APSCO Pumping Services-ScrewSucker High Efficiency- Non Ragging Pumps Presented by: Dan Vejar ScrewSucker? APS? A Dry Priming, Dry Running, portable packaged Screw Centrifugal pumping system Key Components Hidrostal Diesel

slide-1
SLIDE 1

APSCO Pumping Services-ScrewSucker High Efficiency- Non Ragging Pumps Presented by: Dan Vejar

slide-2
SLIDE 2

ScrewSucker?

 APS?  A Dry Priming, Dry Running, portable packaged Screw Centrifugal

pumping system

 Key Components  Hidrostal  Diesel or Electric drive system  Integrated Controls  Actuated Vacuum Priming System  Applications  Temporary Services: Bypass, site dewatering, Flood Control, Slurry

pumping.

slide-3
SLIDE 3

What is it?

 Modular Self Contained Pump  Self Dry Priming  Screw-Centrifugal Hidrostal Pump  Whisper Quiet Noise  Highly Efficient  Easy to Operate  Low Maintenance

slide-4
SLIDE 4

ScrewSucker Features and Benefits

 Most Fuel Efficient Portable

Pump in the World

 Quietest Pump in the World  Will not Rag  Dry Running, Dry Self

Priming max lift 28 ft

 Raw Unscreened Sewerage

and Sludge pump

slide-5
SLIDE 5
slide-6
SLIDE 6

Hidrostal

Screw Centrifugal 4”-20”

  • Large solids handling
  • Low Shear
  • Slurry/Sludge pump
  • Unmatched Efficiency with

Solids Handling

  • High Volume Capabilities and

amazing Turn down

slide-7
SLIDE 7

Screw Centrifugal Impeller

Tandem Oil bath

Mechanical Seals…indefinite dry running

Large Free Passage

slide-8
SLIDE 8

Vacuum Priming System

 No spillage to Environment  Venturi priming systems can add up to 5gpd of sewage spilled onto

streets and floors

 Only Runs as Needed  Reduces your wear and operating cost  Keeps Efficiencies higher and $$$ in your pocket  Increased Suction Capabilities  Overcomes small leaks  Less Maintenance

slide-9
SLIDE 9

Priming Chamber

High Probe, Vacuum Pump off Low Probe, Vacuum Pump on Ground Probe Vacuum System operates on demand and is controlled via conductivity sensors. Off condition is met when water makes conductivity between the short probe and ground this will Clutch off Vacuum pump and shut Solenoid valve. Resets when water level clears the medium length probe.

slide-10
SLIDE 10

Only Primes as needed saving Power Consumption and improving efficiency

Priming System

slide-11
SLIDE 11

Controls

 12 V Relay Logic  Level Actuated Start/Stop  No pivoting mercury float to tangle around ladders  Easy/definite set points  Included in our STANDARD  Enclosed with pump controls, no extra devices  Remote start/stop capabilities

slide-12
SLIDE 12
slide-13
SLIDE 13

Weatherproof Enclosure

  • Galvanized and Powder Coat

Finish

  • Nema 4X Control Panel
  • Weather Sealant around all access

points

slide-14
SLIDE 14

Secure/ Silent Packaging

Standard Build is

Enclosed

 50 dBa @ 23’  Secure Locking, Vandal

Proof

 Double Containment  PowderCoat Galvanized.

Optional Galvanized

Steel Cage-electric

slide-15
SLIDE 15

APPLICATIONS

 VARIOUS APPS in Wide Range of

markets

 Municipal

 CSO and SSO prevention  Lift Station Redundancy  Emergency Preparedness  Bypass Pumping for new

Construction or Rehabilitation

 IFAS/MBBR Media Pumping  Collections System survey

slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25

Lift Station Redundancy

slide-26
SLIDE 26

Lift Station Redundancy

slide-27
SLIDE 27

Lift Station Redundancy

slide-28
SLIDE 28

Thank You

Q&A
