Applications to high dimensional problems

Francesca Odone and Lorenzo Rosasco RegML 2013

Regularization Methods for High Dimensional Learning Intro

Machine Learning

systems are trained

• n examples

rather than being programmed

Application domains

Regularization Methods for High Dimensional Learning Applications

fa

Some success stories

Pedestrian detection

speech recognition

face detection OCR

Regularization Methods for High Dimensional Learning Applications

Plan

✤ bioinformatics: gene selection (elastic net) ✤ computer vision: object detection (l1 regularization) ✤ human robot interaction : action recognition (dictionary learning and multi-class categorization) ✤ video-surveillance: pose detection (semi-supervised learning)

Regularization Methods for High Dimensional Learning Applications

Microarray analysis

Goals: ✤ Design methods able to identify a gene signature, i.e., a panel of genes potentially interesting for further streening ✤ Learn the gene signatures, i.e., select the most discriminant subset of genes on the available data

Regularization Methods for High Dimensional Learning Applications

Microarray analysis

A typical “-omics” scenario: ✤ High dimensional data - Few samples per class

• tenths of data - tenths of thousands genes

→ Variable selection ✤ High risk of selection bias

• data distortion arising from the way the data are collected due to the

small amount of data available

→ Model assessment needed ✤ Find ways to incorporate prior knowledge ✤ Deal with data visualization

Regularization Methods for High Dimensional Learning Applications

Gene selection

THE PROBLEM ✤ Select a small subset of input variables (genes) which are used for building classifiers ADVANTAGES: ✤ it is cheaper to measure less variables ✤ the resulting classifier is simpler and potentially faster ✤ prediction accuracy may improve by discarding irrelevant variables ✤ identifying relevant variables gives useful information about the nature of the corresponding classification problem (biomarker detection)

Regularization Methods for High Dimensional Learning Applications

Elastic net and gene selection

✤ Consistency guaranteed - the more samples available the better the estimator ✤ Multivariate - it takes into account many genes at once Output: ✤ One-parameter family of nested lists with equivalent prediction ability and increasing correlation among genes ✤ minimal list of prototype genes ✤ longer lists including correlated genes

min

β∈Rp ||Y − X||2 + ⌧(||||1 + ✏||||2 2)

✏ → 0 ✏1 < ✏2 < ✏3 < . . .

Regularization Methods for High Dimensional Learning Applications

Double optimization approach

✤ Variable selection step (elastic net) ✤ Classification step (RLS)

min

β∈Rp ||Y − X||2 + ⌧(||||1 + ✏||||2 2)

||Y − βX||2

2 + λ||β||2 2

for each ✏ we have to choose and ⌧

the combination prevents the elastic net shrinking effect

Mosci et al, 2008

Regularization Methods for High Dimensional Learning Applications

Dealing with selection bias

λ → (λ1, . . . , λA) τ → (τ1, . . . , τB) the optimal pair (λ∗, τ ∗) is one of the possible A · B pairs (λ, τ)

Barla et al, 2008

Regularization Methods for High Dimensional Learning Applications

Computational issues

• Computational time for LOO (for one task)

time1−optim = (2.5s to 25s) depending on the correlation parameter total time = A · B · Nsamples · time1−optim ∼ 20 · 20 · 30 · time1−optim ∼ 2 · 104s to 2 · 105s

• 6 tasks → 1 week!!

Regularization Methods for High Dimensional Learning Applications

Image understanding

✤ Image understanding is still largely unsolved ✤ today we are starting to answer more specific questions such as

• bject detection, image categorization, ...

✤ Machine learning has been the key to solve this kind of problems: ✤ it deals with noise and intra-class variability by collecting appropriate data and finding suitable descriptions ✤ Notice that images are relatively easy to gather (but not to label!)

• many benchmark datasets
• labeling tools
• and services

✤ image representations are very high dimensional

• curse of dimensionality
• computational cost at run time (while often we need real time performances)

Regularization Methods for High Dimensional Learning Applications

Adaptive representations from fixed dictionaries

✤ Overcomplete general purpose sets of features are effective for modeling visual information ✤ Many object classes have peculiar intrinsic structures that can be better appreciated if one looks for symmetries or local geometries ✤ Examples of dictionaries: ✤ wavelets, ranklets, chirplets, banks of filters, ... ✤ See for instance

• face detection [Heisele et al.,

Viola & Jones, Destrero et al.],

• pedestrian detection [Oren et al., Dalal and Triggs]
• car detection [Papageorgiou & Poggio]

Regularization Methods for High Dimensional Learning Applications

Object detection in images

✤ object detection is a binary classification problem

• image regions of variable size are classified: is it an

instance of an object or not?

✤ unbalanced classes

• in this 380x220 px image we perform ~6.5x105 tests

and we should find only 11 positives

✤ the training set contains

• images of positive examples (instances of the object)
• negative examples (background)

Regularization Methods for High Dimensional Learning Applications

• bject detection in images

xi → (φ1(xi), . . . , φp(xi))

image processing & computer vision offer a variety of local and global features for different purposes

Regularization Methods for High Dimensional Learning Applications

feature selection on fixed dictionaries

✤ We start off from an overcomplete dictionary of features ✤ ✤ usually p is big; existence of the solution is ensured, uniqueness is not ✤

• vercomplete dictionaries contain many correlated features

✤ Thus, the problem is ill-posed. We assume Φβ = Y where Φ = {Φij} is the data matrix; β = (β1, ..., βp)T vector of unknown weights to be estimated; Y = (y1, ..., yn)T output labels Selection of meaningful features subsets ✤ L1 regularization allows us to select a sparse subset of meaningful features for the problem, with the aim of discarding correlated ones D = {φγ : X → R, γ ∈ Γ} min

β∈Rp ||Y − βΦ||2 + τ||β||1

Regularization Methods for High Dimensional Learning Applications

an example of fixed size dictionary

✤ rectangle features aka Haar-like features (Viola & Jones) are one of the most effective representations of images for face detection ✤ size of the initial dictionary: a 19 x 19 px image is mapped into a 64.000-dim feature vector! ✤ the features selected

Destrero et al, 2009

Regularization Methods for High Dimensional Learning Applications

the role of prior knowledge

✤ Many image features have a characteristic internal structure ✤ An image patch is divided in regions or cells and represented according to the specific description, then all representations are concatenated ✤ many features used in computer vision share this common structure (SIFT, HOG, LBP , ...) ✤ In such cases it is beneficial to select groups of features belonging to the same region (so called Group Lasso)

Regularization Methods for High Dimensional Learning Applications

Selecting features groups

Pedestrian detection with HOG features: binary classification

B∗ = arg min

B

kY ΦBk2

2 + τ G

X

g=1

• BIg
• F

! .

Face recognition with LBP features: multi-class categorization

β∗ = arg min

β

ky Φβk2

2 + τ G

X

g=1

• βIg
• 2

!

10

10

10

10

10

10

false positives per window miss rate fixed size HOG (105 blocks)[DalTri05] group lasso 50 blocks group lasso 104 blocks group lasso 210 blocks group lasso 387 blocks

Zini & Odone, 2010 Fusco et al, 2013

Regularization Methods for High Dimensional Learning Applications

adaptive dictionaries

keypoints clusters

Regularization Methods for High Dimensional Learning Applications

adaptive dictionaries

✤ sparse codes

min

D,u kx Duk2 2 + λkuk1 subject to kdik2  1.

fixed vs adaptive

Regularization Methods for High Dimensional Learning Applications

HRI: iCub recognizing actions

Gori, Fanello et al 2012

Regularization Methods for High Dimensional Learning Applications

Semi-supervised pose classification

✤ The capability of classifying people with respect to their orientation in space is important for a number of tasks

• An example is the analysis of

collective activities, where the reciprocal orientation of people within a group is an important feature

• The typical approach relies on

quantizing the possible

• rientations in 8 main angles
• Appearance changes very

smoothly and labeling may be subjective

Noceti & Odone, in preparation

Back Left Left Front Left Back Left Left Front Left Back Back Right Right Front Right Front

Regularization Methods for High Dimensional Learning Applications

Semi-supervised pose classification

✤ Instead of using a fully labeled dataset, we adopt manifold regularization with both labeled and unlabeled data: ✤ A gallery of highly representative examples is extracted from the training set for each class (e.g. with k-means, LLE, ...). These are the labeled examples ✤ The remaining data are used as unlabeled examples, letting the algorithm in charge of associating them with the most appropriate class f ∗ = arg min

f∈H

1 n

n

X

i=1

V (f(xi), yi) + λAkfk2

K + λI

u2 f T Lf

Method

• Acc. 1
• Acc. 2

MultiClass-SVM 48% 75% LAPSVM 72% 80% feature sel.+LAPSVM 79% 86% An example is correctly classified if it associated with its class or one of the two adjacent

Regularization Methods for High Dimensional Learning Applications

Appendices

✤ learning how to grasp objects ✤ learning common behaviors (dealing with variable length inputs)

Regularization Methods for High Dimensional Learning Applications

learning the appropriate type of grasp

estimate the most likely grasps estimate the hand posture vector

Regularization Methods for High Dimensional Learning Applications

learning common patterns in temporal sequences

φP

u (s) = |{(v1, v2) : s = v1uv2}|

where u 2 AP , while v1, v2 are substrings such that v1 2 AP1, v2 2 AP2, and P1 + P2 + P =| s |. The associated kernel between two strings s1 and s2 is defined as: KP (s1, s2) = hφP (s1), φP (s2)i = X

u∈AP

φP

u (s1)φP u (s2).

String length independence is achieved with an appropriate normalization ˆ KP (s1, s2) = KP (s1, s2) p KP (s1, s1) p KP (s2, s2) .

temporal sequences

{xi}N

i=1 with xi = (x1 i , x2 i , . . . , xki i )>

adaptive space quantization P-spectrum kernel for sequences
