Nuno Borges Carvalho Passive Backscatter Sensors for IoT Ricardo Correia applications Daniel Belo Felisberto Pereira Motivation Present IoThings Near future IoThings Page 2 IT- DETI Universidade de Aveiro (nbcarvalho@ua.pt)

slide-1
SLIDE 1

Passive Backscatter Sensors for IoT applications

Nuno Borges Carvalho Ricardo Correia Daniel Belo Felisberto Pereira

slide-2
SLIDE 2 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Motivation

Page 2

Present Io“Things” Near future Io“Things”

slide-3
SLIDE 3 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Motivation

Page 3
slide-4
SLIDE 4 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Motivation

Page 4 from QUALCOMM
slide-5
SLIDE 5 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Motivation Energy waste in IoT

Page 5 http://edna.iea-4e.org Source: 2016 data

Standby Energy Battery Manufacturing

One battery per IoT device and replaced every 2nd year

slide-6
SLIDE 6 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Motivation Energy waste in IoT

Page 6

Standby Energy

Batteries take hundreds of years to decompose, posing a serious threat to the public health and to the environment.

slide-7
SLIDE 7 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Market Solutions Power Consumption

Page 7

Type AAA CR2032 CR123A CR2 Material Alkaline LiMn02* Lithium Lithium Voltage 3V 3V 3V 3V Capacity 500 mAh 225 mAh 1500 mAh 800 mAh

10 20 30 40 50 60 50 100 150 200 250 300 350 Years Transactions per day AAA CR2032 CR123A CR2
slide-8
SLIDE 8 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Energy harvesting sources

Page 8

Wi-Fi Radio and TV broadcast GSM/Cellular

slide-9
SLIDE 9 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

The Solution

Page 9

Backscatter communications Wireless Power Transmission Energy Harvesting LoRa – 60 mW to 400 mW Bluetooth – 5 mW to 90 mW WiFi – 50 mW to 1 W

  • Remove the need of power for transmit / receive!
  • Eliminate batteries!

Passive

slide-10
SLIDE 10 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt) Page 10

Backscatter communications Wireless Power Transmission Energy Harvesting

SWIPT

Simultaneous Wireless Information and Power Transfer

slide-11
SLIDE 11 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Our Solution – SWIPT backscatter

Page 11

Low Cost SDR Readers Dummy Wireless Power Transmitters Passive Sensors

slide-12
SLIDE 12 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Backscatter Battery-less Paradigm

12

slide-13
SLIDE 13 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

Towards the FUTURE!!

Page 13

Passive Sensors Increase Data rate Increase data rate and enable WPT capabilities 2015 2017 2018 2019 2016 Increase frequency and decrease size Total size = 0.92 mm2

kbit/s Gbit/s

slide-14
SLIDE 14 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

14

Backscatter ambient backscatter

Spyridon N Daskalakis et all, “Spectrally Efficient 4-PAM Ambient FM Backscattering for Wireless Sensing and RFID Applications”, to be presents in the next IMS2018 in Philadelphia
slide-15
SLIDE 15 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt)

mmWave low power connectivity – Applications & Investors

Page 15
  • Glaucoma
  • Diabetes (track the blood

sugar levels – measure glucose) Extremely small, low power and cheap connectivity solution which can be embedded in every object

slide-16
SLIDE 16 IT- DETI – Universidade de Aveiro (nbcarvalho@ua.pt) Page 16

Thank you very much for your attention
