Bengali Speech Recognition: A Double Layered LSTM-RNN Approach

Md Mahadi Hasan Nahid, Bishwajit Purkaystha, Md Saiful Islam Department of Computer Science and Engineering Shahjalal University of Science and Technology, Sylhet-3114.

➢ Provides efficient communication between humans and machine

Speech Recognition Is Important

➢ Provides efficient communication between humans and machine ➢ Increases throughput

Speech Recognition Is Important

➢ Provides efficient communication between humans and machine ➢ Increases throughput ➢ Is the most natural way of communication

Image sources: [1] www.glasbergen.com [2] www.playbuzz.com

Speech Recognition Is Important

➢ Intuitive for humans, not for machines

We say, "Let there be light".

Speech Recognition Is Difficult

➢ Intuitive for humans, not for machines

We say, "Let there be light". Machine hears,

Speech Recognition Is Difficult

➢ Intuitive for humans, not for machines

We say, "Let there be light". Machine hears,

➢

Different pitches, accents, durations, noise levels

Speech Recognition Is Difficult

➢ A recurrent neural network (RNN) architecture proposed

• Double layered bidirectional long short term memory (LSTM) used

Our Contribution

➢ A recurrent neural network (RNN) architecture proposed

• Double layered bidirectional long short term memory (LSTM) used

➢ Individual phonemes detected

• to some extent

Our Contribution

➢ A recurrent neural network (RNN) architecture proposed

• Double layered bidirectional long short term memory (LSTM) used

➢ Individual phonemes detected

• to some extent

➢ Compared results with other methods on Bengali automatic speech recognizer

Our Contribution

➢ Preprocessing

• noise reduction, mel frequency cepstral coefficients (MFCC)

extraction

➢ Training

➢ Postprocessing

Methodology

➢ Speech signal is divided into a number of frames

• each frame has 13 features (i.e., MFCCs)

Methodology: Preprocessing (1/2)

➢ Speech signal is divided into a number of frames

• each frame has 13 features (i.e., MFCCs)

➢ An example word: (pronounced as: SOTERO)

Methodology: Preprocessing (1/2)

➢ Speech signal is divided into a number of frames

• each frame has 13 features (i.e., MFCCs)

➢ An example word: (pronounced as: SOTERO)

• S-O-T-E-R-O
• 5 phones

Methodology: Preprocessing (1/2)

➢ Speech signal is divided into a number of frames

• each frame has 13 features (i.e., MFCCs)

➢ An example word: (pronounced as: SOTERO)

• S-O-T-E-R-O
• 5 phones
• 17 frames

Methodology: Preprocessing (1/2)

➢ Speech signal is divided into a number of frames

• each frame has 13 features (i.e., MFCCs)

➢ An example word: (pronounced as: SOTERO)

• S-O-T-E-R-O
• 5 phones
• 17 frames
• SSS-OO-TTT-EEEE-RRR-OO
• roughly 3 frames for each phone

Methodology: Preprocessing (1/2)

SSS-OO-TTT-EEEE-RRR-OO

Methodology: Preprocessing (2/2)

➢ Each timestamp carries a frame

Methodology: Training with LSTM (1/3)

➢ Each timestamp carries a frame ➢ Input layer contains 13 units

• ne for each coefficient

Methodology: Training with LSTM (1/3)

➢ Each timestamp carries a frame ➢ Input layer contains 13 units

• ne for each coefficient

➢ Next two layers are recurrent

• each contains 100 LSTM cells

Methodology: Training with LSTM (1/3)

➢ Each timestamp carries a frame ➢ Input layer contains 13 units

• ne for each coefficient

➢ Next two layers are recurrent

• each contains 100 LSTM cells

➢ The final layer is a softmax layer with 30 units

• there are 30 phonemes in total

Methodology: Training with LSTM (1/3)

➢ An LSTM cell

• exploits context using gates
• has recurrent connection for temporal

modeling

• has nonlinear squashing activation

functions for capturing complex relation

➢ Together, responsible for associating cepstral coefficients to phones

Methodology: Training with LSTM (2/3)

Methodology: Training with LSTM (3/3)

➢ A phone found in consecutive frames

STRONG EVIDENCE, it is present. How many?

➢ Depends on threshold T

Methodology: Postprocessing

Methodology: Postprocessing

➢ An example: (Labeled: Sh,Sh,Sh,O,O,O,L,L,O,O,O)

• 12 frames

Methodology: Postprocessing

➢ An example: (Labeled: Sh,Sh,Sh,O,O,O,L,L,O,O,O)

• 12 frames

➢ Network output: S,Sh,Sh,O,O,O,L,L,O,O,O

Methodology: Postprocessing

➢ An example: (Labeled: Sh,Sh,Sh,O,O,O,L,L,O,O,O)

• 12 frames

➢ Network output: S,Sh,Sh,O,O,O,L,L,O,O,O ➢ Initial Noise Elimination: _,Sh,Sh,O,O,O,L,L,O,O,O

Methodology: Postprocessing

Methodology: Postprocessing

Final Output: "ShOLO"

Methodology: Postprocessing

➢ Phone Detection Error rate (Perr)

Analysis: Evaluation Metrics

➢ Phone Detection Error rate (Perr) ➢ Word Detection Error rate (Werr)

Analysis: Evaluation Metrics

➢ Phone Detection Error rate (Perr) ➢ Word Detection Error rate (Werr) ➢ Bengali Real Number Dataset (Nahid et al., 2016)

Analysis: Evaluation Metrics

➢ 28.7% Perr 13.2% Werr ➢ CMU Sphinx4 incurred 15% Werr (Nahid et al., 2016)

Analysis: How Model Learns

➢ Some phons almost always detected with higher confidence (e.g., 'A', 'O', 'L')

• they occurred more frequently
• no other phon pronounced similarly

Analysis: Phon labeling

➢ Some phons almost always detected with higher confidence (e.g., 'A', 'O', 'L')

• they occurred more frequently
• no other phon pronounced similarly

➢ Some phons frequently garbled

Analysis: Phon labeling

➢ It seems, on average, there are 5 phones in a word in dataset ➢ Robustness not checked

Analysis: Threshold Affects Learning

➢ Phon alignment very difficult

• Same example introduced thrice, but with different

alignment

➢ Only vocabulary words recognized

• 114 unique words

➢ Robustness in threshold selection not tested

Limitations

➢ An RNN architecture is proposed based on phon detection ➢ Bengali Real Numbers are recognized with higher accuracy ➢ The vocabulary can be increased on larger datasets ➢ How to align phones can be learned too

Conclusion

• Nahid, M. M. H., Islam, M. A., & Islam, M. S. (2016, May). A noble approach for

recognizing Bangla real number automatically using CMU Sphinx4. In Informatics, Electronics and Vision (ICIEV), 2016.

• Graves, Alex, Abdel-rahman Mohamed, and Geoffrey Hinton. "Speech recognition

with deep recurrent neural networks." Acoustics, speech and signal processing (icassp), 2013 ieee international conference on. IEEE, 2013.

• Ravuri, Suman, and Steven Wegmann. "How neural network features and depth

modify statistical properties of HMM acoustic models." Acoustics, Speech and Signal Processing (ICASSP), 2016 IEEE International Conference on. IEEE, 2016.

References

Thank you

Phoneme List
