Arizona Water Policy: Should we be worried? NACOG February 6, 2020 1 Arizonas Water Problem Annual Rainfall 2 Source: Water Resources Research Center, University of Arizona WHERE DOES OUR WATER COME FROM? 3 Arizonas Sources of

slide-1
SLIDE 1

Arizona Water Policy: Should we be worried?

NACOG

February 6, 2020

1
slide-2
SLIDE 2

Arizona’s “Water Problem”

Annual Rainfall

Source: Water Resources Research Center, University of Arizona 2
slide-3
SLIDE 3

WHERE DOES OUR WATER COME FROM?

3
slide-4
SLIDE 4

Arizona’s Sources of Water

Colorado 39% Other Surface 19% [CATEGO RY NAME] [PERCENT AGE] [CATEGO RY NAME] [PERCENT AGE]

Colorado Other Surface Groundwater Effluent Source: Arizona Dept. of Water Resources 4
slide-5
SLIDE 5

The Colorado River Basin

  • 40 million people
  • 7 states, 22 tribes

& Mexico

  • 4.5 million acres

agriculture

  • Significant

biodiversity

  • Grand Canyon &
  • ther national

parks & monuments

Source: US Bureau of Reclamation 5
slide-6
SLIDE 6 Source: Central Arizona Water Conservation Dist.
  • 83% Arizonans in service area
  • Maricopa, Pinal & Pima Counties
  • 330 miles
  • 2400’ elevation change
6
slide-7
SLIDE 7 Source: Univ. of Ariz. Coop. Extension

Arizona Watersheds

7
slide-8
SLIDE 8

Avondale, Chandler, Gilbert, Glendale, Mesa, Peoria, Phoenix, Scottsdale, Tempe, Tolleson

8
slide-9
SLIDE 9

SRP Inflows & Outflows

9 Source: SRP
slide-10
SLIDE 10

WHERE DOES THE WATER GO?

10
slide-11
SLIDE 11

Arizona Water Demand by Sector

Municipal 24 % Industrial 8 % Agriculture 68 %

Annual Demand ≈ 6.28 MAF

Source: Arizona Dept. of Water Resources
slide-12
SLIDE 12

How much is an acre- foot?

325,851 gallons

2 – 4 households/year

slide-13
SLIDE 13 13

Phoenix AMA Demand

Annual Demand ≈ 2.29 MAF

Source: ADWR Phoenix AMA Assessment (2017)

Municipal 49% Agriculture 32% Industrial 8% Tribal 11%

slide-14
SLIDE 14

What’s going right?

14
slide-15
SLIDE 15

Water Demand & Growth

slide-16
SLIDE 16

0.6 0.65 0.7 0.75 0.8 0.85 0.9 0.95 1

1955 1960 1965 1970 1975 1980 1985 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014

Agricultural Demand (% / Statewide)

Source: Arizona Dept. of Water Resources 16
slide-17
SLIDE 17

Phoenix Population and Water Use

17

900,000 1,000,000 1,100,000 1,200,000 1,300,000 1,400,000 1,500,000 1,600,000 1,700,000 50 100 150 200 250 300

Population GPCD

Population Total GPCD Residential GPCD

slide-18
SLIDE 18

Example of a Phoenix Neighborhood

Source: City of Phoenix
slide-19
SLIDE 19

greater water demand more people & bigger economy

19
slide-20
SLIDE 20

Active Management Areas

Groundwater Management Act of 1980

Sources: HDR, Technical Memorandum (Dec. 3, 2013); ADWR 20
  • 83% of Arizonans
  • Water banking
  • 95% re-use
  • Mandatory system-level

conservation

  • 100-year Assured Water

Supply requirement

slide-21
SLIDE 21

Active Management Areas

Groundwater Management

Sources: HDR, Technical Memorandum (Dec. 3, 2013); ADWR 21

growth is tied to renewable supplies

slide-22
SLIDE 22

Greater Phoenix – Palo Verde NGS Tucson – 18 golf courses ▪ Scottsdale – 23 golf courses Chandler – Intel Ocotillo Plant Gilbert, Phoenix, Tucson – Constructed Wetlands & Some Agriculture

Water ReUse

22
slide-23
SLIDE 23

Water Banking

23

11 MAF

slide-24
SLIDE 24 24
slide-25
SLIDE 25

What should we be worried about?

25
slide-26
SLIDE 26

Colorado River Supplies

slide-27
SLIDE 27

Lake Mead Structural Deficit

Inflow = + 9.0 MAF Outflow = - 9.6 MAF Evaporation = - 0.6 MAF Balance = - 1.2 MAF

slide-28
SLIDE 28
slide-29
SLIDE 29

CAP delivers ~ 1.6 MAF/yr

  • Maricopa
  • Pinal
  • Pima
slide-30
SLIDE 30

Lower Basin Drought Contingency Plan

slide-31
SLIDE 31

Arizona DCP – Who’s Impacted

200,000 400,000 600,000 800,000 1,000,000 1,200,000 1,400,000 1,600,000 Acre Feet Indian Priority 326 KAF M&I Priority 448 KAF NIA Priority 222 KAF Ag Pool 157 KAF Ag Pool Shortage 143 KAF Other Excess Shortage Priority 3 - 68 KAF

CAP Delivery Priority

Low High

Cities Tribes Pinal County Ag Tribes, Cities, Homebuilders

Tier 1 (512 KAF) Tier 2a (590 KAF) Tier 3 (720 KAF) Tier 2b (640 KAF)

Not to scale!

slide-32
SLIDE 32

Arizona DCP – Mitigation Plan

2020-22

  • 100% mitigation for NIA Pool
  • Fixed volume for Ag Pool, depending on tier

2023-25

  • No Ag Pool mitigation (conversion to

groundwater)

  • NIA volume tbd based on orders & conditions

○ 75% under Tier 1 & Tier 2a ○ 50% under Tier 2b

  • M&I & Indian full mitigation

2026 or Tier 3: No Mitigation

Indian Priority 326 KAF M&I Priority 448 KAF NIA Priority 222 KAF Ag Pool 157 KAF Ag Pool Shortage 143 KAF Other Excess Shortage Priority 3 - 68 KAF
slide-33
SLIDE 33

Arizona DCP - Implications

  • 1. Reduces risk of a Tier 3 shortage (protects

cities)

  • 2. Provides ground rules to enable conservation

in Lake Mead

  • 3. Mitigates impacts of cuts to Ag & NIA
  • 4. ~ $200 million cost (CAP, state & federal)
  • 5. Increases groundwater mining in Pinal

County

slide-34
SLIDE 34
slide-35
SLIDE 35

Lake Mead Storage with DCP in Place

1,025' 1,050' 1,100' 1,125' 1,150' 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019

Lake Mead End of Calendar Year Elevation

Level 2 Shortage Condition Level 3 Shortage Condition and reconsultation under the 2007 Interim Guidelines 1,000' Projected end of CY 2019 elevation is 1,089.40 feet (based on August 24-Month Study) Surplus Condition Adoption of 2007 Interim Guidelines Normal or ICS Surplus Condition 1,075' IBWC Level 1 Shortage Condition Minute 318 IBWC Minute 319 Pilot System Conservation Program and Lower Basin Drought MOU IBWC Minute 323 DCP & BWSCP
slide-36
SLIDE 36

Groundwater Dependent Places

slide-37
SLIDE 37

Groundwater Dependent Places

37
slide-38
SLIDE 38

Arizona Water Rights Cases

38
slide-39
SLIDE 39
slide-40
SLIDE 40

Verde Basin Well Development – 1974 (2,311 wells)

slide-41
SLIDE 41

Verde Basin Well Development – 1987 (7,457 wells)

slide-42
SLIDE 42

Verde Basin Well Development – 2017 (17,754 wells)

slide-43
SLIDE 43

The 4 Forest Restoration Initiative

slide-44
SLIDE 44 44

supplies for growth

slide-45
SLIDE 45

The Arizona Republic

March 5, 2019

‘A recipe for disaster’: Pinal County might not have enough water for 139,000 planned homes

State water regulators have confirmed their data shows there may not be enough water underground for dozens of planned developments in Pinal County, new subdivisions that, if built, would bring more than 139,000 homes. That finding is based on data the Arizona Department of Water Resources has complied that shows a long-term groundwater shortage in the area is possible. The data, which The Arizona Republic obtained through a public-records request, raises red flags about growth and the water supply in one of the fastest growing parts of the state.

slide-46
SLIDE 46 Source: CAGRD
slide-47
SLIDE 47
  • Water Supply Planning
  • Adjudication
  • Colorado River
  • Rural Groundwater
slide-48
SLIDE 48

Sarah Porter 602-828-0866 s.porter@asu.edu

48
slide-49
SLIDE 49
slide-50
SLIDE 50

new infrastructure & supplies

visual

augmentation strategies

Arizona’s water future

policy barriers

water data hub

partnerships

durable

new uses of infrastructur e

modern

re-envision policy

dynamic web-based application

continually updated

project costs

slide-51
SLIDE 51

Data layers (to date)

Watersheds Sub Watersheds Aquifers Groundwater Basins Streams Rivers Land Subsidence Dams Water Treatment Facilities CAP Canal CAP–SRP Interconnect SRP Canals Underground Storage Facilities Groundwater Savings Facilities Active Management Areas Irrigation Non-expansion Areas Adjudication Areas Adjudication Sub-areas Irrigation Districts Municipal Boundaries Municipal Populations Municipal Water Service Areas Private Water Company Service Areas Community Water Service Areas CAGRD Member Land Subdivisions CAGRD Member Service Areas Buckeye Waterlogged Area Critical Habitat Important Bird Areas Land Ownership Mines Tribal Leases ADWR Planning Areas Augmentation Projects Augmentation Projects Viability Delivery Infrastructure Projects

slide-52
SLIDE 52

Spatial exploration

slide-53
SLIDE 53

Data visualizations

slide-54
SLIDE 54

Municipal resilience

slide-55
SLIDE 55

Topics for upcoming meetings: History, context and bigger picture regarding significant water policies (how we got here) Rural water hotspots and challenges, including hotspots like Supplies/options for management within AMAs Water for Arizona agriculture Urban water management Change the Arizona dialogue Data and projections Water technologies Adjudication Habitat values and ecosystem services Misconceptions > Myth busters

Tool for dialogue & planning

slide-56
SLIDE 56

Augmentation Concepts

  • Cost
  • Capacity
  • Regulatory

hurdles

  • Timeline
  • Beneficiaries
  • Potential partners
slide-57
SLIDE 57

50 100 150 200 250 300 350

1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016

AWBA Long Term Storage Credits 1997-2016

KAF 192 KAF

Source AZ Water Banking Auth. 57
slide-58
SLIDE 58

Greater Phoenix’s Water Sources

CAP 41% Groundwat er 30% Effluent 2% Salt-Verde 27%

CAP Groundwater Effluent Salt-Verde Source: Arizona Dept. of Water Resources 58
slide-59
SLIDE 59 900,000 1,000,000 1,100,000 1,200,000 1,300,000 1,400,000 1,500,000 1,600,000 1,700,000 90 100 110 120 130 140 150 160 1990 1992 1994 1996 1998 2000 2002 2004 2006 2008 2010 2012 2014 2016 2018

Pho Phoen enix Re ix Reside sidential ntial Wate Water Us r Use

slide-60
SLIDE 60

Upper San Pedro Basin – 1987 Well Development (3,592 wells)

slide-61
SLIDE 61

Upper San Pedro Basin – 2017 Well Development (8,765 wells)
