Slide 1 / 199

AP BIOLOGY Gene Expression

www.njctl.org Summer 2013

Slide 2 / 199

Gene Expression Unit Topics

· Discovery of DNA · DNA Replication

Click on the topic to go to that section

· Transcription & Translation · Recombinant DNA · Nucleic Acid Structure

Slide 3 / 199

Discovery of DNA

Return to Table of Contents

Slide 4 / 199

The precipitate at the bottom of this flask is Deoxyribose Nucleic

• Acid. This chemical is the

informational basis for all life. Its properties allow for the storage of instructions to build living things.

Nucleic Acid Slide 5 / 199

Every molecule, organelle, cell,

• rgan, organ system, organism

and population is built by this molecule. It is the building block of the genes that control how bodies are shaped and how organisms react to environmental factors. This molecule is evolution.

Nucleic Acid Slide 6 / 199

"Individuals are not stable things, they are

• fleeting. Chromosomes too are shuffled into
• blivion, like hands of cards soon after they

are dealt. But the cards themselves survive the shuffling. The cards are the genes. They merely change partners and march on. They are the replicators and we are their survival machines. When we have served

• ur purpose we are cast aside. But genes are

denizens of geological time: genes are forever."

The Selfish Gene

Richard Dawkins, Evolutionary Biologist and Oxford University professor.

Slide 7 / 199

As an example, blue eyes are a phenotype; a physical trait, controlled by a single gene.

Genes Live Beyond Individuals

A recent study showed that a mutation in one individual's OCA2 gene, which produces the pigment that gives color to eyes, created a gene for blue eyes. This occurred 8,000 years ago and the new gene was passed generation to generation.

Slide 8 / 199 Genes live beyond individuals

Today approximately 560,000,000 people have blue eyes. Each individual carries 2 copies of the original mutation. The gene has long outlived the human that it originated in.

Slide 9 / 199

Primary Discovery

Nucleic acids were first isolated by the Swiss physician Friedrich Miescher who, in 1869, discovered a microscopic substance in the pus of discarded surgical bandages. At the time it was an unknown cellular substance and was not considered important until many years later.

Miescher's Lab where he discovered nucleic acid

Slide 10 / 199 The Search for Genes

Frederick Griffith in 1928 conducted the following experiment using 2 different strains of the bacterium Streptococcus pneumoniae.

Slide 11 / 199

S strain bacteria kills mice. R strain bacteria does not kill mice. Killed S strain does not kill mice. Killed S strain mixed with living R strain kills mice. Dead mouse blood contains living S strain.

Slide 12 / 199

The Search for Genes

In Griffith's experiment why does the dead mouse contain living S strain when only dead S strain was injected? Theorize what may be happening. Griffith's conclusion: Living R strain absorbs a chemical left from the dead S strain. This chemical transforms the living bacteria into the deadly S strain. What we know now: Bacteria is capable of transformation. This is when DNA is taken in from the environment and incorporated into the bacteria's DNA. In this case the gene that produces the deadly toxin is absorbed.

Slide 13 / 199

1 Which strain of S. pneumoniae was virulent?

A

R strain

B

S strain

C

both

D

neither

Slide 14 / 199

1 Which strain of S. pneumoniae was virulent?

A

R strain

B

S strain

C

both

D

neither

[This object is a pull tab]

Answer B

Slide 14 (Answer) / 199

2 What does Griffith's experiment illustrate?

A

Bacteria can transfer genes via sex pili

B

Phages increase the genetic variation of bacteria

C

DNA is the genetic material of cells

D

Bacteria can absorb genetic information from their environment

Slide 15 / 199

2 What does Griffith's experiment illustrate?

A

Bacteria can transfer genes via sex pili

B

Phages increase the genetic variation of bacteria

C

DNA is the genetic material of cells

D

Bacteria can absorb genetic information from their environment

[This object is a pull tab]

Answer D

Slide 15 (Answer) / 199 Closing in on the Genetic Material

After Griffith's experiment most scientists believed that the chemical transforming bacteria was a protein, not a nucleic acid. In the early 1940s experiments performed by Oswald T. Avery and his colleagues at the Rockefeller Institute for Medical Research challenged that assumption.

Slide 16 / 199

Closing in on the Genetic Material

Avery used a test tube assay. This is when a scientist compares differences in test tubes after treating each differently. The benefit is that you can discover more specific reactions. This approach will lead to more information than dead

• r living mice can provide.

Slide 17 / 199 Closing in on the Genetic Material

First he heat-killed the S strain bacteria and mixed it with detergent. This caused the bacterial cells to break apart. Their membranes lysed and spilled out the cell's contents. The upper portion of the test tube, the lysate, contains less dense materials like proteins, enzymes, and nucleic acids.

precipitate lysate

Slide 18 / 199 Closing in on the Genetic Material

The precipitate contained the large organelles and proteins of the

• cell. Avery isolated the lysate to use because it contained smaller

molecules that were more likely to be the genetic material.

precipitate lysate lysate DNA RNA Proteins

Slide 19 / 199

Closing in on the Genetic Material

To be sure he took the lysate and mixed it with R strain to see if it would transform the bacteria to S strain and it worked.

lysate R strain S strain

Slide 20 / 199 Closing in on the Genetic Material

It is easy to tell the difference from R and S because they look different when grown on a petri dish. (R for rough edge; S for smooth edge).

R strain S strain

Slide 21 / 199 Closing in on the Genetic Material

Next Avery put in an enzyme that digests proteins into the lysate and did the same experiment. What do you suspect is the result and why?

R strain lysate mixed with an enzyme that digests protein

Slide 22 / 199

Closing in on the Genetic Material

Next Avery put in an enzyme that digests proteins into the lysate and did the same experiment. What do you suspect is the result and why?

S strain

Slide 23 / 199 Closing in on the Genetic Material

What could you do to confirm this result? In other words what would be another way to treat the lysate that would give usable data?

Slide 24 / 199 Closing in on the Genetic Material

Avery and his team devised a technique that used alcohol to isolate and purify nucleic acids from solution. In a later experiment they mixed the purified nucleic acid from S strain with R strain bacteria. What is the expected result? S strain

Slide 25 / 199

3 Avery's work retested Griffith's hypothesis using a test tube assay. What was the purpose of Avery's experiment?

A

To test the validity of Griffith results

B

To determine the macromolecule responsible for genetic information

C

To determine the accuracy of a modern technique

D

To illustrate that the R and S strains were two separate species

• f bacteria

Slide 26 / 199

3 Avery's work retested Griffith's hypothesis using a test tube assay. What was the purpose of Avery's experiment?

A

To test the validity of Griffith results

B

To determine the macromolecule responsible for genetic information

C

To determine the accuracy of a modern technique

D

To illustrate that the R and S strains were two separate species

• f bacteria

[This object is a pull tab]

Answer B

Slide 26 (Answer) / 199 The Definitive Proof

The Hershey–Chase experiments were a series of experiments conducted in 1952 by Alfred Hershey and Martha Chase that confirmed DNA was the genetic material. By this time many new discoveries allowed these scientists to go beyond what others had been able to discover about nucleic acids.

Slide 27 / 199

The Definitive Proof

Most importantly, intense research on viruses at the time expanded the knowledge of these tiny particles. Hershey and Chase concentrated on bacteriophages. These viruses that infected and killed bacteria were known to only be composed of 2 things: proteins and DNA

Slide 28 / 199 The Definitive Proof

Secondly, a lot was being learned about radioactivity. Since they could not see the viruses, Hershey and Chase used a novel approach that took advantage of a new technique called radioactive labeling. This allowed them to track different parts

• f the virus by looking for radiation.

A geiger counter can find and measure radioactive particles

Slide 29 / 199 The Definitive Proof

Hershey and Chase began by creating 2 kinds of radioactive virus using a labeling technique. Below is how they made virus A.

bacteriophages

Viruses grow via lytic cycle. When they make proteins they must use the radioactive sulfur.

bacteria radioactive SULFUR

Slide 30 / 199

The Definitive Proof

Since proteins, not DNA, need sulfur to be constructed only the proteins in these new phages are radioactive

Slide 31 / 199 The Definitive Proof

The procedure is repeated to make virus B with a change in the radioactive material.

bacteriophages

Viruses grow via lytic cycle. When they make DNA they must use the radioactive phosphorus.

bacteria radioactive PHOSPHORUS

Slide 32 / 199 The Definitive Proof

Since DNA, not proteins, need phosphorus to be constructed only the DNA in these new phages are radioactive.

Slide 33 / 199

The Definitive Proof

Virus A is mixed with bacteria. If the bacteria were sampled and isolated, would it be radioactive? Apply what you know about the lysogenic cycle and genes to hypothesize. radioactivity? 36 hours

Slide 34 / 199 The Definitive Proof

Virus B is mixed with bacteria. If the bacteria were sampled and isolated, would it be radioactive? Apply what you know about the lysogenic cycle and genes to hypothesize. radioactivity? 36 hours

Slide 35 / 199 The Definitive Proof

Summary of Hershey Chase experiments:

Slide 36 / 199

4 Hershey and Chase utilized phages in their research because phages...

A have easily controlled reproductive cycles B

are inexpensive to maintain

C

contain only nucleic acids and proteins

D

have a higher mutation rate than living organisms

Slide 37 / 199

4 Hershey and Chase utilized phages in their research because phages...

A have easily controlled reproductive cycles B

are inexpensive to maintain

C

contain only nucleic acids and proteins

D

have a higher mutation rate than living organisms

[This object is a pull tab]

Answer C

Slide 37 (Answer) / 199

5 After viral infection, radioactive phosphorus was found in the bacterial cells. This result occurred because...

A

Expression of the viral DNA incorporated radioactive phosphorus into the proteins

B

Only viral DNA was inserted into the host cell

C

The viral DNA was incorporated in the host DNA during the lysogenic cycle

D

DNA and proteins require phophorus while only proteins require sulfur

Slide 38 / 199

5 After viral infection, radioactive phosphorus was found in the bacterial cells. This result occurred because...

A

Expression of the viral DNA incorporated radioactive phosphorus into the proteins

B

Only viral DNA was inserted into the host cell

C

The viral DNA was incorporated in the host DNA during the lysogenic cycle

D

DNA and proteins require phophorus while only proteins require sulfur

[This object is a pull tab]

Answer B

Slide 38 (Answer) / 199

6 Which of the following illustrates the sequence of events leading to the confirmation of nucleic acids as the genetic material of the cell?

A

Hershey-Chase experiments, Avery experiments, Miescher's discovery, Griffith experiments

B

Griffith experiments, Miescher's discovery, Avery experiments, Hershey-Chase experiments

C

Miescher's discovery, Griffith experiments, Avery experiments, Hershey-Chase experiments

D

Miescher's discovery, Avery experiments, Hershey-Chase experiments, Griffith experiments

Slide 39 / 199

6 Which of the following illustrates the sequence of events leading to the confirmation of nucleic acids as the genetic material of the cell?

A

Hershey-Chase experiments, Avery experiments, Miescher's discovery, Griffith experiments

B

Griffith experiments, Miescher's discovery, Avery experiments, Hershey-Chase experiments

C

Miescher's discovery, Griffith experiments, Avery experiments, Hershey-Chase experiments

D

Miescher's discovery, Avery experiments, Hershey-Chase experiments, Griffith experiments

[This object is a pull tab]

Answer C

Slide 39 (Answer) / 199

The Double Helix

With the data collected by Hershey and Chase the focus of the scientific community shifted to nucleic acids. DNA in particular became the focus of scientists looking to make the next big discovery. Two pairs of scientists working in the same facility ultimately made the discoveries about DNA that lead to the modern understanding

• f the genetic material.

Slide 40 / 199 The Double Helix

Working at King's College London in 1951, Rosalind Franklin and Maurice Wilkins produced x-ray diffraction images of DNA to try to discover its shape and understand its mechanisms.

Slide 41 / 199 The Double Helix

X-ray diffraction shoots subatomic particles into a substance. The collison of these particles with those of the molecules in the substance cause them to diffract, or ricochet, at specific angles. This gives insight to the structure of the substance.

X-rays Crystalized DNA photo paper sensitive to x-rays

Slide 42 / 199

The Double Helix

Wilkins shared this now famous "photo 51" (that was prepared by Franklin) with his colleagues James Watson and Francis Crick.

photo 51 James Watson Francis Crick

Slide 43 / 199 The Double Helix

Watson and Crick deciphered from the photo that DNA was a double helix. They began to build models of the structure so they could speculate on how DNA can: 1) Self replicate 2) Code for all the traits of living things

The discoverers of the DNA structure, James Watson, left, and Francis Crick, with their model of a DNA

• molecule. (A. Barrington Brown/Photo Researchers, Inc.)

Slide 44 / 199

Nucleic Acid Structure

Return to Table of Contents

Slide 45 / 199

RNA and DNA

Uracil is a nitrogenous base in RNA but not DNA. Thyamine is a nitrogenous base in DNA but not RNA. RNA is single stranded and can fold into many shapes. DNA is double stranded and can only be a double helix.

1 2 1

RNA and DNA are the 2 nucleic acids necessary for living organisms.

Slide 46 / 199 DNA

DNA is an informational molecule encoding the genetic instructions used in the development and functioning of all known living organisms. This diagram highlights the major chemical features. Notice that guanine and cytosine form 3 hydrogen bonds, while adenine and thymine for only 2 hydrogen bonds.

Slide 47 / 199 DNA

The two strands run in

• pposite directions to each
• ther and are therefore anti-

parallel, one backbone being 3' (three prime) and the other 5' (five prime). This refers to the direction the 3rd and 5th carbon on the sugar molecule is facing.

Slide 48 / 199

RNA

RNA makes the molecular machinery necessary for the function of DNA. It plays a major role in the replication of DNA and the reading of the information stored in DNA.

Three-dimensional representation of the small ribosomal subunit. RNA is in brown, protein in blue. The active site is in the middle (red). This molecule reads the genetic code.

Slide 49 / 199

7 Which of the following is not true regarding DNA and RNA?

A

Ribose has one more hydroxyl group than DNA

B

Both RNA and DNA backbones consist of a sugar-phosphate chain

C

Only DNA bases form hydrogen bonds

D

DNA forms only one shape. RNA forms many shapes

Slide 50 / 199

7 Which of the following is not true regarding DNA and RNA?

A

Ribose has one more hydroxyl group than DNA

B

Both RNA and DNA backbones consist of a sugar-phosphate chain

C

Only DNA bases form hydrogen bonds

D

DNA forms only one shape. RNA forms many shapes

[This object is a pull tab]

Answer C

Slide 50 (Answer) / 199

8 Which of the following is true regarding uracil?

A

It is only found in DNA

B

It forms 2 hydrogen bonds with adenine

C

It is more stable than thymine

D

It is only found outside the nucleus of eukaryotic cells

Slide 51 / 199

8 Which of the following is true regarding uracil?

A

It is only found in DNA

B

It forms 2 hydrogen bonds with adenine

C

It is more stable than thymine

D

It is only found outside the nucleus of eukaryotic cells

[This object is a pull tab]

Answer B

Slide 51 (Answer) / 199 Chromosomes Defined

A chromosome is an organized structure of DNA and protein found in cells. It is a single piece

• f coiled DNA containing

many genes.

Slide 52 / 199

Chromosomes Defined

Chromosomes vary widely between different organisms. The DNA molecule may be circular or linear, and can be composed of 100,000 to over 3,750,000,000 nucleotides in a long chain. Typically, eukaryotic cells have large linear chromosomes and prokaryotic cells have smaller circular chromosomes.

Slide 53 / 199 Prokaryotic Chromosomes

This is a chromosomal map of a bacteria, H. orenii. Like all bacteria, this circular DNA molecule contains all the genes that are needed to make the entire

• rganism.

This particular bacterial genome is made of ~2,500,000 nucleotides. Each different color in the outer circle represents another gene.

Slide 54 / 199 Eukaryotic Chromosomes

In eukaryotes, nuclear chromosomes are packaged by proteins into a condensed structure called chromatin. This allows the very long DNA molecules to fit into the cell nucleus. Chromosomes are the essential unit for cellular division and must be replicated, divided, and passed successfully to their daughter cells to ensure the genetic diversity and survival of offspring.

Slide 55 / 199

Eukaryotic Chromosomes

Since eukaryotes are larger and more complex, eukaryotic chromosomes are much larger and require more complex methods for storage of their numerous genes. Special proteins called histones and scaffolds pack the DNA strand into tight coils.

Slide 56 / 199 Eukaryotic Chromosomal Structure see next slide Slide 57 / 199 see next slide Eukaryotic Chromosomal Structure Slide 58 / 199

Eukaryotic Chromosomal Structure Slide 59 / 199 Eukaryotic Chromosomal Structure

This diagram represents a eukaryotic chromosome after replication has occurred. (1) Chromatid – one of the two identical copies of the chromosome. (2) Centromere – the point where the two chromatids touch, and where the microtubules attach during cell division. (3) Short arm. (4) Long arm.

Slide 60 / 199 Eukaryotic Chromosomal Structure

Chromosomes are often represented as genetic maps that show the loci of

• genes. This is a representation of

human chromosome 7

3 4 2

Slide 61 / 199

Human Chromosomes

Each band represents a gene or a group of genes that code for a phenotype of the human. Humans have 23 pairs of chromosomes in each of their cells that contain multiple copies of ~40,000 genes.

Slide 62 / 199

Chromosome Number

Chromosomes can be diploid, 2 versions of each chromosome, or haploid, 1 version of each chromosome. N= Number of chromatids

Slide 63 / 199

9 How is prokaryotic and eukaryotic DNA similiar?

A

It is double stranded

B

The DNA is wrapped around histone proteins

C

The DNA condenses into chromosomes during cellular replication

D

Chromosomes are located in the cell nucleus

Slide 64 / 199

9 How is prokaryotic and eukaryotic DNA similiar?

A

It is double stranded

B

The DNA is wrapped around histone proteins

C

The DNA condenses into chromosomes during cellular replication

D

Chromosomes are located in the cell nucleus

[This object is a pull tab]

Answer A

Slide 64 (Answer) / 199

10 When would human chromosomes have this appearance?

A

in gametes

B

in somatic cells

C

during interphase

D

during mitosis

Slide 65 / 199

10 When would human chromosomes have this appearance?

A

in gametes

B

in somatic cells

C

during interphase

D

during mitosis

[This object is a pull tab]

Answer D

Slide 65 (Answer) / 199

Human Karyotype

A karyotype is a photograph of the actual chromosomes of an individual human. A nucleus is isolated and the chromosomes are removed and arranged. They can be used to learn about possible chromosomal abnormalities.

Slide 66 / 199 Human Karyotype

What can you learn about this individual from their chromosomes?

Most likely a normal female

Slide 67 / 199 Human Karyotype

What can you learn about this individual from their chromosomes?

Abnormal number of sex chromosomes Klinefelter syndrome XXY

Slide 68 / 199

Human Karyotype

What can you learn about this individual from their chromosomes?

Male with extra chromosome 21 Down Syndrome

Slide 69 / 199

DNA Replication

Return to Table of Contents

Slide 70 / 199 Replication

The functions of a cell are determined by its DNA. Cells have to reproduce many times. In complex organisms, trillions of copies are made from one original cell. But when cells reproduce, they must replicate (or copy) their DNA. The structure of DNA reveals how trillions of copies of the DNA in one of your cells can be made, and be almost exactly the same each time.

Slide 71 / 199

Watson & Crick

When Watson and Crick published the structure of DNA in a short article in 1953 they stated: "It has not escaped our notice that the specific pairing we have postulated immediately suggests a possible copying mechanism for the genetic material." The fact that there are two DNA strands that are mirror images

• f one

another suggested how copies could be made of each DNA sequence.

Slide 72 / 199 DNA Molecule as Template

Each molecule of DNA is made

• f a template strand and a new

strand. The template is used to make the new strand. The template strand is also known as the parent strand since it came from the original DNA molecule. The new strand is also known as the daughter strand. template strand

Slide 73 / 199

The template strands of the DNA molecule separate and the new strands are made on the inside.

Separation of Strands

Click here to see an animation of the mechanism of replication

Slide 74 / 199

Nucleotides can only be added to the -OH end (3`), not the 5`so all new strands are made in the 5' - 3' direction.

Adding New Nucleotides Slide 75 / 199

DNA nucleotide monomers are made ahead of time and stored in the cell. DNA polymerase is the enzyme responsible for adding each new nucleotide to the growing strand.

Enzyme Catalyzed Reaction Slide 76 / 199

Two parent strands One parent and

• ne daughter

strand One parent and

• ne daughter

strand

Semi-Conservative DNA Replication

The result of this process is 2 new DNA molecules each having an

• ld template strand and new strand. This is called semi-conservative

because it "conserves" some of the old DNA in each copy.

Slide 77 / 199

11 The 3' end of a DNA strand has a phosphate at the end.

True False

Slide 78 / 199

11 The 3' end of a DNA strand has a phosphate at the end.

True False

[This object is a pull tab]

Answer False

Slide 78 (Answer) / 199

12 Why does a DNA strand only "grow" in the 5' to 3' direction?

A because DNA can only add nucleotides to the 3' end of the molecule B because DNA can only add nucleotides to the 5' end of the molecule C because mRNA can only read a DNA molecule from 5' to 3' D because mRNA can only read a DNA molecule from 3' to 5'

Slide 79 / 199

12 Why does a DNA strand only "grow" in the 5' to 3' direction?

A because DNA can only add nucleotides to the 3' end of the molecule B because DNA can only add nucleotides to the 5' end of the molecule C because mRNA can only read a DNA molecule from 5' to 3' D because mRNA can only read a DNA molecule from 3' to 5'

[This object is a pull tab]

Answer A

Slide 79 (Answer) / 199

3' ATCGGGTTAACGCGTAAA 5' template strand 5' ______________________ 3' new strand

Replication Practice

What is the sequence of the new strand? 3' GGTTACTAATCGAGCCCCT 5' template strand 5' ______________________ 3' new strand What is the sequence of the new strand?

Slide 80 / 199

13 If the parent DNA strand is 5' ATCGATACTAC 3', what will the

daughter stand be A 5' TAGCTATGATG 3' B 3' ATCGATACTAC 5' C 5' UAGCUAUGAUG 3' D 3' TAGCTATGATG 5'

Slide 81 / 199

13 If the parent DNA strand is 5' ATCGATACTAC 3', what will the

daughter stand be A 5' TAGCTATGATG 3' B 3' ATCGATACTAC 5' C 5' UAGCUAUGAUG 3' D 3' TAGCTATGATG 5'

[This object is a pull tab]

Answer D

Slide 81 (Answer) / 199

The Molecular Process of Replication

A strand of DNA is replicated in segments. At intervals down the DNA molecule portions of the 2 strands separate creating replication

• bubbles. Either side of the replication bubble is know as a

replication fork.

Slide 82 / 199

Replication Fork

DNA replication is a precise process that must minimize error. To do this cells use many enzymes in a complex process that uses template strands to create new DNA molecules

Slide 83 / 199

Topoisomerase is an enzyme that controls winding of DNA during

• replication. A winding problem in DNA arises due to the intertwined

nature of its double helical structure. During DNA replication, DNA becomes overwound ahead of a replication fork. This tension would eventually stop replication.

Topoisomerase

Slide 84 / 199

Helicase breaks the weak hydrogen bonds that hold nucleotides together opening up both strands to become templates for new

• strands. Helicase is the molecule that creates the replication fork.

Helicase

Slide 85 / 199

Single stranded binding proteins ensure that the nucleotide pairs do not re-bind after helicase passes.

Single Stranded Binding Proteins

Slide 86 / 199

Since the strands are anti-parallel they are arranged in opposite

• directions. In order to replicate both strands in the same direction

there are 2 different strategies, one for each template ( leading and lagging).

Leading vs. Lagging Strands

Slide 87 / 199

The leading strand is simple since it runs 3' to 5'. DNA polymerase can follow behind helicase and simply copy the template as it is being exposed.

DNA Polymerase

Slide 88 / 199

DNA polymerase can only read in the 3' to 5' direction. So on the lagging strand there has to be a way to make the new strand in

• reverse. It starts with an enzyme called primase that adds RNA

nucleotides as a primer for DNA polymerase.

Primase

Slide 89 / 199

DNA polymerase can latch onto the RNA primers and begin to write fragment of the new strand. Since it is going away from the replication fork it only does a portion, then it jumps back in front of the portion it just did to start again.

DNA Polymerase

Slide 90 / 199

The fragments formed by this process are called Okazaki fragments. When the RNA primers fall away from the strand gaps are left between the fragments that must be repaired.

Okazaki Fragments

Slide 91 / 199

DNA ligase finishes the job by filling in the gaps between the Okazaki fragments.

Ligase

Slide 92 / 199

14 Hydrogen bonds hold base pairs together in DNA. Which enzyme severs these bonds during replication?

A

Ligase

B

Polymerase

C

Primase

D

Helicase

Slide 93 / 199

14 Hydrogen bonds hold base pairs together in DNA. Which enzyme severs these bonds during replication?

A

Ligase

B

Polymerase

C

Primase

D

Helicase

[This object is a pull tab]

Answer D

Slide 93 (Answer) / 199

15 A mutation has caused a change in the shape of the topisomerase enzyme. This would most likely affect...

A

the directionality of DNA synthesis

B

the formation of bonds between Okazaki fragments

C

the tension in the DNA double helix

D

the separation of the DNA strands

Slide 94 / 199

15 A mutation has caused a change in the shape of the topisomerase enzyme. This would most likely affect...

A

the directionality of DNA synthesis

B

the formation of bonds between Okazaki fragments

C

the tension in the DNA double helix

D

the separation of the DNA strands

[This object is a pull tab]

Answer C

Slide 94 (Answer) / 199

16 Incorrect base pairing does occur during the replication process, however, most of these errors are corrected. Which enzyme effectively decreases the mutation rate

• f cells?

A

helicase

B

ligase

C

primase

D

polymerase

Slide 95 / 199

16 Incorrect base pairing does occur during the replication process, however, most of these errors are corrected. Which enzyme effectively decreases the mutation rate

• f cells?

A

helicase

B

ligase

C

primase

D

polymerase

[This object is a pull tab]

Answer D

Slide 95 (Answer) / 199

Polymerase Chain Reaction

PCR (Polymerase Chain Reaction) is a technique which uses the principles of DNA replication to amplify the amount of DNA available for testing and manipulation. This reaction is carried out by a special machine that utilizes repeating cycles of heat, DNA polymerase, DNA primers and free nucleotides to build copies of the DNA fragment. This technology enables small amounts

• f DNA to be turned into large amounts.

Slide 96 / 199 Polymerase Chain Reaction

• 1. DNA is heated to high

temperature, the DNA strands denature, separating the double helix The cycle is repeated, doubling the amount of DNA each cycle.

• 2. DNA is cooled, primers

and polymerase in the mixture anneal to the DNA

• 3. The temperature is

increased slightly to increase the rate of replication reactions

Slide 97 / 199

17 A single DNA molecule is placed in a PCR machine. After 20 cycles, how many copies of DNA will be present?

Slide 98 / 199

17 A single DNA molecule is placed in a PCR machine. After 20 cycles, how many copies of DNA will be present?

[This object is a pull tab]

Answer 1,048,576

Slide 98 (Answer) / 199

18 Taq polymerase is typically used in polymerase chain

• reactions. This polymerase enzyme is found in

thermophilic bacteria, Thermus aquaticus. What is the best explanation for the use of this enzyme?

A

Enzymes from thermophilic bacteria are stable at high temperatures

B

Bacterial enzymes are easier to replicate than eukaryotic enzymes

C

Ethical objections exist to the use of human macromolecules, such as DNA polymerase

D

Only Taq polymerase is available commerically

Slide 99 / 199

18 Taq polymerase is typically used in polymerase chain

• reactions. This polymerase enzyme is found in

thermophilic bacteria, Thermus aquaticus. What is the best explanation for the use of this enzyme?

A

Enzymes from thermophilic bacteria are stable at high temperatures

B

Bacterial enzymes are easier to replicate than eukaryotic enzymes

C

Ethical objections exist to the use of human macromolecules, such as DNA polymerase

D

Only Taq polymerase is available commerically

[This object is a pull tab]

Answer A

Slide 99 (Answer) / 199

Transcription & Translation

Return to Table of Contents

Slide 100 / 199 Gene Expression

Gene expression is the molecular process of reading the order of nucleotides in a DNA molecule and making the coded product. This product is usually a protein but RNA is also coded for in genes. Gene expression occurs whenever a specific protein or RNA molecule is needed by the cell.

Slide 101 / 199

Expressing the information stored on a gene into a protein requires : · translating from the 4 letter language of DNA to RNA · Then from the 4 letter language of RNA, to the 20 letter language of proteins (their amino acid sequence).

DNA to RNA to Protein Slide 102 / 199

The mRNA "message" is read in 3-letter words called codons. Each codon codes for an amino acid or tells the process to stop.

Codons

There are 64 codons (4x4x4) but only 20 amino acids. So some codons code for the same amino acid.

Slide 103 / 199 The Universal Genetic Code

· 61 of the codons code for an amino acid · 3 of the remaining codons are "STOP" codons that do not code for an amino acid. They just signal that translation is over. · 1 codon that codes for the amino acid "methionine" is also the "START" codon. Methionine is always the first amino acid in a protein.

Slide 104 / 199

This is called a "universal" code because ALL LIFE uses

the same genetic code... from the smallest bacteria or

virus to the largest animal or tree. This tells us that this code goes back billions of years, in the first cell...or even before that. If there were alternative codes that could work, they would have appeared in nature. There are very minor alterations, but they are rare and insignificant in their effect.

The Universal Genetic Code Slide 105 / 199

A Adenine B Glycine (Gly) C STOP D Arginine E Valine

19

The codon UAA specifies:

Slide 106 / 199

A Adenine B Glycine (Gly) C STOP D Arginine E Valine

19

The codon UAA specifies:

[This object is a pull tab]

Answer C

Slide 106 (Answer) / 199

A Adenine

B

Glycine C STOP D Arginine

E

Valine

20

The codon GGG specifies:

Slide 107 / 199

A Adenine

B

Glycine C STOP D Arginine

E

Valine

20

The codon GGG specifies:

[This object is a pull tab]

Answer B

Slide 107 (Answer) / 199

21 Why is methionine the very first amino acid in all proteins? A because it is coded by the stop codon B because it is coded for by AUG which is the start codon C Methionine is coded for by more than one codon D none of the above

Slide 108 / 199

21 Why is methionine the very first amino acid in all proteins? A because it is coded by the stop codon B because it is coded for by AUG which is the start codon C Methionine is coded for by more than one codon D none of the above

[This object is a pull tab]

Answer B

Slide 108 (Answer) / 199

The processes of replication, transcription and translation are so critical that they are called the Central Dogma of Biology. A "Dogma" is a postulate; an idea; a philosophy. It is "Central" because it is what life is based on.

The Central Dogma

DNA RNA

PROTEIN

replicatio n

transcription translation

Slide 109 / 199

The Central Dogma is a one way process. Changes in DNA affect mRNA and protein. But changes in proteins or mRNA do not affect the DNA. This will have important implications when we study genetics.

DNA mRNA Protein

transcription translation

The Central Dogma Slide 110 / 199 The First Step - Transcription

Transcription is the first step of gene expression, in which a particular segment of DNA is copied into RNA by the enzyme RNA polymerase.

Slide 111 / 199

Gene Anatomy

Transcription of genes is regulated by the cell. Genes are turned on and off in response to environmental signals.

Slide 112 / 199

Control Region

This control region is where transcription factors bind to the gene. When all the necessary factors are combined RNA polymerase can bind to the gene and initiate transcription.

Slide 113 / 199

Transcription initiated when RNA polymerase and cofactors bind to the promoter (a section of the control region). The RNA polymerase unwinds the DNA creating an initiation bubble . This is a space that grants RNA polymerase access to a single strand of the DNA molecule.

Transcription - Initiation

• lymerase

Non- Template Promotor Region

Slide 114 / 199

The RNA polymerase never attaches to the strand that actually contains the gene. The strand with the genes is called the "non-template strand." This IS NOT the strand that is transcribed. The other strand is the mirror image of the first, it carries the mirror image of the gene, not the gene itself. It is called the "template strand." This IS the strand where the RNA polymerase attaches.

Template vs. Non-Template Strands Slide 115 / 199

non-template strand of DNA template strand of DNA transcription of template strand RNA

Note: the non-template strand of DNA (the gene) matches the new RNA strand This makes sense in that the RNA will be the mirror image

• f the DNA it is transcribed from. And the non-coding strand

is the mirror image of the gene.

Transcription: DNA Strands Slide 116 / 199

22

The strand that is transcribed into RNA is called the A Template Strand B Non Template Strand C RNA Strand D Amino Acid Strand

Slide 117 / 199

22

The strand that is transcribed into RNA is called the A Template Strand B Non Template Strand C RNA Strand D Amino Acid Strand

[This object is a pull tab]

Answer A

Slide 117 (Answer) / 199

23

What is the function of the controlling sequence on the DNA? A it is where the RNA polymerase recognizes and binds to initiate translation B it is where the RNA gets copied C it where transcription terminates D it is where the RNA polymerase binds to on the 3' end

• f the DNA initiating transcription

Slide 118 / 199

23

What is the function of the controlling sequence on the DNA? A it is where the RNA polymerase recognizes and binds to initiate translation B it is where the RNA gets copied C it where transcription terminates D it is where the RNA polymerase binds to on the 3' end

• f the DNA initiating transcription

[This object is a pull tab]

Answer D

Slide 118 (Answer) / 199

To make the RNA strand, RNA polymerase runs down the DNA template strand reading the bases and bringing in the new RNA nucleotides with the proper complementary bases. As the RNA polymerase runs down the DNA, it unwinds the DNA.

Non- Template new mRNA

Transcription - Elongation Slide 119 / 199

Transcription is made possible by the fact that the different bases are attracted to one another in pairs based

• n the number of hydrogen bonds they

can make. RNA DNA A bonds with T U bonds with A G bonds with C C bonds with G

Base Pairing

Note: In DNA replication adenine paired with thymine, in DNA transcription uracil is now paired with adenine. Remember that RNA does not contain thymine as a nucleotide base.

Slide 120 / 199 Transcription

RNA is made from the 5' end to the 3' end. Just like in DNA replication,

DNA("template strand") 3' TACGGCATTA

5'

RNA

5' AUGCCGUAAU 3' being made in 5'--------->3' direction.

Slide 121 / 199

24 If the template strand of DNA is 5' ATAGATACCATG 3', which is

the RNA strand produced from transcription

A

5' UAUCUAUGGUAC 3'

B

5' TATCTATGGTAC 3'

C 3' UAUCUAUGGUAC 5' D 3' TATCTATGGTAC 5'

Slide 122 / 199

24 If the template strand of DNA is 5' ATAGATACCATG 3', which is

the RNA strand produced from transcription

A

5' UAUCUAUGGUAC 3'

B

5' TATCTATGGTAC 3'

C 3' UAUCUAUGGUAC 5' D 3' TATCTATGGTAC 5'

[This object is a pull tab]

Answer C

Slide 122 (Answer) / 199

25 If the template strand of DNA is 5' AAAGACACTATT 3', which is

the RNA strand produced from transcription

A

5' UUUCUGUGAUAA 3'

B

5' TTTCTGTGATAA 3'

C 3' UUUCUGUGAUAA 5' D 3' TTTCTGTGATAA 5'

Slide 123 / 199

25 If the template strand of DNA is 5' AAAGACACTATT 3', which is

the RNA strand produced from transcription

A

5' UUUCUGUGAUAA 3'

B

5' TTTCTGTGATAA 3'

C 3' UUUCUGUGAUAA 5' D 3' TTTCTGTGATAA 5'

[This object is a pull tab]

Answer C

Slide 123 (Answer) / 199

26 If the non-template strand of DNA is 3' ACGATTACT 5', which is

the RNA strand produced through transcription

A 5' TGCTAATGA 3' B

3' UGCUAAUGA 5'

C 5' UGCUAAUGA 3' D

3' ACGAUUACU 5'

Slide 124 / 199

26 If the non-template strand of DNA is 3' ACGATTACT 5', which is

the RNA strand produced through transcription

A 5' TGCTAATGA 3' B

3' UGCUAAUGA 5'

C 5' UGCUAAUGA 3' D

3' ACGAUUACU 5'

[This object is a pull tab]

Answer D

Slide 124 (Answer) / 199

RNA polymerase gets to a sequence on the DNA called a termination sequence. This sequence signals the RNA Polymerase to STOP transcription.

Transcription - Termination

Non- Template Termination Sequence

The RNA polymerase falls off the DNA. The new RNA strand separates from the DNA. The DNA recoils into a helix.

Click here to see an animation of transcription

Slide 125 / 199

Controlling Gene Expression

Individual cells respond to environmental change by regulating their gene expression. Prokaryotes and eukaryotes have evolved different mechanisms for regulating their gene expression. Remember: one of the properties of life is "response to the environment"

Slide 126 / 199 Prokaryotic Gene Expression Slide 127 / 199

The following are 2 examples of the regulation of gene expression in prokaryotes:

Regulating Prokaryotic Gene Expression

Lac Operon Trp Operon

Slide 128 / 199

In prokaryotes, genes are often clustered into

• perons within the

chromosome. Operons consist of 3 parts... An operator - essentially an “on-off” switch A promoter - an area that attracts RNA polymerase The genes - which code for the protein needed by the cell

Operons: The Basic Concept Slide 129 / 199 Repressors

An operon can be switched off by a protein called a repressor. The repressor can be controlled through allosteric regulation with co-repressors and inducers. A co-repressor is a small molecule that cooperates with a repressor to help switch an operon off. An inducer is small molecule that inhibits a repressor to help switch an operon on.

Slide 130 / 199

Inducible Operons

An inducible operon is one that is usually off ; a molecule called an inducer inactivates the repressor and turns on transcription. An example of an inducible operon is the lac operon, which contains genes coding for enzymes that break down lactose into glucose so the bacteria can use it for energy. If no lactose is present then no enzyme needs to be made. The bacteria saves energy this way. In this operon, the lactose molecule is the inducer.

Click here to see an animation of the Lac Operon

Slide 131 / 199

A repressible operon is one that is usually on. When a repressor binds to an operator, transcription is shut off. The trp operon is a repressible operon. The trp operon codes for a number of genes responsible for the production of the amino acid

• tryptophan. If tryptophan is present in the environment, the

trp operon is not used. Tryptophan acts as the co-repressor in this operon.

Repressible Operons

Click here to see an animation of the Trp Operon

Slide 132 / 199

27 The lac operon is an example of an _____.

A inducible operon B repressable operon

Slide 133 / 199

27 The lac operon is an example of an _____.

A inducible operon B repressable operon

[This object is a pull tab]

Answer A

Slide 133 (Answer) / 199

28 In the presence of Trp ______.

A the repressor is activated B the cell makes more Trp C the operon is turned on

Slide 134 / 199

28 In the presence of Trp ______.

A the repressor is activated B the cell makes more Trp C the operon is turned on

[This object is a pull tab]

Answer A

Slide 134 (Answer) / 199

29 In the presence of lactose ______.

A the lac operon is turned off B the lac operon is turned on C the repressor becomes active

Slide 135 / 199

29 In the presence of lactose ______.

A the lac operon is turned off B the lac operon is turned on C the repressor becomes active

[This object is a pull tab]

Answer B

Slide 135 (Answer) / 199

Gene Expression in Eukaryotes

Eukaryotes have much more complex chromosomes that require multiple levels of regulation including: · "unpacking" of genes · transcription factors · RNA processing

Slide 136 / 199

Chromatin's Role in Gene Expression

When DNA is packed in chromatin it is not accessible to RNA polymerase so transcription can not happen. The main factor in the specialization of cells in multi-cellular

• rganisms is what genes are "unpacked" from the chromatin to be

exposed to RNA polymerase.

All gene sequences are exposed to RNA polymerase Some genes exposed No genes exposed

Slide 137 / 199 Chromatin Modifying Enzymes

The genes that need to be expressed are unwound from histones by chromatin modifying enzymes in order to expose their nucleotide sequences. Genes that are unnecessary to a particular cell will remain packed while the neccessary ones are unpacked.

Slide 138 / 199 mRNA Processing

After transcription of eukaryotic DNA, the transcript is known as pre-

• mRNA. Enzymes in the nucleus modify pre-mRNA before the

genetic messages are sent to the cytoplasm. This is know mRNA processing. During mRNA processing, both ends of the pre-mRNA are altered. Some interior sequences of pre-mRNA may be cut out, and other parts spliced together.

Slide 139 / 199

Alteration of mRNA Ends

The 5`end of the pre-mRNA receives a molecule known as a nucleotide (or 5') cap. This cap is a modified guanine molecule (the G in A, T, C, G)

AUGCCCUUAGCC GAUGCCCUUAGCC

pre-mRNA 5' cap added

Slide 140 / 199 Alteration of mRNA Ends

The 3` end of the pre-mRNA gets a poly-A tail. This tail is series

• f adenosine (A) nucleotides.

A A A A A A A A A A A A

AUGCCCUUAGCC GAUGCCCUUAGCCAAAAAAAA

• riginal pre-mRNA

3' tail added

Slide 141 / 199 Alteration of mRNA Ends

The modifications to the ends of the pre-mRNA have several functions: · They facilitate the export of mRNA from the nucleus to the cytoplasm · They protect mRNA from hydrolytic enzymes once it is in the cytoplasm · They help ribosomes attach to the mRNA so they can be translated into a protein.

Slide 142 / 199

RNA Splicing

Most eukaryotic genes and their RNA transcripts have long noncoding stretches of nucleotides that lie between coding regions. These noncoding regions are called intervening sequences, or introns. The other regions called exons (because they are eventually expressed ), are usually translated into amino acid sequences. RNA splicing removes introns and joins exons, creating an mRNA molecule with a continuous coding sequence.

Slide 143 / 199 mRNA Processing

This is an example of a pre-mRNA becoming a final transcript.

Slide 144 / 199

Some genes can code more than one kind of polypeptide, depending on which segments are treated as exons during RNA splicing. Alternative splicing allows the number of different proteins an organism can produce to be much greater than its number of genes.

Alternative RNA Splicing Slide 145 / 199

Alternative RNA Splicing

DNA sequence AAATTTCCCGGGAAATTTCCCGGG Pre-mRNA

(Cap)-UUUAAAGGGCCCUUUAAAGGGCCC-(Tail)

Alternate splices

(Cap)-UUU AAA UUU AAA-(Tail) OR (Cap)-GGC CCG GGC-(Tail)

Resulting polypeptide (protein) Phe - Lys - Phe - Lys OR Gly - Pro - Gly Alternate splicing can dramatically change the length and/or the sequence of the polypeptide chain that will be made

Slide 146 / 199

30 The first step in eukaryotic gene expression is...

A transcription B translation C RNA processing D unraveling the gene

Slide 147 / 199

30 The first step in eukaryotic gene expression is...

A transcription B translation C RNA processing D unraveling the gene

[This object is a pull tab]

Answer D

Slide 147 (Answer) / 199

31 Where does transcription occur in eukaryotic

cells?

A nucleus B nucleiod C cytoplasm D cell membrane

Slide 148 / 199

31 Where does transcription occur in eukaryotic

cells?

A nucleus B nucleiod C cytoplasm D cell membrane

[This object is a pull tab]

Answer A

Slide 148 (Answer) / 199

32 Once the DNA is unwound from the chromatin, which of

the following is necessary to begin transcription?

A RNA polymerase B ribosome C transcription factors D both A & C

Slide 149 / 199

32 Once the DNA is unwound from the chromatin, which of

the following is necessary to begin transcription?

A RNA polymerase B ribosome C transcription factors D both A & C

[This object is a pull tab]

Answer D

Slide 149 (Answer) / 199

33 A transcription unit that is 8,000 nucleotides long may use

1,200 nucleotides to make a protein consisting of 400 amino

• acids. This is best explained by the fact that

A

many introns are present in mRNA.

B there is redundancy and ambiguity in the genetic code. C

many nucleotides are needed to code for each amino acid.

D

many exons are present in mRNA

Slide 150 / 199

33 A transcription unit that is 8,000 nucleotides long may use

1,200 nucleotides to make a protein consisting of 400 amino

• acids. This is best explained by the fact that

A

many introns are present in mRNA.

B there is redundancy and ambiguity in the genetic code. C

many nucleotides are needed to code for each amino acid.

D

many exons are present in mRNA

[This object is a pull tab]

Answer A

Slide 150 (Answer) / 199

34 A mutation in which of the following parts of a gene is likely to

be most damaging to a cell? A intron B exon C both would be equally damaging.

Slide 151 / 199

34 A mutation in which of the following parts of a gene is likely to

be most damaging to a cell? A intron B exon C both would be equally damaging.

[This object is a pull tab]

Answer B

Slide 151 (Answer) / 199

After the finalized mRNA transcript is complete and correct, the pores in the nuclear envelope allow it to pass to the cytoplasm where it can be translated into proteins by ribosomes. The nuclear pore is a protein structure that controls the traffic flow

• f the nucleus. Each

nuclear pore is made up

• f hundreds of

individual proteins that insure only mRNAs with proper caps and tails can make it to the cytoplasm.

Entrance into the Cytoplasm Slide 152 / 199

Hydrolytic enzymes in the cytoplasm breakdown mRNA molecules. The length of time an mRNA survives in the cytoplasm relates to how much protein is made from it. Longer time in the cytoplasm means more translation by ribosomes. The length of the poly-A tail is one of many factors that determines the time of survival in the cytoplasm. The longer the tail, the longer it's survival.

Degradation of mRNA Slide 153 / 199 Summary of Gene Expression Regulation in Eukaryotes

· The gene must be unpacked from chromatin · The right transcription factors must be present Transcription occurs · Cap and tail must be added to the mRNA · Pre-mRNA must be edited (spliced) · Nuclear pores allow passage to the cytoplasm · mRNA comes into contact with a ribosome Translation occurs · Protein is used within the cell or exported to the environment

Slide 154 / 199 Translation

Translation is the process by which RNA strands are read to build proteins. Translate means to convert something from one language to another, you can remember that the process of making protein from RNA is called translation because the "language" of nucleotides" is being changed to the "language" of amino acids.

Slide 155 / 199

Three Types of RNA

• 1. mRNA or messenger RNA, carries the information for

protein synthesis. This type of RNA is key to The Central Dogma.

• 2. rRNA or ribosomal RNA, is a catalyst for protein

synthesis

• 3. tRNA or transfer RNA, helps in the assembly of amino

acids during protein synthesis Translation requires 3 types of RNA that are created using transcription.

Slide 156 / 199

The specific RNA that contains the protein's information from DNA is called Messenger RNA (mRNA); it carries the genetic message to ribosomes, where it is translated.

Messenger RNA (mRNA) Slide 157 / 199

Ribosomal RNA (rRNA) and some additional proteins make up the ribosome. The ribosome includes two subunits: one small, and

• ne large.

During translation, the ribosome catalyzes the reaction that makes covalent bonds between amino acids, thus building the protein. Large subunit Small subunit

Ribosomal RNA (rRNA) Slide 158 / 199

RNA, being single stranded, can fold in on itself. In tRNA, the RNA folds into a t-shape.

Transfer RNA (tRNA)

The Anticodon Loop is a 3 base sequence on the tip that is complementary to the codon on the mRNA. The Amino Acid Attachment Site is where the amino acid will attach to the tRNA.

Transfer RNA (tRNA) carries amino acids to the ribosome so that the ribosome can covalently bond them together to form the protein.

Slide 159 / 199

35 What is the function of the ribosome? A to make an ionic bond between amino acids B

to make a covalent/peptide bond between amino acids thus building the protein

C to make hydrogen bonds D to make RNA

Slide 160 / 199

35 What is the function of the ribosome? A to make an ionic bond between amino acids B

to make a covalent/peptide bond between amino acids thus building the protein

C to make hydrogen bonds D to make RNA

[This object is a pull tab]

Answer B

Slide 160 (Answer) / 199

36 Why does tRNA fold into its specific shape? A The sequence and bonding of its amino acids B The sequence of and bonding of nucleotides C Its protein structure D A and B E A and C

Slide 161 / 199

36 Why does tRNA fold into its specific shape? A The sequence and bonding of its amino acids B The sequence of and bonding of nucleotides C Its protein structure D A and B E A and C

[This object is a pull tab]

Answer B

Slide 161 (Answer) / 199

37 What is the anticodon for GGU?

A

CCT

B

CCA

C

GGU

D

GGA

Slide 162 / 199

37 What is the anticodon for GGU?

A

CCT

B

CCA

C

GGU

D

GGA

[This object is a pull tab]

Answer B

Slide 162 (Answer) / 199

38 If the anticodon of a tRNA is AUG, what is attached to the amino acid attachment site of that tRNA molecule?

A RNA B

methionine

C

tyrosine

D

glycine

Slide 163 / 199

38 If the anticodon of a tRNA is AUG, what is attached to the amino acid attachment site of that tRNA molecule?

A RNA B

methionine

C

tyrosine

D

glycine

[This object is a pull tab]

Answer C

Slide 163 (Answer) / 199

All the pieces are ready to begin translation: a coded strand of mRNA a set of 20 amino acids ribosomes tRNA to match all the amino acids

Translation - An Overview Slide 164 / 199

tRNAs bond to the amino acid specified by their anti-codon. The opposite side of each tRNA, the anti-codon, bonds to the matching codon on the mRNA, creating a string of amino acids in the proper sequence. The ribosome makes covalent bonds between the amino acids. The result is a protein chain with the specified sequence of amino acids.

Translation - An Overview Slide 165 / 199

The length and sequence of these amino acids allow all the proteins in the world to be created from only 20 amino acids. This is very similar to how all the words can be created from only 26 letters in the alphabet.

Proteins: Words Amino Acids :: Letters Slide 166 / 199

Translation - Initiation

5' 3'

The small subunit of the ribosome attaches to the mRNA at the bottom of the start codon(at the 5' end). Then the large subunit of the ribosome comes in over the top. The result is that the mRNA is "sandwiched" between the mRNA at the start codon (and the second codon as well!)

Slide 167 / 199

The ribosome goes to the 5' end of the mRNA because the 5' end is the beginning of where the gene on the DNA was transcribed into mRNA. Also notice that there are 2 sites within the ribosome. · The P-site - where the new protein will emerge · The A-site - where the Amino Acids are delivered in

Translation - Initiation

5'

3'

Slide 168 / 199

As the leading edge of the mRNA, with the starting code AUG, is exposed in the A site, the tRNA with the code UAC enters the site and hydrogen bonds with it, carrying methionine into the ribosome.

Translation - Initiation

A U G UAC

Met

The tRNAs, hydrogen bonded to their specific amino acids, surround the ribosome.

Slide 169 / 199

The methonine is removed from the tRNA and stays in the ribosome to be bonded with the next amino acid. The tRNA leaves the ribosome so another tRNA can enter. Each tRNA will carry the appropriate amino acid into the ribosome to be bonded in the proper sequence, since each tRNA anticoding site matches the coding site on the mRNA, which is located at the A site of the ribosome. Because each tRNA has an anticoding sequence it complimentary base pairs with the codon on the mRNA.

Translation - Initiation Slide 170 / 199

39 How does the anticodon on the tRNA and the codon on the

mRNA match up?

A by hydrogen bonding/complimentary base pairing B by ionic bonding C

by peptide bonds

D

none of the above

Slide 171 / 199

39 How does the anticodon on the tRNA and the codon on the

mRNA match up?

A by hydrogen bonding/complimentary base pairing B by ionic bonding C

by peptide bonds

D

none of the above

[This object is a pull tab]

Answer A

Slide 171 (Answer) / 199

40

What is the P site of the ribosome? A it is where the amino acids are delivered in B it is where the protein or peptide will emerge C it where the tRNA's will deliver in the next amino acid after each translocation D it is where the proteins fold into their 3-d shape

Slide 172 / 199

40

What is the P site of the ribosome? A it is where the amino acids are delivered in B it is where the protein or peptide will emerge C it where the tRNA's will deliver in the next amino acid after each translocation D it is where the proteins fold into their 3-d shape

[This object is a pull tab]

Answer B

Slide 172 (Answer) / 199

The 2nd tRNA with its amino acid is delivered into the A-site in the ribosome. The ribosome catalyzes a covalent bond between the amino acids.

Translation - Elongation Slide 173 / 199

The tRNA that was in the A-site moves to the P-site and the tRNA that was in the P-site separates from its amino acid. Notice the protein emerging from the P- site!

Translation - Elongation

The ribosome moves the mRNA using chemical energy.

Slide 174 / 199

Elongation continues by adding one amino acid after another. Each amino acid is delivered to the A-site by its matching tRNA. The ribosome makes a peptide bond between the 2 amino acids in the P and A sites.

until......

Translation - Elongation Slide 175 / 199

The ribosome reaches a STOP codon. Remember that STOP codons do not code for amino acids. This signals the end of translation. The protein is complete. The 2 subunits (large and small) separate from each other. UAA is 1 of the 3 possible STOP codons.

Translation - Termination Slide 176 / 199

The Result- A protein in its "primary sequence". Remember that Primary level (1

0 ) of protein

structure is the sequence of amino acids.

Translation - Termination

Click here to see an animation of translation

Slide 177 / 199

41

What is the first event of translation?

A the tRNA comes in B the small subunit of the ribosome and the 1st tRNA brings in

Methionine to the start codon

C

elongation happens

D

the large subunit of the ribosome comes in

Slide 178 / 199

41

What is the first event of translation?

A the tRNA comes in B the small subunit of the ribosome and the 1st tRNA brings in

Methionine to the start codon

C

elongation happens

D

the large subunit of the ribosome comes in

[This object is a pull tab]

Answer B

Slide 178 (Answer) / 199

42

What is the function of the ribosome in translation?

A it makes a peptide/covalent bond using the energy

from translocation

B it makes hydrogen bonds between the codons C it makes covalent/peptide bonds between the codons D none of the above

Slide 179 / 199

42

What is the function of the ribosome in translation?

A it makes a peptide/covalent bond using the energy

from translocation

B it makes hydrogen bonds between the codons C it makes covalent/peptide bonds between the codons D none of the above

[This object is a pull tab]

Answer D

Slide 179 (Answer) / 199

43 What does termination in translation involve? A translocation of the ribosome B

the ribosome gets to a stop codon and the small and large subunits of the ribosome separate

C RNA polymerase falls off the DNA D a tRNA brings in an amino acid

Slide 180 / 199

43 What does termination in translation involve? A translocation of the ribosome B

the ribosome gets to a stop codon and the small and large subunits of the ribosome separate

C RNA polymerase falls off the DNA D a tRNA brings in an amino acid

[This object is a pull tab]

Answer B

Slide 180 (Answer) / 199

Recombinant DNA

Return to Table of Contents

Slide 181 / 199

Biotechnology

Understanding the structure, replication, and expression of genes has allowed scientists to create biotechnologies which improve human lives. One of the first procedures to use DNA to successfully was recombinant DNA technology. In this procedure genes from one organism are spliced into the genome of another. Since all organisms use the same genetic code the cells that contained the recombined DNA will produce the protein encoded by the new gene.

Slide 182 / 199

Slide 183 / 199 Diabetes

Diabetes is a disease in which a person has high blood sugar either because the pancreas does not produce enough insulin,

• r because cells do not respond to the insulin that is

produced.

The cells of the pancreas release insulin in response to high levels of glucose in the blood. Cells respond by taking glucose in, out of the blood, to reduce the concentration. Insulin structure (a protein)

Slide 184 / 199 Diabetes

Untreated, diabetes causes many

• problems. Most

severe is damage to the kidneys resulting from the increased solute of the blood for extended periods.

Slide 185 / 199

Early Treatment of Diabetes

At first doctors treated by injecting bovine insulin harvested from cows blood. This had some effect but the protein is not exactly the same as the human insulin protein. The symptoms would eventually overcome the patient.

Slide 186 / 199

Recombinant DNA

In the late 1970s scientists started to look for a way to make human insulin in a laboratory. Their efforts produced the first product ever made using genes from multiple organisms. They recombined fragments of DNA from humans with the bacterial chromosome of E. coli. The new bacteria was then able to produce human insulin.

Slide 187 / 199

Humulin

The result was a new product called Humulin. The first human hormone to ever be produced by another organism.

Slide 188 / 199

Recombinant DNA Technology

DNA pieces can be recombined to make unique, man made

• sequences. There are 7 main

steps.

Slide 189 / 199 Recombinant DNA Technology

Step 1: Find the piece of DNA in the genome, the gene of interest. Today this step is done by computers attached to robotic DNA sequencers that fragment, analyze and find a gene based

• n user input.

Slide 190 / 199 Recombinant DNA Technology

Step 2: "Cut" the gene of interest from the genome This is made possible by restriction enzymes. In nature these enzymes are used by bacteria as weapons against invading viruses. For example: EcoRI is a restriction enzyme that makes a staggered cut when it reads the sequence GAATTC. The staggered ends are called sticky ends because they leave a few unpaired nucleotides that will easily stick to another piece of DNA with the same sticky end.

Slide 191 / 199

Recombinant DNA Technology

If the sequence of the gene of interest, say the insulin gene, is known and the sequences in the surrounding DNA are known, then restriction enzyme cut sites that are on opposite sides of the gene can be utilized to cut the gene out.

EcoRI cut site EcoRI cut site Insulin Gene (gene of interest) DNA fragment

Slide 192 / 199 Recombinant DNA Technology

If we look at the insulin gene again we can see that the sequence between the two EcoRI cut sites has a unique length.

EcoRI cut site EcoRI cut site Insulin Gene (gene of interest) DNA fragment 5,000 nucleotides (bp) 15,000 nucleotides (bp) to end of fragment 10,000 nucleotides (bp) to end of fragment

So in this digest there are DNA fragments that are 5k,10k, and 15k nucleotides long. The gene of interest here is the 5k piece. Step 3: Isolate the gene of interest

Slide 193 / 199 Recombinant DNA Technology

15k 10k 5k start Insulin gene

Gel electrophoresis is used to separate DNA fragments based on length.

Slide 194 / 199

Recombinant DNA Technology

Step 4: Make more of the gene of interest (amplification) Once the gene of interest is isolated in the gel, the band that contains the gene can be cut from the gel, but this is a very small

• sample. More copies of the can be made using polymerase chain

reaction (PCR).

Slide 195 / 199

EcoRI cut site

Recombinant DNA Technology

Step 5: "Paste" the gene of interest into the host's DNA Sticking to the insulin example, the technique utilized to get the insulin gene into the E. Coli bacteria involved using a plasmid, the small circular pieces of DNA that bacteria use to trade pieces of genetic information. A plasmid with an EcoRI cut site is "digested" using the same restriction enzyme that was used to cut out the insulin gene.

Slide 196 / 199 Recombinant DNA Technology

Mix the cut plasmid with the gene of interest to create a recombinant DNA plasmid that contains a human insulin gene

Insulin gene with sticky ends Plasmid with sticky ends Recombinant DNA Plasmid

Slide 197 / 199

Recombinant DNA Technology

Step 6: Put the recombined piece of DNA into the host organism Now that the gene of interest is in a plasmid, it can be mixed with bacterial cells and be taken up into the bacterial chromosome. Remember, all living things use the universal genetic code. The bacterial cells will read the newly acquired gene, transcribe it into mRNA and its ribosomes will translate the mRNA into a protein. The bacterial cells will reproduce and express the gene. Each time a recombinant bacterial cell divides by binary fission it will make a new copy of the gene.

Slide 198 / 199 Recombinant DNA Technology

Step 7: Collect the protein product The protein can be extracted from bacterial cultures using various

• techniques. It can then be delivered to the patient.

Currently there is no cure for diabetes, but with advancements in insulin therapy patients can now avoid many of the life threatening complication.

Slide 199 / 199
