SLIDE 1
MANCHESTER SCHOOL OF ARCHITECTURE
ARCHITECTURAL DIGITAL SKILLS PESENTATION
SOL & ALEX
20.11.2019
2 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
ARCHITECTURAL DIGITAL SKILLS PESENTATION SOL & ALEX - - PowerPoint PPT Presentation
ARCHITECTURAL DIGITAL SKILLS PESENTATION SOL & ALEX - - PowerPoint PPT Presentation
MANCHESTER SCHOOL OF ARCHITECTURE ARCHITECTURAL DIGITAL SKILLS PESENTATION SOL & ALEX 20.11.2019 01 Photoshop Exercise: working with section from CAD SOL & ALEX DIGITAL SKILLS PRESENTATION 2 20.11.2019 2019-2020 Leave this as
SLIDE 2
SLIDE 3
3 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Open photoshop and drag and drop your Section file.
Opening Photoshop
01
Leave this as it has it for now, we will next make sure its the right size.
SLIDE 4
4 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Image > Canvas Size
Canvas Size
01
Go to the image tab and edit the canvas size to be a landscape A3 size. Double click and rename your layer.
SLIDE 5
5 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Drag and drop your brick texture image
Place Brick texture
01
Resize it to be a roughly appropriate size for the wall its going
- n. Then press enter.
SLIDE 6
6 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Hold ALT and drag.
Duplicate the image
01
Hold ALT and drag the image until its adjacent to the original. It should snap, repeat this until it goes beyond the width of the wall.
SLIDE 7
7 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Select layers, right click and merge them
Merge Layers
01
You can see that each brick image has its own layer, but we want them as 1. So, with them all selected, right click and click Merge Layers to combine them.
SLIDE 8
8 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Hold ALT and drag.
Duplicate Vertically
01
Repeat the duplication process, holding ALT and dragging the merged brick images up so that they go beyond the wall. Then Merge the layers.
SLIDE 9
9 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Magic wand tool and Delete.
Trim off excess Wall
01
With the magic wand tool activated (you may have to right click
- n the tool location and switch to magic wand), and the Section
layer selected, click in the area where the wall is. Now press CTRL + SHIFT + I to select the inverse of the wall, and DELETE the excess.
SLIDE 10
10 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Image > Adjustment > Levels
Make the Texture more faint
01
With the brick texture layer selected, go to Image > Adjustment > Levels and on the window, move the arrow at the black end on the left towards the right until you are happy with it.
SLIDE 11
11 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Adjust size
Place the Person file
01
Drag and drop your ‘person’ image. Right click on the person image layer and Rasterise it.
SLIDE 12
12 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Select > Colour Range
Delete Background Colour
01
With the person layer selected, go to the select tab, go to colour range, and with the window open, click on the background white
- space. Click ok.
SLIDE 13
13 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Polygonal Lasso Tool
Improve your selection
01
The white background is selected but so is some of the persons
- shirt. Use the Polygonal Lasso Tool and, whilst holding ALT,
select the area on his shirt that you don’t want selected. Right click on the person layer and Rasterise it. Then press DELETE to delete the white background.
SLIDE 14
14 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Select and DELETE. Then Save.
Delete the overlap
01
Select the bit of shoe that is overlapping the section line and DELETE it. Your Photoshop edit is now complete. Tidy up your layers if they aren’t already so that there are 3 and they are named.
SLIDE 15
15 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Turn off the Section layer and SAVE.
Finishing Up
01
Click on the eye on the Left of the Section layer. Go to File and Save it.
SLIDE 16
16 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
16 DIGITAL SKILLS
2019-2020
02
Illustrator Exercise: diagram
SLIDE 17
PRESENTATION
17 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
You are prompted to select a size for you new document layout
Opening Illustrator
02
OVERVIEW
Use the right side to select width, height and orientation of your page - A3 Landscape (420mm x 297mm)
SLIDE 18
PRESENTATION
18 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
File > Place > Original Section.pdf file.
Place Section File
02
OVERVIEW
Place the original Section file we had. This file is a Vector. Vectors are more editable and do not pixelate. Where Photoshop works in pixels, Illustrator works in vectors.
SLIDE 19
19 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
With the Section file selected, go to Object, and Ungroup.
Ungroup the new file.
You may have to do this multiple times.
SLIDE 20
20 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Select > Same Stroke Weight
Move the Section Cut lines to a new layer
02
With a line from the Section cut selected (You may need to repeatedly click on it to get it selected), go to Object, Select, Same Stroke Weight.
SLIDE 21
21 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Move the Section Cut lines to a new layer
02
Create a new layer called Section Cut Edit > Paste in Place
SLIDE 22
22 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Turn the section cut lines into a solid shape.
Shape builder
With the section cut lines selected, use the Shape Builder tool on the right and click in the 2 areas between the section cut lines. This will build them into a solid object. Press escape when done. With one of these built shapes selected, double click on the fill colour on the right and change it to a colour. You may need to right click here and change it to RGB
SLIDE 23
23 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Eye dropper tool.
Fill The other Section Cut
With your second (unfilled) section cut shape selected, choose the Eye dropper tool. Then click on your filled section cut shape. This will give it the same attributes as the first.
SLIDE 24
24 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Draw a ventillation line using the Pen tool. If you click, hold and drag at each point this will give it a curve.
Pen Tool
With your second (unfilled) section cut shape selected, choose the Eye dropper tool. Then click on your filled section cut shape. This will give it the same attributes as the first. Repeat until you have a curvy line. If you right click on the pen tool you can switch to the anchor tool and edit each control point on the line.
SLIDE 25
25 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Turn off the Fill and give it a blue colour. Turn off the Fill and give it a blue colour. Then edit the stroke weight. Tick Dashed Line and change the dash and gap scaling, and give it an arrow head from the drop down menu.
Change Line Settings
SLIDE 26
26 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
Move your ventilation arrow to a new Layer
Organise your layers
02
SLIDE 27
27 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Use the elipse tool and the line tool to draw a basic tree Make sure the elipse is on top and its on the Background layer.
Draw some simple trees
SLIDE 28
28 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Press Alt and drag to duplicate. Then rescale whilst holding Shift
Duplicate
SLIDE 29
29 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
File > Place > Navigate the Photoshop file
Place the Photoshop file
02
SLIDE 30
30 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02 Scale and Place
Drag scale and place it on the bottom layer
SLIDE 31
31 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Right click > Transform > Reflect Flip the ventillation line. Then, using the Direct Select Tool, edit the individual control points on the line until it looks right
Transform and Edit
SLIDE 32
32 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
With your JPEG selected, go to Image, Image trace This will convert a raster image into a vector file. Have a play with this wioth different types of image and different types of
- trace. Its an incredibly useful tool.
Image Trace
SLIDE 33
33 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
02
Select > Same Fill , and change the colour Save
Change the Fill Colour and Finish
SLIDE 34
34 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
34 DIGITAL SKILLS
2019-2020
03
Indesign Exercise: booklet layout
SLIDE 35
35 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
PRESENTATION
35 DIGITAL SKILLS
2019-2020
35 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
You are prompted to select a size for you new document layout
Opening InDesign
03
Use the right side to select width, height and orientation of your page as well as number of pages for your project.
SLIDE 36
PRESENTATION
36 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Select the Pages Tab, on the right. Right Click on the master page section of the pages tab and select new master
Setting up Master Pages
03
SLIDE 37
PRESENTATION
37 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Name your Master Page and press ok to generate it.
Setting up Master Pages
03
SLIDE 38
PRESENTATION
38 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Go to the Layout Tab and select Create Guides
Create Grid Guides for your File
03
Select the number of columns, rows, gutter and whether to include margins or not.
SLIDE 39
PRESENTATION
39 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
While on your master page, create a text box by selecting the text command on the left and dragging your mouse to create a box on the page
Setting up Master Pages
03
Double click on the text box you created to make it active then go to Type, Insert Special Character, Markers, Current Page Number.
SLIDE 40
PRESENTATION
40 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Name your Master Page and press ok to generate it.
Create Character Styles
03
Create a new character style by pressing the page icon on the bottom of the tab and them right click and select edit
SLIDE 41
PRESENTATION
41 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Use the option provided on the different tabs to name your style and add associated font styles and sizes to it. Click ok to confirm
- changes. You can right click and duplicate the styles forming a
series of them.
Edit Character Styles
03
SLIDE 42
PRESENTATION
42 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Create new text boxes and apply character styles by selecting the box and then while selected clicking on the character style you wish to apply.
Applying Character Styles
03
SLIDE 43
PRESENTATION
43 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Select all pages you wish to apply the master page to and right click / apply master page. This will apply all master pages to them. Then to edit the text boxes on each page you must overwrite all master page items by right clicking on the page again and selecting
- verwrite all master page items.
Apply Master to Pages and Overwrite
03
SLIDE 44
PRESENTATION
44 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
To place an image click on the file tab and select place. This will
- pen a new window where you can select the image / diagram file to
be inserted and click ok. The image will appear around your cursor and you can now click to indicate the location of placement. The image can be resized by dragging the control points in or out when the image is selecting while pressing control and shift (for uniform resizing only).
Inserting an Image or Diagram
03
SLIDE 45
PRESENTATION
45 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
To export your work as a pdf document select file on the top tab and select export. The first window to pop up asks you to select the
- utput location and file type (preferably interactive pdf).
Exporting your portfolio
03
SLIDE 46
PRESENTATION
46 DIGITAL SKILLS
2019-2020
SOL & ALEX
20.11.2019
Once the location has been selected. All you have to do is select the pages to export and then set whether it is a single page or as a spread, the dpi of the images (useful to play around with to lower portfolio sizes). Once all options are acceptable click export and indesign will generate a pdf document of your portfolio.
Exporting your portfolio
