APTCHA

I am Andreas Charalampous, April 2020 CS682 - Advanced Security Topics Instructor: Elias Athanasopoulos

Contents

• 1. Introduction to Captcha
• 2. Paper 1: Re: Captchas – Understanding Captcha-Solving Services in an

economic context

• 3. Paper 2: I am Robot: (DEEP) Learning to break Semantic Image Captchas

• 1. Introduction to Captcha

i.

Motivation

• ii. Definition

iii.Type of Captcha Challenges iv.reCaptcha

Motivation

• Using computers for bot fraud, attackers can attack at scale.
• Fake Registrations - Create multiple accounts automatically.
• Comment/Posting Spam.
• Purchase of tickets.
• Resource that has to be guarded.
• A defense mechanism is needed to distinguish computers and humans, let humans

in and spammers out of resources.

Definition of Captcha

• Captcha: Completely Automated Public Turing test to tell Computers and Humans Apart.
• Reverse Turing Test.
• Term coined by Luis von Ahn, Manuel Blum, Nicholas J. Hopper, and John Langford in 2003.
• Captchas protect open Web Resources from being exploited at scale.
• Challenge-Response to determine whether the user is human or not.
• A Captcha challenge must at the same time make the bot fail and the human easily solve it.
• Approximately 10 seconds for a human to solve a typical Captcha.

Type of Captcha Challenges

• First version of Captcha (v.1) is the “twisted text”,

made in 1997.

• Earliest commercial use by idrive.com and Paypal in 2002

and 2001 respectively.

• Math problems captchas.
• Audio captchas.
• Picture captchas.

Type of Captcha Challenges

Advertisement Captcha Game Captcha SlideLock Captcha Drag-And-Drop Captcha Trivial Captcha

reCaptcha

• Was developed by Luis von Ahn, David Abraham,

Manuel Blum, Michael Crawford, Ben Maurer, Colin McMillen, and Edison in May 2007.

• It was acquired by Google in September 2009.
• Used for digitization of The New York Times

archives and books from Google Books.

• Two of the reCaptcha challenges are image and

distorted text identification.

No Captcha ReCaptcha

• Developed in 2014.
• Consists of a checkbox where the user is asked

to just click it.

• Performs behavioral analysis on the browser

predicting if the user is human or not.

• Easier for humans.
• “Harder” for bots.

Evolution and Variety in Captchas

• Captchas are evolving for more than 20 years and will keep on doing. Many

different kinds of captcha challenges.

• Are improved, finding ways to make it easier to users, more difficult to bots.
• Provide accessibility to health impaired users.
• Captchas are kept being bypassed by automation software or solver services, creating

an arms race between solvers and providers.

• 2. Paper 1: Re: Captchas – Understanding Captcha-

Solving Services in an economic context

i.

Introduction

• ii. What is examined in this paper
• iii. Automated Software Solvers
• iv. Human Solver Services
• v. Conclusion

• Captchas attached value to the problem of solving them, creating an

industrial market, where captcha providers and solver are competing.

• Providers come against two types of solvers:
• Automated solving technology.
• Real time Human Labor .
• Captchas are evaluated in economic terms.

Introduction

What is examined in the paper?

• How this new market works
• Serving quality to price.
• Solving capacity of the market leaders.
• Details about solving services.
• How the two categories of solvers work:
• Automated solving:
• How it evolved.
• How the arms race favors the providers (defender).
• Human Labor:
• Why it surpassed automated solving.
• How the cost of it dropped significantly.
• Which Captchas are targeted most.

To support further the study

• Interviewed Mr. E., owner of a successful CAPTCHA-solving service. He

provided validation and insight of the underlying business processes.

• Studied the whole market, from all aspects and view.
• Purchased solving services from both categories and tested them.
• Became part of the human labor pool.

Automated Software Solvers

• Use segmentation algorithms – Optical Character Recognition (OCR)
• Complex.
• Fails to replicate human accuracy.
• Advantages:
• Near-zero cost. Only cost is in creating solver.
• Near-infinite capacity.
• Tested Xrumer and reCaptchaOCR.

Xrumer

• Software for spamming, mostly forums and comment sections.
• Integrated support for bypassing many different anti-spam mechanisms,

including Captcha.

• Available from 2006 and in 2010 it cost $540. Authors purchased it for

evaluation.

• In 2008 was capable of solving Captchas of major message boards.

XrumerTests

• Tested on netbook with 1.6Ghz Intel Atom Processor.
• On all but one captchas scored 100% accuracy, requiring 1 second or less for each

Captcha.

• Only on phpBB which uses GD Captcha generator and foreground noise, scored 35%

accuracy, requiring 6-7 seconds per captcha.

• Even though the scores are pretty impressive, a couple of months later

theses captchas were updated, defeating Xrumer.

reCaptchaOCR

• Created in December 2009.
• Focused on reCaptcha.
• Developed to defeat early 2008 reCaptchas.
• Was able to defeat late 2009 reCaptchas.
• Early 2010 reCaptcha was updated and

reCaptchaOCR was unable to defeat it.

(a) Early 2008 (b) Late 2009 (c) Early 2010

reCaptchaOCRTests

• Tested on netbook with 2.13Ghz Intel Core 2 Duo Processor.
• Uses iteration for improving accuracy.
• With 613 iterations:
• 100 (a) captchas scoring 30%.
• 100 (b) captchas scoring 18%.
• Average 105 seconds per challenge.
• With 75 iterations:
• 100 (a) captchas scoring 29%.
• 100 (b) captchas scoring 17%.
• Average 12 seconds per challenge.

Conclusion

• Arms races traditionally favor the attacker. Here attackers have the more

challenging recognition problem, while providers can be agile.

• Economics of automated solving are driven by several factors:
• Cost of developing new solvers.
• Accuracy of those solvers.
• Responsiveness of the sites whose captchas are attacked.

Human Solver Services

• Instead of using automated solving software, the workload of captchas is

given to humans to solve.

• Opportunistically.
• On a “For a Hire” Basis.

Opportunistic Solving

• Individual solving a Captcha as part of some other task.
• An attacker controlling a popular Website, might use its visitors for solving

third-party Captchas by offering them as the visitor’s challenge.

• Did not play a major role in the market.

Paid Solving

• Core of the CAPTCHA-solving ecosystem.
• Services are paying individuals to solve captchas.
• Price is calculated as $X/1000, where X is the amount paid for solving 1000

Captchas.

• An advertisement in 2006 was looking for a full-time CAPTCHA solver for

$10/1000.

decaptcher.com

DeCaptcher

PixProfit

Pictures are life

demenoba

1 2 3 4 5 6 7 8

Workers all around the world

Paid Solving Evolution

• From 2007 to 2010 the market has been expanding with wages declining.
• 2007: $10/1000.
• Mid-2008: $1.5/1000.
• Mid-2009: $1/1000.
• 2010: $0.75/1000 – $0.5/1000.
• Solving is unskilled activity.
• Services preferred labor from Eastern Europe, Bangladesh, China, India, Vietnam.
• Competition made wages reduce even more.

Solver Service Quality

• Evaluate 8 Paid Services:
• Antigate https://anti-captcha.com/
• BeatCaptchas https://beatcaptchas.com.cutestat.com/
• BypassCaptcha http://bypasscaptcha.com/
• CaptchaBot http://www.captchabot.com/
• CaptchaBypass – Ceased Operation during evaluation
• CaptchaGateway – Ceased Operation during evaluation
• DeCaptcher https://de-captcher.com/
• ImageToText – Ceased Operation
• Based on:

1.

Customer Interface

2.

Solution Accuracy

3.

Response time

4.

Capacity

5.

Load and Availability

Verifying Results

• For each captcha, the most frequent solution from solvers is used.
• If there are more frequent solutions, the answers are incorrect.
• Heuristic Evaluation:
• 1025 random selected captchas that had at least one solution and checked manually.
• 1009 correct.
• 16 incorrect
• 6 of them because of characters similarities (zero vs O (0 – o), six versus letter B (6 – b))

Customer Account Creation

• All of them required prepayment.
• Antigate and Decaptcher, offer bidding systems for higher priority access when load is high.
• For most services, account registration is accomplished via Web and email.
• Some of them presented obstacles during registration:
• CaptchaBot and Antigate required third-party invitation codes.
• Antigate guards against Western users and required the name of Prime Minister in Cyrillic.
• Some of them, like ImageToText, required live phone call.

Evaluation Details

• Tested as customer for about five months using captchas from 25 popular

sites, some of them including PayPal, eBay, Google etc.

• Submitted a single Captcha every five minutes to all services, recording the

time submitted.

• 1. Customer Interface
• Most provide an API package for uploading Captchas and receiving results.
• Two ways when interacting with the services:
• API performs HTTP Post that uploads the image and waits for the result in HTTP

response: BeatCaptcha, BypassCaptcha, CaptchaBypass and CaptchaBot.

• API performs one HTTP POST to upload the image, receives an image ID in the HTTP

response and polls the site for the solution using the ID: Antigate, CaptchaGateway, ImageToText.

• 2. Solution Accuracy

Error rate for each combination of service and CAPTCHA type

• 2. Solution Accuracy

Median error rate for all services Median error rate for all CAPTCHAs

• 3. Response Time

Median Response Time for every service Median Response Time for all Captchas

• 3. Response Time

Response time for each combination of service and CAPTCHA type

• 4. Capacity
• Number of captchas solved in given time.
• Increase number of load until service is overloaded.
• Antigate has the best capacity, 27 to 41 captchas per second.
• 1,536 threads submitting with bid set 3/1000.
• Rejection rate very low.
• Around 400-500 workers for their requests, the number may be larger.
• DeCaptcher and CaptchaBypass sustained 14-15 captchas per second
• BeatCaptchas 8 and BypassCaptcha 4 captchas per second.

• 5. Load and Availability
• Customers can poll services for load reports.
• Examine how workers get affected by load.

Load per hour reported by Antigate (Left) and DeCaptcher (Right)

Workforce

• Examine solving services from the solver’s (worker) aspect.
• Export Demographic conclusions about the solvers, like origin.
• Evaluates solvers adaptability.
• Identify the most targeted sites.
• Test two job sites:
• Kolotibablo http://kototibablo.com/
• PixProfit http://pixprofit.com/

Worker Interface

• First an account is needed to be created.
• Web based Interface.

Worker Wages

• PixProfit: $1/1000
• Kolotibablo: $0.5/1000 - $0.75/1000
• Provides list for the top 100 solvers per day.
• Average payout for 1 December 2009: $106.31
• Average payout for 1 January 2010: $47.32

Geo locating Workers

• Crafted captchas using words from various languages to reveal geographic demographics
• f solvers.
• Captchas were showing number written in different languages.
• Instructions were in the same language.
• Language Varieties:
• Prevalence of Web Native speakers: English, Chinese, Hindi.
• Regions with low-cost labor markets: India, China, Latin America.
• Developed Regions: Western Europe.
• Synthetic language: Klingon.

Geo locating Workers

Accuracy of each service on different language captchas

Adaptability

• Examined how services and solvers adapt to changes.
• Sent image captchas where solvers had to identify cats and dogs.
• Sent one captchas every 3 minutes to all services, for 12 days.
• ImageToText had average 39.9% success.
• BeatCaptchas had average 20.4% success.
• The rest had success below 7%.

Error Rate of ImageToText on image captchas

Targeted Sites

• Identified the targeted sites of Kolotibablo and PixProfit.
• 1. For 82 days, gathered from Kolotibablo and PixProfit 25K and 28K

captchas respectively.

• 2. Grouped them by image dimensions.
• 3. Manually tried to identify sites with same dimensions.

Conclusion

• Quality of captchas made easy to outsource to the global unskilled labor market.
• There is a whole highly competitive business market for solving captchas, following

different models.

• Do Captchas work:

1.

Telling computer and humans apart: Succeeded

• 2. Preventing automated site access: Failed

3.

Limiting automated site access: Debatable

• 3. Paper 2: I am Robot: (DEEP) Learning to break Semantic Image

Captchas

i.

What is examined in this paper?

• ii. reCaptcha Analyzed
• iii. System Overview
• iv. Automated Solving Image reCaptcha
• v. Influencing Advanced Risk Analysis System
• vi. Guidelines and Countermeasures

What is examined in this paper?

• Explore Google’s Advance Risk Analysis System (ARAS) used on the latest version of

reCaptcha.

• How it works.
• Flaws.
• Methods to influence it.
• Design of novel low-cost attack using deep learning technologies for the image reCaptcha.
• Introduce new safeguards and modifications for preventing the manipulation of ARAS and

mitigating attacks on image reCaptcha.

reCaptcha Analyzed

• ReCaptcha is the most widely used captcha service.
• 200 million reCaptchas are solved every day.
• Many captchas deter valid users from visiting a website.
• Automated solvers are less lucrative than human solvers.
• The motivation is to make challenges easier for valid users and at the same time harder for frauds, human
• r automated.
• Advanced Risk Analysis System:
• Acquires user information from Google tracking cookies and browser. Even when not logged in or in incognito.
• Based on the above, ARAS provides an easy, hard or no challenge at all to user.

reCaptcha Workflow

• Site that protect resources with reCaptcha, contains a

reCaptcha Widget.

• Widget collects information about the user’s browser

and checks for automation kits.

• 1. The user clicks on the checkbox, and a request is sent

to Google containing:

• Referrer
• Sitekey
• Cookie
• Information gathered by widget.
• 2. The above are checked by ARAS and a HTML frame,

containing the corresponding challenge, is sent.

reCaptcha checkbox

reCaptcha Workflow (cont.)

3.

When the checkbox is clicked, HTML field recaptcha-token is populated with a token.

• If user is legitimate, token becomes valid by Google.
• If not, it is invalid until user solves challenge.

4.

The token is then submitted to the site.

5.

Website sends a verification request to Google.

6.

Google sends a response, which is JSON object with a boolean field indicating if the verification was a success.

• If the verification fails, error codes offer more information.
• Solution must be provided in 55 seconds.
• If not, user clicks on checkbox again to get a new challenge.

reCaptcha Challenges

No captcha reCaptcha 1. 2. Image Recaptcha 3a.

Scanned words

3b. Street view numbers 3c.

Distorted one-word Distorted two- word

3d. 3e. Fallback captcha

System Overview

• Built on Selenium, specifically Mozilla Webdriver (Mozilla Firefox v.36)
• Functionality for locating specific HTML DOM elements.
• Features for executing JavaScript.
• Controllers for handling keyboard and mouse event.
• Easily saving and loading browser cookies.
• Has two main components:

1.

Cookie Manager.

• 2. Recaptcha Breaker.

Cookie Manager

• Each cookie receives up to 8 checkbox per day.
• Around 63,000 cookies per day are required.
• Cookies are automatically created and trained on virtual machine, in order to be

viewed as a user.

• System configured to perform specific humane actions:
• Mimicking diurnal cycle, with random resting intervals between actions.
• Google search certain terms and follow links.
• Open videos in Youtube.

Recaptcha Breaker

• Uses the cookies from manager.
• 1. Visits sites that employ reCaptchas.
• 2. The system locates the checkbox element through recaptcha-anchor and

performs mouse click action.

• 3. In case of checkbox challenge, recaptcha-token is extracted.
• In case of image captcha, it is passed to another module.

Breaking the image captcha

• In case of image, a popup is created in goog-bubble-content element. Inside the popup there

is an Iframe, with the challenge.

• To identify the challenge system looks for:
• rc-imageselect: image captchas
• rc-defaultchallenge-response-field:text captchas
• Image captcha
• hint: rc-imageselect-desc.
• Candidate Images: rc-imageselect-tile
• Verification Button: recaptcha-verify-button

Image Tags

• Goal: Using Image Annotation Module, get tags of candidate images that match the given hint.
• All extracted images are passed to an Image Annotation Module.
• Clarifai: 20 tags with confidence score.
• Alchemy: up to 8 tags with confidence score .
• TDL: 8 tags with confidence score .
• NeuralTalk: free-form description.
• Caffe: 10 labels, 5 with high score, 5 more specific with lower score.
• Also took advantage of Google Reverse Image Search (GRIS), in order to get description and

page titles. Also if found, a better quality of image is obtained.

Tag Classifier

• Implemented tag classifier, which allows system to select images with

similar content, in case tags do not match hint.

• Classifier guesses the content using a subset of the given tags.

History Module

• Many images in captchas are repeated.
• A labelled dataset is created containing images and their tags.
• Each image’s hint is stored in hint_list.

Automated Solving Image reCaptcha

• Each candidate image will be assigned to one of 3 sets: Select, Discard, Undecided.
• Initially all candidate images are placed in Undecided.

1.

If hint is not provided, sample image is searched in labelled dataset to obtain one.

• 2. Information about all images are collected from GRIS.
• 3. Every candidate image is searched in labelled dataset of the history module.
• If found, compares their tag to hint and if found match, candidate image is placed in select

set.

• If not found, hint_list is checked, and if found match, candidate image is placed in discard

set.

Automated Solving Image reCaptcha(cont.)

• 4. Image annotation processes all images and tags are assigned.
• If tags match the hint, the image is added in select.
• If it matches one of the tags in the hint_list, added in discard.
• 5. System picks from select set, if not enough, picks from undecided.

Influencing Advanced Risk Analysis System

• Different approaches to influence ARAS:
• Browsing History
• Google Account Usage
• Geo location
• Browser Checks:
• 1. Automation
• 2. User-Agent
• 3. Screen Resolution
• 4. Mouse
• 5. Cookie Reputation
• 6. Site restriction
• 7. Token Harvesting

ARAS Influence Evaluation Browsing History

• Quantify the minimum amount of browsing history needed in order to get a

checkbox captcha.

• Multiple network connection setups.
• ToR connections, with exit nodes in USA.
• Result: ARAS is neutralized if the appended cookie is 9 days old, no matter the

network connection.

• Even without browsing.

ARAS Influence Evaluation Google Account Usage

• Tried various accounts, with different settings.
• Without phone verification.
• With verified phone.
• With alternative email from another provider.
• Result: With an account, no matter the setting, after 60 days ARAS gives a

checkbox captcha.

• Conclusion: Is easier not to use an account at all.

ARAS Influence Evaluation Cookie Geolocation

• Used ToR to create cookies from different regions.
• Result: no restrictions on the location of IP of cookie creation.

ARAS Influence Evaluation Browser Checks

• Automation:
• WebDriver sets the webdriver attribute to TRUE if automation is found
• Manually set attribute to TRUE, using Javascript.
• Result: No difference, checkbox captcha provided.
• Screen Resolution:
• Tried various resolutions, from 1x1 to 4096 x 2160.
• Result: No difference, checkbox captcha provided.

ARAS Influence Evaluation Browser Checks

• User-Agent:
• User-Agent is compared to the Canvas Fingerprint for validity.

ARAS Influence Evaluation Browser Checks

• Mouse:Tried different behaviors to check if ARAS is affected.
• Timing of movements.
• Erratic Movement Patterns.
• Multiple clicks in widget and checkbox.
• Used getElementById().click() Javascript function, to simulate clicking without

hovering.

• Result: None of the above had a negative effect.

ARAS Influence Evaluation Browser Checks

• Token Harvesting:
• Experimented if creating a large number of cookies from single IP is prohibited.
• Result: 63000 cookies per day without getting blocked. Only restriction was

when triggering concurrent request.

• Selling token harvesting attacks for $2/1000, could make $104-110 daily, or

even higher with multiple attacks.

ARAS Influence Evaluation Maximum number of checkbox

• Identify how many checkbox captchas can solve in a day without being

blocked.

Checkbox captchas obtained per minute

ARAS Influence Evaluation Overall Evaluation

• ReCaptcha suffers from significant flaws and omissions.
• In an attempt to remove the burden for legitimate users, attacks were

enabled.

• The checks performed, can be used to introduce more safeguards.

Automated Solving Image reCaptcha Evaluation

• The image captcha breaking is evaluated based on these aspects:
• Solution flexibility: how many wrong answers are allowed.
• Image Repetition: at what rate challenges/images are repeated.
• Live Attack: Real attack results.

Automated Solving Image reCaptcha Solution Flexibility

• Manually solved image challenges using

different combination of correct and wrong selections.

• 74% of the image captchas had 2 correct

images out of 9 candidates, the rest had 3-4.

• Based on these results, system was set

to select 3 images.

Combinations of correct and wrong answers that pass image reCaptcha

Automated Solving Image reCaptcha Image Repetition

• Searched challenges with identical MD5 values.
• From 700 captchas, found 6 pairs of identical challenge. In 2 different sites within two hours.
• Conclusion: Challenges are not created on-the-fly, but from a small pool of challenges.
• Searched images using perceptual hashes.
• Identified 1368 images identical in total.
• 358 different repeating images.
• Most repeated image, was found 92 times.

Automated Solving Image reCaptcha Attack Simulation

Accuracy of simulated attack for different combinations of modules against the image reCaptcha

Automated Solving Image reCaptcha Live Attack

• Used Clarifai.
• Labelled dataset: Manually labelled 3000 images from challenges, with a tag from

hint_list.

• Run the attack on 2235 captchas, scoring 70.78% accuracy.
• Better results because of repetition (found 1515 sample images and 385 candidate in

labelled dataset).

• Also found 4 pairs of identical challenges. Google doesn’t remove challenges even if

completed correctly.

Live Attack Time and Hints Repetition

Cumulative distribution of time required for each step Frequency and success rate for each type of hint

Facebook Captcha Attack

• Facebook uses captchas to prevent bots

from sending suspicious URLs and spam.

• Resizes images dynamically in html,

allowing access to high resolution versions.

• May have 2 to 10 correct images, 5 - 7 in

most cases.

Facebook Captcha Attack

Attack accuracy against Facebook’s image captcha

Guidelines and Countermeasures

• Token Auctioning:
• Token verification api has an optional field comparing ip address of user that solved and the one that

submitted the token. Should be mandatory.

• Risk Analysis:
• Account:
• Those that are not logged in, will have to solve the hardest challenge.
• Limit number of tokens per IP address.
• Cookie Reputation:
• Number of cookies that can be created within a time period, should be regulated.
• Browser Checks:
• Stricter approach and return no challenge if overtly suspicious.
• E.g. mismatch browser-user-agent.

Guidelines and Countermeasures (cont.)

• Image captcha attacks:
• Remove flexibility.
• Increase number and increase range of correct images.
• Repetition:
• When a challenge is shown, it should be removed from pool.
• Pool of challenges should be larger.
• Hint and Content:
• Hint should be removed
• Providers can make experiments to find problematic image categories for image annotation software.
• Content homogeneity:
• Populate challenges with filler images of the same category as solutions.

Guidelines and Countermeasures (cont.)

• Advanced Semantic Relations:
• Instead of similar objects, user could be asked to select semantically related objects.
• Adversarial Images:
• Altering a small number of pixels, the image are misclassified, but are same visually.
• Introducing noise:
• Experiment on random grid, with varying parameters.
• Grid reduces probability of retrieved higher resolution images.
• Images will have to be cleaned first, so computational cost is added.
