Applications of Secure Location Sensing in Healthcare Michael Rushanan, David Russell, Aviel D. Rubin Johns Hopkins University Introduction Healthcare Application Benefit patient care, delivery, and safety Protect sensitive patient

slide-1
SLIDE 1

Applications of Secure Location Sensing in Healthcare

Michael Rushanan, David Russell, Aviel D. Rubin Johns Hopkins University

slide-2
SLIDE 2

Introduction

  • Healthcare Application
  • Benefit patient care, delivery, and safety
  • Protect sensitive patient data
  • Tracking and managing assets in real-time
  • Access Control
  • Barcode medication administration system
slide-3
SLIDE 3

Real-time Tracking

  • Tracking and managing assets in real-time
  • Hospitals
  • 1/3 Nurses spend at least 1hr/shift
  • 35,000 Units; 32-48% Being used
  • $4,000 equipment per bed
slide-4
SLIDE 4

Problem

  • Tracking needs to be secure
  • Resilient to passive and active attacks

Asset Tracker Backend Server

Position

Passive Adversary

slide-5
SLIDE 5

Problem

  • Tracking needs to be secure
  • Resilient to passive and active attacks

Asset Tracker Active Adversary Backend Server

Position

slide-6
SLIDE 6

BCMA

  • Scan barcodes on patients and medications
  • Improve patient safety by reducing human error
  • Electronic information integration
  • Interface with electronic medical records
slide-7
SLIDE 7

Problem

  • Scanning considered impractical
  • Koppel et al. identify 31 unique causes that

influence workarounds

  • Malfunctioning scanner
  • Unreadable wristbands
  • Wrong administration of medication
slide-8
SLIDE 8

Access Control

  • Electronic medical records
  • Require access all the time
  • Mobile device
  • BYOD or Hospital asset
  • Single-factor
  • Password or pin

Mike’s Personal Medical Record Height: x Weight: x Sex: Male Diseases: x, y, z History:

  • 1. Something happened.
  • 2. Something else.

Doctor Notes: He’s cool.

slide-9
SLIDE 9

Problem

  • Attacker can bypass this access control
  • All the data stored no the device is compromised

Mike’s Personal Medical Record Active Adversary

slide-10
SLIDE 10

Solution

  • Implement secure real-time tracking system
  • Secure against active and passive attacks
  • Implement other applications:
  • Location-based restrictions
  • BCMA with physical proximity
slide-11
SLIDE 11

Outline

  • We will discuss:
  • Common architecture
  • Secure real-time tracking system
  • Location-based access restrictions
slide-12
SLIDE 12

Common Architecture

  • We need a physical device that is:
  • Simple (computation, space)
  • Wireless
  • Efficient (i.e., run on battery)
  • Low-cost
  • Trusted central server
slide-13
SLIDE 13

BLE Beacons

13

slide-14
SLIDE 14

Apple iBeacon

  • Low-cost device
  • Bluetooth Low Energy (BLE)
  • Unidirectional
  • Computes distance via RSSI
  • Intended for advertising
  • “Spoofing” as a feature

14

slide-15
SLIDE 15

iBeacon

Beacon Beacon Beacon Gamestop Target Kroger Welcome to Target Coupon

Advertisement Not in range. Not in range.

slide-16
SLIDE 16

Other Technologies

  • RFID is expensive
  • Infrastructure (i.e., ingress and egress antennas)
  • Hospital RF policies
  • GPS doesn't work well indoors
slide-17
SLIDE 17

Other Technologies

  • Wi-Fi is bi-directional
  • Introduces complexity
  • Consumes more power
  • Larger attack surface

17

Access Point Access Point Access Point

slide-18
SLIDE 18

iBeacon Problem

  • iBeacon specification is not secure

18

Beacon Beacon Beacon Gamestop Kroger Welcome to Target Coupon

Advertisement Not in range. Not in range.

slide-19
SLIDE 19

Introducing Beacon+

  • Modify iBeacon specification
  • Add an AES CBC-MAC (i.e., authentication)
  • Secret key assigned a priori to deployment
  • Monotonically increasing sequence number
  • To handle clock skew

19

slide-20
SLIDE 20

Crypto Primer

  • Message Authentication Code
  • Short piece of information
  • Authenticates a message
  • Message came from state sender
  • Has not changed
  • Secret key needed to compute MAC
slide-21
SLIDE 21

Beacon+

21

slide-22
SLIDE 22

Initialization

  • Beacon+ on initialization:
  • ID
  • Sequence Number
  • Secret
  • Location

22

slide-23
SLIDE 23

Design

  • Every second, Beacon+:
  • Increments sequence number
  • Computes new MAC
  • MAC sent to BLE BoosterPack via UART at a

regular interval (i.e., 8x per second)

  • Replace previous advertisement

23

slide-24
SLIDE 24

Advertisements

iBeacon(Adver-sement( BLE(Adver-sement(Payload( 31(bytes(

UUID( (16(bytes)( Major( (2(bytes)( Minor( (2(bytes)( Ad(Structure(1( Size( (1(byte)( BLE(Flags( (2(bytes)( Ad(Structure(2( Size( (1(byte)( TX(Power( (1(byte)( Unused( (1(byte)(

Beacon+(Adver-sement(

ID( (2(bytes)( Sequence(Number( (8(bytes)( MAC( (16(bytes)( Ad(Structure(1( Size( (1(byte)( BLE(Flags( (2(bytes)( Ad(Structure(2( Size( (1(byte)( TX(Power( (1(byte)(

Reserved((4(bytes)( UserQDefined(Data((27(bytes)(( Reserved((4(bytes)( UserQDefined(Data((27(bytes)((

24

slide-25
SLIDE 25

Communication

3 2 1

I am 2

Trusted Server

Tracking

BLE WIFI I am 1 I am 3

slide-26
SLIDE 26

Communication

b1 b2 b3 b1 b2

X X

r1 r2 r3 r 1 r2

slide-27
SLIDE 27

Real-time Tracking

  • Beacon+’s are fixed at physical locations
  • Tracked BLE-speaking devices collect
  • Authenticated advertisements
  • RSSI
  • Beacon+’s data is shared with the trusted server

27

slide-28
SLIDE 28

Real-time Tracking

Beacon+ Unidirectional broadcast Multidirectional wireless communication Beacon+ Backend Server Data Collector Medical Device Beacon+ Beacon+ Beacon+ Beacon+ Smartphone 28

slide-29
SLIDE 29

Access Control

  • Bypass or breaks traditional access control
  • Password
  • Location-based access restrictions
  • Restrict access to data based on location
  • Another factor of authentication

29

slide-30
SLIDE 30

Beacon+

Nearby Patient Records Smith, John Doe, Jane Claus, Nicholas Roberts, Alice ID: 0004 Name: Roberts, Alice Address: 1056 Mountain Dr. Sex: Female DOB: 11/5/1967 History: N/A Therapy: Electroshock Medication: N/A Doctor: Dr. Evil Notes: None

30

slide-31
SLIDE 31

Criticisms of Beacon+

  • Access control
  • Need access to data immediately
  • Location verification issues
  • Inside attacker can modify RSSI to fake location
  • Proxy received signals
  • Trusted server

31

slide-32
SLIDE 32

No Central Trusted Authority

Beacon+ Beacon+ Certificate Authority Map Authority Medical Device Beacon+ Beacon+ Beacon+ Beacon+ Smartphone

signed(ids, locations)

Tracking & Location-based Access Queries 32

slide-33
SLIDE 33

Summary

  • Described common architecture
  • Beacon+
  • Discussed location sensing applications
  • Benefit patient safety
  • Addressed some criticisms

33

slide-34
SLIDE 34

Questions

34

Thank you for attending my talk!

slide-35
SLIDE 35

Backup Slides

slide-36
SLIDE 36

Trilateration

slide-37
SLIDE 37

No Central Trusted Authority

37

S={0,1}256 ID={0,1}128 HN=HN(s) C={ }

Setup

ID HN sig{ } ID HN sig

A hash chain is the successive application

  • f a hash function to a

piece of data. Its used to produce many one-time keys from a single key or password.

slide-38
SLIDE 38

No Central Trusted Authority

38

S ID

[Sender] Beacon+

M

ki = HN-i( ) i tagi=MAC(M, HN-(i+1)( )) S S C

{

slide-39
SLIDE 39

No Central Trusted Authority

39

[Sender] Beacon+ At time ,send M and

i tagi

At time ,send M and

j tagj

[Verifier] Phone Check time Verify Hj( ) =?

C kj HN
