ArrowSpan Wireless Mesh Network Solutions Oct 2008 1 Company - - PowerPoint PPT Presentation
ArrowSpan Wireless Mesh Network Solutions Oct 2008 1 Company - - PowerPoint PPT Presentation
ArrowSpan Wireless Mesh Network Solutions Oct 2008 1 Company Located in the heart of Silicon Valley, ArrowSpan Inc., was founded in 2005 by Max Lu, a former Cisco employee, who currently holds the title of President/CEO of ArrowSpan.
SLIDE 2
SLIDE 3
3
ArrowSpan Solutions
Switching Wireless Mesh Technology for Wi-Fi service in rural, suburb,
and metro areas as well as special application services like surveillance, RFID warehousing,...
Mobile Switching Wireless Mesh Technology for mobile application
(900MHz/700MHz, i.e. military application)
Cost effective design supports mass deployment Layer 2.5 software design provides compatibility to existing network
device
Layer 2.5 software design maintains critical features provided by
Atheros driver
Layer 2.5 software design supports user friendly single I P network
management capability
SLIDE 4
4
The Value of ArrowSpan Wireless Mesh Network
- Cost - ArrowSpan Outdoor Wireless Mesh Access Points are Low unit
price, Industry standard 5GHz and 2.4GHz spectrums, Easily deploy wirelessly.
- Time - ArrowSpan Wireless Mesh Access Points can usually be setup
and working within a couple of hours.
- Speed - ArrowSpan Wireless Mesh Access Points can create backhaul
throughput up to 30+Mbps.
- Security - ArrowSpan Wireless Mesh Access Points offer a variety of
security options; the strongest of which is WPA2 with AES, but also support WPA/TKIP, MAC authentication, and 64.128 bit WEP
- Flexibility - ArrowSpan Wireless Mesh Access Points can be located
anywhere wireless coverage is required. Durable weatherproof housings with carrier class temperature range assure reliable operation year round.
SLIDE 5
5
Software Features
Spectrum & Standard: Support 5GHz/4.9GHz/2.4GHz/900MHz/700MHz spectrum and IEEE
802.11a/b/g
QoS: IEEE 802.11e prioritized traffic control (WMM) provides quality of service for voice or video traffic Multiple SSID: Support up to 16 independently configurable Multiple SSIDs with VLAN tag, able to create
multiple independent secure networks serviced simultaneously.
VLAN: Support IEEE 802.1q VLAN Tags fully compatible with 3rd party standard equipments Remote Firmware: Smart Firmware Update – Update the entire mesh nodes with a single commend Fault Tolerance: Always Connect Protocol ensure every nodes on the mesh network is reachable and
manageable
Redundancy: Auto Failover Protocol create system redundancy for critical mesh link Diagnostic: Mesh node monitoring, Signal quality, Link quality, Traffic counter, and Radio self-test SNMP: Support SNMP v2c/v3, and private MIB Mesh Routing: Mesh nodes auto-discover, and self-healing mesh for network optimization Security: Support 128bit WPA/WPA-2 AES encryption, and legacy 64 bit WEP security Network Management: Single IP Mesh Network Management Point-to-Point Device Deployment Tools: Remote Antenna Locator (RAL) - Real time HTML GUI
indicator detect remote antenna, and Signal Strength Tuner (SST)- Fine tuning Antenna position to maximize node-to-node signal quality
User Adjustable Tx Power: Optimizing node-to-node RF quality Interoperability: Seamless interoperability with the 802.11 b/g clients
SLIDE 6
6
Highly Compatibles with Legacy Network Devices
Layer 2.5 Mesh Network design benefits:
Highly Compatible with existing Routers, Switchs, Gateways,
access servers
Fast packet switching design to minimize latency
Layer 2 switching, operates at the Data Link layer in the Open Systems Interconnection model. Layer 2 switching can deliver data at the Link Speeds, and highly compatible compare with the Layer 3 design because it’s not required to deeply examine individual data packets.
Layer 2.5
SLIDE 7
7
Multiple RFs Vs Single RF Mesh (1/2)
Shared Wireless Architecture
Shared wireless architecture (e.g. Tropos, Cisco, Firetide) All Mesh nodes run in the same frequency Easier technology to implement Interference among nodes reduce throughput and increase latency Theoretically, the best throughput is 1/n, n is node numbers Hop counts recommended to less than 3 Low scalability because of throughput drop with hop count
Theoritical Mesh Performance
4 8 12 16 20 24 28 32
1 2 3 4 Mesh Type 1 [1/n] Mesh Type 2 [(1/2) ]
n
28Mbps 14Mbps 7Mbps 3.4Mbps
CH 100 CH 100 CH 100
SLIDE 8
8
Switching wireless architecture (e.g. Arrowspan, Bellair, Strixsystems) All adjacent Mesh nodes run in different frequency Need multiple radios, 3 to 6 radios Maintain maximum throughput across unlimited hop counts Usually throughput is 5 to 10 times faster than shared switching Complete scalability
CH 100 CH 104 CH 108
28Mbps 28Mbps 28Mbps 28Mbps
Theoritical Mesh Performance
4 8 12 16 20 24 28 32
1 2 3 4 ArrowSpan
Multiple RFs Vs Single RF Mesh (2/2)
Switching Wireless Architecture
SLIDE 9
9
MeshAP station MeshAP configured as Mesh Manager of this Mesh Network Broken MeshAP station : Virtual link : Mesh link
POP routing
Internet
auto-healing
Internet
Patented POP (Predictable Optimum Path)
Intelligent Mesh Routing Technology POP (Predictable Optimum Path) patented routing algorithm
generates mesh network structure with smart intelligence
Self-sustain, Auto-configuration, and Auto-healing
SLIDE 10
10
Automatic Re-Routing upon new bandwidth insertion
I nsertion of new bandwidth
Internet Internet Internet
Patented POP (Predictable Optimum Path)
Intelligent Mesh Routing Technology
SLIDE 11
11
Bandwidth Score System
Intelligent Mesh Routing Technology Bandwidth score based on Hop Count, Signal Quality, and Mesh Manager Weight. This guideline affects the routing decision of each node on the mesh network to decide which Mesh Manager to associate with.
Score: High with higher Weight setting for T3 Score: Low with lower Weight setting for T1
More Nodes will connect to a Manager with a higher Bandwidth score
SLIDE 12
12
Fault Tolerance & Redundancy
Intelligent Mesh Routing Technology
In Normal usage, Nodes could be set to associate with the Mesh Manager with a High bandwidth by setting the Weight of the Mesh Manager to increase the Bandwidth score When a High bandwidth Mesh Manager encounters a problem, the Nodes under the High bandwidth Mesh Manager will automatically re- route to the Low bandwidth Mesh Manager to maintain service.
Score: 8 Score: 2 Score: 8 Score: 2
Backup Link
SLIDE 13
13
MeshAP Performance Data
Node-to-node distance (US 1W
EIRP): > 1000 feet
Throughput (big packet, small
packet): > 30Mbps 5 hops, 12K pps
Latency per Hop: < 1ms Scale (Deployment): > 100 nodes Routing decision making speed
(US) version: 3 sec
Establish new mesh link speed:
400ms
1000ft (304m)
30Mbps
Throughput: 30Mbps; Latency: <1ms
Hop 1 Hop 2
Hop 3 Hop 4 Hop 5 30Mbps 30Mbps
SLIDE 14
14
VoIP Performance
Concurrent Calls - 5 hops environment
Number of Calls: 98 Encoding: G.729 Hope Count: 5 hops Throughput: (Avg) 7.8Mbps Jittler: 2-4 ms (No more than 10ms for ISP)
Data based on lab environment
SLIDE 15
15
Video Performance
Concurrent IPTV usage - 5 hops environment
Data based on lab environment
Number of IPTV: 15 Encoding: MPEG / 1.45 Mbps Resolution: 640x480 (DVD
Quality)
Total Throughput used: 21.5
Mbps
Hope Count: 5 hops
SLIDE 16
16
Mix Wireless Network Deployment
Point-to-Point and Point-to-multipoint
Internet MA3100 Mesh Manager
Rural Area
MA3100 (Manual Mode)
High Gain Directional Antenna
Mesh Station MA3100 MA3100 MA3100
2.4GHz 2.4GHz 5GHz 5GHz 5GHz 5GHz
~km @54Mbps*
5GHz
* For detail of Tx Power, Antenna, and Distance, check the RF Table on Slide 17
In a point-to-point bridging scenario, a MB3800 or MA3100 Series can be used to extend a network distance by using high gain directional antennas
Point-to-point Point-to-multipoint
SLIDE 17
17
Tx Power Table
Point-to-point [Directional Antenna]
19dBi 23dBi 26dBi 29dBi
Data Rate Tx Power
15dBm 1.3Km 2.4Km 3.8Km 5.8Km 16dBm 1.4Km 2.6km 4.1Km 6Km 17dBm 1.5Km 2.8Km 4.4Km 6.5Km 18dBm 1.7Km 3Km 4.8Km 7Km 15dBm 2Km 3.8Km 6Km 9.2Km 16dBm 2.2Km 4Km 6.4Km 9.8Km 17dBm 2.4Km 4.3Km 6.9Km 10.8Km 18dBm 2.6Km 4.7Km 7.4Km 11.7Km 19dBm 2.8Km 5.1Km 8Km 17.5 km 15dBm 3Km 5.6Km 8.5Km 13.5Km 16dBm 3.3Km 5.9Km 9.2Km 14.5Km 17dBm 3.6Km 6.4Km 10Km 15.5Km 18dBm 3.9Km 6.9Km 10.8Km 16.5Km 19dBm 4.1Km 7.4Km 11.6Km 18 km 20dBm 4.4Km 8Km 12.5Km 19.5 km 17dBm 4.4Km 8Km 12.5Km 18.5Km 18dBm 4.8Km 8.5Km 13.5Km 20Km 19dBm 5.2Km 9.2Km 14.5Km 22 km 20dBm 5.5Km 10Km 15.5Km 24 km
36Mbps 24Mbps Directional Antenna Gain
Maximum Node-to-Node Distance
54Mbps 48Mbps
Distance Data based on non-interference environment
*Above US & Taiwan Regulation
Product: MA3100: 5.745-5.825GHz
Regulations (Region) US
- 5.47 - 5.725GHz
Tx power: 250 mW (24dBm) EIRP: 30dBm
- 5.725 - 5.825GHz
Tx power: 1W (30dBm) EIRP: 36dBm
China
- 5.47 - 5.725GHz
Tx power: 500 mW (27dBm) EIRP: 33dBm
Taiwan
- 5.47 - 5.725GHz
Tx power: 250 mW (24dBm) EIRP: 30dBm
- 5.725 - 5.825GHz
Tx power: 1W (30dBm) EIRP: 36dBm
SLIDE 18
18
Tx Power Table
Point-to-multipoint [Omni-directional Antenna]
54Mbps (30Mbps) 48Mbps (27Mbps) 36Mbps (20Mbps) 24Mbps (13Mbps) 18Mbps (10Mbps) 5dBm
74 m 140 m 240 m 320 m 460 m
6dBm
83 m 155 m 270 m 350 m 500 m
7dBm
93 m 175 m 300 m 390 m 550 m
8dBm
102 m 200 m 320 m 420 m 600 m
9dBm
113 m 220 m 350 m 460 m 660 m
10dBm
125 m 240 m 390 m 500 m 720 m
11dBm
140 m 270 m 420 m 550 m 780 m
12dBm
155 m 300 m 460 m 600 m 840 m
13dBm
175 m 320 m 500 m 660 m 900 m
14dBm
200 m 350 m 550 m 720 m 1,000 m
15dBm
220 m 390 m 600 m 780 m 1,070 m
16dBm
240 m 420 m 660 m 840 m 1,150 m
17dBm
270 m 460 m 720 m 900 m 1,250 m
18dBm
300 m 500 m 780 m 980 m 1,350m
19dBm
N/A
550 m 840 m 1,060 m 1,450 m
20dBm
N/A
N/A 900 m 1,150 m 1,600 m
21dBm
N/A N/A N/A N/A
1,700 m
22dBm
N/A N/A N/A N/A
1,800 m
Wireless Rate (Throughput) Tx Power
Maximum Node-to- Node Distance
Distance Data based on non-interference environment
Product: MA3100: 5.745-5.825GHz, 8dBi ANT-ODA5108 Antenna
Regulations (Region) US
- 5.47 - 5.725GHz
Tx power: 250 mW (24dBm) EIRP: 30dBm
- 5.725 - 5.825GHz
Tx power: 1W (30dBm) EIRP: 36dBm
China
- 5.47 - 5.725GHz
Tx power: 500 mW (27dBm) EIRP: 33dBm
Taiwan
- 5.47 - 5.725GHz
Tx power: 250 mW (24dBm) EIRP: 30dBm
- 5.725 - 5.825GHz
Tx power: 1W (30dBm) EIRP: 36dBm
SLIDE 19
19
MeshAP 3800 - Outdoor
Carrier Class Multi-Radio Wireless Mesh Network Access Point
MA3800 Features
- Supports three(3) 5GHz 802.11a and one(1) 2.4GHz 802.11b/g
- Hardware-enhanced WEP/WPA/WPA2, and MAC filtering AP security
- Point-to-point Antenna: (3x) detachable 5.4 – 5.8 GHz 8 dBi Omni-directional
antennas
- (1x) detachable 2.4GHz 8 dBi Omni-directional antenna or adjustable 90-180
degree 29dBi patch antenna
- Point-to-multipoint antenna option: 23dBi, 26dBi, 29dBi directional antenna
- 4.9GHz for licensed band (optional)
- Layer 2.5 mesh routing, POP (Predictable Optimum Path) intelligent routing
algorithm, fast packet switching on mesh link traffic
- (1x) 10/100 Ethernet Port to connect with existing network infrastructure
(3rd-party router/gateway/access server/application server)
- Web server and SNMP* management
- PoE (power over Ethernet) support (on WAN port)
- Typical power consumption = 15W
- Horizontal pole, vertical pole, and wall mounting
- IP66 waterproof certification
- Industrial grade operating temperature -40°F to 131°F (-40°C to 55 °C)
SLIDE 20
20
MeshAP 3100 - Outdoor
Carrier Class Multi-Radio Wireless Mesh Network Access Point
MA3100 Features
- Supports two(2) 5GHz 802.11a and one(1) 2.4GHz 802.11b/g
- Hardware-enhanced WEP/WPA/WPA2, and MAC filtering AP security
- Point-to-point Antenna: (2x) detachable 5.4 – 5.8 GHz 8 dBi Omni-
directional antennas
- (1x) detachable 2.4GHz 8 dBi Omni-directional antenna or adjustable
90-180 degree 29dBi patch antenna
- (1x) GPS antenna provides location information (optional)
- 4.9GHz for licensed band (optional)
- Point-to-multipoint antenna option: 23dBi, 26dBi, 29dBi directional
antenna
- Layer 2.5 mesh routing, POP (Predictable Optimum Path) intelligent
routing algorithm, fast packet switching on mesh link traffic
- (1x) 10/100 Ethernet Port to connect with existing network
infrastructure (3rd-party router/gateway/access server/application server)
- Web server and SNMP* management
- PoE (power over Ethernet) support (on WAN port)
- Typical power consumption = 15W
- Horizontal pole, vertical pole, and wall mounting
- IP66 waterproof certification
- Industrial grade operating temperature -40°F to 131°F (-40°C to 55 °C)
SLIDE 21
21
ArrowSpan Wireless Mesh Network
MeshAP 3800XX
IP67 RJ-45 Connector Membrane Vent Cap
N-type Antenna Connector (5GHz Backhaul) N-type Antenna Connector (5GHz Backhaul) N-type Antenna Connector (2.4GHz Client)
SLIDE 22
22
Network Management
Features
- Single IP address for entire mesh network
- Http Web-server for configuration, topology, GPS, and
management
- Individual Node based TX/RX packet counter, User list,
MAC based filtering
- Routing channel selection and assignment
- Mesh Network Site survey to scan all available Nodes
In Progress Feature
- NMS Server management system
- Google Map and custom map based topology
- Statistic data monitoring: (packet, byte, error counters,
and link speed
- User based Node location tracking and traffic count
- Alarm based on node health check, mesh routing
change, and statistic counter
- Consider licensing Cognio spectrum analyzer
SLIDE 23
23
Customers
Municipal
– CAN Corporation – Nagasaki, Japan – Estes Valley Networks – Town of Estes Park, Colorado, USA – Expensive Networks – Fraser Lake, BC Canada – Telecommunications Authority – Majuro, Republic of the Marshall Islands
WISP – Wireless Internet Service Provider
– Golden Valley Cable – Adobe RV Park, Arizona, USA – Shenzhen, Wuhan, Chen-Du in China – Netse7en – Wenatchee, WA Convention Center – Great Auk Wireless – Vermont Campgrounds, VT, USA – Great American Networks – Camp Victory, Baghdad, Iraq
Security & Surveillance
– Beijing in China – SW Access & Video – Harborwalk Condominiums Los Angeles, CA, USA – WebPerception – Center for Noetic Sciences, Novato, CA, USA
Hospitality
– ISE - Midrand, Knysna, Stellenbosch hotels, South Africa – Heron Technology – The Stanley Hotel, Davis, CA, USA – Estes Valley Networks – Condominiums, Estes Park CO, USA
SLIDE 24
24
Case Study
CAN Corp. (Japan)
Number of MeshAP: 120 nodes
Located near the port city of Nagasaki, Nagayo Village is bounded by both steep mountains and the sea. The challenge has been finding a way to deliver them cost-effectively to the village’s community over difficult terrain.
Solution: MeshAP Wireless Access Point with CAN Corp’s proprietary Subscribers Management System
SLIDE 25
25
Technology Partners
Security & Surveillance Camera System Access, Authentication & Accounting (AAA) Equipment Access, Authentication & Accounting (AAA) Service Provider RTLS – Real Time Assets and People Tracking Solution RTLS – Real Time Location Service System Integrator Intelligent network traffic identification, control and service management solutions.
