Architecture, Design and Implementation of a Mathematical Derivation Editor

Johannes Eriksson

The Mathematical Derivation Editor (nicknamed “Mathedit”) is work in progress; it aims be a useful tool for creating, editing and correctness checking mathematical papers.

What is the Derivation Editor?

2 / 24

Gaudi software factory Ralph-Johan Back Main director and producer Victor Bos Designer Viorel Preoteasa Designer Johannes Eriksson Developer

Main developers

What is the Derivation Editor? 3 / 24

• Outlining editor
• Editing of hierarchically structured text
• Useful for writing mathematical papers
• Input of special characters
• Editing structured calculational proof

Examples from Back, Grundy, v. Wright: Structured Calculation Proof

Goals

What is the Derivation Editor? 4 / 24

• Correctness checking
• Export to presentation formats such as HTML and LaTeX
• Extensible
• Define an API to allow users to modify and extend the editor's

behaviour

Goals (Continued)

What is the Derivation Editor? 5 / 24

Features

6 / 24

The basic features of a graphical text editor:

• Basic editing commands (type character, delete, move cursor,...)
• Editable keybindings
• Input of unicode characters (using a keybinding or the menu)
• Cut, copy, paste via system clipboard
• Load and save files (XML)

Basic text editing

Features 7 / 24

• Hierarchically structured text
• Strict outlining
• Possiblity to collapse/expand items

Outlining

Features 8 / 24

• Expression and rule markup
• Syntax understanding
• Mathematical profiles
• Profile interface
• The universal profile (UP)

Formula syntax

Features 9 / 24

• Determines applicable rules by unification
• Steps can be generated automatically or written manually
• Correctness checking
• Parsing of complete derivations
• Re-application of rules, compares terms
• Nested derivations
• Result of a conditional rule
• Focuses on a subexpression
• Assumptions = scoped rules

Derivation

Features 10 / 24

• Extensibility, user-defined tools
• Some source code features (mainly syntax highlighting)
• Export filters
• HTML with Javascript or CSS
• LaTeX
• Possibility to #include documents
• Hyperlinks between documents
• Other minor features

Other features

Features 11 / 24

Development

12 / 24

The programming work has been carried out by computer science and computer engineering students from Åbo Akademi, who have been em- ployed as programmers at the Gaudi Software Factory. The bulk of the work has been done during the two summers of 2002 and 2003, when four programmers worked full-time. Some part-time work during the semesters. Several different teams, altogether 11 individuals have been working as programmers on the project.

People

Development 13 / 24

• Short iterations
• Pair programming
• Unit tests
• Continuous refactoring

Extreme programming

Development 14 / 24

• Python language
• Linux PCs
• xemacs editor
• Gaudi Sourceforge on xprog0.cs.abo.fi
• Task tracking
• Bugtracking

Development tools

Development 15 / 24

Architecture, design and implementation

16 / 24

A bottom-up, incremental software development methodology. Soft- ware is built in thin layers where each successive layer introduces a new feature and does not break the functionality of previous layers.

• Classes in a new layer become subclasses of the corresponding

classes in previous layer, i.e. the application is extended by inherit- ance of its classes.

• Overridden methods should preserve functionality from previous

layers.

• The different components (packages, modules, classes) and the lay-

er hierarchy are orthogonal partitionings of the software.

Stepwise Feature Introduction (SFI)

Architecture, design and implementation 17 / 24

Layer structure of Mathedit

Architecture, design and implementation 18 / 24

Command

Main window, menu, toolbar and command pat- tern.

Frame

Multiple (empty) windows.

Text

Text editing (unicode) with the QTextEdit widget, Open, Save, Save As, Save All. Our own docu- ment model.

MV

Multiple views of the same document, New View command.

Edit

Copy, cut and paste text.

CmdList

Support for undo/redo of editing commands. Ex- tended the document model with a command list.

Outline1

Extended the document model and editing capab- ilities of the text widget to support an outlining structure.

Outline2

Support for collapsing and expanding an item. Collapse hides all lines indented deeper than the current line, expand shows them again.

Format

Rich text formatting of text.

Derivation

Formula syntax. Is is possible to define math- emathical expressions, which the editor parses

Layer structure of Mathedit (Continued)

Architecture, design and implementation 19 / 24

according to its grammar. Perform mathemathical derivations by applying rules on expressions.

Profile

Possibility to add own profiles.

Filter

Filters for export to HTML and LaTeX, import of LaTeX.

Highlight

Syntax highlighting for programming languages.

Hook

Possibility to connect custom functions to hooks in mathedit.

Layer structure of Mathedit (Continued)

Architecture, design and implementation 20 / 24

• Naming conventions. Each class/subclass name is prefixed with

Layername_ to identify the layer it belongs to. Example:

Text_Document, Outline1_Document, Derivation_Document, ...

• Store metadata, e.g. the list of layers. Possible to find out the layer
• f any class as well as the layer's position in the hierarchy.
• Import modules by “try-and-catch”. Reduces the amount of factory

methods.

layers = [ Command, Frame, Text, ... ] layeri = layers.index(layer) while layeri>=0: try: exec("import "+layer+"_"+modulename) except ImportError: layeri -= 1 layer = layers[layeri] else: return eval(layer+"_"+modulename) raise "No module " + modulename

Special solutions to aid in SFI

Architecture, design and implementation 21 / 24

• Works well with incremental software development
• Each layer can be run as a standalone application, making it easier

to track down bugs

• Unit tests can follow layer hierachy

Advantages of SFI

Architecture, design and implementation 22 / 24

• Can make some refactorings difficult
• Changes to existing features may not fit well into the hierarchy
• Large number of classes and deep inheritance hierarchies may be

difficult to deal with

Disadvantages of SFI

Architecture, design and implementation 23 / 24

• Python 2.2
• Interpreted, object-oriented language
• Easy to learn
• Garbage collection
• Highly dynamic
• Introspective power
• www.python.org
• Qt 3.1
• A cross-platform C++ widget toolkit
• Language bindings for Python (PyQt)
• www.trolltech.com

Implementation

Architecture, design and implementation 24 / 24
