) S, (L,229) T, (F,239) S

20

Dijkstra’s algorithm: example

Open: (C,366) R, (P,317) R, (B,450) F, (D,374)M Closed: (Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z, (R,220) S, (L,229) T, (F,239) S, (M,299) L

21

Dijkstra’s algorithm: example

Open: (C,366) R, (B,450) F, (D,374) M, (B,418)P Closed:(Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z, (R,220) S, (L,229) T, (F,239) S, (M,299) L, (P,317) R

 317+138>366

22

Dijkstra’s algorithm: example

Open: (D,374) M, (B,418) P Closed:(Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z, (R,220) S, (L,229) T, (F,239) S, (M,299)L, (P,317) R, (C,366) R

366+120>374

23

Dijkstra’s algorithm: example

Open: (B,418) P Etc…. (Dijkstra continues, we stop…) Closed: (Arad,0), (Z,75) A, (T,118) A, (S,140) A (O,146) Z, (R,220) S, (L,229) T, (F,239) S, (M,299) L, (P,317) R, (C,366) R, (D,374) M

24

Dijkstra’s algorithm: example

Retrieve path to … Bucharest

(Arad,0), (Z,75) A, (T,118) A, (S,140) A, (O,146) Z, (R,220) S, (L,229) T, (F,239) S, (M,299) L, (P,317) R, (C,366) R, (D,374) M,(B,418) P

Dijkstra’s algorithm: summary

• Start with paths of length 1 and expand the
• ne with lowest (non‐negative!) cost first
• All paths will be found (and no path will be

found more than once)

• GRAPH‐SEARCH algorithm: i.e. uses closed list

concept to avoid loops

• Recall: solves the single‐source shortest path

problem  Not aimed at finding path to one specific goal…

25

26

TREE-SEARCH algorithms

Simulated exploration of state space by generating successors of already‐explored states (a.k.a. expanding) – initial state  start node of tree – expand: function that generates leafs for successors  fringe (= frontier = open list) with all leafs – goal state: used in goal test

Note: goal‐test only when node is considered for expansion, not already upon generation!

27

Pseudocode general TREE-SEARCH

# fringe = frontier = open list Note: goal‐test upon expansion; sometimes more efficient upon generation!

28

Implementation: states vs. nodes

• (As before) State S is abstract representation of physical

configuration in problem domain; it corresponds to a node in the state space representation

• A node x in a search tree constructed upon exploring the

state space is a data structure containing info on:

– state S – parent node – action – path cost g(x), – depth,…

• Expand: function that

– creates new nodes – fills in the various node fields – uses problem‐associated Successor‐Fn to generate successors

29

TREE-SEARCH example

Node for initial state “Arad” in fringe

30

TREE-SEARCH example

• Node related to state “Arad” is expanded and removed

from fringe

• Nodes related to states “Sibiu” (~path from Arad to Sibiu),

“Timisoara” and “Zerind” are generated and added to the fringe

31

TREE-SEARCH example

Suppose strategy selects node related to state “Sibiu” for expansion:

• a.o. node related to state “Arad” is generated
• and added to the fringe

 oops….there’s a loop….!

32

Repeated states

Failure to detect repeated states can turn a linear problem into an exponential one!

33

Avoiding loops

Method 1:

• Don’t add node to the fringe if we generated a node for

the associated state before  What if there are multiple paths to a node and we want to be sure to get the shortest ? (like e.g. to Oradea) Method 2: GRAPH SEARCH

• Don’t add node to the fringe if we expanded a node for

the associated state before Keep a closed (=explored=visited) list of expanded states (c.f. Dijkstra) This is not for free: takes up time and memory!

34

GRAPH-SEARCH

35

TREE-SEARCH vs GRAPH-SEARCH

GRAPH‐SEARCH = TREE‐SEARCH + a closed list of explored states

GRAPH‐SEARCH is used to prevent searching redundant paths; search algorithms can be implemented as either one. NB tree vs graph in this context refers to:

• structure underlying the state space

It does not refer to:

• structure built during search (a tree in both cases)
• simplified representation of problem domain

– e.g. the road map

36

Search strategies

• A search strategy defines the order of node expansion
• Strategies are evaluated along the following dimensions:

– completeness: does it always find a solution if one exists? – optimality: does it always find a least‐cost solution? – time complexity: how long does it take to find a solution? – space complexity: how much memory is needed?

• Time and space complexity are measured in terms of

– b: maximum branching factor of the search tree (max # succ.) – d: depth of optimal (least‐cost) solution

(start with d=0)

– m: maximum length of path in state space

(may be ∞)

– total number of nodes generated

(= time)

– maximum number of nodes in memory

(= space)

Solution quality Search complexity

37

Uninformed search strategies

Use only the information available in the problem definition (a.k.a. blind search)

• Breadth‐first search

(BFS)

• Uniform‐cost search

(UCS)

• Depth‐first search

(DFS)

• Depth‐limited search

(DLS)

• Iterative deepening search

(IDS) Can only generate successors and distinguish goal‐state from non‐goal state

38

Breadth-first search

• Expand shallowest unexpanded node
• Implementation:

– fringe is a FIFO queue, i.e., new successors go at end – ties: (in this case) queue in alphabetical order ( subsequently expanded in alphabetical order too)

fringe = A

39

Breadth-first search

fringe = BC

• Expand shallowest unexpanded node
• Implementation:

– fringe is a FIFO queue, i.e., new successors go at end – ties: (in this case) queue in alphabetical order

40

Breadth-first search

fringe = CDE

• Expand shallowest unexpanded node
• Implementation:

– fringe is a FIFO queue, i.e., new successors go at end – ties: (in this case) queue in alphabetical order

41

Breadth-first search

fringe = DEFG

• Expand shallowest unexpanded node
• Implementation:

– fringe is a FIFO queue, i.e., new successors go at end – ties: (in this case) queue in alphabetical order

42

Properties of BFS

Assumption: goal‐test upon generation, finite d

• Complete? Yes, as long as b is finite
• Optimal? Yes, if step costs equal shallowest == optimal
• Time? 1+b+b2+b3+… +bd = O(bd)

(if goal‐test upon expansion: + b(bd‐1) = O(bd+1))

• Space? same as time

Exponential space is bigger problem (even more than time)  works only for smaller instances

dominate costs for closed list in GRAPH‐SEARCH

43

Uniform-cost search

Incorporates step costs

• Expand least‐cost unexpanded node
• Like Dijkstra, but now with goal test
• Implementation:

– fringe = priority queue, ordered by path cost g(n)

• Equivalent to breadth‐first search if step costs all

equal

• ! But step costs need not be equal (even though

the name may suggest otherwise) !

44

Properties of UCS

Assumptions: goal‐test upon expansion, finite d; ε = minimal step cost; C* = cost of cheapest solution

• Complete? Yes, if ε > 0 and b is finite
• Optimal? Yes: nodes expanded in increasing order of g(n)
• Time?

O(bceiling(C*/ ε))

(# of nodes with path cost g ≤ C * )

• Space?

O(bceiling(C*/ ε))

typically dominate costs for closed list in GRAPH‐SEARCH

45

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order ( subsequently expanded in alphabetical order!) fringe = A

46

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = BC

47

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = DEC

48

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = HIEC

49

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = IEC

done at H

50

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = EC

done at I  done at D

51

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = JKC

52

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = KC

done at J

53

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = C

done at K  done at E  done at B

54

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = FG

55

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = LMG

56

Depth-first search

• Expand deepest unexpanded node
• Implementation:

– fringe = LIFO queue, i.e., put successors at front – ties: (in this case) stack in reverse alphabetical order fringe = MG

done at L

Etc.

• Complete? No, unless GRAPH‐SEARCH in finite state space, finite d
• Optimal? No, it finds “left‐most” solution, regardless of cost
• Time?

O(bm)

– terrible if m is much larger than d – but if solutions are dense, may be much faster than breadth‐first

• Space? O(bm), in case of tree search

(“black” nodes are removed from memory)

57

Properties of DFS

Advantage may be lost in GRAPH‐SEARCH due to costs for closed list !

58

Depth-limited search

= depth‐first search with depth limit l, i.e., nodes at depth l do not generate successors  solves infinite path problem (m = ∞) Recursive implementation:

59

Properties of DLS

Note: DFS is special case of DLS with l = m (possibly ∞)

• Complete? Not if l < d

(do we know d ??)

• Optimal? Not if d < l
• Time?

O(bl)

• Space? O(bl)

Again advantage may be lost in GRAPH‐SEARCH due to costs for closed list !

60

Iterative deepening search

• Repeats DFS for increasing depth limit

 Finds best depth limit  Combines benefits of BFS and DFS

61

Iterative deepening search limit=0

62

Iterative deepening search limit=1

63

Iterative deepening search limit=2

64

Iterative deepening search limit=3

65

Iterative deepening search

• Number of nodes generated in a depth‐limited search

(DLS) to depth d with branching factor b: NDLS = b0 + b1 + b2 + … + bd‐2 + bd‐1 + bd

• Number of nodes generated in an iterative deepening

search (IDS) to depth d with branching factor b: NIDS = (d+1)b0 + d b1 + (d‐1)b2 + … + 3bd‐2 +2bd‐1 + 1bd

• For b = 10, d = 5:

– NDLS = 1 + 10 + 100 + 1,000 + 10,000 + 100,000 = 111,111 – NIDS = 6 + 50 + 400 + 3,000 + 20,000 + 100,000 = 123,456

Overhead = (123,456 ‐ 111,111)/111,111 = 11%

66

Properties of IDS

Assumption: finite d

• Complete? Yes
• Optimal?

Yes

• Time? O(bd)

(d+1)b0 + d b1 + (d‐1)b2 + … + bd

• Space? O(bd)

Inherited from BFS; same assumptions apply Inherited from DFS, but max depth restricted to d; same observations wrt GRAPH‐SEARCH apply

67

Summary of search algorithms

This overview assumes TREE‐SEARCH, with goal‐test upon expansion, and finite solution depth d. Recall (!):

• most yes’s and no’s depend on additional assumptions
• Space complexity may be different if GRAPH‐SEARCH is employed

Is there one best algorithm?

68

Summary pathfinding and uninformed search

• Algorithms find path to goal
• Problem‐specific ingredients used only for:
• Goal test
• Path cost

(used in solution, and sometimes for expansion)
