ARKi is an Augmented Reality service for real-time visualisation of architectural and real-estate models. By incorporating AR technology within the architectural design process, ARki is able to visualise 3d models for both design and presentation

SLIDE 1

SLIDE 2

ARKi is an Augmented Reality service for real-time visualisation of architectural and real-estate

models. By incorporating AR technology within the architectural design process, ARki is able to

visualise 3d models for both design and presentation purposes, helping to create an immersive visualisation technique with multiple layers of interactivity. ARki can be deployed on any ios/android device, and allows the user to explore 3d data with an added level of navigational

freedom. By simply overlaying 3d models onto existing 2d floor plans, ARki provides real-time

architectural visualisation which has several benefits in design communication for a multitude of architectural projects. The AR Visualisation can be easily displayed on larger projection screen to demonstrate the superimposition of virtual data on top of 2d images for large presentations.
